QUICK START GUIDE
USER GUIDE
Connect Nitrogen to Kegs
1. Cut 2" of hose from supplied 1/4" white nitrogen hose.
2. Insert one end of hose into elbow on infuser regulator.
3. Attach T-connector to other end of hose.
4. Connect gas line from the tower to end of T-connector.
5. Connect blue gas line to center of T-connector.
2
To Slim Keg
5
From
Tower
6. Attach gray coupler of the gas jumper line to keg. With
your thumb press down on the top of the coupler while
pulling up on collar. Press coupler down firmly onto "in
valve. Release collar - listen for a click. Pull up on the
coupler to ensure it is locked down.
Other end is connected to
T- connector on Infuser
Regulator
In Valve
General Installation
3
4
7. Attach and clamp blue hose to lo-boy coupling.
Connecting Internal CO
Install Regulator
NOTE: Make sure gas valve on tank and two
gas valves on regulator are turned all the way
clockwise to the off position.
1. Attach regulator to CO
coupling nut and then use an adjustable wrench for an
additional quarter turn. DO NOT OVER TIGHTEN
2. Attach 9/16 " CO hose (blue) to each regulator nipple
2
and clamp into place. If necessary, make the hose
more pliable by heating the end in boiling water.
3. Attach and clamp CO
14
Source
2
tank. Hand tighten the
2
1
2
hose to lo-boy coupling.
2
