CABLE SPECIFICATIONS

The physical characteristics of the media cable must meet or exceed IEEE 802.3 specifications.
Fiber Cable
Bit error rate:
MULTIMODE
Fiber Optic Cable Recommended:
Optional:
CGETF1013
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
Typical Maximum Cable Distance*:
CGETF1018
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
Typical Maximum Cable Distance*:
SINGLEMODE
Fiber Optic Cable Recommended:
CGETF1014
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
Typical Maximum Cable Distance*:
CGETF1015
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
Typical Maximum Cable Distance*:
CGETF1017
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
Typical Maximum Cable Distance*:
CGETF1025
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
Typical Maximum Cable Distance*:
*Actual distance dependent upon physical characteristics of network installation.
Copper Cable
Category 5 twisted-pair copper wire is required. Either shielded twisted-pair (STP) or
unshielded twisted-pair (UTP) can be used. DO NOT USE FLAT OR SILVER SATIN WIRE.
10-9
62.5 / 125 µm multimode fiber
100 / 140 µm multimode fiber
85 / 125 µm multimode fiber
50 / 125 µm multimode fiber
850 nM
min: -10.0 dBm max: -4.0 dBm
min: -17.0 dBm max: -0.0 dBm
7.0 dB
220 meters
850 nM
min: -9.5 dBm max: -4.0 dBm
min: -17.0 dBm max: -0.0 dBm
7.0 dB
220 meters
9 µm singlemode fiber
1300 nM
min: -13.0 dBm max: -3.0 dBm
min: -20.0 dBm max: -3.0 dBm
7.0 dB
10 kilometers
1300 nM
min: -5.0 dBm max: -0.0 dBm
min: -20.0 dBm max: -3.0 dBm
15.0 dB
25 kilometers
1550 nM
min: -3.0 dBm max: -2.0 dBm
min: -23.0 dBm max: -3.0 dBm
20.0 dB
65 kilometers
1550 nM
min: -9.5 dBm max: -3.0 dBm
min: -20.0 dBm max: -3.0 dBm
20.0 dB
65 kilometers
Install Slide-In-Module in PointSystem
CAUTION: Any Slide-in-Module installation slot in which a Media Converter
Slide-in-Module is NOT installed MUST have a protective plate instead.
Failure to observe this caution will void Class A and/or Class B compliance.
NOTE: Install Media Converter Slide-in-Modules in any slot, in any order.
1. Carefully slide Media Converter Slide-in-Module into installation slot,
aligning Media Converter Slide-in-Module with installation guides.
NOTE: Ensure that Slide-in-Module is firmly seated against backplane.
2. Secure Slide-in-Module by securing panel fastener screw (attached to
Slide-in-Module) to chassis front.
3. Install protective plate at ANY Slide-in-Module installation slot in which
a Media Converter Slide-in-Module is not installed by securing attached
protective plate panel fastener screw to chassis front.
Install Cable
COPPER
NOTE: The CGETF10xx series media converter auto-negotiation feature
allows the media converter to bring up the copper link in the highest
mode possible for ALL the attached network devices.
1. Locate or build 1000BASE-TX-compliant cables with male RJ-45
connectors installed at both ends.
2. Connect RJ-45 connector at one end of cable to media converter
RJ-45 port connector.
3. Connect RJ-45 connector at other end of cable to 1000BASE-TX-
compliant device RJ-45 port connector.
FIBER
1. Locate or build 1000BASE-SX/LX-compliant fiber cable with male
two-stranded TX to RX connectors installed at both ends.
TX
RX
2. Connect cable with connector installed at TX location on media
converter to RX location on attached device.
3. Connect cable with connector installed at RX location on media
converter to TX location on attached device.
Power the Slide-In-Module
NOTE: The Slide-In-Module is powered through the
™
Center .
™
Chassis
TX
RX
Conversion
