U-Line CDE215H Quick Start Manual

2 tap coffee
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
QUICK START GUIDE
DISPENSERS
• CDE215H (115v) • 2 Tap Coffee
30654_D

Advertisement

Table of Contents
loading

Related Manuals for U-Line CDE215H

Summary of Contents for U-Line CDE215H

  • Page 1 QUICK START GUIDE DISPENSERS • CDE215H (115v) • 2 Tap Coffee 30654_D...
  • Page 2 ® to preserve the right product, in the right place, at the right temperature. Since 2014, U-Line has been part of the Middleby family of brands. All products are designed, engineered, and assembled in Milwaukee, Wisconsin, USA, and select products are available worldwide.

  • Page 3: Table Of Contents

    This Quick Start Guide covers the basics of installation and general use of your product. CONTENTS Safety and Warning Environmental Requirements Electrical Door Swing Door Adjustments General Installation Control Operation First Use Airflow & Product Loading Cleaning Warranty For more details, see the complete User Guide & Service Manual on u-line.com.

  • Page 4: Safety And Warning

    QUICK START GUIDE USER GUIDE u-line.com Safety and Warning DANGER NOTICE This unit contains R600a (Isobutane) which is a Please read all instructions before installing, flammable hydrocarbon. It is safe for regular operating, or servicing the appliance. use. Do not use sharp objects to expedite defrosting.

  • Page 5: Environmental Requirements

    QUICK START GUIDE USER GUIDE Always keep your working area dry. u-line.com Environmental Requirements NOTICE Electrical installation must observe all state and This model is intended for indoor/interior applications only local codes. This unit requires connection to a and is not to be used in installations that are open/ grounded (three-prong), polarized receptacle exposed to natural elements.

  • Page 6: Door Adjustments

    QUICK START GUIDE USER GUIDE u-line.com Door Adjustments REVERSING THE DOOR Location of the unit may make it desirable to mount the HINGE COVER door on the opposite side of the cabinet. Hinge cover included with the literature bag is optional.
  • Page 7 QUICK START GUIDE USER GUIDE u-line.com Remove door by tilting forward and lifting door off Install top hinge and door: bottom hinge. Retain shoulder washers; they will be reused. Use a Philips screwdriver to remove hinge pin and reinstall on the opposite surface of the hinge.

  • Page 8: General Installation

    3. Infuser regulator (hoses & hardware) 4. Liquid jumper line (with in-line filter) and gas jumper line 5. Drip tray 6. Cleaning solution (2-ounce packet) (Additional cleaner, ULACOFFEECLEAN, is available at u-line.com) 7. Four casters (2 locking, 2 non-locking) Required (not included): Safety and Warning Food grade nitrogen - available at your local gas supplier.
  • Page 9 QUICK START GUIDE USER GUIDE u-line.com Install Tower on Free-Standing Refrigerator Do not remove all the protective film on the stainless Screw the handles onto the faucets and continue to exterior until the tower is installed. assemble and connect regulator to Nitrogen tank.
  • Page 10 QUICK START GUIDE USER GUIDE u-line.com Install Tower on Countertop (See template on next page) Note: These instructions are designed for a standard 36" countertop application. Note: For a customized fit, it may be necessary to acquire screws that are sized to the thickness of your countertop.
  • Page 11 QUICK START GUIDE USER GUIDE u-line.com Template for Countertop Installation Note: Verify template has printed true to scale - double check hole dimensions and placement. 1 Inch 7-1/2“ TO SIDE OF REFRIGERATOR 2-3/4“ HOLE 12-1/2“ TO FRONT FACE OF REFRIGERATOR...
  • Page 12 QUICK START GUIDE USER GUIDE u-line.com Connecting Internal Nitrogen Attach nitrogen hose to ball valve on tank regulator. Source Make sure valve is in the off position - turned clockwise as far as it can go. Tighten hose clamp. Install Infuser Regulator...
  • Page 13 QUICK START GUIDE USER GUIDE u-line.com Attach gray coupler of the gas jumper line to keg. Connect keg to tower With your thumb press down on the top of the coupler while pulling up on collar. Press coupler down firmly Attach black nitrogen coupler of the liquid jumper line onto "in"...
  • Page 14 USER GUIDE QUICK START GUIDE u-line.com Connecting External Nitrogen Insert gasket ring into hole that corresponds to the drilled-out hole in bulkhead. Source Note: Connection to an external Nitrogen source requires drilling one hole through the pre- installed bulkhead located near the top of the back wall.
  • Page 15 USER GUIDE u-line.com Connections When complete, the connections should look like this: Infuser Regulator Filter Assembly LEVELING INFORMATION CAUTION Use a level to confirm the unit is level. Level should To comply with applicable federal, state, be placed along top edge and local codes, it may be necessary to and side edge as shown.

  • Page 16: Control Operation

    Time section of this guide.) to reach set point varies based upon ambient temperature, temperature of product loaded, door openings, etc. U-Line Remove keg from refrigerator. recommends allowing the unit to reach set points before Lift handle and remove lid.
  • Page 17 QUICK START GUIDE Set Nitrogen Pressure On infuser regulator, pull out middle knob to unlock then turn knob until needle points at 7 - turn right to The pressure should be set around 20 - 30 PSI. Start at 25 increase;...
  • Page 18 QUICK START GUIDE Dispensing Coffe The left tap delivers still cold brew which is refreshing and less acidic than hot coffee. The right tap delivers nitrogen-infused coffee which is the ultimate cold brew experience. Thousands of micro-nitrogen bubbles are infused as the coffee is dis- pensed.

  • Page 19: Airflow & Product Loading

    USER GUIDE surface of the stainless steel and complete NOTICE removal of the rust may not be possible. Restricting airflow may result in poor product u-line.com USER GUIDE performance, product failure, and uneven internal u-line.com temperatures and may freeze contents.
  • Page 20 Disassemble by unscrewing the cap. Rinse cap and filter product to prevent further problems. product and more can be purchased at u-line.com. Nose Cone a solution of water and ULACOFFEECLEAN. One packet of with warm potable water and reassemble.
  • Page 21 QUICK START GUIDE USER GUIDE u-line.com DEFROSTING Under normal conditions this unit does not require manual defrosting. Minor frost on the rear wall or visible through the evaporator plate vents is normal and will melt during each cycle. If there is excessive build-up of 1/4” (6 mm) or more, manually defrost the unit.

  • Page 22: Warranty

    For products installed and used for normal residential use, material cosmetic defects are included in this warranty, with coverage limited to 60 days from the date of original purchase. All service provided by U-Line under the above warranty must be performed by a U-Line factory authorized servicer, unless otherwise specified by U-Line.
