QUICK START GUIDE
DISPENSERS • CDE224E (115v) • 4 Tap Mixed
30663_C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDE224E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for U-Line CDE224E

Summary of Contents for U-Line CDE224E

  • Page 1 QUICK START GUIDE DISPENSERS • CDE224E (115v) • 4 Tap Mixed 30663_C...
  • Page 2 ® to preserve the right product, in the right place, at the right temperature. Since 2014, U-Line has been part of the Middleby family of brands. All products are designed, engineered, and assembled in Milwaukee, Wisconsin, USA, and select products are available worldwide.

  • Page 3: Table Of Contents

    This Quick Start Guide covers the basics of installation and general use of your product. CONTENTS Safety and Warning Environmental Requirements Electrical Door Swing Door Adjustments General Installation Control Operation Airflow & Product oading First Use Cleaning Warranty For more details, see the complete User Guide & Service Manual on u-line.com.

  • Page 4: Safety And Warning

    QUICK START GUIDE USER GUIDE u-line.com Safety and Warning NOTICE DANGER Please read all instructions before installing, operating, or servicing the appliance. Service must be done by factory authorized service personnel. Any parts shall be replaced Use this appliance for its intended purpose only and follow with like components.

  • Page 5: Environmental Requirements

    QUICK START GUIDE 16-1/2" 16-1/2" 90° 90° Door Swing Door Swing Environmental Requirements NOTICE Stainless Models Electrical installation must observe all state and Black and White Models local codes. This unit requires connection to a This model is intended for indoor/interior applications only 2115WC Models grounded (three-prong), polarized receptacle and is not to be used in installations that are open/...

  • Page 6: Door Adjustments

    QUICK START GUIDE Door Adjustments REVERSING THE DOOR Location of the unit may make it desirable to mount the HINGE COVER door on the opposite side of the cabinet. Hinge cover included with the literature bag is optional. The hinge hardware will be removed and reinstalled on the opposite side of the cabinet.
  • Page 7 QUICK START GUIDE Remove door by tilting forward and lifting door off Install top hinge and door: bottom hinge. Retain shoulder washers; they will be reused. Use a Philips screwdriver to remove hinge pin and reinstall on the opposite surface of the hinge. Remove three screws from hinge holes on the opposite side.

  • Page 8: General Installation

    Liquid jumper line (with in-line filters) and gas jumper lin Lo-boy keg couplers hoses (connecting hardware) Cleaning solution (2-ounce packet) (Additional cleaner, ULACOFFEECLEAN, is available at u-line.com) Four casters (2 locking, 2 non-locking) Drip tray 10. Adapter plate & Foam rubber gasket Required (not included): Food grade 5 lb.
  • Page 9 USER GUIDE QUICK START GUIDE u-line.com Connect Hoses to Tower Install adapter plate to unit with 4 long screws and nuts (a) then place foam rubber gasket on top - open holes Your tower comes with two hoses already attached.
  • Page 10 USER GUIDE QUICK START GUIDE u-line.com Install Tower on Countertop (See template on next page) Note: These instructions are designed for a standard 36" countertop application. Note: For a customized fit, it m y be necessary to acquire screws that are sized to the thickness of your countertop.
  • Page 11 QUICK START GUIDE USER GUIDE u-line.com Template for Countertop Installation Note: Verify template has printed true to scale - double check hole dimensions and placement. 1 Inch 11-13/16 “ TO SIDE OF REFRIGERATOR 1/4” HOLE 2-3/4” HOLE 12-1/2 “ TO FRONT OF...
  • Page 12 QUICK START GUIDE USER GUIDE u-line.com Connecting Internal Nitrogen Attach braided line to ball valve on tank regulator Source using white snap ring. Install Infuser Regulator To Tap Tower Align infuser regulator with pre-drilled holes in upper left/right of interior side wall. Use 2 screws to secure.
  • Page 13 QUICK START GUIDE USER GUIDE u-line.com Connecting External Nitrogen Insert grommet into hole that corresponds to the drilled-out hole in bulkhead and apply food grade Source lubricant to inside of the grommet. Note: Connection to an external Nitrogen source requires drilling one hole through the pre- installed bulkhead located near the top of the back wall.
  • Page 14 QUICK START GUIDE USER GUIDE u-line.com Connect Nitrogen to Kegs Attach and clamp blue hose to lo-boy coupling. Cut 2" of hose from supplied 1/4" white nitrogen hose. Insert one end of hose into elbow on infuser regulator. Attach T-connector to other end of hose.
  • Page 15 QUICK START GUIDE USER GUIDE u-line.com Connecting External CO Source Inside cabinet push CO hose through drilled-out hole. Note: Connection to an external CO2 source requires drilling a hole through the pre-installed bulkhead located near the top of the back wall. It...
  • Page 16 USER GUIDE QUICK START GUIDE u-line.com Connecting Kegs to Tower Press down and rotate clockwise an additional 1/4 turn. Attach black coupler of the liquid jumper line to ball-tap keg. With your thumb press down on the top of the coupler while pulling up on the collar. Press coupler down firmly onto "out"...
  • Page 17 QUICK START GUIDE USER GUIDE u-line.com Connections When complete, the connections should look like this: To CO2 Two CO2 Lines Source 1 /6 Slim Barrel To Nitrogen 1 /4 Slim Source Barrel One Nitrogen Line Infuser Regulator Filter Assembly Standard...

  • Page 18: Control Operation

    • When loading, leave space between internal fans, vents, temperature of product loaded, door openings, etc. U-Line and side walls to allow air to circulate freely recommends allowing the unit to reach set points before loading.
  • Page 19 QUICK START GUIDE Setting CO2 Pressure To minimize foam for most beverages the pressure should be set between 8-12 PSI. • Set the pressure by turning the handle on the front of the regulator counterclockwise until it is all the way out. This will turn the regulator off •...

  • Page 20: Cleaning

    QUICK START GUIDE USER GUIDE u-line.com Cleaning CLEAN INTERIOR COMPONENTS CLEANING VS. SANITIZING Use warm or hot water with dish soap to clean all removed This guide will address both the cleaning and the sanitizing components and interior surfaces. You may use a vinegar and of the unit.
  • Page 21 Disassemble by unscrewing the cap. Rinse cap and filter ULACOFFEECLEAN (Stera-Sheen®) was included with your with warm potable water and reassemble. product and more can be purchased at u-line.com. Notice Confirm system is not pressurized by turning off nitrogen – turn handle clockwise. Release...
  • Page 22 QUICK START GUIDE USER GUIDE u-line.com Cleaning the Beer-Dispensing System Clean the system using a suitable solution designed for beer- dispensing systems. Beer cleaning kits are also available. Solution and/or kit not included. Close CO tank. Pull pin on coupler to release pressure from keg.
  • Page 23 QUICK START GUIDE USER GUIDE u-line.com Remove tap head from tower with supplied tap head wrench. Disassemble, and place all the parts in drainage bucket. 10. Add washer and attach cleaning pump connector to tower. Tighten with tap head wrench.
  • Page 24 QUICK START GUIDE USER GUIDE u-line.com DEFROSTING Under normal conditions this unit does not require manual defrosting. Minor frost on the rear wall or visible through the evaporator plate vents is normal and will melt during each cycle. If there is excessive build-up of 1/4” (6 mm) or more, manually defrost the unit.

  • Page 25: Warranty

    For products installed and used for normal residential use, material cosmetic defects are included in this warranty, with coverage limited to 60 days from the date of original purchase. All service provided by U-Line under the above warranty must be performed by a U-Line factory authorized servicer, unless otherwise specified by U-Line.
