U-Line TORK H-9344 Manual

H-9344
TORK MINI JUMBO BATH TISSUE
®
DISPENSER – STAINLESS STEEL
TOOLS NEEDED
Electric 6 mm Drill Bit
Drill
Dispenser x 1
USING THE KEY AND OPTIONAL PUSH BUTTON MODE
USING THE KEY
1. To open dispenser while keeping it locked, insert key
at position A. (See Figure 1)
A
2. Turn and hold key clockwise to open dispenser.
(See Figure 2)
NOTE: Release key back to position A after
closing to lock dispenser.
A
B
PAGE 1 OF 9
Phillips
Screwdriver
Dispenser Key x 1
Figure 1
B
Figure 2
1-800-295-5510
uline.com
Tape Level
Measure
PARTS
Wall Anchor x 4
USING PUSH BUTTON MODE
1. Insert key at position A. (See Figure 1)
2. Turn counterclockwise to position B. (See Figure 3)
3. Remove key and push in lock to open dispenser.
(See Figure 4)
Para Español, vea páginas 4-6.
Pour le français, consulter les pages 7-9.
Screw x 4
Figure 3
A
B
Figure 4
0221 IH-9344
