BiG Pack Baler
BiG Pack 870 HDP
BiG Pack 870 HDP XC
(from serial no.: 940 085)
Order no.: 150 000 170 03 en
03.05.2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 870 HDP and is the answer not in the manual?

Questions and answers

Related Manuals for Krone 870 HDP

Summary of Contents for Krone 870 HDP

  • Page 1 BiG Pack Baler BiG Pack 870 HDP BiG Pack 870 HDP XC (from serial no.: 940 085) Order no.: 150 000 170 03 en 03.05.2016...
  • Page 2 Table of Contents Pos: 1 /BA/Konformitätserklärungen/Großpackenpressen/Neu/Big Pack 870 HDP Baureihe @ 447\mod_1461048209048_78.docx @ 3044229 @ @ 1 EC Declaration of Conformity Maschinenfabrik Bernard Krone GmbH & Co. KG Heinrich-Krone-Str. 10, D-48480 Spelle hereby declare as manufacturer of the product named below, on our sole responsibility,...

  • Page 3: Table Of Contents

    Table of Contents Pos : 3 /Ü berschriften/Ü bers chriften 1/F-J/Inhalts verzeic hnis @ 31\mod_1251969952727_78.doc x @ 302165 @ 1 @ 1 Table of Contents Pos : 4 /BA/Inhalts verz eichnis Spr ac henneutr al @ 10\mod_1221574899104_0.doc x @ 135495 @ @ 1 Table of Contents ...........................
  • Page 4 Table of Contents Safety stickers on the machine ......................33 3.6.1 Re-Ordering Safety Labels and Information Labels ..............43 3.6.2 Attaching Safety Labels and Information Labels ..............43 3.6.3 Contact ............................43 Safety Equipment ..........................44 3.7.1 Ladder ............................44 3.7.2 Fire extinguisher ........................
  • Page 5 Putting Down ISO Plug........................103 Hydraulic brake (Export) ........................ 103 Hydraulic Brake (Export France) ....................104 Compressed Air Connections for the Compressed Air Brake ............105 Connecting KRONE ISOBUS-Terminal ..................106 Connecting External ISOBUS-Terminal ..................110 Connecting the Joystick ......................... 111 9.10 Lighting ............................
  • Page 6 Touch Sensitive Display ......................... 132 11.3 Switching Terminal On or Off ......................133 11.4 Display Design ..........................134 KRONE ISOBUS Terminal [Medium Plus/Comfort Plus Version Electronics] ......135 External ISOBUS Terminal ........................ 136 13.1 General Information on ISOBUS ....................136 13.2 ISOBUS Shortcut Button not Available ..................
  • Page 7 Table of Contents Terminal – Menus [Medium/Comfort Version Electronics] ............160 16.1 Menu Structure ..........................160 16.2 Recurring Icons ..........................162 16.3 Calling up the menu level ....................... 163 16.4 Changing the value ........................164 16.5 Changing mode ..........................165 16.6 Menu 1 "Knotter"...
  • Page 8 Table of Contents 18.3 Pick-up ............................238 18.4 Lifting / Lowering Bale Chute ......................239 18.4.1 Medium Electronics Design ....................239 18.4.2 Comfort Version Electronics Design ..................240 18.5 Operating Bale Ejector ........................241 18.6 Parking Jack ........................... 243 18.7 Hydraulic parking jack ........................
  • Page 9 Table of Contents 19.14.1 Setting the baling ram blades ....................276 19.14.2 Setting the Lateral Plunger Blades ..................278 19.14.3 Cleaning the running rails ....................... 279 19.14.4 Lateral setting of the plunger ....................279 19.15 Adjusting the Packer Relative to the Plunger ................. 280 19.15.1 Description of components .....................
  • Page 10 Table of Contents Maintenance - Gearbox ........................319 22.1 Main gearbox ..........................319 22.2 Packer gearbox ..........................320 22.3 Transfer gearbox ..........................321 22.4 Pick-up gearbox ..........................322 22.5 Cutting system drive gear ......................323 Maintenance - Brake System ......................325 23.1 Compressed-air reservoir .......................
  • Page 11 Table of Contents 31.5 Work Hydraulics Comfort Version Electronics ................378 31.6 Circuit Diagram [Medium/Comfort Version Electronics] ..............379 Pos : 5 /Layout Modul e /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 12: To This Document

    These operating instructions apply to Big Pack Square Balers of the following types: BiG Pack 870 HDP BiG Pack 870 HDP XC In the HighSpeed design. Pos : 6.3.1 /Ü bers chriften/Ü bersc hriften 2/K- O/N/N ac hbes tell ung (N achbestellung di es es D okuments) @ 349\mod_1436355974813_78.doc x @ 2625865 @ 2 @ 1 Re-Ordering Pos : 6.3.2 /BA/Zu di es em Dokument/N ac hbestellung_T ext @ 349 \mod_1436355830140_78.doc x @ 2625835 @ @ 1...

  • Page 13: How To Use This Document

    To this Document Pos : 6.10.1 /Übersc hriften/Übersc hriften 2/P-T/SSo benutz en Si e dieses Dokument @ 188\mod_1380548350021_78.doc x @ 1614365 @ 2 @ 1 How to use this document Pos : 6.10.2 /Übersc hriften/Übersc hriften 3/U-Z/Verzeic hniss e und Ver weise @ 336\mod_1429854437094_78.doc x @ 2556421 @ 3 @ 1 2.5.1 Directories and References Pos : 6.10.3 /BA/Z u diesem D okument/So benutz en Si e dieses Dokument_Verz eic hniss e und Ver weis e_Text @ 333\mod_1429085378408_78.doc x @ 2544425 @ @ 1...

  • Page 14: Scope Of Document

    To this Document Pos : 6.10.10 /Ü berschriften/Ü berschriften 3/U-Z/U mfang des Dokuments @ 346\mod_1434979896995_78.doc x @ 2611366 @ 3 @ 1 2.5.5 Scope of Document Pos : 6.10.11 /BA/Z u dies em D okument/U mfang des Dokuments_alle Beipac ks und Vari anten enthalten_T ext @ 346\mod_1434979460226_78.doc x @ 2611335 @ @ 1 In addition to standard equipment, accessories kits and versions of the machine are described in this document.

  • Page 15: Direction Of Travel

    To this Document Pos : 6.10.16 /Ü berschriften/Z wis chenübers chriften/P-T/Symbole i n Abbildungen @ 336\mod_1430121455379_78.doc x @ 2557570 @ @ 1 Symbols in figures Pos : 6.10.17 /BA/Z u dies em D okument/D arstellungs mittel_Ü bersicht Symbole_BA @ 329\mod_1427193088297_78.doc x @ 2523598 @ @ 1 To visualize parts and actions steps, the following icons are used: Icon Explanation...
  • Page 16 To this Document Pos : 6.10.19 /Ü berschriften/Z wis chenübers chriften/U-Z/Warnhinweis e_Z u diesem D okument @ 337\mod_1430720690194_78.doc x @ 2563366 @ @ 1 Warning signs Pos : 6.10.20 /BA/Z u dies em D okument/Warnhinweis e_Z u di esem Dokument_T ext @ 337\mod_1430720301162_78.doc x @ 2563335 @ @ 1 Warning WARNING! - Type and source of hazard! Effect: Injuries, serious material damage.
  • Page 17 To this Document Pos : 9 /Layout Modul e /Dies e Sei te i st bewuss t fr eigelassen worden. @ 1\mod_1201783680373_78.doc x @ 54443 @ @ 1 This page has been left blank deliberately!! Pos : 10 /Layout M odul e /---------------Seitenumbruc h---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 18: Safety

    Pos : 13 /BA/M asc hinenbesc hrei bung/M asc hinenübersic ht/Groß pac kenpres sen/Ver wendungsz wec k Bi G Pac k HS Baur eihe @ 93 \mod_1327323688288_78.doc x @ 786957 @ @ 1 KRONE Big Pack square balers are machines for collecting and baling cut crops (grass, hay, leguminous vegetation and straw, etc.) on farms.

  • Page 19: Basic Safety Instructions

    Safety Pos : 19.1 /Übersc hriften/Übersc hriften 2/F-J/GGrundlegende Sic her hei tshi nweise @ 186\mod_1380009482364_78.doc x @ 1606585 @ 2 @ 1 Basic safety instructions Pos : 19.2 /BA/Sicher heit/1. Gr undl egende Sicherheits hinweis e/Nic htbeac htung der SiHi und WaHi (Ei nführtext Grundl egende SiHi) @ 175\mod_1372834139379_78.doc x @ 1504793 @ @ 1 Non-compliance with the safety instructions and warnings Non-compliance with the safety instructions and warnings may result in injuries and damage to the environment and property.

  • Page 20: Children In Danger

    Safety Pos : 19.8 /Übersc hriften/Übersc hriften 3/K-O/KKinder in Gefahr @ 187\mod_1380011650765_78.doc x @ 1606732 @ 3 @ 1 3.4.3 Children in danger Pos : 19.9 /BA/Sicher heit/1. Gr undl egende Sicherheits hinweis e/Kinder i n Gefahr (Anhängeger ät, Anbauger ät, Anhänger) @ 176 \mod_1372842540941_78.doc x @ 1505758 @ @ 1 Children cannot assess danger and behave unpredictably.

  • Page 21: Operational Safety: Technically Perfect Condition

    Safety Pos : 19.20 /Ü bersc hriften/Ü berschriften 3/A-E/B/Betriebssic her hei t: T ec hnisc h ei nwandfrei er Z ustand @ 187\mod_1380012216128_78.doc x @ 1606877 @ 3 @ 1 3.4.8 Operational safety: Technically perfect condition Pos : 19.21 /BA/Sic herheit/1. Grundlegende Sic herheits hinweise/Betriebssic herheit - Betrieb nur nach or dnungsgemäß er Inbetriebnahme @ 176\mod_1372854464728_78.doc x @ 1506530 @ @ 1 Operation only when the machine has been started up correctly If the machine is not started up correctly according to these operating instructions, the operational safety of the machine is not ensured.

  • Page 22: Danger Zones

    Safety Pos : 19.25 /BA/Sic herheit/1. Grundlegende Sic herheits hinweise/Betriebssic herheit - T ec hnis che Grenz werte_Ver weis auf Maschbesc hr Techn D aten @ 176\mod_1372857251111_78.doc x @ 1506647 @ @ 1 Technical limit values If the technical limit values of the machine are not observed, the machine may be damaged. As a result, accidents may occur and people may be seriously injured or killed.
  • Page 23 Safety Pos : 19.30 /BA/Sic herheit/1. Grundlegende Sic herheits hinweise/Gefahr enbereic h z wisc hen Traktor und Masc hi ne @ 176 \mod_1372930525648_78.doc x @ 1507354 @ @ 1 Danger zone between tractor and machine People standing between the tractor and machine may be seriously injured or killed if the tractor rolls away or by machine movements: •...

  • Page 24: Keeping Safety Devices Functional

    Safety Pos : 19.35 /BA/Sic herheit/1. Grundlegende Sic herheits hinweise/Gefahr enbereic h N ac hlaufende Maschi nenteile - Bi G PAC K @ 273\mod_1404138597567_78.doc x @ 2059669 @ @ 1 Danger zone due to coasting machine parts When the drives have been switched off, the following machine parts will coast: –...

  • Page 25: Safety Signs On The Machine

    Safety Pos : 19.41 /BA/Sic herheit/1. Grundlegende Sic herheits hinweise/Geeig nete Klei dung tragen @ 176\mod_1373011520074_78.doc x @ 1508413 @ @ 1 Wear suitable clothing Loose clothing increases the risk of it becoming caught or wrapped around rotating parts and of it becoming caught on protruding parts.

  • Page 26: Parking The Machine Safely

    Safety Pos : 19.49 /Ü bersc hriften/Ü berschriften 3/K-O/MM asc hine sic her abs tell en @ 187\mod_1380021652951_78.doc x @ 1607221 @ 3 @ 1 3.4.14 Parking the machine safely Pos : 19.50 /BA/Sic herheit/1. Grundlegende Sic herheits hinweise/Mas chi ne sicher abstellen @ 176\mod_1373262472095_78.doc x @ 1509055 @ @ 1 The parked machine may overturn.

  • Page 27: Sources Of Danger On The Machine

    Safety Pos : 19.59 /Ü bersc hriften/Ü berschriften 3/F-J /GGefahrenquellen an der Maschi ne @ 187\mod_1380022841201_78.doc x @ 1607417 @ 3 @ 1 3.4.17 Sources of danger on the machine Pos : 19.60 /BA/Sic herheit/1. Grundlegende Sic herheits hinweiseGefahrenquellen - Lär m (Tr aktor und M asc hine) Ver weis auf Technisc he Daten @ 407\mod_1450079366677_78.doc x @ 2885005 @ @ 1 Noise may lead to health problems When working with the machine for a longer time, serious health damage may result such as hearing loss, deafness or tinnitus.

  • Page 28: Dangers Associated With Certain Activities: Climbing Up And Down

    Safety Pos : 19.66 /Ü bersc hriften/Ü berschriften 3/F-J /GGefahren bei besti mmten T ätig keiten: Auf- und Abs teig en @ 187\mod_1380022928541_78.doc x @ 1607506 @ 3 @ 1 3.4.18 Dangers associated with certain activities: Climbing up and down Pos : 19.67 /BA/Sic herheit/1.

  • Page 29: Dangers Associated With Certain Activities: Working On Wheels And Tyres

    The fitting of wheels and tyres requires adequate knowledge and approved tools. • If there is a lack of knowledge, have the wheels and tyres fitted by the KRONE dealer or by a qualified tyre service. •...

  • Page 30: Safety Routines

    Safety Pos : 21.1 /Übersc hriften/Übersc hriften 2/P-T/SSic herheitsrouti nen @ 187\mod_1380089318480_78.doc x @ 1608182 @ 2 @ 1 Safety routines Pos : 21.2 /Übersc hriften/Übersc hriften 3/K-O/MMas chi ne stillsetz en und sic her n @ 190\mod_1381323544614_78.doc x @ 1624780 @ 3 @ 1 3.5.1 Stopping and securing the machine Pos : 21.3 /BA/Sicher heit/3.

  • Page 31: Coupling The Machine Safely

    Safety Pos : 21.7 /Übersc hriften/Übersc hriften 3/K-O/MMas chi ne sicher ankuppel n @ 274\mod_1404282415732_78.doc x @ 2062014 @ 3 @ 1 3.5.3 Coupling the machine safely Pos : 21.8 /BA/Sicher heit/3. Sic herheitsr outinen/Masc hi ne an den Tr aktor ankuppel n (Bi G PAC K) @ 273\mod_1404105657612_78.doc x @ 2057995 @ @ 1 WARNING! Risk of injury when coupling the machine The machine or machine parts may move unintentionally while the machine is coupled to the...

  • Page 32: Preparing The Machine For Repair, Maintenance And Adjustment Work

    Safety Pos : 21.12 /Ü bersc hriften/Ü berschriften 3/K-O/MM asc hine für Ins tandhaltungs-, Repar atur-, War tungs- und Einstellar beiten vorber eiten @ 274\mod_1404283183227_78.doc x @ 2062418 @ 3 @ 1 3.5.5 Preparing the machine for repair, maintenance and adjustment work Pos : 21.13 /BA/Sic herheit/3.

  • Page 33: Safety Stickers On The Machine

    Pos : 25 /BA/Sic her heit/Gr oßpac kenpr ess en/Sic her hei t Ei nführung BiG Pac k @ 273\mod_1403690043254_78.doc x @ 2054816 @ @ 1 The KRONE BiG PACK baler is equipped with all safety devices (protective equipment). However, it is not possible to eliminate all potential hazards on this machine as this would impair its full functional capability.
  • Page 34 Safety Pos : 27.1 /BA/Sicher heit/Aufkl eber/Groß pac kenpress e/BiG PACK 870 HDP / 870 HDP XC /Sic herheits aufkleber BiG Pac k 870 HDP Bil d linke Seite @ 274\mod_1404299581149_78.doc x @ 2063834 @ @ 1 BPHS0270 Fig. 1 left-hand side of the machine...
  • Page 35 Safety Pos : 27.3 /BA/Sicher heit/4. Sic herheits aufkleber/EU - ISO /939/939 471 1 ( 1x) Bes tell-Nr. @ 189\mod_1381220124664_78.doc x @ 1622309 @ @ 1 1) Order no. 939 471 1 (1x) Pos : 27.4 /BA/Sicher heit/4. Sic herheits aufkleber/EU - ISO /939/939 471 1 Bild/Text Immer als ersten Sicherheits aufkl eber benutz en @ 189\mod_1381212141744_78.doc x @ 1621596 @ @ 1 Danger due to incorrect operation and lack of knowledge Incorrect operation and lack of knowledge of the machine as well as incorrect behaviour in hazardous situations is risking the life of...
  • Page 36 Safety Pos : 27.12 /BA/Sic herheit/Aufkleber/Gr oßpac kenpr ess e/BiG PAC K 870 HD P / 870 HDP XC/Sic her heitsaufkl eber BiG Pac k 870 HD P Bil d linke Seite @ 274\mod_1404299581149_78.doc x @ 2063834 @ @ 1 BPHS0270 Fig.
  • Page 37 Safety Pos : 27.14 /BA/Sic herheit/4. Sic her hei tsaufkl eber/EU - ISO /939/939 408 2 (1x) Bestell-Nr. @ 198\mod_1384852186096_78.doc x @ 1672881 @ @ 1 5) Order no. 939 408 2 (1x) Pos : 27.15 /BA/Sic herheit/4. Sic her hei tsaufkl eber/EU - ISO /939939 408 2 Bil d/T ext @ 350\mod_1436433066436_78.doc x @ 2626478 @ @ 1 Danger from rotating machine parts.
  • Page 38 Safety Pos : 27.25 /BA/Sic herheit/Aufkleber/Gr oßpac kenpr ess e/BiG PAC K 870 HD P / 870 HDP XC/Sic her heitsaufkl eber BiG Pac k 870 HD P Bil d linke Seite @ 274\mod_1404299581149_78.doc x @ 2063834 @ @ 1 BPHS0270 Fig.
  • Page 39 Safety Pos : 27.27 /BA/Sic herheit/4. Sic her hei tsaufkl eber/EU - ISO /942/942 459 0 (3x) Bestell-Nr. @ 274\mod_1404299329209_78.doc x @ 2063805 @ @ 1 9) Order no. 942 459 0 (3x) Pos : 27.28 /BA/Sic herheit/4. Sic her hei tsaufkl eber/EU - ISO /942/942 459 0 Bild/T ext @ 189\mod_1381214888144_78.doc x @ 1622041 @ @ 1 Danger due to crushing or shearing Risk of injury due to crushing or shearing points on moving machine parts.
  • Page 40 Safety Pos : 29.1 /BA/Sicher heit/Aufkl eber/Groß pac kenpress e/BiG PACK 870 HDP / 870 HDP XC /Sic herheits aufkleber BiG Pac k 870 HDP Bil d rec hte Seite @ 274 \mod_1404300881280_78.doc x @ 2063949 @ @ 1 BPHS0271 Fig.
  • Page 41 Safety Pos : 29.3 /BA/Sicher heit/4. Sic herheits aufkleber/EU - ISO /939/939 520 1 ( 1x) Bes tell-Nr. @ 200\mod_1385457758221_78.doc x @ 1683506 @ @ 1 11) Order no. 939 520 1 (1x) Pos : 29.4 /BA/Sicher heit/4. Sic herheits aufkleber/EU - ISO /939/939 520 1 Bild/Text @ 200\mod_1385457791955_78.doc x @ 1683535 @ @ 1 Danger due to rotating auger.
  • Page 42 Pos : 29.13 /BA/Sic herheit/Aufkleber/Gr oßpac kenpr ess e/BiG PAC K 870 HD P / 870 HDP XC/Sic her heitsaufkl eber BiG Pac k 870 H D P Bild rec hte Seite @ 274\mod_1404300881280_78.doc x @ 2063949 @ @ 1...

  • Page 43: Re-Ordering Safety Labels And Information Labels

    3.6.3 Contact Pos : 47 /BA/Adress en/Adresse Mas chi nenfabrik KR ONE Spelle @ 444\mod_1460097223706_78.doc x @ 3031795 @ @ 1 Maschinenfabrik Bernard Krone GmbH & Co. KG Heinrich-Krone-Strasse 10 D-48480 Spelle (Germany) Telephone: + 49 (0) 59 77/935-0 (Head Office) Fax.: + 49 (0) 59 77/935-339 (Head Office)

  • Page 44: Safety Equipment

    Safety Pos : 51.1 /Übersc hriften/Übersc hriften 2/P-T/SSic herheits ausstattung @ 17\mod_1236613960651_78.doc x @ 205812 @ 2 @ 1 Safety Equipment Pos : 51.2 /Übersc hriften/Übersc hriften 3/A-E/A/Aufs tiegslei ter @ 17\mod_1236246728956_78.doc x @ 203788 @ 3 @ 1 3.7.1 Ladder Pos : 51.3 /BA/Sicher heit/Aufs tiegslei ter/Aufsti egsleiter BiG Pac k Bild 870 Baur eihe @ 338\mod_1430738779146_78.doc x @ 2564592 @ @ 1 BPHS0266_1...

  • Page 45: Wheel Chocks

    Safety Pos : 51.10 /Ü bersc hriften/Ü berschriften 3/U-Z/U nterleg keile @ 33\mod_1254202555660_78.doc x @ 318451 @ 3 @ 1 3.7.3 Wheel chocks Pos : 51.11 /BA/F ahr en und Trans por t/Gr oßpac kenpr ess e/U nterleg keil e Bild BP 870 Baurei he @ 338\mod_1430738987003_78.doc x @ 2564623 @ @ 1 BPHS0267_1 Fig.

  • Page 46: Flywheel Brake

    Safety Pos : 51.19 /Ü bersc hriften/Ü berschriften 2/P-T/SSc hwungradbr ems e @ 71\mod_1305785577816_78.doc x @ 639924 @ 2 @ 1 Flywheel brake Pos : 51.20 /BA/Ers tinbetriebnahme/Groß pac kenpressen/Sc hwungradbr emse/Sc hwungradbrems e Bild BiG PACK 870 Baurei he @ 246 \mod_1396360844078_78.doc x @ 1923687 @ @ 1 BPHS0268 Fig.
  • Page 47 Safety Pos : 51.27 /BA/Maschi nenbeschr eibung/Masc hi nenübersicht/Gr oß pac kenpr ess en/Medi um- Elektroni k @ 61\mod_1299223169539_78.doc x @ 570971 @ @ 1 Medium Version Electronics Pos : 51.28 /BA/Ers tinbetriebnahme/Groß pac kenpressen/Abstellstütz e/H ydraulischer Stützfuß M edium Elektroni k Bild HS Baur eihe @ 92\mod_1326870734408_78.doc x @ 782789 @ @ 1 BPHS0012 BPHS0014_1 Fig.12...

  • Page 48: Shut-Off Valve Pick-Up

    Safety Pos : 51.34 /Ü bersc hriften/Ü berschriften 2/A-E/AAbs perrhahn Pic k-up @ 155\mod_1363682265328_78.doc x @ 1373791 @ 2 @ 1 3.11 Shut-Off Valve Pick-up Pos : 51.35 /BA/Ers tinbetriebnahme/Groß pac kenpressen/Absperrhahn Pic k- up Bild mit Leg ende @ 155\mod_1363682181297_78.doc x @ 1373728 @ @ 1 Fig.

  • Page 49: Data Memory

    Data memory Pos : 53 /BA/D atenspeic her/D atenspeic her @ 368\mod_1441604875252_78.doc x @ 2698746 @ 1 @ 1 Data memory A variety of electronic components of the machine contains data memories that save temporarily and permanently technical information on machine condition, events and errors. This technical information generally documents the condition of a part, module, system or of the environment: –...

  • Page 50: Machine Description

    Machine Description Pos : 55.1 /Übersc hriften/Übersc hriften 1/K-O/Mas chi nenbes chr eibung @ 107\mod_1334231806004_78.doc x @ 965201 @ 1 @ 1 Machine Description Pos : 55.2 /Übersc hriften/Übersc hriften 2/K-O/MMas chi nenübersicht @ 0\mod_1195565731130_78.doc x @ 555 @ 2 @ 1 Machine overview Pos : 55.3 /BA/M asc hinenbesc hrei bung/M aschi nenübersic ht/Groß...
  • Page 51 Machine Description Pos : 55.5 /BA/M asc hinenbesc hrei bung/M aschi nenübersic ht/Groß pac kenpres sen/M asc hinenübersic ht linke Seite mi t T andemac hs e BP 890_1270_1290 H S @ 308\mod_1416995805537_78.doc x @ 2391971 @ @ 1 Wide-angle universal shaft Hydraulic oil storage tank Fire extinguisher Compressed air reservoir for the...

  • Page 52: Right-Hand Side Of Large Square Baler Big Pack With Tandem Axle

    Machine Description Pos : 55.7 /Übersc hriften/Übersc hriften 3/P-T/RR ec hte Seite der Gr oßpac kenpr ess e Bi G Pac k mit T andemachse @ 312\mod_1420787689918_78.doc x @ 2412536 @ 3 @ 1 5.1.2 Right-hand Side of Large Square Baler BiG Pack with Tandem Axle Pos : 55.8 /BA/M asc hinenbesc hrei bung/M aschi nenübersic ht/Groß...

  • Page 53: Identification Plate

    Authentic KRONE spare parts and accessories authorised by the manufacturer help to ensure safety. The use of spare parts, accessories and other devices which are not manufactured, tested or approved by KRONE will result in the revoking of the liability for damages resulting thereof.

  • Page 54: Description Of The Baling Process

    Machine Description Pos : 55.15 /BA/Maschi nenbeschr eibung/Masc hi nenübersicht/Gr oß pac kenpr ess en/Besc hrei bung Press vorgang @ 153\mod_1363008350826_78.doc x @ 1359371 @ 2 @ 1 Description of the Baling Process When switching on the terminal, the terminal shows at first the manual mode basic screen. Starting with an empty bale channel In manual mode, pre-set the target bale channel flap pressure to 50 bar / 725 PSI (in case of dry crops, e.

  • Page 55: Compacting The Big Bale

    Machine Description Pos : 55.17 /BA/Maschi nenbeschr eibung/Masc hi nenübersicht/Gr oß pac kenpr ess en/Verdic hten des Gr oßpac kens alle Bi G PAC K´s @ 151\mod_1362137260923_78.doc x @ 1345221 @ 2 @ 1 Compacting the BiG Bale The machine enables pressing hay and straw to a highly compacted big bale (square balers). The square baler is compacted in eight steps.

  • Page 56: Multibale Design

    Therefore, the set number of small bales depends on the bale length and the minimum length of the small bales. If you want to increase the number of small bales to max. 9 units, please contact your KRONE dealer. In case of 9 small bales, the variable length of the small bales is 30 cm to 135 cm.
  • Page 57 Machine Description Fig. 19 a) Big bale / length of the big b) Small bale / length of the c) Layer thickness of the bale small bale small bale / number of layers The bale length and the number of small bales (from 2 to 9) must only be set at the beginning of a bale to get ideal small bales.

  • Page 58: Drives

    Machine Description Pos : 55.22 /Ü bersc hriften/Ü berschriften 2/A-E/AAntri ebe @ 20\mod_1238751478183_78.doc x @ 225045 @ 2 @ 1 Drives Pos : 55.23 /Ü bersc hriften/Ü berschriften 3/F-J /HHauptantri eb @ 20\mod_1238751529465_78.doc x @ 225070 @ 3 @ 1 5.7.1 Main drive Pos : 55.24 /BA/Bedienung /Groß...
  • Page 59 Machine Description Pos : 55.28 /Ü bersc hriften/Z wis chenübers chriften/P-Trec hte M aschi nens eite @ 60\mod_1297935179130_78.doc x @ 562741 @ @ 1 Right-hand Side of the Machine Pos : 55.29 /Ü bersc hriften/Z wis chenübers chriften/A-EBei Ausführ ung mit Sc hnei dwer k @ 157\mod_1364379388830_78.doc x @ 1387653 @ @ 1 Design with cutting system Pos : 55.30 /BA/Bedienung /Groß...

  • Page 60: Overload Protections On The Machine

    Machine Description Pos : 55.34 /Ü bersc hriften/Ü berschriften 2/U-Z/UÜ berlastsicherung an der Maschi ne @ 155\mod_1363674757378_78.doc x @ 1373335 @ 2 @ 1 Overload Protections on the Machine Pos : 55.35 /BA/Bedienung /Groß pac kenpres se/Überlas tsicherungen / Kuppl ungen / Sternr atsc he / Sc herschr aube/Ü berl astsic her ungen an der Mas chi ne: N achfolgende Komponenten werden gesc hützt @ 155\mod_1363346950723_78.doc x @ 1371086 @ @ 1 The following components are protected by overload protections against damages.

  • Page 61: Cutting System Drive For The Design With Xc Cutting System

    Machine Description Pos : 55.45 /Ü bersc hriften/Ü berschriften 3/P-T/SSc hnei dwer kantrieb @ 192\mod_1382011621479_78.doc x @ 1635994 @ 3 @ 1 5.8.3 Cutting System Drive for the Design with XC Cutting System Pos : 55.46 /BA/Bedienung /Groß pac kenpres se/Überlas tsicherungen / Kuppl ungen / Sternr atsc he / Sc herschr aube/Ü berl astsic her ung des Sc hneidwer ks und der Pic k-up, Ausführ ung H S mit Sc hnei dwer k @ 136\mod_1353063267793_78.doc x @ 1213945 @ @ 1 Fig.

  • Page 62: Needle Yoke

    Machine Description Pos : 55.53 /Ü bersc hriften/Ü berschriften 3/K-O/NN adelsc hwi nge @ 158\mod_1365140055004_78.doc x @ 1405035 @ 3 @ 1 5.8.5 Needle Yoke Pos : 55.54 /BA/Bedienung /Groß pac kenpres se/Überlas tsicherungen / Kuppl ungen / Sternr atsc he / Sc herschr aube/Ü berl astsic her ung der Nadelsc hwinge / Sc hersc hraube Bil d all e H S-T ypen auß er 1290 HD P II @ 192\mod_1382077992442_78.doc x @ 1637526 @ @ 1 Fig.

  • Page 63: Roller Crop Guide

    Cutting Length Pos : 55.67 /BA/Maschi nenbeschr eibung/Sc hnei dwer k/Sc hnittl änge BigPac k Bi G PAC K 890 H S / 870 HDP mit 16 Messer @ 192\mod_1382080824345_78.doc x @ 1637759 @ @ 1 The cutting system can be fitted with max. 16 blades.

  • Page 64: Hydraulic System

    Machine Description Pos : 55.69 /Ü bersc hriften/Ü berschriften 2/F-J /HH ydr auli ks ystem @ 274\mod_1404363871846_78.doc x @ 2064995 @ 2 @ 1 5.12 Hydraulic system Pos : 55.70 /BA/War tung/Load- Sensi ng/Groß pac kenpresse/Bil d Load- Sensi ng Ansc hlus s HS Baurei he @ 64\mod_1300278753983_78.doc x @ 582789 @ @ 1 Fig.31 Pos : 55.71 /BA/War tung/Load- Sensi ng/Das H ydr auli ks ystem der M asc hine is t wer kss eitig auf D auer umlauf @ 121 \mod_1343828402858_78.doc x @ 1108849 @ @ 1 The hydraulic system of the machine is designed ex works for continuous circulation (the...

  • Page 65: Pressure Limiting Valve Block (On-Board Hydraulic System)

    Machine Description Pos : 55.76 /BA/Maschi nenbeschr eibung/BiG PAc k/Pr eß kraftreguli erung / Dr uc kbegr enz ungs ventil-Bl oc k 890/1270/1290/1290 HD P (HS) @ 194\mod_1383579575073_78.doc x @ 1650652 @ 2 @ 1 5.13 Pressure Limiting Valve Block (On-Board Hydraulic System) Fig.

  • Page 66: Twine

    Pos : 55.85 /BA/Ei nstellungen/Groß pac kenpres se/Bindegarn ei nfädel n/Hinweis Verwenden Si e nur KR ONE Original Bi ndegar n @ 32\mod_1253083955561_78.doc x @ 308448 @ @ 1 Note Only use original KRONE twine Pos : 55.86 /Layout Module /---------------Seitenumbr uch---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 67: Electrical Twine Empty Display For Lower Thread

    Note The acoustic warning signal can be switched off while the twine is threaded in, see chapter KRONE ISOBUS Terminal "Alarm message". Pos : 55.88 /Layout Mod ule /---------------Seitenumbr uch---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 68: Twine Motion Indicator Upper Twine (Double Knotter)

    Machine Description Pos : 55.89 /BA/Bedienung /Groß pac kenpres se/Garnl aufanz eige Oberfaden (Doppel knoter) @ 20 \mod_1238741788902_78.doc x @ 224916 @ 3 @ 1 5.14.2 Twine motion indicator upper twine (double knotter) Fig. 36 The upper twine motion is monitored by reflectors (twine motion indicator) positioned above the machine.

  • Page 69: Knotter Gear

    Machine Description Pos : 55.93 /BA/Bedienung /Groß pac kenpres se/Knotergetriebe / R uhes tell ung / Bi ndevorgang von H and auslösen @ 168\mod_1367993844032_78.doc x @ 1452575 @ 2 @ 1 5.15 Knotter Gear Fig. 38 Knotter gear in idle position The knotter gear is in idle position if the trigger roller (1) is located in the recess of the cam disc (2) of the knotter gear.

  • Page 70: Bale Ejector / Bale Chute

    Machine Description Pos : 55.95 /BA/Maschi nenbeschr eibung/Masc hi nenübersicht/F unktions weise/Gr oßpac kenpr ess en/Ballenauss chi eber / Ballensc hurr e betätig en Ei nführ text BP 890_1270_1290_1290 HDP_4x4 @ 173\mod_1371025842883_78.doc x @ 1484464 @ 2 @ 1 5.16 Bale Ejector / Bale Chute BPHS0252 Fig.

  • Page 71: For Comfort Version Electronics Design

    Machine Description Pos : 55.98 /BA/Maschi nenbeschr eibung/Masc hi nenübersicht/F unktions weise/Gr oßpac kenpr ess en/Ballenauss chi eber / Ballensc hurr e betätig en bei Aus führung Komfort-El ektr oni k @ 157\mod_1364316843931_78.doc x @ 1386057 @ 3 @ 1 5.16.2 For Comfort Version Electronics Design: Fig.

  • Page 72: Compressed-Air Reservoir

    Machine Description Pos : 55.100 /Ü bers chriften/Ü bersc hriften 2/A- E/DDruc kluftbehäl ter @ 12\mod_1224144256075_78.doc x @ 150965 @ 2 @ 1 5.17 Compressed-air reservoir Pos : 55.101 /BA/Wartung/Dr uc kl uftbehälter/Druc kl uftbehälter Bild BP 890/1270/1290 HS Baur eihe M asc hbesc hrei bu ng @ 62\mod_1299662280569_78.doc x @ 574094 @ @ 1 BPHS0018 Fig.42 Pos : 55.102 /BA/Wartung/Dr uc kl uftbehälter/Druc kl uftbehälter T ext Zus atz Big Pac k H S Baurei he @ 62\mod_1299662408501_78.doc x @ 574121 @ @ 1...

  • Page 73: Technical Data Of The Machine

    Pos : 59.2 /BA/Einl eitung/T ec hnis che D aten/Gr oss pac kenpr ess e/BiG PAC K 870_890_1270_1290 H S_1290 HDP H S/BiG PACK 870 HDP/Techni sc he Daten: Gewicht Bi G PAC K 870 @ 233\mod_1393925742360_78.doc...
  • Page 74 Pos : 59.9 /BA/Einl eitung/T ec hnis che D aten/Gr oss pac kenpr ess e/BiG PAC K 870_890_1270_1290 H S_1290 HDP H S/BiG PACK 870 HDP/Techni sc he Daten: Preß kol ben BiG PACK 870 HDP @ 230\mod_1393334954972_78.doc...
  • Page 75 Pos : 59.13 /BA/Ei nlei tung/T echnisc he Daten/Gros spac kenpresse/Bi G PAC K 870_890_1270_1290 H S_1290 HD P H S/BiG PAC K 870 HD PT ec hnisc he D aten: Überlastsic her ung / Schersc hraube BiG PACK 870 HDP @ 353 \mod_1437656384526_78.doc...
  • Page 76 Pos : 59.18 /BA/Ei nlei tung/T echnisc he Daten/Gros spac kenpresse/Bi G PAC K 870_890_1270_1290 H S_1290 HD P H S/BiG PAC K 870 HD P/T ec hnis che D aten: Mi ndestanforderung an den Tr aktor BiG PAC K 870 HDP @ 230\mod_1393335844647_78.doc...

  • Page 77: Tyres

    Technical Data of the Machine Pos : 59.23 /BA/Ei nlei tung/T echnisc he Daten/Gros spac kenpresse/Bi G PAC K 1290 HDP II/Technisc he Daten: Ausrüs tung der M asc hine ( optional) Alle HS T ypen auß er BiG PAC K 1290 HD P II @ 308\mod_1416999695976_78.doc x @ 2392006 @ @ 1 Machine equipment (optional) Additional working lights Moisture measurement...

  • Page 78: Consumables

    Technical Data of the Machine Pos : 65.1 /Übersc hriften/Übersc hriften 2/A-E/BBetriebsstoffe @ 174\mod_1371620600320_78.doc x @ 1490571 @ 2 @ 1 Consumables Pos : 65.2 /Übersc hriften/Übersc hriften 3/F-J/FF üllmengen und Schmi er mittelbez eichnungen der Getriebe @ 33\mod_1254230622207_78.doc x @ 318675 @ 3 @ 1 6.5.1 Filling Quantities and Lubrication Designations for Gearboxes Pos : 65.3 /BA/Wartung/U mweltHinweis U mwelt Betriebss toffe ents orgen und l agern (2016- 01- 25 09:46:09) @ 313\mod_1421247863386_78.doc x @ 2418631 @ @ 1...

  • Page 79: Oil Quantities And Designations For The On-Board Hydraulic System

    Technical Data of the Machine Pos : 65.6 /Übersc hriften/Übersc hriften 3/F-J/FF üllmenge und Ölbez eichnung der Bor dhydrauli k @ 17\mod_1236177374918_78.doc x @ 201862 @ 3 @ 1 6.5.2 Oil quantities and designations for the on-board hydraulic system Pos : 65.7 /BA/Wartung/U mwelt/Hi nweis Ents orgen / Lager n von Öl e und Ölfilter Umwelt @ 32\mod_1253101375171_78.doc x @ 311770 @ @ 1 ENVIRONMENT! - Disposal and storage of used lubricants and oil filters Effect: Environmental damage Store or dispose used oil and oil filters according to statutory provisions.

  • Page 80: Control And Display Elements

    Control and Display Elements Pos : 67 /Ü bersc hriften/Übersc hriften 1/A-E/Bedien- und Anz eigeelemente @ 107\mod_1334231983896_78.doc x @ 965285 @ 1 @ 1 Control and Display Elements Pos : 68 /Ü bersc hriften/Übersc hriften 2/P-T/S/Steuergeräte des Traktors @ 368\mod_1441699155843_78.doc x @ 2700765 @ 2 @ 1 Control units of the tractor Pos : 69 /BA/M asc hinenbesc hrei bung/M asc hinenübersic ht/Groß...

  • Page 81: Operation Terminal

    Pos : 75 /BA/Info-C enter/CC I-ISOBU S-Ter mi nal/Si ehe die Kapi tel z um KRON E ISOBU S_Ter minal @ 368\mod_1441700068280_78.doc x @ 2700837 @ @ 1 See chapter on the KRONE ISOBUS-Terminal. Pos : 76 /Layout M odul e /---------------Seitenumbruc h---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 82: Commissioning

    Commissioning Pos : 77.1 /Übersc hriften/Übersc hriften 1/A-E/Ers tinbetriebnahme @ 0\mod_1196314201498_78.doc x @ 5855 @ 1 @ 1 Commissioning Pos : 77.2 /BA/Sicher heit/7. Gefahrenhi nweis e alt/Ersti nbetri ebnahme/Warnung - Ersti nbetriebnahme nur von autorisi erter F ac hpers on @ 111\mod_1336724783740_78.doc x @ 987284 @ @ 1 WARNING! Risk of accident or damage to the machine due to an incorrect initial operation! Only an authorized service technician is permitted to carry out the initial operation.

  • Page 83: Attaching Hydraulic Parking Jack

    Commissioning Pos : 77.9 /Übersc hriften/Übersc hriften 2/F-J/HH ydraulischen Stützfuß anbauen @ 193\mod_1383215414302_78.doc x @ 1646685 @ 2 @ 1 Attaching Hydraulic Parking Jack Pos : 77.10 /BA/Ers tinbetriebnahme/Groß pac kenpressen/Bei Ausführung hydraulisc her Stütz fuß @ 193\mod_1383214866332_78.doc x @ 1646602 @ @ 1 With hydraulic parking jack design.
  • Page 84 Commissioning Pos : 77.14 /BA/Ers tinbetriebnahme/Groß pac kenpressen/H ydr aulisc hen Stütz fuß anbauen T2 @ 169 \mod_1369381329007_78.doc x @ 1464043 @ @ 1 Attaching hydraulic hoses. Fig. 44 Retracting parking jack connection Extending parking jack connection Collect escaping oil in a suitable container. •...

  • Page 85: Electrical Power Supply

    Commissioning Pos : 77.16 /Ü bersc hriften/Ü berschriften 2/P-T/SSpannungs vers orgung @ 28\mod_1250578107003_78.doc x @ 275490 @ 2 @ 1 Electrical power supply Pos : 77.17 /BA/Ers tinbetriebnahme/Spannungs vers orgung/Dauerstroms tec kdos e Bild @ 36 \mod_1260454934575_78.doc x @ 336632 @ @ 1 SW2000058 Fig.

  • Page 86: Adjusting The Drawbar Height

    Commissioning Pos : 77.20 /Ü bersc hriften/Ü berschriften 2/F-J /HHöhenanpass ung der Deic hs el @ 17\mod_1236255816988_78.doc x @ 204061 @ 2 @ 1 Adjusting the drawbar height Pos : 77.21 /BA/Ers tinbetriebnahme/Groß pac kenpressen/Einstell ung der Anhängehöhe 4x4 @ 108 \mod_1334732430989_78.doc x @ 970024 @ @ 1 Fig.

  • Page 87: Adjusting The Height Of The Drive Train

    Commissioning If the adjustment of the towing ring is not adequate, adjust the side parts (4). To do this: • Unscrew the screws (3) • Adjust the height of the front parts of the drawbar (4) to the height of the tractor hitch •...

  • Page 88: Shortening Universal Shaft

    Commissioning Pos : 77.25 /Ü bersc hriften/Ü berschriften 2/F-J /GGel enkwelle kürzen @ 274\mod_1404372446709_78.doc x @ 2065920 @ 2 @ 1 Shortening Universal Shaft Pos : 77.26 /BA/Sic herheit/8. Vorauss etz ungen/Handlungsanweisung für all e M asc hinen/Handlungsanweis ung: M asc hine stills etz en und sic hern @ 274\mod_1404365253849_78.doc x @ 2065151 @ @ 1 •...
  • Page 89 Commissioning Pos : 77.29 /BA/Ers tinbetriebnahme/Gelenkwelle/Groß pac kenpress en/Gel enkwelle ByPyGel enkwell e kürzen T eil 2 @ 170\mod_1369728951081_78.doc x @ 1467935 @ @ 1 X+2cm Fig. 49 • Connect the machine without universal shaft to the tractor • Move the machine to the narrowest position (driving around curves). •...
  • Page 90 Commissioning Pos : 77.31 /BA/Ers tinbetriebnahme/Gelenkwelle/Groß pac kenpress en/Gel enkwelle ByPyMit inner er Schmi erleitung @ 170\mod_1369728863034_78.doc x @ 1467827 @ @ 1 With inner lubrication line The inner lubrication lines may be cut when shortening the section tube inside. If this is the case, the lubrication lines must be removed and adjusted and a new access hole must be drilled.
  • Page 91 Commissioning Pos : 77.33 /BA/Ers tinbetriebnahme/Gelenkwelle/Groß pac kenpress en/Gel enkwelle ByPyGel enkhälften monti eren @ 170\mod_1369728798111_78.doc x @ 1467799 @ @ 1 Installing the PTO shaft halves Fig. 51 Inner PTO shaft half Outer PTO shaft half Section tube inside Raceway inside Fastening screw Guard tube inside...
  • Page 92 Commissioning Pos : 77.35 /BA/Ers tinbetriebnahme/Gelenkwelle/Groß pac kenpress en/Gel enkwelle ByPyVersc hi ebeweg (Überlappung) ermi tteln @ 170\mod_1369728715377_78.doc x @ 1467771 @ @ 1 Determining the displacement path (overlapping) Fig. 52 • Lay the both PTO shaft halves in front of one another, the outer section tube is in front of the inner section tube.

  • Page 93: Adjusting The Hydraulic System

    Commissioning Pos : 77.37 /Ü bersc hriften/Ü berschriften 2/A-E/AAnpassen des H ydrauli ks ys tems @ 1\mod_1201241743588_78.doc x @ 52013 @ 2 @ 1 Adjusting the hydraulic system Pos : 77.38 /BA/War tung/Load- Sensi ng/Groß pac kenpresse/Bil d Load- Sensi ng Ansc hlus s HS Baurei he @ 64\mod_1300278753983_78.doc x @ 582789 @ @ 1 Fig.53 Pos : 77.39 /BA/Maschi nenbeschr eibung/BiG PAc k/Handl ungsanweis ung: H ydrauli ks ysteme Traktor -Masc hine druc kl os / M asc hine stillsetzen und sichern @ 274\mod_1404364138167_78.doc x @ 2065053 @ @ 1 •...

  • Page 94: Setting The Bale Chute

    If the inclination of the bale chute is changed, the bale scale must be recalibrated if the machine has one (see chapter on KRONE ISOBUS terminal CCI "Calibrating the Bale Scale"). Pos : 77.49 /Layout Module /---------------Seitenumbr uch---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 95: Bale Brake

    Commissioning Pos : 77.50 /Ü bersc hriften/Ü berschriften 4/A-E/Ballenbr emse @ 324\mod_1425459464877_78.doc x @ 2492307 @ 4 @ 1 8.7.1.1 Bale Brake Pos : 77.51 /BA/Bedienung /Groß pac kenpres se/Ballenbr ems e/Ballenbrems e_Text @ 324\mod_1425459091066_78.doc x @ 2492136 @ @ 1 Only in combination with bale scale BPHS0068 Fig.

  • Page 96: Start-Up

    Start-up Pos : 79.1 /Übersc hriften/Übersc hriften 1/F-J/Inbetri ebnahme @ 0\mod_1196327075811_78.doc x @ 6375 @ 1 @ 1 Start-up Pos : 79.2 /BA/Sicher heit/2. Vor angestellte Warnhi nweis e/WARNUNG - Nichtbeachtung der grundl egenden Sicherheits hinweis e alte F orm @ 254 \mod_1397485793575_78.doc x @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 97: Connect The Machine To The Tractor

    Start-up Pos : 79.6 /Übersc hriften/Übersc hriften 2/K-O/MMas chi ne an den Tr aktor ankuppel n @ 279\mod_1405350506791_78.doc x @ 2150095 @ 2 @ 1 Connect the machine to the tractor Pos : 79.7 /BA/Ersti nbetriebnahme/Gr oßpac kenpr ess en/Anhängen an den Traktor alle Bi G PAC K´außer 1290 HD P II Bild @ 282\mod_1406700271355_78.doc x @ 2175007 @ @ 1 Fig.

  • Page 98: Install The Pto Shaft

    Start-up Pos : 79.10 /Ü bersc hriften/Ü berschriften 3/F-J /GGel enkwelle monti eren @ 11\mod_1223358863095_78.doc x @ 145571 @ 3 @ 1 9.1.1 Install the PTO shaft Pos : 79.11 /BA/Ers tinbetriebnahme/Groß pac kenpressen/Sc hwungradbr emse/War nung - Schwungradbrems e @ 272\mod_1403527213260_78.doc x @ 2051587 @ @ 1 WARNING! There is an increased risk of injury if the flywheel brake is not applied.
  • Page 99 Start-up Pos : 79.18 /BA/Inbetri ebnahme/Groß pac kenpress e/Anbau Gelenkwelle Auf ausreic hend Fr eiraum im Sc hwenkbereic h der Gelenkwelle ac hten. @ 172\mod_1370444743813_78.doc x @ 1479168 @ @ 1 Fig. 58 • Make certain there is sufficient free room in the swivel range of the universal shaft in all operating states.

  • Page 100: Hydraulics

    Start-up Pos : 79.21 /Ü bersc hriften/Ü berschriften 2/F-J /HH ydr auli k @ 0\mod_1199776034950_78.doc x @ 34205 @ 2 @ 1 Hydraulics Pos : 79.22 /BA/Sic herheit/H ydr auli k/WARNUNG - Vertaus chen der H ydrauli kkl eitungen, wenn D W @ 168\mod_1368508723414_78.doc x @ 1456727 @ @ 1 WARNING! - If the hydraulic hoses are interchanged when connecting them to the hydraulic system of the tractor, the functions will be interchanged as well.

  • Page 101: Connecting The Hydraulic Lines

    Start-up Pos : 79.26 /Ü bersc hriften/Ü berschriften 3/F-J /HH ydr auli kl eitungen ansc hließ en @ 0\mod_1199777037794_78.doc x @ 34244 @ 3 @ 1 9.2.1 Connecting the hydraulic lines Pos : 79.27 /BA/Inbetri ebnahme/Groß pac kenpress e/H ydr auli k/H ydr auli kanschl uss Bild Bi G Pac k 870 HD P @ 271\mod_1402645320277_78.doc x @ 2042669 @ @ 1 Fig.
  • Page 102 Start-up Pos : 79.35 /BA/Maschi nenbeschr eibung/Masc hi nenübersicht/Gr oß pac kenpr ess en/Komfort-El ektr oni k @ 61\mod_1299223046976_78.doc x @ 570919 @ @ 1 Comfort - Electronic Pos : 79.36 /BA/Maschi nenbeschr eibung/BiG PAc k/Handl ungsanweis ung: H ydrauli ks ysteme Traktor -Masc hine druc kl os / M asc hine stillsetzen und sichern @ 274\mod_1404364138167_78.doc x @ 2065053 @ @ 1 •...

  • Page 103: Putting Down Iso Plug

    Start-up Pos : 79.43.1 /Ü berschriften/Ü berschriften 2/F-J/IISO-Stec ker ableg en @ 364\mod_1440594785663_78.doc x @ 2681127 @ 2 @ 1 Putting Down ISO Plug Pos : 79.43.2 /Beipac ks /Sonstige Beipac ks _maschi nenuebergreifend/ISOBUS- Kabel/Beipac k IOSBUS-Kabel _ISO- Stec ker ableg en BiG Pac k Bil d @ 364\mod_1440513852606_78.doc x @ 2679724 @ @ 1 Fig.

  • Page 104: Hydraulic Brake (Export France)

    Start-up Pos : 79.49 /Ü bersc hriften/Ü berschriften 2/F-J /HH ydr aulisc he Brems e (Export Fr ankr eic h) @ 129\mod_1346767988893_78.doc x @ 1155782 @ 2 @ 1 Hydraulic Brake (Export France) Pos : 79.50 /BA/Sic herheit/Brems en/War nung - hydraulische Brems e Fr ankr eic hauss tattung Sicherungs kette z u kurz @ 289\mod_1410250791418_78.doc x @ 2285995 @ @ 1 WARNING! Risk of injury and serious material damages due to unintentional braking of the machine.

  • Page 105: Compressed Air Connections For The Compressed Air Brake

    Start-up Pos : 79.56 /Ü bersc hriften/Ü berschriften 2/A-E/DDr uc kl uftansc hlüss e bei Druc kl uftbr emse @ 0\mod_1201161304258_78.doc x @ 51103 @ 2 @ 1 Compressed Air Connections for the Compressed Air Brake Pos : 79.57 /BA/Inbetri ebnahme/Dr uc kluftbrems e/Z weileitungss ystem @ 5\mod_1213850550416_78.doc x @ 89668 @ @ 1 The machine features a dual-line compressed-air braking system.

  • Page 106: Connecting Krone Isobus-Terminal

    Pos : 79.61.1 /Ü berschriften/Ü berschriften 2/K-O/K/KRON E ISOBU S-Ter minal anschli eßen @ 375\mod_1442836273898_78.doc x @ 2728405 @ 2 @ 1 Connecting KRONE ISOBUS-Terminal Pos : 79.61.2 /BA/Sic herheit/elektrische Bedi enung/Ac htung - Ansc hlus s der Bedi enung @ 11\mod_1222421029499_78.doc x @ 141746 @ @ 1...
  • Page 107 Note The terminal is connected to the tractor via a special cable set (5) which can be ordered by stating the KRONE article no. 20 081 223 0. • Connect the plug (2) of the cable set (5) with the socket (1) (CAN1-IN) of the terminal.
  • Page 108 Start-up Pos : 79.61.12 /Ü bersc hriften/Z wisc henübersc hriften/P-T/Tr aktoren ohne ISOBU S-Sys tem @ 366\mod_1441170400829_78.doc x @ 2691305 @ @ 1 Tractors without ISOBUS system Pos : 79.61.13 /BA/Sic her hei t/8. Vor aussetzungen/H andl ungs anweis ung für alle Mas chi nen/Vor aussetz ung: Die M asc hine is t stillges etzt und g esichert, ..@ 259\mod_1398674434170_78.doc x @ 1979947 @ @ 1 Prerequisite: –...
  • Page 109 Start-up Connection tractor to machine Note The connection of tractor to machine takes place via a provided power cable (8) (article no. 20 080 601 0). • Connect plug (9) of power cable (8) with continuous current socket (10) of the tractor •...

  • Page 110: Connecting External Isobus-Terminal

    Start-up Pos : 79.63.1 /Ü berschriften/Ü berschriften 2/F-J/FFremd-ISOBU S-Ter mi nal ansc hließ en @ 375\mod_1442847282473_78.doc x @ 2729291 @ 2 @ 1 Connecting External ISOBUS-Terminal Pos : 79.63.2 /BA/Sic herheit/elektrische Bedi enung/Ac htung - Ansc hlus s der Bedi enung @ 11\mod_1222421029499_78.doc x @ 141746 @ @ 1 Caution! - Connecting the electrical controls Effect: Damage to the control unit Before inserting the plugs, make certain the plugs and sockets are clean and dry.

  • Page 111: Connecting The Joystick

    Note The terminal is connected to the tractor via a special cable set (5) which can be ordered by stating the KRONE article no. 20 081 223 0. • Connect the plug (2) of the cable set (5) with the socket (1) (CAN1-IN) of the terminal.
  • Page 112 The terminal is connected to the multi-function lever via a special cable set (9) which can be ordered by stating the Krone product no. 20 081 676 0. Pos : 79.65.11 /BA/Sic her hei t/8. Vor aussetzungen/H andl ungs anweis ung für alle Mas chi nen/Vor aussetz ung: Die M asc hine is t stillges etzt und g esichert, ..@ 259\mod_1398674434170_78.doc x @ 1979947 @ @ 1 Prerequisite: –...
  • Page 113 The terminal is connected to the multi-function lever via a special cable set (9) which can be ordered by stating the Krone product no. 20 081 676 0. Pos : 79.65.18 /BA/Sic her hei t/8. Vor aussetzunge n/H andl ungs anweis ung für alle Mas chi nen/Vor aussetz ung: Die M asc hine is t stillges etzt und g esichert, ..@ 259\mod_1398674434170_78.doc x @ 1979947 @ @ 1 Prerequisite: –...

  • Page 114: Lighting

    Start-up Pos : 79.67 /Ü bersc hriften/Ü berschriften 2/A-E/BBel euc htung @ 0\mod_1195658399935_78.doc x @ 1881 @ 2 @ 1 9.10 Lighting Pos : 79.68 /BA/Inbetri ebnahme/Groß pac kenpress e/Beleuchtung/Bel euc htung ansc hließ en Bil d HD P II @ 171\mod_1370344610812_78.doc x @ 1475988 @ @ 1 BPHS0216 Fig.
  • Page 115 Start-up Fig. 71 Pos : 79.72.6 /BA/Sic herheit/8. Vorauss etz ung en/Handlungsanweis ung für all e M asc hinen/Handlungsanweis ung: M asc hine stills etz en und sic hern @ 274\mod_1404365253849_78.doc x @ 2065151 @ @ 1 • Shut down and safeguard the machine, see chapter Safety -> Safety routines, "Shutting down and safeguarding the machine".

  • Page 116: Driving And Transport

    Driving and Transport Pos : 81.1 /Übersc hriften/Übersc hrift en 1/F-J/F ahr en und Trans port @ 0\mod_1196330049217_78.doc x @ 6553 @ 1 @ 1 Driving and Transport Pos : 81.2 /BA/Sicher heit/2. Vor angestellte Warnhi nweis e/WARNUNG - Nichtbeachtung der grundl egenden Sicherheits hinweis e alte F orm @ 254\mod_1397485793575_78.doc x @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 117: Preparations For Road Travel

    Driving and Transport Pos : 81.7 /Übersc hriften/Übersc hriften 2/U-Z/VVor bereitung en zur Str aß enfahrt @ 25\mod_1244092605963_78.doc x @ 254666 @ 2 @ 1 10.1 Preparations for road travel Pos : 81.8 /BA/F ahren und Tr ansport/Groß pac kenpress ePrüfen Si e vor der Str aß enfahrt, dass Bi G PAC K 890_1270_1290_4x4 HS @ 325\mod_1425893751195_78.doc x @ 2501725 @ @ 1 Before road travel, make certain –...

  • Page 118: Bale Chute Hydraulically Actuated

    Pos : 81.11 /Ü bersc hriften/Ü berschriften 3/F-J /HH ydr aulisc h betätigte Ballensc hurr e @ 312\mod_1420636057218_78.doc x @ 2410001 @ 3 @ 1 10.1.1 Bale Chute Hydraulically Actuated Pos : 81.12 /BA/F ahr en und Trans por t/Gr oßpac kenpr ess e/H ydraulisc hRoll ens churre Bild 870 HDP Baur eihe @ 270\mod_1402485959956_78.doc x @ 2039588 @ @ 1 BPHS0274 Fig. 73 Pos : 81.13 /BA/F ahr en und Trans por t/Gr oßpac kenpr ess eH ydraulisch betätigte Ballensc hurre T ext @ 312 \mod_1420638282241_78.doc x @ 2410032 @ @ 1...

  • Page 119: Checking The Lighting System

    Driving and Transport Pos : 81.16 /Ü bersc hriften/Ü berschriften 3/A-E/B/Bel euchtungsanl age prüfen @ 25\mod_1244090937463_78.doc x @ 254566 @ 3 @ 1 10.1.3 Checking the lighting system Pos : 81.17 /BA/F ahr en und Trans por t/Gr oßpac kenpr ess e/Bel euchtungsanlag e pr üfen Bil d BP 890_1270_1290 Hs Baur eihe @ 62 \mod_1299574637575_78.doc x @ 572905 @ @ 1 BPHS0011 Fig.75 Pos : 81.18 /BA/F ahr en und Trans por t/Gr oßpac kenpr ess e/Bel euchtungsanlag e pr üfen T ext @ 17 \mod_1236588258401_78.doc x @ 205489 @ @ 1...

  • Page 120: Handling The Coaster/Steering Axle (Special Equipment)

    Driving and Transport Pos : 81.23 /Ü bersc hriften/Ü berschriften 2/F-J /HHandhabung der N achl auf-Lenkac hs e ( Sonder aus stattung) @ 0\mod_1201167915356_78.doc x @ 51383 @ 2 @ 1 10.2 Handling the Coaster/Steering Axle (Special Equipment) Pos : 81.24 /BA/Inbetri ebnahme/Groß pac kenpress e/H ydr auli k/Hi nweis: Benutz erhi nweis e des Tr aktorherstellers z um Par allel betrieb beac hten. @ 233\mod_1393930674316_78.doc x @ 1858122 @ @ 1 Note Observe the user instructions provided by the tractor manufacturer for parallel operation of the tractor control units! The locking cylinder of the steering axle must be connected before or at...
  • Page 121 Driving and Transport Pos : 81.29 /BA/F ahr en und Trans por t/Na chl auf-Lenkac hs e/N ac hlaufl enkac hs e AX und MX Ladewagen/Verriegel n der N ac hlauf- Lenkac hse @ 60\mod_1297786258507_78.doc x @ 561294 @ @ 1 Locking the coaster/steering axle To lock the coaster/steering axle: Pos : 81.30 /BA/Maschi nenbeschr eibung/Masc hi nenübersicht/Gr oß...

  • Page 122: Operating The Machine Via Ls (Load-Sensing Connection)

    Driving and Transport Pos : 81.37 /BA/Maschi nenbeschr eibung/Masc hi nenübersicht/Gr oß pac kenpr ess en/Komfort-El ektr oni k @ 61\mod_1299223046976_78.doc x @ 570919 @ @ 1 Comfort - Electronic Pos : 81.38 /Ü bersc hriften/Ü berschriften 3/A-E/B/Betrieb der M asc hine über LS (Load-Sensing-Ansc hluss) @ 91\mod_1326699464848_78.doc x @ 780190 @ 3 @ 1 10.2.1 Operating the Machine via LS (Load-Sensing Connection) Pos : 81.39 /BA/F ahr en und Trans por t/Nachl auf-Lenkac hs e/N ac hlauf-Lenkachs e Big Pac k/Nac hl auf-Lenkac hs e verriegel n Komfort Elektroni k über Load Sensi ng @ 91\mod_1326702544634_78.doc x @ 780363 @ @ 1...

  • Page 123: Moving The Machine Without Hydraulic Connections

    Driving and Transport Pos : 81.49 /BA/F ahr en und Trans por t/Nachl auf-Lenkac hs e/N ac hlauf-Lenkachs e Big Pac k/Bei Opti on N achl auf-Lenkac hs e r angier en HS Baur eihe @ 62\mod_1299593571338_78.doc x @ 573301 @ 3 @ 1 10.2.3 Moving the machine without hydraulic connections In order to be able to move the machine even when the hydraulic lines are not connected, the...

  • Page 124: Moving

    Driving and Transport Pos : 81.52.1 /Ü berschriften/Ü berschriften 2/P-T/RR angier en @ 13\mod_1225364693769_78.doc x @ 155850 @ 2 @ 1 10.3 Moving Pos : 81.52.2 /Ü berschriften/Z wis chenübers chriften/A-EBei Ausführ ung Dr uc kluftbrems e @ 168\mod_1368456181882_78.doc x @ 1456665 @ @ 1 With compressed air brake design Pos : 81.52.3 /BA/Sic herheit/2.

  • Page 125: Switching Off The Machine

    Driving and Transport Pos : 81.54 /Ü bersc hriften/Ü berschriften 2/K-O/MM asc hine abstellen @ 196\mod_1384184875882_78.doc x @ 1661525 @ 2 @ 1 10.4 Switching off the machine Pos : 81.55 /BA/Sic herheit/2. Voranges tellte Warnhinweise/War nung - M asc hine sic her abstellen ohne Tr aktor_F ests tell brems e, Unterleg keile und Sc hwungradbrems e @ 274\mod_1404214703082_78.doc x @ 2060841 @ @ 1 WARNING! Risk of injury due to the unsecured machine rolling away! If the machine is not secured against rolling away when it has been switched off, there is a risk...

  • Page 126: Parking Brake

    Driving and Transport Pos : 81.58 /Ü bersc hriften/Ü berschriften 3/F-J /FFeststellbr emse @ 322\mod_1424873704700_78.doc x @ 2482657 @ 3 @ 1 10.4.1 Parking Brake Pos : 81.59 /BA/Inbetri ebnahme/F eststell brems e/F eststellbrems e Bild Bi G Pac k 890_1270_1290 H S Baurei he @ 92\mod_1326881975736_78.doc x @ 782991 @ @ 1 BPHS0009_1 Fig.

  • Page 127: Stowing The Compressed Air Hoses

    Driving and Transport Pos : 81.66 /Ü bersc hriften/Ü berschriften 3/A-E/D /Druc kl uftsc hläuche ablegen @ 279\mod_1405072075407_78.doc x @ 2148036 @ 3 @ 1 10.4.3 Stowing the compressed air hoses Pos : 81.67 /BA/Inbetri ebnahme/Dr uc kluftbrems e/Dr uc kluftsc hläuc he abl egen Bil d BiG Pac k @ 279\mod_1405071878377_78.doc x @ 2147992 @ @ 1 Fig.

  • Page 128: Preparing The Machine For Transportation

    Driving and Transport Pos : 81.70.1 /Ü berschriften/Ü berschriften 2/U-Z/V/Vor ber eitung der Mas chi ne für di e Beför der ung @ 395\mod_1446625169194_78.doc x @ 2815316 @ 2 @ 1 10.5 Preparing the machine for transportation Pos : 81.70.2 /BA/Sic herh eit/2. Vorangestellte Warnhinweise/Ac htung - Mas chi nensc haden durc h nicht gesic herte bewegliche Mas chi nenteile bei m Tr ans port @ 395\mod_1446618988846_78.doc x @ 2815285 @ @ 1 CAUTION! Risk of machine damage due to unsecured moving machine parts When transporting the machine on transportation vehicles (e.g.

  • Page 129: Securing Guide Wheels

    Driving and Transport Pos : 81.70.7 /Ü berschriften/Ü berschriften 3/P-T/T/T astr äder sic hern @ 382\mod_1444211893669_78.doc x @ 2754110 @ 3 @ 1 10.5.2 Securing guide wheels Pos : 81.70.8 /BA/F ahr en und Trans port/Gr oßpac kenpr ess e/Trans port/T astr äder sic her n_Bild_BP @ 382\mod_1444211627010_78.doc x @ 2753988 @ @ 1 BPHS0324 Fig.

  • Page 130: Krone Isobus Terminal [Medium/Comfort Version Electronics]

    Those KRONE machines which are ISOBUS equipped are adapted to this system. Pos : 85.5 /BA/Info-C enter/CC I-ISOBU S-Ter mi nal/CC I-BiG Pac k/Allgemeine Bes chr eibung (Di e elektronische Ausstattung der M asc hine ..) Text/Bild @ 377\mod_1443172669418_78.doc x @ 2736562 @ @ 1 Fig.

  • Page 131: Isobus Shortcut Button

    KRONE ISOBUS Terminal [Medium/Comfort Version Electronics] Pos : 85.7.1 /Übersc hriften/Übersc hriften 2/F-J/IISOBU S Shortc ut Button @ 364\mod_1440571658458_78.doc x @ 2680236 @ 2 @ 1 11.1 ISOBUS Shortcut Button Pos : 85.7.2 /BA/Sicherheit/2. Vorangestell te Warnhinweis e/Warnung - ISOBU S Shortc ut Button @ 364\mod_1440662693340_78.doc x @ 2682480 @ @ 1 WARNING! The ISOBUS Shortcut Button is not an EMERGENCY STOP switch.

  • Page 132: Touch Sensitive Display

    KRONE ISOBUS Terminal [Medium/Comfort Version Electronics] Pos : 85.7.6 /BA/Info-C enter/CC I-ISOBU S-Ter mi nal/M odul e für Bei pac k/ISOBU S Short C ut Button/ISOBUS Shortcut Button_wird g elöst @ 378 \mod_1443432962739_78.doc x @ 2738146 @ @ 1 Releasing ISOBUS shortcut button CC000071_1 Fig.

  • Page 133: Switching Terminal On Or Off

    KRONE ISOBUS Terminal [Medium/Comfort Version Electronics] Pos : 85.12 /Ü bersc hriften/Ü berschriften 2/P-T/T/T er minal ein- oder aussc halten @ 356\mod_1438694754146_78.doc x @ 2654344 @ 2 @ 1 11.3 Switching Terminal On or Off Pos : 85.13 /BA/Info-Center/ALLE Ter mi nals in einem - ISOBU S, Delta, BETA II (ab BJ 15/16)/N ur KR ONE ISOBUS/Rundballenpr ess enT er minal ein/aussc halten_Bil d_nur KRON E ISOBU S (2016- 04- 14 09:54:46) @ 365\mod_1441023398078_78.doc x @ 2686981 @ @ 1 IBT000057 Fig.

  • Page 134: Display Design

    KRONE ISOBUS Terminal [Medium/Comfort Version Electronics] Pos : 85.19 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- Swadro/Swadro 1400/Dis play Aufbau @ 365\mod_1441029601805_78.doc x @ 2687500 @ 2 @ 1 11.4 Display Design IBT000050 Fig. 91 The display of the terminal is divided into the following sections: Status line (1) The status line shows the current states of the machine (depending on how it is equipped).

  • Page 135: Krone Isobus Terminal [Medium Plus/Comfort Plus Version Electronics]

    KRONE ISOBUS Terminal [Medium Plus/Comfort Plus Version Electronics] Pos : 85.21 /Ü bersc hriften/Ü berschriften 1/K-O/KRON E ISOBU S-Ter minal [Medium Pl us-/Komfort Plus-Elektroni k] @ 430\mod_1455534531930_78.doc x @ 2968425 @ 1 @ 1 KRONE ISOBUS Terminal [Medium Plus/Comfort Plus Version Electronics] Pos : 85.22 /Ü...

  • Page 136: External Isobus Terminal

    Pos : 85.24.3 /BA/Info-Center/Is o-Bedienung/Gefahr durc h nicht von KR ONE gelieferte T er minals / Bedi enei nheiten @ 365 \mod_1441107337208_78.doc x @ 2689275 @ @ 1 DANGER! When using terminals and other operation units which have not been delivered by KRONE mind that the user: •...

  • Page 137: Isobus Shortcut Button Not Available

    The values for “Bale channel flap pressure/force”, “Bale length” and “Number of MultiBales” which are set by the scroll wheel in the basic screen on the KRONE ISOBUS terminal CCI, are set on the ISO terminal with the selection key predetermined by the ISO terminal (refer to the operating instructions of the ISO terminal manufacturer).

  • Page 138: Terminal - Machine Functions [Medium/Comfort Version Electronics]

    For possible causes and how to remedy them, refer to chapter entitled “Alarm Messages”. • In case the malfunction cannot be remedied, contact KRONE customer service. Pos : 85.28 /Ü bersc hriften/Ü berschriften 2/P-T/S/Status zeil e @ 167\mod_1367914020218_78.doc x @ 1450853 @ 2 @ 1 14.1 Status line Pos : 85.29 /BA/Info-Center/ALLE Ter mi nals in einem - ISOBU S, Delta, BETA II (ab BJ 15/16)/N ur KR ONE ISOBUS/Rundballenpr ess en/Displ ay-Aufbau_Status zeil e_Bild_nurKR ONE ISOBUS_C ompri ma_F orti ma_Ulti ma @ 382 \mod_1444126230738_78.doc x @ 2752517 @ @ 1...
  • Page 139 Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.31 /BA/Info-Center/ALLE Ter mi nals in einem - ISOBU S, Delta, BETA II (ab BJ 15/16)/ALLE Ter mi nals /Übergreifend über alle M asc hinen/Dis play- Aufbau_Statusz eile_Text_ALLE T er minals @ 354\mod_1438179883536_78.doc x @ 2645443 @ @ 1 The status line (1) in the display shows current states of the machine (depending on equipment): Pos : 85.32 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/Grundbild Handbetrieb/Statusz eile BiG PACK/Statusz eile (I) oberste Z eile H S und 1290 HD P II Baur eihe @ 3 50\mod_1436790936114_78.doc x @ 2628676 @ @ 1...

  • Page 140: Keys

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.34 /Ü bersc hriften/Ü berschriften 2/P-T/T/T as ten @ 365\mod_1441031168099_78.doc x @ 2687792 @ 2 @ 1 14.2 Keys Pos : 85.35 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/F unkti ons tas ten F 1 bis F 12/F unkti onstasten besc hrei ben Bild BiG PACK @ 350\mod_1436793220334_78.doc x @ 2628737 @ @ 1 CC000902_1 Fig.
  • Page 141 Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.40 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/F unkti ons tas ten F 1 bis F 12/Besc hreibung all er Funktionstasten Big PAC K T 2 @ 351\mod_1436863698068_78.doc x @ 2629876 @ @ 1 Symbol Designation Explanation...

  • Page 142: Displays In The Working Screen

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.42 /Ü bersc hriften/Ü berschriften 2/A-E/A/Anzeigen i m Arbeits bild @ 378\mod_1443538650498_78.doc x @ 2741134 @ 2 @ 1 14.3 Displays in the working screen</dg_bm "text_mod_1443538650498_0001"> Pos : 85.43 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/Grundbild Handbetrieb/Anzeig en i m Hauptfenster/Hauptfenster (III) Bild Bi G PAC K @ 376\mod_1442991621787_78.doc x @ 2733386 @ @ 1 CC000073_2 Fig.
  • Page 143 Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.47 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/Grundbild Handbetrieb/Anzeig en i m Hauptfenster/Anz eigen im Hauptfenster (III) linke Spalte H S Baurei he T1 @ 351\mod_1436879942388_78.doc x @ 2630859 @ @ 1 Selectable display elements Depending on the machine configuration, the following display elements can be positioned in the main window:...
  • Page 144 Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.50 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/Grundbild Handbetrieb/Anzeig en i m Hauptfenster/Hauptfenster (III) Bild Bi G PAC K @ 376\mod_1442991621787_78.doc x @ 2733386 @ @ 1 CC000073_2 Fig. 96 Pos : 85.51 /Layout Module /---------------Seitenumbr uch---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...
  • Page 145 Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.52 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/Grundbild Handbetrieb/Anzeig en i m Hauptfenster/Anz eigen im Hauptfenster (III) rec hte Spalte H S Baurei he @ 351 \mod_1436959136836_78.doc x @ 2631535 @ @ 1 Right column Symbol Designation...

  • Page 146: Selecting Working Screens

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.54 /Ü bersc hriften/Ü berschriften 2/A-E/A/Arbeits bilder aufr ufen @ 368\mod_1441698950682_78.doc x @ 2700527 @ 2 @ 1 14.4 Selecting Working Screens Pos : 85.55 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/Arbeits bilder aufr ufen_Aus Menüs_Aus Straß enfahrtbild_Bild BiG Pac k @ 386\mod_1445245314635_78.doc x @ 2773909 @ @ 1 CC000011 CC000095 Road travel screen...

  • Page 147: Selecting Road Travel Screen

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.61 /Ü bersc hriften/Ü berschriften 2/P-T/S/Straß enfahrtbild aufrufen @ 386\mod_1444998664990_78.doc x @ 2773255 @ 2 @ 1 14.7 Selecting road travel screen Pos : 85.62 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/Grundbild Handbetrieb/Str aßenfahrtbil d aufrufen_Bild + Text @ 352\mod_1437551073992_78.doc x @ 2637207 @ @ 1 CC000011 Fig.

  • Page 148: Switching The Warning Beacon On/Off

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.64.1 /Ü berschriften/Ü berschriften 2/P-T/RR unduml euchte ei n-/auss chalten @ 380\mod_1444030187976_78.doc x @ 2748846 @ 2 @ 1 14.8 Switching the warning beacon on/off Pos : 85.64.2 /BA/Info-Center/CCI-ISOBUS-T er minal/CCI- BiG Pac k/F unkti ons tas ten F 1 bis F 12/R undumleuc hte ein- / auss chalten @ 278\mod_1404978535177_78.doc x @ 2083891 @ @ 1 Switching ON •...

  • Page 149: Locking / Releasing Steering Axle

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.64.8 /Ü berschriften/Ü berschriften 2/K-O/L/Lenkac hs e s perren/l ös en @ 380\mod_1444034810638_78.doc x @ 2749109 @ 2 @ 1 14.11 Locking / Releasing Steering Axle Pos : 85.64.9 / BA/Info-Center/CCI-ISOBUS-T er minal/CCI- BiG Pac k/F unkti ons tas ten F 1 bis F 12/Seite 1/2 F4 Nac hl auf- Lenkac hs e s perren/lös en @ 351\mod_1437125126234_78.doc x @ 2633208 @ @ 1 Releasing •...

  • Page 150: Lower The Bale Chute

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.64.21 /BA/Info-C enter /CCI-ISOBUS-T ermi nal /CCI-Bi G Pac k/F unktionstasten F 1 bis F 12/Ballensc hurre s enken @ 351\mod_1437381019764_78.doc x @ 2633726 @ 2 @ 1 14.14 Lower the bale chute WARNING! –...

  • Page 151: Reset Bale Length To Zero

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.64.27 /Ü bersc hriften/Ü bersc hriften 2/A- E/B/Ballenl änge auf Null z ur üc ks etz en @ 380\mod_1444039594107_78.doc x @ 2749544 @ 2 @ 1 14.19 Reset bale length to zero Pos : 85.64.28 /BA/Info-C enter /CCI-ISOBUS-T ermi nal /CCI-Bi G Pac k/F unktionstasten F 1 bis F 12/Aktuell e Ballenl änge auf Null zur üc ks etz en @ 352 \mod_1437392136631_78.doc x @ 2634099 @ @ 1 •...

  • Page 152: Setting The Target Bale Channel Flap Pressure (Manual Mode)

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.66.1 /Ü berschriften/Ü berschriften 2/P-T/SSoll-Press kl appendr uc k einstellen (Handbetrieb) @ 352\mod_1437545367243_78.doc x @ 2637111 @ 2 @ 1 14.22 Setting the target bale channel flap pressure (manual mode) Pos : 85.66.2 /BA/Info-Center/Gr oßpac kenpr ess e/Grundbild Handbetrieb/Warnung zu hoher Dr uc k @ 18\mod_1237389601150_78.doc x @ 210149 @ @ 1 WARNING! –...

  • Page 153: Setting Target Force Of Pressure (Automatic Mode)

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.66.7 /BA/Info-Center/CCI-ISOBUS-T er minal/CCI- BiG Pac k/Grundbild Automati kbetri eb/Soll-Press kr aft eins tell en (Automati kbetrieb) @ 352\mod_1437486459383_78.doc x @ 2636177 @ 2 @ 1 14.23 Setting target force of pressure (automatic mode) Pos : 85.66.8 /BA/Info-Center/CCI-ISOBUS-T er minal/CCI- BiG Pac k/Grundbild Automati kbetri eb/Soll-Press kr aft (Automati kbetri eb) _Bil d @ 352\mod_1437558540267_78.doc x @ 2637377 @ @ 1 100% CC000091_1...

  • Page 154: Setting Bale Length (Manual And Automatic Mode)

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.66.12 /Ü bersc hriften/Ü bersc hriften 2/A- E/B/Ballenl änge ei nstellen (H and- und Automati kbetrieb) @ 381\mod_1444048005079_78.doc x @ 2750052 @ 2 @ 1 14.24 Setting bale length (manual and automatic mode) Pos : 85.66.13 /BA/Info-C enter /CCI-ISOBUS-T ermi nal /CCI-Bi G Pac k/Gr undbild H andbetrieb/Ball enl äng e ei nstellen H andbetrieb Bild H S Baurei he @ 352\mod_1437479408613_78.doc x @ 2636012 @ @ 1 Fig.102 Pos : 85.66.14 /BA/Info-C enter /CCI-ISOBUS-T ermi nal /CCI-Bi G Pac k/Gr undbild H andbetrieb/Ball enl äng e ei nstellen H and- und Automati kbetri eb @ 381\mod_1444048499984_78.doc x @ 2750083 @ @ 1...

  • Page 155: Setting The Number Of Multibales

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.66.16 /Ü bersc hriften/Ü bersc hriften 2/A- E/A/Anz ahl der M ultiBale ei nstellen @ 381\mod_1444048980340_78.doc x @ 2750144 @ 2 @ 1 14.25 Setting the number of MultiBales Pos : 85.66.17 /BA/Info-C enter /CCI-ISOBUS-T ermi nal /CCI-Bi G Pac k/Gr undbild H andbetrieb/Eins tellen der Mul tibaleanzahl H andbetrieb Bil d H S Baurei he @ 353 \mod_1437719782559_78.doc x @ 2641172 @ @ 1 Fig.

  • Page 156: Operating Machine Via Joystick

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.68.1 /Ü berschriften/Ü berschriften 2/K-O/M /Masc hi ne über Joystic k bedi enen @ 377\mod_1443193042804_78.doc x @ 2737184 @ 2 @ 1 14.26 Operating Machine via Joystick Pos : 85.68.2 /Ü berschriften/Ü berschriften 3/A-E/A/Auxili ar y-Funkti onen (AU X) @ 377\mod_1443193175950_78.doc x @ 2737214 @ 3 @ 1 14.26.1 Auxiliary Functions (AUX) Pos : 85.68.3 /BA/Info-Center/ALLE Ter minals i n einem - ISOBU S, Delta, BETA II (ab BJ 15/16)/N ur Fremdtermi nal ISOBUS/Rundballenpr ess en/Auxiliar y-F unktionen_Ei nlei tung_Fr emd ISOBU S_KR ONE ISOBU S @ 362\mod_1439552162877_78.doc x @ 2669996 @ @ 1...

  • Page 157: Example Of A Joystick Assignment For Fendt (Default Setting)

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.68.8 /Ü berschriften/Ü berschriften 3/A-E/B/Beis pi el ei ner Joystic k- Bel egung bei F endt (Default-Ei nstellung) @ 117\mod_1341214720469_78.doc x @ 1021106 @ 3 @ 1 14.26.2 Example of a joystick assignment for Fendt (default setting) Pos : 85.68.9 /BA/Info-Center/Is o-Bedienung/Hinweis Für weitere Vorgaben bitte die Betriebs anl eitung des verwendeten T ermi nals beachten @ 87 \mod_1321000865882_78.doc x @ 750002 @ @ 1 Note For further guidelines, please refer to the operating instructions of the terminal being used.

  • Page 158: Recommended Assignment Of A Wtk- Multi-Function Lever

    Terminal – Machine Functions [Medium/Comfort Version Electronics] Pos : 85.68.12 /Ü bersc hriften/Ü bersc hriften 3/A- E/E/Empfohlene Beleg ung eines WT K- M ultifunktions hebels @ 117\mod_1341221253128_78.doc x @ 1021492 @ 3 @ 1 14.26.3 Recommended assignment of a WTK- multi-function lever Pos : 85.68.13 /BA/Info-C enter /Is o-Bedi enung/Hinweis F ür weiter e Vorgaben bitte di e Betriebsanlei tung des ver wendeten Ter minals beac hten @ 87\mod_1321000865882_78.doc x @ 750002 @ @ 1 Note For further guidelines, please refer to the operating instructions of the terminal being used.

  • Page 159: Terminal - Machine Functions [Medium Plus/Comfort Plus Version Electronics]

    Terminal - Machine Functions [Medium Plus/Comfort Plus Version Electronics] Pos : 85.70 /Ü bersc hriften/Ü berschriften 1/P-T/T ermi nal – Mas chi nenfunktionen [M edi um Plus-/Komfort- Plus El ektr oni k] @ 430\mod_1455534645155_78.doc x @ 2968456 @ 1 @ 1 Terminal - Machine Functions [Medium Plus/Comfort Plus Version Electronics] Pos : 85.71 /Ü...

  • Page 160: Terminal - Menus [Medium/Comfort Version Electronics]

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.73 /Ü bersc hriften/Ü berschriften 1/P-T/T ermi nal – Menüs [M edi um-/Komfort-El ektr oni k] @ 429\mod_1455523174603_78.doc x @ 2967046 @ 1 @ 1 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.74 /Ü bersc hriften/Ü berschriften 2/K-O/M /Menüstruktur @ 134\mod_1350884165998_78.doc x @ 1191201 @ 2 @ 1 16.1 Menu Structure Pos : 85.75 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/M enüebene Kurzüberblic k M asc hine H S Baurei he @ 353\mod_1437725386814_78.doc x @ 2641207 @ @ 1...
  • Page 161 Terminal – Menus [Medium/Comfort Version Electronics] Main menu Sub-menu Designation ISOBUS settings 14-1 Auxiliary diagnostics (AUX) 14-2 Diagnostics for driving speed / direction indicator 14-8 Configure main window 14-9 Switching between terminals Settings 15-1 Sensor test 15-2 Actuator test 15-5 Software info 15-6 Technician level...

  • Page 162: Recurring Icons

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.77 /Ü bersc hriften/Ü berschriften 2/U-Z/W/Wi eder kehr ende Symbole @ 376\mod_1443009322459_78.doc x @ 2734658 @ 2 @ 1 16.2 Recurring Icons Pos : 85.78 /BA/Info-Center/CCI-ISOBU S-Ter minal/M enüs bedi enenWieder kehrende Symbol e T abelle @ 354\mod_1438068777770_78.doc x @ 2642945 @ @ 1 Symbol Designation Explanation...

  • Page 163: Calling Up The Menu Level

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.80 /Ü bersc hriften/Ü berschriften 2/K-O/M /Menüebene aufr ufen @ 386\mod_1444828720930_78.doc x @ 2765055 @ 2 @ 1 16.3 Calling up the menu level Pos : 85.81 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/M enüebene aufr ufen Bild HS Baur eihe @ 354\mod_1438148451988_78.doc x @ 2644045 @ @ 1 CC000095 CC000096 Fig.

  • Page 164: Changing The Value

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.86 /Ü bersc hriften/Ü berschriften 2/U-Z/W/Wert ändern_T ermi nal @ 381\mod_1444052936020_78.doc x @ 2750606 @ 2 @ 1 16.4 Changing the value Pos : 85.87 /BA/Info-Center/CCI-ISOBU S-Ter minal/M enüs bedi enen/Wer t änder n_dr ei Möglichkeiten @ 354\mod_1438077699197_78.doc x @ 2642977 @ @ 1 Values must be entered or changed for the settings in the menus.

  • Page 165: Changing Mode

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.92 /Ü bersc hriften/Ü berschriften 2/K-O/M /Modus änder n @ 377\mod_1443010974904_78.doc x @ 2734998 @ 2 @ 1 16.5 Changing mode Pos : 85.93 /BA/Info-Center/CCI-ISOBU S-Ter minal/M enüs bedi enen/M odus ändern_T ext @ 354\mod_1438090569459_78.doc x @ 2643517 @ @ 1 It is possible to select between different modes in individual menus.

  • Page 166: Menu 1 "Knotter

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.95 /Ü bersc hriften/Ü berschriften 2/K-O/M /Menü 1 „Knoter“ @ 381\mod_1444114538493_78.doc x @ 2751651 @ 2 @ 1 16.6 Menu 1 "Knotter" Pos : 85.96 /BA/Info-Center/CCI-ISOBU S-Ter minal/CCI- BiG Pac k/H auptmenüs /Hauptmenü 1 Eins tell ung en/M enü 1 „Knoter“ Bild @ 381\mod_1444116045474_78.doc x @ 2751682 @ @ 1 CC000095 CC000097 Fig.

  • Page 167: Menu 1-1 "Correction Value For Bale Length

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.100 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 1-1 „Korrektur wer t Ballenlänge“ @ 381\mod_1444116959866_78.doc x @ 2751834 @ 3 @ 1 16.6.1 Menu 1-1 "Correction value for bale length" Pos : 85.101 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 1 Ei nstellungen/M enü 1-1 „Korrektur wert Ballenlänge“ Einführung @ 381\mod_1444117027238_78.doc x @ 2751865 @ @ 1 Because of the different properties of materials (e.g.

  • Page 168: Menu 1-2 "Knotter Signal

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.108 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 1-2 "Knotersig nal" @ 381\mod_1444113549263_78.doc x @ 2751246 @ 3 @ 1 16.6.2 Menu 1-2 "Knotter signal" Pos : 85.109 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 1 Ei nstellungen/M enü 1-2 "Knotersignal" Einführung @ 381\mod_1444113607344_78.doc x @ 2751437 @ @ 1 This menu can be used to set whether an acoustic signal is to sound after a knot is tied.

  • Page 169: Menu 1-3 "Knotter Monitoring

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.116 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 1-3 „Knoter kontroll e“ @ 355\mod_1438335972546_78.doc x @ 2648825 @ 3 @ 1 16.6.3 Menu 1-3 "Knotter monitoring" Pos : 85.117 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 1 Ei nstellungen/M enü 1-1- 3 „Knoter kontr olle“ N ur bei Ausführ ung Komfort- Elektroni k s erienmäßig @ 281\mod_1405936615345_78.doc x @ 2160829 @ @ 1 Fitted as standard only on the Comfort version electronics.

  • Page 170: Menu 1-4 "Blow Interval

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.125 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 1-4 „Bl asinter vall“ @ 381\mod_1444112021767_78.doc x @ 2751062 @ 3 @ 1 16.6.4 Menu 1-4 "Blow interval" Pos : 85.126 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 1 Ei nstellungen/M enü 1-4 „Blasinter vall“ Einführung @ 381\mod_1444112197694_78.doc x @ 2751184 @ @ 1 This menu can be used to set after how many bales the knotters are cleared ("blown free") of dust and accumulation of crops by compressed air.

  • Page 171: Menu 1-5 "Blowing Time

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.133 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 1-5 „Bl asz eit“ @ 382\mod_1444119526959_78.doc x @ 2751958 @ 3 @ 1 16.6.5 Menu 1-5 "Blowing time" Pos : 85.134 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 1 Ei nstellungen/M enü 1-5 „Blaszei t“ Ei nführ ung @ 382\mod_1444119716398_78.doc x @ 2752020 @ @ 1 This menu can be used to set how long the knotters are blown.

  • Page 172: Menu 2 "Sensitivity Of Direction Indicator

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.141 /Ü bers chriften/Ü bersc hriften 2/K- O/M/M enü 2 „ Empfindlichkeit Ric htungsanz eiger“ @ 382\mod_1444120979674_78.doc x @ 2752113 @ 2 @ 1 16.7 Menu 2 "Sensitivity of direction indicator" Pos : 85.142 /BA/Info-C enter /ALLE T er minals i n einem - ISOBU S, D elta, BET A II ( ab BJ 15/16)/ALLE T er minals/R undball enpressenM enü xxx Empfi ndlichkeit Ric htungsanz eige_Einl eitung _ALL E T er minals_R P_LW_BP @ 402\mod_1448017823971_78.doc x @ 2852699 @ @ 1 The sensitivity of direction display is set in this menu.

  • Page 173: Menu 3 "Central Lubrication

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.148 /Ü bers chriften/Ü bersc hriften 2/K- O/M/M enü 3 „Z entralsc hmier ung“ @ 382\mod_1444122212068_78.doc x @ 2752309 @ 2 @ 1 16.8 Menu 3 "Central lubrication" Pos : 85.149 /Ü bers chriften/Z wisc henübersc hriften/A- E/Bei Ausführ ung Z entralsc hmi erung @ 382\mod_1444123271260_78.doc x @ 2752411 @ @ 1 For the central lubrication version Pos : 85.150 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü...

  • Page 174: Menu 4 "Bale Scales

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.158 /Ü bers chriften/Ü bersc hriften 2/K- O/M/M enü 4 „ Ball enwaage“ @ 382\mod_1444124344733_78.doc x @ 2752442 @ 2 @ 1 16.9 Menu 4 "Bale scales" Pos : 85.159 /Ü bers chriften/Z wisc henübersc hriften/A- E/Bei Ausführ ung Ball enwaage @ 281\mod_1405595676259_78.doc x @ 2157509 @ @ 1 For the bale scales version Pos : 85.160 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü...
  • Page 175 Note If the limit range is not reached to adjust the bale scales, contact KRONE customer service. Pos : 85.167 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 1 Ei nstellungen/M enü 4 „ Ball enwaag e“ T 3_Ball enwaage nullen @ 377 \mod_1443102798739_78.doc x @ 2736198 @ @ 1...

  • Page 176: Menu 5 "Moisture Measurement

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.169 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 1 Ei nstellungen/M enü 5 „F euchtemess ung“ @ 368\mod_1441626012816_78.doc x @ 2699393 @ 2 @ 1 16.10 Menu 5 "Moisture measurement" CC000099 CC000095 Fig.

  • Page 177: Menu 5-1 "Alarm Message For Moisture Measurement

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.171 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 5-1 „Al armmeldung für Feuc htemes sung“ @ 386\mod_1444839629626_78.doc x @ 2766712 @ 3 @ 1 16.10.1 Menu 5-1 "Alarm message for moisture measurement" Pos : 85.172 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü...

  • Page 178: Menu 5-2 "Correction Value For Moisture Measurement

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.179 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 1 Ei nstellungen/M enü 5-2 „Korrektur wert für F euc htemessung“ @ 368\mod_1441633971850_78.doc x @ 2700221 @ 3 @ 1 16.10.2 Menu 5-2 "Correction value for moisture measurement"...

  • Page 179: Menu 6 "Silage Additive System

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.182 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 1 Ei nstellungen/M enü 6 " Silier mittelanlag e" @ 371\mod_1442224319600_78.doc x @ 2712842 @ 2 @ 1 16.11 Menu 6 "Silage additive system" CC000424_3 CC000098 Fig.

  • Page 180: Menu 13 "Counters

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.186 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 2/Menü 13 Zähler @ 371\mod_1442223994230_78.doc x @ 2712815 @ 2 @ 1 16.12 Menu 13 "Counters" CC000944 CC000095 Fig. 120 The menu level has been selected, see chapter Terminal – Menus, "Selecting menu level". •...

  • Page 181: Menu 13-1 "Customer Counter

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.188 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 2/Kundenzähler /Menü 13-1 Kundenzähler @ 371\mod_1442230532437_78.doc x @ 2713309 @ 3 @ 1 16.12.1 Menu 13-1 "Customer counter" 13-1 Name 01 Name 02 Name 03 CC000560_2...
  • Page 182 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.192 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 2/Kundenzähler /Menü 13-1 Kundenzähler zur üc ks etz en/akti vier en BiG PAC K @ 372\mod_1442233249378_78.doc x @ 2713751 @ @ 1 Keys Symbol Designation...

  • Page 183: Menu 13-1 Selecting Detail Counter/Customer Counter

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.196 /Ü bers chriften/Ü bersc hriften 4/A- E/M enü 13- 1 D etailzähler /Kundenz ähler aufrufen @ 372\mod_1442235870371_78.doc x @ 2714012 @ 4 @ 1 16.12.1.1 Menu 13-1 Selecting detail counter/customer counter Pos : 85.197 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü...
  • Page 184 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.201 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 2/Detailz ähler/M enü 13-1 D etailzähler Besc hrei bung T asten Bi G PAC K @ 372\mod_1442295528245_78.doc x @ 2714785 @ @ 1 Keys Symbol Designation...
  • Page 185 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.206 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 2/Detailz ähler/Ball enanzahl ändern @ 372\mod_1442297567641_78.doc x @ 2714893 @ @ 1 Changing the number of bales • Press until the customer counter has been selected. The selected customer counter does not have to be activated.

  • Page 186: Menu 13-2 "Total Counter

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.208 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 2/Menü 13- 2 „Ges amtz ähl er“ @ 372\mod_1442300043683_78.doc x @ 2714985 @ 3 @ 1 16.12.2 Menu 13-2 "Total counter" 13-2 CC000038_2 CC000944...
  • Page 187 Terminal – Menus [Medium/Comfort Version Electronics] Recurring symbols • See chapter Terminal – Menus, "Recurring symbols". Pos : 85.211 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 2/Sais onz ähler z urüc ks etz en @ 372\mod_1442304881886_78.doc x @ 2715356 @ @ 1 Resetting season counter 1 •...

  • Page 188: Menu 14 "Isobus Settings

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.213 /Ü bers chriften/Ü bersc hriften 2/K- O/M/M enü 14 „ISOBUS- Eins tellungen“ @ 372\mod_1442311218372_78.doc x @ 2715613 @ 2 @ 1 16.13 Menu 14 "ISOBUS settings" Pos : 85.214 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/M enü 14 ISOBU S-Einstellungen/Menü 14 „ISOBU S-Ei nstellungen“ @ 372\mod_1442307451823_78.doc x @ 2715583 @ @ 1 The menu level has been selected, see chapter Terminal –...

  • Page 189: Menu 14-2 "Diagnostics For Driving Speed / Direction Indicator

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.220 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 14-2 „Di agnose Fahrgesc hwi ndig kei t/Ric htungs anz eiger“ @ 372\mod_1442317923396_78.doc x @ 2715845 @ 3 @ 1 16.13.2 Menu 14-2 "Diagnostics for driving speed / direction indicator" Pos : 85.221 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/M enü...

  • Page 190: Menu 14-8 "Configuring Main Window

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.224 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 14-8 „H auptfenster konfigurier en" @ 372\mod_1442322982265_78.doc x @ 2716359 @ 3 @ 1 16.13.3 Menu 14-8 "Configuring main window" Pos : 85.225 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/M enü 14 ISOBU S-Einstellungen/Menü 14- 8 „Hauptfenster konfigurieren“_T ext @ 372\mod_1442323596600_78.doc x @ 2716490 @ @ 1 This menu can be used to set the information which is to be displayed in the left column of the main window.
  • Page 191 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.229 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/M enü 14 ISOBU S-Einstellungen/Menü 14- 8 „Hauptfenster konfigurieren“_Konfig urieren @ 373\mod_1442326938902_78.doc x @ 2716921 @ @ 1 Configuring • To select the page to be configured, press •...
  • Page 192 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.232 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/Gr undbild H andbetrieb/Anz eigen i m H auptfens ter/Anzeigen i m H auptfens ter ( III) li nke Spalte HS Baur eihe T 2 @ 351\mod_1436882893725_78.doc x @ 2631110 @ @ 1 Symbol Designation Explanation...

  • Page 193: Menu 14-9 "Switching Between The Terminals

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.234 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 14-9 „U msc halten z wischen T ermi nals" @ 359\mod_1439218022535_78.doc x @ 2663609 @ 3 @ 1 16.13.4 Menu 14-9 “Switching Between the Terminals” Pos : 85.235 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/M enü...

  • Page 194: Menu 15 "Settings

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.238 /Ü bers chriften/Ü bersc hriften 2/K- O/M/M enü 15 „Ei nstellungen“ @ 373\mod_1442388879194_78.doc x @ 2717596 @ 2 @ 1 16.14 Menu 15 "Settings" Pos : 85.239 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/M enü 15 „ Einstellungen“/M enü 15 „Ei nstellungen“_Bild @ 373\mod_1442389332656_78.doc x @ 2717698 @ @ 1 CC000098 CC000095 Fig.

  • Page 195: Menu 15-1 "Sensor Test

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.243 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 15-1 " Sens ortest" @ 360\mod_1439362477074_78.doc x @ 2665635 @ 3 @ 1 16.14.1 Menu 15-1 “Sensor Test” Pos : 85.244 /BA/Sic her hei t/2. Vor ang estellte War nhi nweis e/Warnung - Verletzungsgefahr im Gefahr enbereic h der M asc hi ne @ 382\mod_1444196164466_78.doc x @ 2753635 @ @ 1 WARNING! Risk of injury in the danger zone of the machine If the PTO shaft is running during the sensor test, machine parts may start moving...
  • Page 196 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.248 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/M enü 15 „ Einstellungen“/M enü 15-1 „ Sens ortest“_Sens or testen @ 373\mod_1442402129767_78.doc x @ 2718294 @ @ 1 Testing sensor • To test a sensor, press on the sensor symbol.
  • Page 197 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.251 /Ü bers chriften/Z wisc henübersc hriften/K-OM ögliche Sens oren (je nac h Aus stattung der Maschi ne) @ 19\mod_1238071336628_78.doc x @ 214010 @ @ 1 Possible sensors (depending on how the machine is equipped) Pos : 85.252 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü...
  • Page 198 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.254 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 4 Ser vic e/Auflis tung der möglichen Sens or en 20 bis 38_Bi G Pac k @ 373\mod_1442405445828_78.doc x @ 2718411 @ @ 1 Sensor Designation Explanation...
  • Page 199 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.258 /BA/Info-C enter /Sensor en/Status anzeigen/Status digital e Sens oren (1,2,3,4) far big_Bi G Pac k @ 373\mod_1442407658630_78.doc x @ 2718628 @ @ 1 Status digital sensors Symbol Status (state) Alive (iron) Not alive (no iron) Cable break Short circuit...
  • Page 200 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.262 /Ü bers chriften/Z wisc henübersc hriften/A- E/Diag nos e Tas ter @ 387\mod_1445266022139_78.doc x @ 2775136 @ @ 1 Diagnostics pushbutton Pos : 85.263 /BA/Info-C enter /Großpac kenpresse/Hauptmenüs/H auptmenü 4 Ser vice/Diag nos e T aster _Bild und T ext_Bi G Pac k @ 387\mod_1445262307519_78.doc x @ 2775105 @ @ 1 CC000951 Fig.
  • Page 201 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.266 /Ü bers chriften/Z wisc henübersc hriften/A- E/Diag nos e Versorgungsspannung @ 377\mod_1443017844161_78.doc x @ 2735431 @ @ 1 Diagnostics supply voltages Pos : 85.267 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 4 Ser vic e/Diag nos e Versorgungsspannungen_BP_Bil d @ 377\mod_1443017366514_78.doc x @ 2735400 @ @ 1 Fig.

  • Page 202: Checking/Adjusting Sensor B22 "Bale On Chute

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.270 /Ü bers chriften/Ü bersc hriften 4/P-T /Sensor B22 „ Ball en auf Sc hurre“ pr üfen/ei nstellen @ 395\mod_1446619855318_78.doc x @ 2815361 @ 4 @ 1 16.14.1.1 Checking/adjusting sensor B22 "Bale on chute" Pos : 85.271 /BA/Ei nstellungen/Gr oß...
  • Page 203 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.274 /BA/Ei nstellungen/Gr oß pac kenpr ess e/Sens or B22 prüfen/eins tellen_Teil 2 @ 395\mod_1446627847774_78.doc x @ 2815745 @ @ 1 BPHS0326_1 Fig. 134 • Continue pressing the bale (2) until it has exited the bale channel (1) completely. The signal sheet (3) covers the sensor (4) fully.

  • Page 204: Setting Sensor B38 "Acceleration Sensor

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.276 /BA/Info-C enter /Großpac kenpresse/Hauptmenüs/H auptmenü 4 Ser vice/Sensor B38 "Besc hleunigungss ensor" einstellen_für H S Baurei he @ 373 \mod_1442409429719_78.doc x @ 2718901 @ 4 @ 1 16.14.1.2 Setting sensor B38 "Acceleration sensor" CC000949 Fig.

  • Page 205: Setting Sensor B55 "Bale Chute At Rear"/Sensor B56 "Bale Chute At Front

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.278 /BA/Info-C enter /Großpac kenpresse/Hauptmenüs/H auptmenü 4 Ser vice/Sensor B55/56 " Ball enschurre hi nten/vor ne" ei nstellen_BiG Pac k @ 374\mod_1442413542284_78.doc x @ 2719305 @ 4 @ 1 16.14.1.3 Setting sensor B55 "Bale chute at rear"/sensor B56 "Bale chute at front" CC000950 Fig.

  • Page 206: Menu 15-2 "Actuator Test

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.280 /Ü bers chriften/Ü bersc hriften 3/K- O/M/M enü 15-2 " Aktortest" @ 360\mod_1439362622356_78.doc x @ 2665666 @ 3 @ 1 16.14.2 Menu 15-2 “Actuator Test” Pos : 85.281 /BA/Sic her hei t/7. Gefahrenhinweise alt/WARNUN G - Aktortest @ 301\mod_1413441650591_78.doc x @ 2349581 @ @ 1 WARNING! The functions are directly executed by energizing the actuators.
  • Page 207 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.288 /Ü bers chriften/Z wisc henübersc hriften/K-O/Möglic he digital e Aktoren (j e nac h Ausstattung der Maschi ne) @ 361\mod_1439386355353_78.doc x @ 2667113 @ @ 1 Possible digital actuators (depending on how the machine is equipped) Pos : 85.289 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü...
  • Page 208 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.291 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 4 Ser vic e/Auflis tung der möglichen digital en Aktor en z usätzlich für HS BAur eihe @ 374\mod_1442479538782_78.doc x @ 2720562 @ @ 1 Actuator Designation Explanation...
  • Page 209 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.296 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 4 Ser vic e/Diag nos e anal oge Aktoren_HS Baur eihe @ 374\mod_1442483850121_78.doc x @ 2721121 @ @ 1 Diagnostics of analogue actuators 15-2 PWM: CC000047_1...

  • Page 210: Menu 15-5 "Software Info

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.299 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 5 Info/M enü 15- 5 Software-Info H S Baurei he @ 374\mod_1442489686905_78.doc x @ 2721348 @ 3 @ 1 16.14.3 Menu 15-5 "Software info" CC000081_1 CC000098 Fig.

  • Page 211: Menu 15-6 "Technician Level

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.302 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/H auptmenü 6 Monteur/Menü 15- 6 "Monteurebene" @ 374\mod_1442491625095_78.doc x @ 2721498 @ 3 @ 1 16.14.4 Menu 15-6 "Technician level" 15-6 0000 054536 CC000098 CC000052_1...

  • Page 212: Alarm Messages

    For possible causes and how to remedy them, refer to chapter entitled “Alarm Messages”. • In case the malfunction cannot be remedied, contact KRONE customer service. Pos : 85.307 /BA/Info-C enter /CCI-ISOBUS-T ermi nal/CCI-Bi G Pac k/H auptmenüs/Alar mmeldungenAlar meldung allgemein @ 404\mod_1449052332566_78.doc x @ 2870296 @ @ 1 CC000053_2 Fig.

  • Page 213: Alarms

    KRONE measurement force measurement force computer computer (KMV1) is interrupted. (KMV1). – The CAN wiring is defective. – The KRONE measurement force computer is inactive. A12/512 – The CAN connection between • Check the CAN wiring. the job computer and the •...
  • Page 214 High A17/517 – The CAN connection between • Check the CAN wiring. the job computer and the • Replace the KRONE moisture KRONE measurement force measurement computer (RMC). computer (KMV2) is interrupted. – The CAN wiring is defective. – The KRONE moisture measurement computer is inactive.

  • Page 215: Logical Alarms

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.315 /Ü bers chriften/Ü bersc hriften 3/K- O/L/Logisc he Al arme @ 185\mod_1379419186279_78.doc x @ 1594483 @ 3 @ 1 16.15.2 Logical Alarms Pos : 85.316 /BA/Info-C enter /Großpac kenpresse/Hauptmenüs/Alar mmeldung en/2) Alar mmeldung en Tabelle allgemein 0 - 9 @ 374\mod_1442555491388_78.doc x @ 2723075 @ @ 1 No./symbol Possible cause Remedy...
  • Page 216 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.318 /BA/Info-C enter /Großpac kenpresse/Hauptmenüs/Alar mmeldung en/3) Alar mmeldung en Tabelle allgemein 10-37 H S Baurei he @ 375\mod_1442566333047_78.doc x @ 2724112 @ @ 1 No./symbol Possible cause Remedy – Error on the pressure limiting •...
  • Page 217 Terminal – Menus [Medium/Comfort Version Electronics] No./symbol Possible cause Remedy – The 2 positions of the MultiBale • Correctly set the sensor. or total bales cannot be set. • Check the mechanism in the – The "MultiBale" sensor has been area of the knotter triggering.
  • Page 218 Terminal – Menus [Medium/Comfort Version Electronics] No./symbol Possible cause Remedy – The axle is not locked. • Check the hydraulic connection. – The "Lock axle" sensor is • Check the sensor and replace if defective. required. – The knotter 7 or 8 is not •...

  • Page 219: Physical Alarms

    Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.320 /Ü bers chriften/Ü bersc hriften 3/P-T /P/Physi kalische Alar me @ 185\mod_1379419277093_78.doc x @ 1594521 @ 3 @ 1 16.15.3 Physical Alarms Pos : 85.321 /BA/Info-C enter /Großpac kenpresse/Hauptmenüs/Alar mmeldung en/4) Alar mmeldung en Tabelle allgemein 101- 113 @ 376\mod_1442909996093_78.doc x @ 2729961 @ @ 1 No./symbol Sensor Possible cause...
  • Page 220 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.323 /BA/Info-C enter /Großpac kenpresse/Hauptmenüs/Alar mmeldung en/5) Alar mmeldung en Tabelle allgemein 114- 125 H S Baurei he @ 368\mod_1441704802571_78.doc x @ 2701745 @ @ 1 No./symbol Sensor Possible cause Remedy Hydraulic –...
  • Page 221 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.325 /BA/Info-C enter /Großpac kenpresse/Hauptmenüs/Alar mmeldung en/6) Alar mmeldung en Tabelle allgemein 126- 138 H S Baurei he @ 376\mod_1442927078877_78.doc x @ 2732991 @ @ 1 No./symbol Sensor Possible cause Remedy Knotter 1 Knotter 2 Knotter 3 Knotter 4...
  • Page 222 Terminal – Menus [Medium/Comfort Version Electronics] Pos : 85.327 /BA/Info-C enter /Großpac kenpresse/Hauptmenüs/Alar mmeldung en/7) Alar mmeldung en Tabelle allgemein 139- 157 H S Baurei he @ 376\mod_1442930223401_78.doc x @ 2733022 @ @ 1 No./symbol Sensor Possible cause Remedy Twine box on right in transport position Twine box on...

  • Page 223: Terminal - Menus [Medium Plus/Comfort Plus Version Electronics]

    Terminal - Menus [Medium Plus/Comfort Plus Version Electronics] Pos : 85.329 /Ü bers chriften/Ü bersc hriften 1/P-T /Ter minal – M enüs [Medi um Pl us-/Komfort Pl us-El ektr oni k] @ 430\mod_1455534747796_78.doc x @ 2968517 @ 1 @ 1 Terminal - Menus [Medium Plus/Comfort Plus Version Electronics] Pos : 85.330 /Ü...

  • Page 224: Operation

    Operation Pos : 87 /Layout M odul e /Di es e Seite ist bewusst freig elass en worden. @ 1 \mod_1201783680373_78.doc x @ 54443 @ @ 1 Pos : 89.1 /Übersc hriften/Übersc hriften 1/A-E/Bedienung @ 0\mod_1199789505403_78.doc x @ 34825 @ 1 @ 1 Operation Pos : 89.2 /BA/Sicher heit/2.
  • Page 225 Operation Pos : 89.7 /BA/Bedi enung /Gr oßpac kenpr ess e/Mit dem Pr ess en beginnen / nac h dem Press en @ 166\mod_1367223499536_78.doc x @ 1441233 @ @ 1 Starting baling Prerequisite: – The conditions mentioned in “Preparation for Baling” and “Before starting baling, check to make certain ...”...

  • Page 226: Tying Unit

    Operation Pos : 89.9 /Übersc hriften/Übersc hriften 2/A-E/BBindeei nrichtung @ 20\mod_1239003005331_78.doc x @ 225610 @ 2 @ 1 18.2 Tying unit Pos : 89.10 /BA/Ei nstellungen/Groß pac kenpres se/Bindegarn ei nfädel n/Bi ndegar n einl egen @ 275\mod_1404376981999_78.doc x @ 2066534 @ 3 @ 1 18.2.1 Setting the tying twine in place The process of setting the tying twine in place is identical for the left and right side of the baler.
  • Page 227 Operation Pos : 89.15.1 /Ü berschriften/Z wis chenübers chriften/K-Olinke M asc hinensei te @ 60\mod_1297934981687_78.doc x @ 562715 @ @ 1 Left-hand Side of the Machine Pos : 89.15.2 /BA/Ei nstellungen/Groß pac kenpress e/Bindegarn ei nfädel n/Bi ndeeinric htung 6 D oppel knoter/Bindeg arn ver binden allge meine Besc hr eibung 6 D oppel knoter @ 175\mod_1372829465941_78.doc x @ 1504555 @ @ 1 Connecting twine Each of the front six twine rolls (1) provides three upper twines.
  • Page 228 Operation Pos : 89.15.9 /BA/Ei nstellungen/Groß pac kenpress e/Bindegarn ei nfädel n/U nter faden ver binden ( 2) @ 154\mod_1363266953393_78.doc x @ 1367551 @ @ 1 Connecting lower twine (2) Pos : 89.15.10 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Bindeg arn einfädeln/Bi ndeei nrichtung 6 Doppel knoter/Bi deg arn ver binden i m Garnkasten6 D oppel knoter Bild 16 R ollen 3 Ober-/ U nterfäden @ 208\mod_1386927926341_78.doc x @ 1720302 @ @ 1 Fig.
  • Page 229 Operation Pos : 89.15.14 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Bindeg arn einfädeln/Bi ndeei nrichtung 6 Doppel knoter/Garnr ollen U nterfaden ver binden 3a, 3b und 3c ( 3 U nterfäden) @ 208\mod_1386931126571_78.doc x @ 1720479 @ @ 1 Connecting twine rolls 3a, 3b, and 3c with each other Guide the beginning of the twine of twine roll (3a) over the red eye above through the twine brake out of the twine box.

  • Page 230: Threading In The Lower Twine

    Operation Pos : 89.15.17 /Ü bersc hriften/Ü bersc hriften 3/U-Z/U nterfaden ei nfädeln @ 154\mod_1363274391674_78.doc x @ 1369094 @ 3 @ 1 18.2.2 Threading in the Lower Twine Pos : 89.15.18 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Bindeg arn einfädeln/Unterfaden vom Gar nkasten zur unteren Gar nführung weiter führen. @ 154\mod_1363274502562_78.doc x @ 1369122 @ @ 1 Then guide the lower twine from the twine box to the lower twine guide.

  • Page 231: Threading In The Upper Twine

    Operation Pos : 89.15.25 /Ü bersc hriften/Ü bersc hriften 3/K- O/OOberfaden einfädel n @ 154\mod_1363276173731_78.doc x @ 1369401 @ 3 @ 1 18.2.3 Threading in the Upper Twine Pos : 89.15.26 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Bindeg arn einfädeln/Oberfaden vom Gar nkasten zur ober en Garnführung weiterführen @ 154\mod_1363276378790_78.doc x @ 1369487 @ @ 1 Then guide the upper twine from the twine box to the upper twine guide.
  • Page 232 Operation Pos : 89.15.32 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Bindeg arn einfädeln/Oberfaden einfädeln Bild 3 @ 155\mod_1363329246968_78.doc x @ 1369890 @ @ 1 BPHS0127 Fig. 150 Pos : 89.15.33 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Bindeg arn einfädeln/Oberfaden einfädeln T 3 @ 155\mod_1363329332881_78.doc x @ 1369919 @ @ 1 •...
  • Page 233 Operation Pos : 89.17.1 /Ü berschriften/Z wis chenübers chriften/P-Trec hte Maschi nens eite @ 60\mod_1297935179130_78.doc x @ 562741 @ @ 1 Right-hand Side of the Machine Pos : 89.17.2 /BA/Ei nstellungen/Groß pac kenpress e/Bindegarn ei nfädel n/Bi ndeeinric htung 4 D oppel knoter 890 H S/Bindegarn ver binden allgemeine Bes chr eibung 4 D oppel knoter @ 191\mod_1381844742544_78.doc x @ 1632370 @ @ 1 Connecting twine Each of the front four twine rolls (1) provides two upper twines.
  • Page 234 Operation Pos : 89.17.8 /BA/Ei nstellungen/Groß pac kenpress e/Bindegarn ei nfädel n/U nter faden ver binden ( 2) @ 154\mod_1363266953393_78.doc x @ 1367551 @ @ 1 Connecting lower twine (2) Pos : 89.17.9 /BA/Ei nstellungen/Groß pac kenpress e/Bindegarn ei nfädel n/Bi ndeeinric htung 5 D oppel knoter 870 HD P/Bidegar n verbi nden i m Garnkas ten 5 D oppel knoter Bild 16 R ollen 2 Ober-/ Unterfäden r ec hte Seite @ 270\mod_1402489906275_78.doc x @ 2039830 @ @ 1 Fig.

  • Page 235: Threading In The Lower Twine

    Operation Pos : 89.17.14 /Ü bersc hriften/Ü bersc hriften 3/U-Z/U nterfaden ei nfädeln @ 154\mod_1363274391674_78.doc x @ 1369094 @ 3 @ 1 18.2.4 Threading in the Lower Twine Pos : 89.17.15 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Bindeg arn einfädeln/Unterfaden vom Gar nkasten zur unteren Gar nführung weiterführen. @ 154 \mod_1363274502562_78.doc x @ 1369122 @ @ 1 Then guide the lower twine from the twine box to the lower twine guide.

  • Page 236: Threading In The Upper Twine

    Operation Pos : 89.17.22 /Ü bersc hriften/Ü bersc hriften 3/K- O/OOberfaden einfädel n @ 154\mod_1363276173731_78.doc x @ 1369401 @ 3 @ 1 18.2.5 Threading in the Upper Twine Pos : 89.17.23 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Bindeg arn einfädeln/Oberfaden vom Gar nkasten zur ober en Garnführung weiterführen @ 154\mod_1363276378790_78.doc x @ 1369487 @ @ 1 Then guide the upper twine from the twine box to the upper twine guide.
  • Page 237 Operation Pos : 89.17.29 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Bindeg arn einfädeln/Oberfaden einfädeln Bild 3 @ 155\mod_1363329246968_78.doc x @ 1369890 @ @ 1 BPHS0127 Fig. 156 Pos : 89.17.30 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Bindeg arn einfädeln/Oberfaden einfädeln T 3 @ 155\mod_1363329332881_78.doc x @ 1369919 @ @ 1 •...

  • Page 238: Pick-Up

    Operation Pos : 89.19 /Ü bersc hriften/Ü berschriften 2/P-T/PPic k up @ 1\mod_1201791975201_0.doc x @ 54586 @ 2 @ 1 18.3 Pick-up Pos : 89.20 /BA/Ers tinbetriebnahme/Groß pac kenpressen/Absperrhahn Pic k- up Bild mit Leg ende @ 155\mod_1363682181297_78.doc x @ 1373728 @ @ 1 Fig.

  • Page 239: Lifting / Lowering Bale Chute

    Operation Pos : 89.25.1 /Ü berschriften/Ü berschriften 2/A-E/BBallensc hurre heben / s enken @ 280\mod_1405498834845_78.doc x @ 2154218 @ 2 @ 1 18.4 Lifting / Lowering Bale Chute Pos : 89.25.2 /BA/Sic herheit/2. Vorangestellte Warnhinweise/War nung - Verletz ungsgefahr, wenn bei laufendem Tr aktormotor F unktionen dir ekt an der M asc hine ausge @ 274\mod_1404304877568_78.doc x @ 2064063 @ @ 1 WARNING! There is an increased risk of injury if functions are performed directly at the machine while the tractor engine is running.

  • Page 240: Comfort Version Electronics Design

    Operation 18.4.2 Comfort Version Electronics Design Pos : 89.25.8 /BA/Bedienung /Groß pac kenpres se/H ydr aulisc h kl appbare R ollensc hurreBedienung R ollenschurre heben/s enken ( bei Ausführ ung Komfort) Bi G PAC K 890/1270/1290 HS Text @ 356\mod_1438686506814_78.doc x @ 2652774 @ @ 1 Using the terminal BPHS0138 Fig.

  • Page 241: Operating Bale Ejector

    Operation Pos : 89.27 /Ü bersc hriften/Ü berschriften 2/A-E/BBallenaussc hieber bedi enen @ 168\mod_1368535471051_78.doc x @ 1458201 @ 2 @ 1 18.5 Operating Bale Ejector Pos : 89.28 /BA/Sic herheit/2. Voranges tellte Warnhinweise/War nung - Verletz ungsgefahr, wenn bei laufendem Tr aktor motor F unkti onen dir ekt an der M asc hine ausge @ 274\mod_1404304877568_78.doc x @ 2064063 @ @ 1 WARNING! There is an increased risk of injury if functions are performed directly at the machine while the tractor engine is running.
  • Page 242 Operation Pos : 89.32 /BA/Bedienung /Groß pac kenpres se/Ballenauss chi eber/Ball enaussc hieber bedi enen, bei Ausführung Komfort T ext @ 152 \mod_1362731210093_78.doc x @ 1357385 @ @ 1 Operating the bale ejector via the operation terminal, for comfort version electronics design BPHS0138 When activating the bale ejector, 10 bales are always ejected via the terminal.

  • Page 243: Parking Jack

    Operation Pos : 89.35 /Ü bersc hriften/Ü berschriften 2/P-T/SStütz fuß @ 175\mod_1372676754261_78.doc x @ 1502329 @ 2 @ 1 18.6 Parking Jack Pos : 89.36 /BA/Ers tinbetriebnahme/Groß pac kenpressen/Abstellstütz eAbstellstütz e Standfl äc he vergröß ern_Hinweis @ 302\mod_1413968281921_78.doc x @ 2353503 @ @ 1 Note In order to increase the base of the support jack when the ground is soft, use a suitable support.

  • Page 244: Hydraulic Parking Jack

    Operation Pos : 89.41 /Ü bersc hriften/Ü berschriften 2/F-J /HH ydr aulisc her Stützfuß @ 108\mod_1335163952883_78.doc x @ 972995 @ 2 @ 1 18.7 Hydraulic parking jack Pos : 89.42 /BA/Ers tinbetriebnahme/Groß pac kenpressen/Abstellstütz eAbstellstütz e Standfl äc he vergröß ern_Hinweis @ 302\mod_1413968281921_78.doc x @ 2353503 @ @ 1 Note In order to increase the base of the support jack when the ground is soft, use a suitable support.

  • Page 245: Bale Brake

    Operation Pos : 89.50 /BA/Bedienung /Groß pac kenpres se/Ballenbr ems eBallenbr emse @ 312 \mod_1420639624347_78.doc x @ 2410255 @ 2 @ 1 18.8 Bale Brake Only in combination with bale scale BPHS0068 Fig. 166 The first two rolls of the bale chute are locked via bale brake (1). This is necessary to reach an exact weight control of the bales.

  • Page 246: Working Floodlight

    Operation Pos : 89.52 /Ü bersc hriften/Ü berschriften 2/A-E/A/Arbeitss cheinwerfer @ 324\mod_1425455750068_78.doc x @ 2492101 @ 2 @ 1 18.9 Working floodlight Pos : 89.53 /BA/Inbetri ebnahme/Groß pac kenpress e/Arbeitss cheinwerfer HS Baureihe_Text @ 324\mod_1425454385072_78.doc x @ 2492001 @ @ 1 The working floodlight is switched on and off via the operating terminal.

  • Page 247: Initiating The Tying Process Manually

    Operation Pos : 89.56 /BA/Bedienung /Groß pac kenpres se/Bi ndevorgang von H and auslös en @ 170\mod_1369744285660_78.doc x @ 1468817 @ 2 @ 1 18.10 Initiating the Tying Process Manually Fig. 167 It is only necessary to trigger the tying process manually when performing maintenance, adjustment and repair tasks.

  • Page 248: Removing Blockages

    Operation Pos : 89.59 /BA/Ei nstellungen/Sc hneidwer k/Vers topfungen entfer nen Big Pac k @ 20\mod_1238654439288_78.doc x @ 224033 @ 2 @ 1 18.12 Removing blockages • Wait until all moving components stop • Apply the flywheel brake • Lower the cutting system with the tractor hydraulics (with the Comfort electronics system: Activate the tractor hydraulics and hold down “Lower blade bar”...
  • Page 249 Operation This page has been left blank deliberately!! Pos : 90 /Layout M odul e /---------------Seitenumbruc h---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 250: Settings

    Settings Pos : 93.1 /Übersc hriften/Übersc hriften 1/A-E/Ei nstellungen @ 0\mod_1199868783862_78.doc x @ 36141 @ 1 @ 1 Settings Pos : 93.2 /BA/Sicher heit/2. Vor angestellte Warnhi nweis e/WARNUNG - Nichtbeachtung der grundl egenden Sicherheits hinweis e alte F orm @ 254 \mod_1397485793575_78.doc x @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 251: Pick-Up

    Settings Pos : 93.6 /Übersc hriften/Übersc hriften 2/P-T/PPic k up @ 1\mod_1201791975201_0.doc x @ 54586 @ 2 @ 1 19.1 Pick-up Pos : 93.7 /BA/Sicher heit/Pic k- up / R ollennieder hal ter/Warnung - Ar beiten an bz w. unter der Pic k- up @ 274\mod_1404215879490_78.doc x @ 2060866 @ @ 1 WARNING! Risk of injury due to unintentional movement of the pick-up! If the pick-up is not secured by the stop cock, the pick-up may move unintentionally.

  • Page 252: Setting The Ground Pressure Of The Guide Wheels

    Settings Pos : 93.13 /Ü bersc hriften/Ü berschriften 3/A-E/A/Auflag edr uc k der Tas träder ei nstellen @ 157\mod_1364377544872_78.doc x @ 1387272 @ 3 @ 1 19.2.1 Setting the Ground Pressure of the Guide Wheels Pos : 93.14 /BA/Ei nstellunge n/Pic k-up / R ollenni ederhalter/Aufl agedruc k der T astr äder 1290 HD P II Bild Ausführ ung ohne Sc hneidwer k @ 157\mod_1364377057422_78.doc x @ 1387153 @ @ 1 Fig.

  • Page 253: Driving With Pick-Up In Fixed Position

    Settings Pos : 93.20 /Ü bersc hriften/Ü berschriften 3/F-J /FFahren mit fests tehender Pic k- up @ 71\mod_1305804535480_78.doc x @ 640896 @ 3 @ 1 19.2.2 Driving with Pick-up in fixed position Pos : 93.21 /BA/Sic herheit/8. Vorauss etz ungen/Handlungsanweisung für all e M asc hinen/Handlungsanweis ung: M asc hine stills etz en und sic hern @ 274\mod_1404365253849_78.doc x @ 2065151 @ @ 1 •...

  • Page 254: Roller Crop Guide

    Settings Pos : 93.25 /Ü bersc hriften/Ü berschriften 2/P-T/RR ollenni ederhalter @ 0\mod_1201163046930_78.doc x @ 51122 @ 2 @ 1 19.3 Roller crop guide Pos : 93.26 /BA/Sic herheit/Pic k-up / R ollenni ederhalter/War nung! - Abbau des Roll enniederhalters @ 274\mod_1404216918043_78.doc x @ 2060895 @ @ 1 WARNING! Risk of injury if the machine is used without a roller crop guide! If the machine is operated without a roller crop guide, people can be seriously injured or killed.

  • Page 255: Setting The Needles

    Settings Pos : 93.32 /BA/Ei nstellungen/Groß pac kenpres se/N adel einstell ung en/Nadelei nstellung ÜS @ 21\mod_1239103867040_78.doc x @ 229569 @ 2 @ 1 19.4 Setting the needles Pos : 93.33 /BA/Ei nstellungen/Groß pac kenpres se/N adel einstell ung en/Seitlic he Ei nstellung der N adeln ÜS @ 25\mod_1242369497056_78.doc x @ 253521 @ 3 @ 1 19.4.1 Lateral setting of the needles Pos : 93.34 /BA/Ei nstellungen/Groß...

  • Page 256: Setting The Height Of The Needles On The Knotter

    Settings Pos : 93.37 /Ü bersc hriften/Ü berschriften 3/F-J /HHöhe der N adel n am Knoter ei nstellen @ 26\mod_1245326395230_78.doc x @ 260901 @ 3 @ 1 19.4.2 Setting the height of the needles on the knotter Pos : 93.38 /BA/Ei nstellungen/Groß pac kenpres se/N adel einstell ung en/Höhe der N adel n am Knoter Bil d nur D oppel knoter @ 172\mod_1370590544056_78.doc x @ 1481262 @ @ 1 Fig.

  • Page 257: Top Dead Centre Of The Needles

    Settings Pos : 93.41 /BA/Ei nstellungen/Groß pac kenpres se/N adel einstell ung en/Ober er T otpunkt der N adeln @ 21\mod_1239093619118_78.doc x @ 228856 @ 3 @ 1 19.4.3 Top dead centre of the needles To be able to check the upper dead point of the needles, turn the needle yoke up to its highest position (dead centre point) (II).

  • Page 258: Adjusting The Multibale

    Settings Pos : 93.45.1 /Ü berschriften/Ü berschriften 2/K-O/MM ulti-Bale ei nstellen @ 272\mod_1403516170463_78.doc x @ 2050813 @ 2 @ 1 19.5 Adjusting the MultiBale Pos : 93.45.2 /BA/Ei nstellungen/Groß pac kenpress e/M uti Bal e/Position z weite N adelsc hwing e / Ansc hlag Bild @ 24 \mod_1241443960165_78.doc x @ 245076 @ @ 1 Fig.

  • Page 259: Setting The Locking (Frame)

    Settings Pos : 93.45.7 /BA/Ei nstellungen/Groß pac kenpress e/M uti Bal e/Eins tell ung Verrieg elung (Rahmen) @ 24 \mod_1241498609820_78.doc x @ 245279 @ 3 @ 1 19.5.4 Setting the locking (frame) Fig. 178 • Set the support tube (10) so that the distance between the locking (11) and the support tube (10) is Z = 15-35 mm Pos : 93.45.8 /BA/Ei nstellungen/Groß...

  • Page 260: Setting The Rubber Pad Between The Needle Yokes

    Settings Pos : 93.45.10 /BA/Ei nstellungen/Gr oßpac kenpr ess e/M utiBale/Ei nstellung Gummipuffer z wischen den N adelsc hwing en @ 24\mod_1241501934539_78.doc x @ 245332 @ 3 @ 1 19.5.6 Setting the rubber pad between the needle yokes Fig. 180 Setting the distance U By adding or removing compensation washers (16) between the rubber pad (17) and the needle yoke (18) the spacing is increased or decreased.

  • Page 261: Checking / Adjusting Position Of Needles - Baling Ram

    Settings Pos : 93.47 /BA/Ei nstellungen/Groß pac kenpres se/N adel einstell ung en/Positi on Nadeln – Preß kol ben prüfen @ 150\mod_1362057381079_78.doc x @ 1343393 @ 2 @ 1 19.6 Checking / adjusting position of needles – baling ram Fig. 181 Check: •...

  • Page 262: Checking / Setting Upper Needle

    Settings Pos : 93.49 /Ü bersc hriften/Ü berschriften 2/K-O/OObernadel prüfen / ei nstellen @ 271\mod_1402649470033_78.doc x @ 2042940 @ 2 @ 1 19.7 Checking / Setting Upper Needle Pos : 93.50 /BA/Ei nstellungen/Groß pac kenpres se/N adel einstell ung en/Ober nadel prüfen / ei nstellen Vorrauss etz ung @ 271 \mod_1402649988061_78.doc x @ 2043118 @ @ 1 Prerequisite: –...

  • Page 263: Checking / Setting Twine Bar

    Settings Pos : 93.53 /BA/Ei nstellungen/Groß pac kenpres se/Garnrieg el/Garnrieg el prüfen ei nstellen Einführtext @ 170\mod_1369723043694_78.doc x @ 1467443 @ 2 @ 1 19.8 Checking / Setting Twine Bar The twine bar moves the twine away from the needle and pushes it against the knotter hook. If the twine is not grasped by the twine bar, the knotter hook cannot pick-up the twine.

  • Page 264: Checking / Setting Twine Bar To The Channel Slot

    Settings Pos : 93.56 /BA/Ei nstellungen/Groß pac kenpres se/Garnrieg el/Garnrieg el z um Kanals chlitz pr üfen / einstellen Bi G PAC K 1290 HD P II @ 170 \mod_1369665315981_78.doc x @ 1466997 @ 2 @ 1 19.9 Checking / Setting Twine Bar to the Channel Slot Fig.
  • Page 265 Settings Pos : 93.58 /BA/Ei nstellungen/Groß pac kenpres se/Garnrieg el/Garnrieg el Ü bergriff am 2ten Knoten prüfen HD P II @ 170\mod_1369666372743_78.doc x @ 1467026 @ @ 1 Checking the overreach of the twine bars on the second knot Fig. 186 Prerequisite: –...

  • Page 266: Tensioning/Relieving The Upper Needle Shaft

    Settings Pos : 93.60 /BA/Ei nstellungen/Groß pac kenpres se/Garnrieg el/Ober nadel wellle s pannen / ents pannen BiG PACK 870 HD P b=235 mm @ 271\mod_1402655757439_78.doc x @ 2043500 @ 2 @ 1 19.10 Tensioning/relieving the upper needle shaft Fig. 187 The upper needle shaft (1) is tensioned or relieved by means of the spring (2).

  • Page 267: Tensioning/Relieving The Twine Locking Shaft

    Settings Pos : 93.62 /BA/Ei nstellungen/Groß pac kenpres se/Garnrieg el/Garnrieg el well e s pannen / entspannen Bi G PAC K 870 HD P b=285 mm @ 271\mod_1402651614865_78.doc x @ 2043322 @ 2 @ 1 19.11 Tensioning/relieving the twine locking shaft Fig.

  • Page 268: Setting The Twine Brake

    Settings Pos : 93.65 /Ü bersc hriften/Ü berschriften 2/F-J /GGar nbr emse ei nstellen @ 127\mod_1346138729566_78.doc x @ 1147164 @ 2 @ 1 19.12 Setting the Twine Brake Pos : 93.66 /BA/Ei nstellungen/Groß pac kenpres se/Garnbrems e/Gar nbr emse Bil d alle H S-T ypen auß er HD P II @ 192\mod_1382085040686_78.doc x @ 1638076 @ @ 1 Fig.

  • Page 269: Setting The Twine Tension On The Upper Twine Strand (Double Knotter)

    Settings Pos : 93.71 /BA/Ei nstellungen/Groß pac kenpres se/Garnbrems e/Gar nspannung am ober en Garns trang (Doppel knoter) @ 24 \mod_1240995388836_78.doc x @ 241628 @ 3 @ 1 19.12.1 Setting the twine tension on the upper twine strand (double knotter) Fig.

  • Page 270: Setting The Twine Tension Of The Lower Twine Strand (Double Knotter)

    Settings Pos : 93.73 /BA/Ei nstellungen/Groß pac kenpres se/Garnbrems e/Gar nspannung am unteren Gar nstrang D oppel knoter @ 24\mod_1240996666196_78.doc x @ 241703 @ 3 @ 1 19.12.2 Setting the twine tension of the lower twine strand (double knotter) Fig. 192 The twine brakes (1) for the lower twine strand are behind the packer under the bale channel chamber.

  • Page 271: Knotter

    Settings Pos : 93.75 /Ü bersc hriften/Ü berschriften 2/K-O/KKnoter @ 24\mod_1241083059412_78.doc x @ 242902 @ 2 @ 1 19.13 Knotter Pos : 93.76 /BA/Sic herheit/7. Gefahr enhinweis e alt/Groß pac kenpress e/WARNUNG - Lebensgefahr durc h ung ewolltes Auslösen der Bi ndeei nrichtung. @ 273\mod_1403694855615_78.doc x @ 2054965 @ @ 1 WARNING! Danger to life due to unintentional triggering of the twine tying device.

  • Page 272: Start-Up

    Settings Pos : 93.80 /BA/Ei nstellungen/Groß pac kenpres se/Knoter/Inbetriebnahme Knoter @ 24 \mod_1241083585365_78.doc x @ 242950 @ 3 @ 1 19.13.2 Start-up The knotter has been set and tested by the manufacturer. It should work properly without requiring any further settings. If there are problems with tying when it is placed in service for the first time, the mechanisms should not be set immediately, since this is usually caused by errors that are caused by paint, rust and bare spots.

  • Page 273: Setting Of Twine Retainer

    Settings Pos : 93.81.6 /Ü berschriften/Ü berschriften 3/A-E/E/Eins tell ung Gar nhalter @ 47\mod_1285054111875_78.doc x @ 455539 @ 3 @ 1 19.13.5 Setting of twine retainer Pos : 93.81.7 /BA/Ei nstellungen/Groß pac kenpress e/Knoter/D oppel knoter/Gar nhalter D oppel knoter Bil d 1290 HDP II @ 156\mod_1363880514392_78.doc x @ 1379138 @ @ 1 Fig.

  • Page 274: Setting The Holding Force Of The Twine Retainer

    Settings Pos : 93.81.10 /Ü bersc hriften/Ü bersc hriften 3/F-J/HH altekraft des Garnhalters ei nstellen @ 156\mod_1363935243159_78.doc x @ 1379375 @ 3 @ 1 19.13.6 Setting the Holding Force of the Twine Retainer Pos : 93.81.11 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Knoter/D oppel knoter/Hal tekr aft des Garnhalters ei nstellen Bil d 1290 HD P II @ 156\mod_1363935328168_78.doc x @ 1379399 @ @ 1 Fig.
  • Page 275 Settings Pos : 93.81.14 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Knoter/D oppel knoter/Messer hebel (Doppel knoter) Bild 1290 HD P II @ 157\mod_1364281746617_78.doc x @ 1384061 @ @ 1 Fig. 197 Pos : 93.81.15 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Knoter/Messer hebel T ext Ei nfachknoter / D oppel knoter R as pe @ 47\mod_1285058951359_78.doc x @ 455617 @ @ 1 The blade lever (1) must be aligned so that the knotter hook (2) can turn freely without touching the blade lever at any point on the blade lever.

  • Page 276: Adjusting The Baling Ram

    Settings Pos : 93.83.1 /Ü berschriften/Ü berschriften 2/P-T/PPreß kol ben einstellen @ 282\mod_1406108748655_78.doc x @ 2165825 @ 2 @ 1 19.14 Adjusting the baling ram Pos : 93.83.2 /BA/Ei nstellungen/Groß pac kenpress e/Press kolbeneinstellung/Preß kol beneins tell ung Bild 890 / HD P 870 @ 271\mod_1403009088027_78.doc x @ 2046610 @ @ 1 Fig.
  • Page 277 Settings Pos : 93.83.7 /BA/Ei nstellungen/Groß pac kenpress e/Press kolbeneinstellung/Einstellung der Pr eß kolbenmess er BiG Pac k 1290 HD P II / 870 @ 271\mod_1403009739054_78.doc x @ 2046668 @ @ 1 • Release the flywheel brake and turn the flywheel manually in the direction of operation until the blades are above the counterblade.

  • Page 278: Setting The Lateral Plunger Blades

    Settings Pos : 93.83.9 /Ü berschriften/Ü berschriften 3/P-T/S/Seitlic he Pr ess kolbenmess er eins tell en @ 354\mod_1438244783253_78.doc x @ 2645866 @ 3 @ 1 19.14.2 Setting the Lateral Plunger Blades Pos : 93.83.10 /BA/ Ei nstellungen/Gr oßpac kenpr ess e/Press kol beneins tellung/Seitlic he Pr ess kolbenmes ser einstellen Bil d 1290 HD P II / 870 / 4x4 @ 3 54\mod_1438178311737_78.doc x @ 2645226 @ @ 1 Fig.

  • Page 279: Cleaning The Running Rails

    Settings Pos : 93.83.12 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Press kol beneins tellung/Laufs chi enenrei nigung @ 24 \mod_1241423347774_78.doc x @ 243762 @ 3 @ 1 19.14.3 Cleaning the running rails Fig. 202 The cleaning rails (2) are positioned on the four rollers (3). They remove dirt deposits from the running rails of the baling ram.

  • Page 280: Adjusting The Packer Relative To The Plunger

    Settings Pos : 93.83.15 /Layout M odul e /Di es e Seite is t bewuss t fr eigelas sen worden. @ 1 \mod_1201783680373_78.doc x @ 54443 @ @ 1 Pos : 93.83.17 /Ü bersc hriften/Ü bersc hriften 2/P-T /RRaffer zum Pr ess kolben ei nstellen @ 107\mod_1334638713108_78.doc x @ 968035 @ 2 @ 1 19.15 Adjusting the Packer Relative to the Plunger Pos : 93.83.18 /Ü...
  • Page 281 Settings Pos : 93.83.21 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Press kol beneins tellung/R affer z um Preß kolben Vorgehens weis e alle H S T Ypen auß er 1290 HD P @ 192\mod_1382092377530_78.doc x @ 1638885 @ @ 1 Adjusting packer to baling ram is only necessary if the following parts have been disassembled: –...

  • Page 282: Checking Packer Coupling

    Settings Pos : 93.83.23 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Press kol beneins tellung/R affer kupplung überpr üfen Ei nrastung der BP 4x4 Baurei he @ 74\mod_1308666241589_78.doc x @ 657137 @ 3 @ 1 19.15.2 Checking packer coupling Fig. 205 Note The packer coupling is correctly engaged when the outer marks (1) on the packer coupling are aligned with the mark (2) on the inner ring of the packer coupling.

  • Page 283: Moving Baling Ram Into Position

    Settings Pos : 93.83.28 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Press kol beneins tellung/Press kol ben i n Posi tion bringen T ext T2 all e H S T Ypen auß er 1290 HDP @ 192\mod_1382092469255_78.doc x @ 1638910 @ 3 @ 1 19.15.4 Moving Baling Ram into Position Fig.

  • Page 284: Component Description Variable Filling System

    Settings Pos : 93.85.1 /Ü berschriften/Ü berschriften 2/A-E/BBaugruppenbesc hreibung VF S @ 322\mod_1424873333144_78.doc x @ 2482785 @ 2 @ 1 19.16 Component Description Variable Filling System Pos : 93.85.2 /BA/Ei nstellungen/Groß pac kenpress e/Variabl es Fülls ys tem VF S/H S-Baur eiheBaugruppenenbesc hrei bung VFS-System Bild 870 HD P mit Legende @ 306\mod_1416209816792_78.doc x @ 2378645 @ @ 1 Fig.

  • Page 285: Presetting Threaded Rod / Stop For The Feeler Rocker

    Settings Pos : 93.85.4 /Ü berschriften/Ü berschriften 3/U-Z/Voreinstellung Gewei ndestange / Ansc hl ag @ 107\mod_1334225437831_78.doc x @ 964998 @ 3 @ 1 19.16.1 Presetting threaded rod / stop for the feeler rocker Pos : 93.85.5 /BA/Ei nstellungen/Groß pac kenpress e/Variabl es Fülls ys tem VF S/H S-Baur eiheVorei nstellung Gewi ndestange Anschl ag Bil d H S-Baur eihe @ 352\mod_1437488402020_78.doc x @ 2636918 @ @ 1 Fig.

  • Page 286: Zero Position (Vfs System)

    Settings Pos : 93.85.12 /Ü bersc hriften/Ü bersc hriften 3/K- O/NN ullstell ung ( VFS- System) @ 107\mod_1334225251167_78.doc x @ 964914 @ 3 @ 1 19.16.2 Zero position (VFS system) Pos : 93.85.13 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Variabl es F ülls ystem VFS/Bi G PAC K 4x4/Nulls tell ung Bild @ 107\mod_1334225327515_78.doc x @ 964942 @ @ 1 Fig.

  • Page 287: Adjusting The Zeroizing Device

    Settings Pos : 93.85.16 /Ü bersc hriften/Ü bersc hriften 3/K- O/NN ullstell er ei nstellen @ 272\mod_1403255157802_78.doc x @ 2049702 @ 3 @ 1 19.16.3 Adjusting the zeroizing device Pos : 93.85.17 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Variabl es F ülls ystem VFS/HS- Baurei he/Nulls tell er ei nstellen Bild BP 870 @ 272\mod_1403255205278_78.doc x @ 2049730 @ @ 1 Fig.

  • Page 288: Setting The Rubber Buffer On The Zero Adjuster

    Settings Pos : 93.85.20 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Variabl es F ülls ystem VFS/HS- Baurei he/Gummipuffer N ullsteller eins tell en @ 309\mod_1417083054491_78.doc x @ 2393996 @ 3 @ 1 19.16.4 Setting the Rubber Buffer on the Zero Adjuster Fig.

  • Page 289: Adjusting The Triggering Sensitivity

    Settings Pos : 93.85.25 /Ü bersc hriften/Ü bersc hriften 3/A- E/A/Ausl öseempfi ndlic hkei t eins tell en @ 107\mod_1334224827926_78.doc x @ 964716 @ 3 @ 1 19.16.6 Adjusting the triggering sensitivity Pos : 93.85.26 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Variabl es F ülls ystem VFS/Bi G PAC K 4x4/Ausl öseempfindlic hkei t ei nstellen Bild @ 107 \mod_1334224882129_78.doc x @ 964744 @ @ 1 Fig.

  • Page 290: Adjusting The Feeler Rocker

    Settings Pos : 93.85.31 /Ü bersc hriften/Ü bersc hriften 3/P-T /TTas tsc hwing e versetzen @ 107\mod_1334224192633_78.doc x @ 964517 @ 3 @ 1 19.16.7 Adjusting the feeler rocker Pos : 93.85.32 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Variabl es F ülls ystem VFS/HS- Baurei he/Vorei nstellung Gewi ndestange Anschl ag Ac htung bei Aus führung M ulti-Bale @ 272\mod_1403260139102_78.doc x @ 2050144 @ @ 1 ATTENTION! Damage to the machine To avoid damaging the machine, never change the position of the feeler rocker (1) on the MultiBale version.

  • Page 291: Adjusting The Feeler Rocker Stop

    Settings Pos : 93.85.40 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Variabl es F ülls ystem VFS/Bi G PAC K 1290 HDP II/Tastsc hwing e versetzen Hi nweis 2 1290 HDP II @ 170 \mod_1369903454290_78.doc x @ 1472081 @ @ 1 Note After moving the feeler rocker, check or if necessary adjust the following settings.
  • Page 292 Settings Pos : 93.85.45 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Variabl es F ülls ystem VFS/Bi G PAC K 1290 HDP II/Ansc hlag T astschwi nge ei nstellen T ext Maß F prüfen BiG PAC K 1290 HD P II @ 171\mod_1370242686695_78.doc x @ 1473784 @ @ 1 Checking dimension „F“: Fig.

  • Page 293: Absorbing Mechanism

    Settings Pos : 93.85.47 /Ü bersc hriften/Ü bersc hriften 3/A- E/D/D ämpungsei nrichtung @ 73\mod_1308655794889_78.doc x @ 656567 @ 3 @ 1 19.16.9 Absorbing mechanism Pos : 93.85.48 /BA/Ei nstellungen/Gr oßpac kenpr ess e/Variabl es F ülls ystem VFS/Bi G PAC K 4x4/Dämpungs einric htung Bild BP 4x4 @ 107 \mod_1334223246406_78.doc x @ 964371 @ @ 1 Fig.

  • Page 294: Default Setting Of Belt Brake (Flywheel)

    Settings Pos : 93.87 /BA/Ei nstellungen/Groß pac kenpres seGrundeinstellung der Bandbrems e ( Sc hwungrad) @ 325 \mod_1425902922399_78.doc x @ 2501845 @ 2 @ 1 19.17 Default Setting of Belt Brake (Flywheel) BPXC0168 Fig. 219 The belt brake is mounted on the left-hand side of the flywheel. If the braking effect is no longer sufficient when actuating the belt brake, it can be readjusted by extending the spindle (1).

  • Page 295: Adjusting The Chop Length

    Settings Pos : 93.89 /Ü bersc hriften/Ü berschriften 2/P-T/SSc hni ttlänge ei nstellen @ 275\mod_1404396419814_78.doc x @ 2067708 @ 2 @ 1 19.18 Adjusting the chop length Pos : 93.90 /BA/Ei nstellungen/Sc hneidwer k/Sc hnittlänge ei nstellen/Voll bes tüc kung/Schnittl äng e eins tell en: Allgemein von der li nken Seite Big Pac k @ 279\mod_1405066787213_78.doc x @ 2147503 @ @ 1 The chop length is set in the same way on the right and left side of the machine.
  • Page 296 Settings Pos : 93.98 /BA/Ei nstellungen/Sc hneidwer k/Sc hnittlänge ei nstellen/Voll bes tüc kung/In Abhängigkeit der M ess erbestüc kung i n den M ess er kassetten @ 279\mod_1405067044479_78.doc x @ 2147647 @ @ 1 Depending on the number of knives in the drawers Pos : 93.99 /Layout Module /----------------Leerz eile 5 Pt.-------------------- @ 120\mod_1342592918145_0.doc x @ 1092566 @ @ 1 Pos : 93.100 /BA/Wartung/Sc hneidwer k/M ess er wechs el Bild @ 275\mod_1404401306487_78.doc x @ 2068091 @ @ 1 BPHS0300...
  • Page 297 Settings Pos : 93.112 /BA/Wartung/Sc hneidwer k/Einzel mess ersicherung entl asten @ 275\mod_1404467559772_78.doc x @ 2069451 @ @ 1 Releasing the single blade locking device • Shut down and safeguard the machine, see chapter Safety -> Safety routines "Shutting down and safeguarding the machine". •...
  • Page 298 Settings Pos : 95 /Layout M odul e /Di es e Seite ist bewusst freig elass en worden. @ 1 \mod_1201783680373_78.doc x @ 54443 @ @ 1 This page has been left blank deliberately!! Pos : 96 /Layout M odul e /---------------Seitenumbruc h---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 299: Maintenance

    Effect: Danger to life, serious injuries or loss of warranty claims as well as exclusion of liability • Use only authentic KRONE spare parts and accessories authorised by the manufacturer. The use of spare parts, accessories or additional equipment not manufactured, tested or approved by KRONE will exclude any liability for consequential damage.

  • Page 300: Maintenance Table

    Maintenance Pos : 98.9 /Übersc hriften/Übersc hriften 2/U-Z/WWartungs tabell e @ 65\mod_1300369413064_78.doc x @ 583966 @ 2 @ 1 20.2 Maintenance table Pos : 98.10 /BA/War tung/Gr oßpac kenpr ess en/Wartungs tabell e 1290 HD P II T 1 @ 325\mod_1425895120862_78.doc x @ 2501818 @ @ 1 Maintenance interval Maintenance work Tighten screws / nuts...
  • Page 301 Maintenance Pos : 98.12 /BA/War tung/Gr oßpac kenpr ess en/Wartungs tabell e 1290 HD P II T 2 @ 171\mod_1370243929901_78.doc x @ 1473813 @ @ 1 Maintenance interval Maintenance work Tyres Tighten wheel nuts Check tyre pressure Check tyres visually for cuts and breaks Compressor Clean suction air filter Oil level check...

  • Page 302: Tightening Torques

    Maintenance Pos : 98.14.1 /Ü berschriften/Ü berschriften 2/A-E/AAnzi ehdrehmomente @ 202\mod_1385711894606_78.doc x @ 1693123 @ 2 @ 1 20.3 Tightening torques Pos : 98.14.2 /Ü berschriften/Ü berschriften 3/K-O/MM etrisc he Gewindesc hrauben mit R egelgewi nde @ 322\mod_1424945442462_78.doc x @ 2483466 @ 3 @ 1 20.3.1 Metric Thread Screws with Control Thread Pos : 98.14.3 /BA/Wartung/Drehmomente / Anziehdrehmomente/Anziehdrehmomente Metrische Gewi ndes chr auben mi t R egelgewinde T abell e @ 321\mod_1424760222607_78.doc x @ 2477725 @ @ 1...

  • Page 303: Metric Thread Screws With Fine Thread

    Maintenance Pos : 98.14.5 /Ü berschriften/Ü berschriften 3/K-O/MM etrisc he Gewindesc hrauben mit F eing ewinde @ 322\mod_1424945855944_78.doc x @ 2484627 @ 3 @ 1 20.3.2 Metric Thread Screws with Fine Thread Pos : 98.14.6 /BA/Wartung/Drehmomente / Anziehdrehmomente/Anziehdrehmomente Metrische Gewi ndes chr auben mi t F eingewi nde Tabell e @ 321\mod_1424845229172_78.doc x @ 2480186 @ @ 1 A = thread size Tightening torque in Nm (unless otherwise stated)

  • Page 304: Blade Changing

    Maintenance Pos : 98.16 /Ü bersc hriften/Ü berschriften 2/K-O/MM ess er wec hs el @ 8\mod_1219657285958_78.doc x @ 119937 @ 2 @ 1 20.4 Blade Changing Pos : 98.17 /BA/War tung/Sc hnei dwer k/Mes ser wec hsel allgemein von der linken Seite Big Pac k @ 275\mod_1404469078762_78.doc x @ 2069681 @ @ 1 Blades are changed in the same way on the right and left side of the machine.
  • Page 305 Maintenance • Turn the special tool (4) until the cams on the upper and lower knife selection are in the ( ) position. Pos : 98.21.12 /Layout M odul e /----------------Leerzeil e 5 Pt.-------------------- @ 120\mod_1342592918145_0.doc x @ 1092566 @ @ 1 Pos : 98.21.13 /BA/Wartung/Sc hneidwer k/M ess er kassette her aus ziehen @ 275\mod_1404467519024_78.doc x @ 2069423 @ @ 1 Removing the knife drawer (7) •...

  • Page 306: Lifting

    Maintenance Pos : 98.23 /Ü bersc hriften/Ü berschriften 2/A-E/AAnheben @ 33\mod_1254380091415_78.doc x @ 319041 @ 2 @ 1 20.5 Lifting Pos : 98.24 /BA/War tung/AnhebenAnheben Bil d BiG PAC K 870 HD P @ 309\mod_1417511485012_78.doc x @ 2396278 @ @ 1 RH+LH RH+LH 942 012- 1...

  • Page 307: Cleaning

    Maintenance Pos : 98.28 /Ü bersc hriften/Ü berschriften 2/P-T/RR einigung @ 24\mod_1241504803133_78.doc x @ 245455 @ 2 @ 1 20.6 Cleaning Pos : 98.29 /BA/Sic herheit/6. Überar beitete Warnhinweis e/Warnung - R einig ung mit Druc kl uft_alt @ 0\mod_1196770018125_78.doc x @ 13211 @ @ 1 Warning! - Cleaning with compressed air! Effect: Loss of eyesight! •...

  • Page 308: Drive Chains

    Maintenance Pos : 98.33 /Ü bersc hriften/Ü berschriften 2/A-E/AAntri ebs ketten @ 27\mod_1246355234599_78.doc x @ 267399 @ 2 @ 1 20.7 Drive chains Pos : 98.34 /BA/War tung/Antriebs ketten ( Ketten)/Antriebs ketten allgemei n @ 107\mod_1334563877892_78.doc x @ 966387 @ @ 1 •...

  • Page 309: Pick-Up Drive (Iii)

    Maintenance 20.7.3 Pick-up drive (III) Fig. 226 Right and left sides of the machine At the factory the spring has been preset (1) to a = 60 mm. • Open the protective cover on the right or left side of the machine •...

  • Page 310: Tyres

    If tyres are not correctly fitted, it could explode when pumped up. This can cause serious injury. If you do not have sufficient experience of fitting tyres, have tyres fitted by the KRONE dealer or a qualified tyre specialist. •...

  • Page 311: Checking And Maintaining Tyres

    Maintenance Pos : 98.44 /Ü bersc hriften/Ü berschriften 3/P-T/RR eifen prüfen und pfl egen @ 0\mod_1197358037214_78.doc x @ 18094 @ 3 @ 1 20.8.1 Checking and maintaining tyres Pos : 98.45 /BA/War tung/Rei fen/R eihenfolg e Bil d 6-Loc h @ 4\mod_1213086131413_78.doc x @ 86197 @ @ 1 KS-0-034 Fig.

  • Page 312: Maintenance - Hydraulic System

    Risk of injury as a result of incorrect handling of liquids under high pressure. Effect: Escaping high-pressure liquids can penetrate the skin and cause serious injury. Repair work on the hydraulic system may only be performed by authorised KRONE professional workshops.

  • Page 313: On-Board Hydraulic System

    Maintenance - hydraulic system Pos : 105 /Übersc hriften/Ü berschriften 3/A-E/B/Bordhydr auli k @ 24\mod_1241518305195_78.doc x @ 245758 @ 3 @ 1 21.1.1 On-board hydraulic system Pos : 106 /BA/War tung/U mwel t/Hinweis Ents orgen / Lagern von Öle und Ölfilter U mwelt @ 32 \mod_1253101375171_78.doc x @ 311770 @ @ 1 ENVIRONMENT! - Disposal and storage of used lubricants and oil filters Effect: Environmental damage Store or dispose used oil and oil filters according to statutory provisions.

  • Page 314: High-Pressure Filter

    Maintenance - hydraulic system Pos : 112.1 /Ü bersc hriften/Ü berschriften 2/F-J /HHoc hdruc kfilter @ 26\mod_1245836423991_78.doc x @ 264126 @ 2 @ 1 21.2 High-pressure filter Pos : 112.2 /BA/War tung/Hochdruc kfilter/Mitteldr uc kfilter optische Verschmutz ungsanzeig e @ 32\mod_1253092558858_78.doc x @ 309853 @ @ 1 The filter takes up depositions of solid particles of the hydraulic system.

  • Page 315: Emergency Manual Activation

    Maintenance - hydraulic system Pos : 114 /BA/War tung/Load- Sensi ng/Großpac kenpresse/Not-Handbetätigung H S Baurei he @ 63\mod_1299838530165_78.doc x @ 576700 @ 2 @ 1 21.3 Emergency Manual Activation The electromagnetic valve block for the In-cab Comfort kitis located at the front on the left under the side cover next to the electronics box.

  • Page 316: Comfort Hydraulic Block Diagram

    Maintenance - hydraulic system Pos : 116 /BA/War tung/Load- Sensi ng/Großpac kenpresse/Sc haubild H ydr auli kbloc k-Komfort 870_890_1270_1290 H S Baurei he @ 234\mod_1394095664274_78.doc x @ 1866116 @ 2 @ 1 21.4 Comfort Hydraulic Block Diagram Funktionsschaubild Magnetv entile Fkt.1 Fkt.2 Funktionen Y4 Y5...

  • Page 317: Examples Of Emergency Manual Activation

    Maintenance - hydraulic system Pos : 118 /Übersc hriften/Ü berschriften 2/A-E/BBeis piel e z ur N ot-Hand-Betätigung @ 0\mod_1199946148163_78.doc x @ 36985 @ 2 @ 1 21.5 Examples of Emergency Manual Activation Pos : 119 /BA/Sicherheit/7. Gefahr enhinweis e alt/Ladewag en/WARNUN G! Bedi enung der Maschi ne über di e N ot-H and-Betätigung @ 274\mod_1404217792675_78.doc x @ 2061048 @ @ 1 WARNING! There is an increased risk of injury if you operate the machine using the emergency manual activation.

  • Page 318: Pressing Force Control (With Emergency Manual Activation)

    Maintenance - hydraulic system Pos : 122.1 /Ü bersc hriften/Ü berschriften 2/P-T/PPress kraftreg elung (bei N ot-Hand-Betätigung) @ 24\mod_1241612862815_78.doc x @ 246772 @ 2 @ 1 21.6 Pressing force control (with emergency manual activation) Pos : 122.2 /BA/War tung/Gr oßpac kenpr ess en/H ydr auli kanlage / Bor dhydr auli k/Warnung - Pr ess kr aftr egelung i m N otbetrieb @ 274\mod_1404218701576_78.doc x @ 2061073 @ @ 1 Warning! There is an increased risk of injury if adjust the force of pressure in emergency mode.

  • Page 319: Maintenance - Gearbox

    Maintenance - Gearbox Pos : 124.1 /Ü bersc hriften/Ü berschriften 1/U-Z/Wartung - Getriebe @ 2\mod_1203058202823_78.doc x @ 64495 @ 1 @ 1 Maintenance - Gearbox Pos : 124.2 /BA/War tung/Öl kontroll e_Wechsel/Groß pac kenpresse/waager echte Stell ung @ 172\mod_1370436011231_78.doc x @ 1478697 @ @ 1 Note When checking the oil level on the gearboxes, make sure that the big pack baler is in horizontal position.

  • Page 320: Packer Gearbox

    Maintenance - Gearbox Pos : 124.12 /Ü bers chriften/Ü bersc hriften 2/P-T /RRafferg etriebe @ 24\mod_1241584428737_78.doc x @ 245996 @ 2 @ 1 22.2 Packer gearbox Pos : 124.13 /BA/Wartung/Öl kontr olle_Wec hs el/Groß pac kenpress e/R affergetriebe Anbri ngungs ort @ 24 \mod_1241585198221_78.doc x @ 246121 @ @ 1 The packer gearbox (3) is located on the left side of the machine.

  • Page 321: Transfer Gearbox

    Maintenance - Gearbox Pos : 124.22 /Ü bers chriften/Ü bersc hriften 2/U-Z/VVerteil ergetriebe @ 2\mod_1202991526780_78.doc x @ 64104 @ 2 @ 1 22.3 Transfer gearbox Pos : 124.23 /BA/Wartung/Öl kontr olle_Wec hs el/Groß pac kenpress e/Ver teil ergetriebe Anbringungsort @ 24\mod_1241586943378_78.doc x @ 246170 @ @ 1 The transfer gearbox (3) is located on the left side of the machine.

  • Page 322: Pick-Up Gearbox

    Maintenance - Gearbox Pos : 124.32 /Ü bers chriften/Ü bersc hriften 2/P-T /PPic k-up-Getriebe @ 24\mod_1241589499831_78.doc x @ 246271 @ 2 @ 1 22.4 Pick-up gearbox Pos : 124.33 /Ü bers chriften/Z wisc henübersc hriften/A- EBei Aus führung ohne Sc hnei dwerk @ 157\mod_1364379318831_78.doc x @ 1387595 @ @ 1 Design without cutting system Pos : 124.34 /BA/Wartung/Öl kontr olle_Wec hs el/Groß...

  • Page 323: Cutting System Drive Gear

    Maintenance - Gearbox Pos : 124.43 /Ü bers chriften/Ü bersc hriften 2/P-T /SSchneidwer ks antriebsgetriebe @ 24\mod_1241595072471_78.doc x @ 246450 @ 2 @ 1 22.5 Cutting system drive gear Pos : 124.44 /Ü bers chriften/Z wisc henübersc hriften/A- EBei Aus führung mit Sc hneidwer k @ 157\mod_1364379388830_78.doc x @ 1387653 @ @ 1 Design with cutting system Pos : 124.45 /BA/Wartung/Öl kontr olle_Wec hs el/Groß...
  • Page 324 Maintenance - Gearbox Pos : 124.55 /BA/Wartung/Öl kontr olle_Wec hs el/Groß pac kenpress e/Sc hneidwer kgetriebe Z wischenüberschrift @ 193\mod_1383225102226_78.doc x @ 1646814 @ @ 1 Cutting system gear Pos : 124.56 /BA/Wartung/Öl kontr olle_Wec hs el/Groß pac kenpress e/Pic k-up Sc hnei dwer ks antriebsgetriebe 4x4 Bild @ 309\mod_1417508946038_78.doc x @ 2396215 @ @ 1 Fig.

  • Page 325: Maintenance - Brake System

    Only a machine with an intact brake system may be used for work in the field or for travelling on roads. • No changes may be made to the brake system without the approval of KRONE. • KRONE is not responsible for natural wear, defects caused by overload or changes made to the brake system.

  • Page 326: Compressed-Air Reservoir

    Maintenance - Brake System Pos : 126.6 /Ü bersc hriften/Ü berschriften 2/A-E/DDr uc kl uftbehälter @ 12\mod_1224144256075_78.doc x @ 150965 @ 2 @ 1 23.1 Compressed-air reservoir Pos : 126.7 /BA/Sic herheit/2. Voranges tellte Warnhinweise/War nung - Druc kluftbehäl ter besc hädigte oder korr odi ert - Alte F orm @ 275\mod_1404385710309_78.doc x @ 2066945 @ @ 1 WARNING! Risk of injury from corroded or damaged compressed air reservoirs.

  • Page 327: Checking The Drain Valve

    Maintenance - Brake System Pos : 126.13 /Ü bers chriften/Ü bersc hriften 3/A- E/E/Entwäss erungs ventil kontr ollieren @ 52\mod_1289391310593_78.doc x @ 503391 @ 3 @ 1 23.1.1 Checking the drain valve Pos : 126.14 /BA/Sic her hei t/2. Vor ang estellte War nhi nweis e/Ac htung - Wass er in der Anl age - ALTE FORM @ 275\mod_1404390143372_78.doc x @ 2067365 @ @ 1 ATTENTION! Water in the plant will cause corrosion damage.

  • Page 328: Adjusting The Transfer Mechanism

    Maintenance - Brake System Pos : 126.18 /Ü bers chriften/Ü bersc hriften 2/U-Z/UÜ bertr agungsei nrichtung ei nstellen @ 275\mod_1404391929258_78.doc x @ 2067590 @ 2 @ 1 23.2 Adjusting the transfer mechanism Pos : 126.19 /BA/Wartung/Dr uc kl uftbehälter/Er höhte U nfallgefahr bei ungenügenden tec hnisc he Kenntnis se für Ei nstell - und Reparaturar bei ten. @ 275\mod_1404380923105_78.doc x @ 2066856 @ @ 1 WARNING! Insufficient technical knowledge to carry out adjustment and repair work poses an increased risk of injury.

  • Page 329: Pneumatic Brake Cylinders

    Maintenance - Brake System Pos : 126.24 /Ü bers chriften/Ü bersc hriften 3/P-T /PPneumatis che Bremsz ylinder @ 24\mod_1241618324893_78.doc x @ 246996 @ 3 @ 1 23.2.1 Pneumatic brake cylinders Pos : 126.25 /BA/Wartung/Dr uc kl uftbehälter/Er höhte U nfallgefahr bei ungenügenden tec hnisc he Kenntnis se für Ei nstell - und Reparaturar bei ten. @ 275\mod_1404380923105_78.doc x @ 2066856 @ @ 1 WARNING! Insufficient technical knowledge to carry out adjustment and repair work poses an increased risk of injury.

  • Page 330: Air Filter For Pneumatic Cylinder (Only Multibale)

    Maintenance - Brake System Pos : 128 /BA/War tung/Gr oßpac kenpr ess en/Luftfilter für Pneumati kz yli nder @ 24\mod_1241674208133_78.doc x @ 247225 @ 2 @ 1 23.3 Air filter for pneumatic cylinder (only MultiBale) Fig. 241 The air filter (1) for pneumatic cylinders is on the left in the twine box (as seen facing direction of travel).
  • Page 331 Maintenance - Brake System Pos : 131 /Layout Module /Diese Seite ist bewusst freigel ass en wor den. @ 1\mod_1201783680373_78.doc x @ 54443 @ @ 1 This page has been left blank deliberately!! Pos : 132 /Layout Module /---------------Seitenumbr uc h---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 332: Maintenance Compressor

    Maintenance Compressor Pos : 133 /Übersc hriften/Ü berschriften 1/U-Z/Wartung - Kompr essor @ 193\mod_1382686806036_78.doc x @ 1642725 @ 1 @ 1 Maintenance Compressor Pos : 134 /Übersc hriften/Ü berschriften 2/K-O/KKompress or @ 24\mod_1241673489914_78.doc x @ 247170 @ 2 @ 1 24.1 Compressor Pos : 135 /BA/War tung/Kompress or/Kompres sor BiG PACK @ 368\mod_1441607324475_78.doc x @ 2698882 @ @ 1...
  • Page 333 Maintenance Compressor Pos : 137 /BA/War tung/Kompress or/Kompres sor-Öls tand Bil d @ 193\mod_1382683006840_78.doc x @ 1642404 @ @ 1 Fig. 244 1) Oil dip stick / oil filling hole 2) Drain plug Pos : 138 /BA/War tung/Öl kontroll e_Wec hsel /Öl kontrolle / Öl wec hs el Inter vall: si ehe Kapitel Wartung „Wartungstabell e“ @ 134\mod_1350483605921_78.doc x @ 1188115 @ @ 1 Interval for oil level check and oil change: refer to chapter Maintenance “Maintenance Table”...

  • Page 334: Maintenance - Lubrication

    Maintenance – lubrication Pos : 143.1 /Ü bersc hriften/Ü berschriften 1/U-Z/Wartung - Sc hmierung @ 24\mod_1241675457008_78.doc x @ 247325 @ 1 @ 1 Maintenance – lubrication Pos : 143.2 /BA/Sic herheit/2. Voranges tellte Warnhinweise/WARNUN G - Nic htbeac htung der grundl egenden Sic herheits hinweise alte For m @ 254\mod_1397485793575_78.doc x @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 335: Lubricants

    Maintenance – lubrication Pos : 143.6 /Ü bersc hriften/Ü berschriften 2/P-T/SSc hmierfette / Sc hmieröl e @ 24\mod_1241676102945_78.doc x @ 247353 @ 2 @ 1 25.1 Lubricants Pos : 143.7 /BA/War tung/Gr oßpac kenpr ess en/Sc hmier ung / Schmi erpl anAllgemei nes wenn nur automatisc he Zentr alschmi erung vorhanden (2016-01-19 13:51:55) @ 92\mod_1326782898523_78.doc x @ 781812 @ 2 @ 1 25.2 General All machines are equipped with automatic central lubrication.

  • Page 336: Lubricating The Cardan Shaft

    Maintenance – lubrication Pos : 143.14 /Ü bers chriften/Ü bersc hriften 2/F-J/G/Gel enkwelle absc hmier en @ 388\mod_1445351149785_78.doc x @ 2778829 @ 2 @ 1 25.3 Lubricating the cardan shaft Pos : 143.15 /BA/Wartung/Gel enkwell e sc hmier enAbsc hmier en Gelenkwelle H übe Bild Bi G PAC K 870HDP/890/1270/1290 HS @ 368\mod_1441615518633_78.doc x @ 2699262 @ @ 1 Fig.

  • Page 337: Lubricating The Rollers For The Blade Lever

    Maintenance – lubrication Pos : 143.19 /BA/Wartung/Groß pac kenpres sen/Sc hmi erung / Sc hmier plan/Laufr ollen der Mess erhebel absc hmier en @ 24\mod_1241695903648_78.doc x @ 247898 @ 2 @ 1 25.4 Lubricating the rollers for the blade lever Fig.

  • Page 338: Manual Lubrication Points On The Machine

    Pos : 143.22 /Ü bers chriften/Z wisc henübersc hriften/K-Oli nke M aschi nens eite @ 60\mod_1297934981687_78.doc x @ 562715 @ @ 1 Left-hand Side of the Machine Pos : 143.23 /BA/Wartung/Groß pac kenpres sen/Sc hmi erung / Sc hmier plan/Sc hmierstellen li nks Ausführ ung Schneidwer k Bild 870 HDP @ 270\mod_1402578642035_78.doc x @ 2042030 @ @ 1 BPHS0282 Fig.
  • Page 339 Maintenance – lubrication Every 200 hours ) Only for version with a cutting system Pos : 143.24 /Layout M odul e /---------------Seitenumbruc h---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...
  • Page 340 Pos : 143.25 /Ü bers chriften/Z wisc henübersc hriften/P-Tr echte Masc hi nens eite @ 60\mod_1297935179130_78.doc x @ 562741 @ @ 1 Right-hand Side of the Machine Pos : 143.26 /BA/Wartung/Groß pac kenpres sen/Sc hmi erung / Sc hmier plan/Sc hmierstellen r echts Ausführ ung Bild 870 HDP @ 270\mod_1402578722569_78.doc x @ 2042089 @ @ 1 BPHS0283 Fig.
  • Page 341 Maintenance – lubrication Every 200 hours ) Only for version with a cutting system ) Only for version without a cutting system Pos : 144 /Layout Module /---------------Seitenumbr uc h---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 342: Maintenance - Central Lubrication

    Maintenance – Central Lubrication Pos : 145 /Übersc hriften/Ü berschriften 1/U-Z/Wartung - Z entrals chmi erung @ 0\mod_1197378235308_78.doc x @ 19471 @ 1 @ 1 Maintenance – Central Lubrication Pos : 146.1 /Ü bersc hriften/Ü berschriften 3/A-E/A/Automatisc he Z entralsc hmier ung ( optional) @ 24\mod_1241763215353_78.doc x @ 248355 @ 3 @ 1 26.1.1 Automatic centralised lubrication system (optional) Pos : 146.2 /BA/War tung/Zentr alsc hmieranl age/BEKA-M AX/Funkti onsbesc hrei bung der BEKA-MAX-F ett-Zentrals chmi eranlag e @ 24\mod_1241765421322_78.doc x @ 248475 @ @ 1...
  • Page 343 Maintenance – Central Lubrication Pos : 148 /Layout Module /Diese Seite ist bewusst freigel ass en wor den. @ 1\mod_1201783680373_78.doc x @ 54443 @ @ 1 This page has been left blank deliberately!! Pos : 149 /Layout Module /---------------Seitenumbr uc h---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 344: Maintenance - Electrical System

    Maintenance – electrical system Pos : 150 /Übersc hriften/Ü berschriften 1/U-Z/Wartung - Elektri k @ 0\mod_1197362427261_78.doc x @ 18572 @ 1 @ 1 Maintenance – electrical system Pos : 151 /BA/War tung/Gr oßpac kenpr ess en/Sensor en/Lage der Sensor en rec hte M asc hinensei te BP 870 HD P @ 270\mod_1402574614064_78.doc x @ 2041736 @ 2 @ 1 27.1 Position of sensors (right side of the machine) B4/B5...
  • Page 345 Maintenance – electrical system Sensor Designation Sensor Designation Measuring Calibration Packer feed Knotter monitoring Setting down bales Needle connecting rod on right Bale ejector Star wheel Bale on chute Steering axle Rear bale chute Front bale chute Pos : 152 /Layout Module /---------------Seitenumbr uc h---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 346: Position Of Sensors (Left Side Of Machine)

    Maintenance – electrical system Pos : 153 /BA/War tung/Gr oßpac kenpr ess en/Sensor en/Lage der Sensor en linke M asc hinensei te BP 870 HD P @ 270\mod_1402576820223_78.doc x @ 2041915 @ 2 @ 1 27.2 Position of sensors (left side of machine) B41-46 BPHS0281 Fig.
  • Page 347 Maintenance – electrical system Sensor Designation Sensor Designation Flywheel brake Central lubrication Packer monitoring Twine monitoring Needle connecting rod on left Bale chute Bale channel flap pressure Plunger force, right Plunger force, left Pick-up Pick-up position PTO speed Acceleration sensor Upper twine monitoring Pos : 154 /Layout Module /---------------Seitenumbr uc h---------------- @ 0\mod_1196175311226_0.doc x @ 4165 @ @ 1...

  • Page 348: Adjusting The Sensors

    Maintenance – electrical system Pos : 155 /Übersc hriften/Ü berschriften 3/A-E/E/Einstell ung der Sensor en @ 0\mod_1199962173428_78.doc x @ 37635 @ 3 @ 1 27.2.1 Adjusting the Sensors Pos : 156 /BA/War tung/Sensor en/Namurs ens or d = 08 mm @ 24\mod_1241770312369_78.doc x @ 248607 @ 4 @ 1 27.2.1.1 Namur sensor d = 8 mm BP-VFS-088-1...

  • Page 349: Namur Sensor D = 30 Mm

    Maintenance – electrical system 27.2.1.2 Namur sensor d = 30 mm BPXC0172 Figure 255 The dimension between the encoder (2) and the sensor (1) must be "a" = 5 mm . Setting • Loosen the nuts on either side of the sensor. •...

  • Page 350: Malfunctions - Causes And Remedies

    Malfunctions - Causes and Remedies Pos : 160.1 /Ü bersc hriften/Ü berschriften 1/P-T/Stör ung en - Ursachen und Behebung @ 0\mod_1200296925180_78.doc x @ 39459 @ 1 @ 1 Malfunctions - Causes and Remedies Pos : 160.2 /BA/Sic herheit/2. Voranges tellte Warnhinweise/WARNUN G - Nic htbeac htung der grundl egenden Sic herheits hinweise alte For m @ 254\mod_1397485793575_78.doc x @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 351: General Malfunctions

    Malfunctions - Causes and Remedies Pos : 160.5 /Ü bersc hriften/Ü berschriften 2/A-E/AAllgemei ne Störungen @ 24\mod_1241775122213_78.doc x @ 248807 @ 2 @ 1 28.1 General malfunctions Pos : 160.6 /BA/Stör ung en - Ursachen und Behebung/Groß pac kenpres sen/Störung: Pr ess kol ben / Bi ndeeinric htung blei bt stehen @ 369\mod_1441800887453_78.doc x @ 2704608 @ @ 1 Fault: Baling ram/twine tying device does not move.
  • Page 352 Malfunctions - Causes and Remedies Pos : 160.12 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung: Die Pic k- up bl eibt stehen @ 369\mod_1441803130931_78.doc x @ 2704983 @ @ 1 Fault: Pick-up does not move. Possible causes Remedy The overload clutch slips.
  • Page 353 Malfunctions - Causes and Remedies Pos : 160.16 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Tabellarisc he Auflistung H ydr auli kbloc k entlüften T 1 @ 352\mod_1437547588957_78.doc x @ 2637177 @ @ 1 Fault: – If load-sensing line is connected, the tractor does not start properly or not at all. –...
  • Page 354 Malfunctions - Causes and Remedies • Depressurise the system and unscrew the load-sensing valve. • If required, attach the plastic cover to the valve (Y17). Test run: Note On the test bench the correct ventilation can be checked only on machines with a connected starting aid.

  • Page 355: Malfunctions On The Knotter

    Malfunctions - Causes and Remedies Pos : 160.19 /Ü bers chriften/Ü bersc hriften 2/P-T /SStörungen am Knoter @ 24\mod_1241775183869_78.doc x @ 248831 @ 2 @ 1 28.2 Malfunctions on the knotter Pos : 160.20 /Ü bers chriften/Ü bersc hriften 3/A- E/E/Ei nfac hknoter @ 24\mod_1241083809568_78.doc x @ 242978 @ 3 @ 1 28.2.1 Single knotter Pos : 160.21 /BA/Störungen - Urs ac hen und Behebung/Gr oß...
  • Page 356 Malfunctions - Causes and Remedies Pos : 160.24 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Tabellarisc he Auflistung Ei nfachknoter T 2 @ 24\mod_1241775278072_78.doc x @ 248859 @ @ 1 Malfunction Cause and/or remedy Incorrect position of knotter needle — change seating of knotter needle on the yoke.
  • Page 357 Malfunctions - Causes and Remedies Pos : 160.26 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Tabellarisc he Auflistung Ei nfachknoter T 3 @ 24\mod_1241777135041_78.doc x @ 248936 @ @ 1 Malfunction Cause and/or remedy Twine is tearing or shows signs of abrasion in places: Right next to the knot.

  • Page 358: Double Knotter

    Malfunctions - Causes and Remedies Pos : 160.28 /Ü bers chriften/Ü bersc hriften 3/A- E/D/D oppel knoter @ 24\mod_1241099544678_78.doc x @ 243310 @ 3 @ 1 28.2.2 Double knotter Pos : 160.29 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Fehl erurs ache Knoterstörungen D oppel knoter allgemei ner Text @ 24\mod_1241779382291_78.doc x @ 248957 @ @ 1 Experience has shown that a majority of tying problems are the result of insufficient twine tension.
  • Page 359 Malfunctions - Causes and Remedies Pos : 160.31 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Doppel knoter T1 @ 24\mod_1242027120229_78.doc x @ 249022 @ @ 1 Malfunction Cause and/or remedy Cause: Second knot remains hanging on the knotter Knotter tongue bends or frequent rupture of tongue.
  • Page 360 Malfunctions - Causes and Remedies Pos : 160.33 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Doppel knoter T2 @ 24\mod_1242029551448_78.doc x @ 249073 @ @ 1 Malfunction Cause and/or remedy Knot remains hanging on the knotter hook. Cause: Excessive tension on the knotter tongue.
  • Page 361 Malfunctions - Causes and Remedies Pos : 160.35 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Doppel knoter T3 @ 24\mod_1242030761307_78.doc x @ 249150 @ @ 1 Malfunction Cause and/or remedy Knot remains hanging on the knotter hook. Cause: Blade lever too far away from the knotter hook.
  • Page 362 Malfunctions - Causes and Remedies Pos : 160.37 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Doppel knoter T4 @ 25\mod_1242033232885_78.doc x @ 249228 @ @ 1 Malfunction Cause and/or remedy First knot: (closing knot): Present only in the Cause: upper twine strand.
  • Page 363 Malfunctions - Causes and Remedies Pos : 160.39 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Doppel knoter T5 @ 25\mod_1242035576557_78.doc x @ 249567 @ @ 1 Malfunction Cause and/or remedy Second knot: (Starting knot) Knot is present Cause: only on the lower twine strand (no knot on The twine bar is adjusted too far away from the...
  • Page 364 Malfunctions - Causes and Remedies Pos : 160.41 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Doppel knoter T6 @ 25\mod_1242036861416_78.doc x @ 249592 @ @ 1 Malfunction Cause and/or remedy Second knot: (Starting knot) Knot is present Cause: only on the upper twine strand (no knot on The lower twine tension springs are not working...
  • Page 365 Malfunctions - Causes and Remedies Pos : 160.43 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Doppel knoter T7 @ 25\mod_1242040506416_78.doc x @ 249617 @ @ 1 Malfunction Cause and/or remedy Second knot: (Starting knot) Twine winds Cause: around the knotter hook.
  • Page 366 Malfunctions - Causes and Remedies Pos : 160.45 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Doppel knoter T8 @ 25\mod_1242041192745_78.doc x @ 249642 @ @ 1 Malfunction Cause and/or remedy No knot present, neither on the upper nor Cause: on the lower twine strand.
  • Page 367 Malfunctions - Causes and Remedies Pos : 160.47 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Doppel knoter T9 @ 25\mod_1242042248604_78.doc x @ 249667 @ @ 1 Malfunction Cause and/or remedy Knot ends too short. The knot often gets 10.1 Cause: wound up (generally the second knot).
  • Page 368 Malfunctions - Causes and Remedies Pos : 160.49 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Doppel knoter T10 @ 25\mod_1242042811416_78.doc x @ 249692 @ @ 1 Malfunction Cause and/or remedy Shear screw on the needle connecting rod Cause: breaks frequently.

  • Page 369: Troubleshooting In The Central Lubrication

    Malfunctions - Causes and Remedies Pos : 160.51 /Ü bers chriften/Ü bersc hriften 2/F-J/FF ehlers uche i n der Zentr alsc hmi erung @ 25\mod_1242052030604_78.doc x @ 249788 @ 2 @ 1 28.3 Troubleshooting in the central lubrication Pos : 160.52 /BA/Störungen - Urs ac hen und Behebung/Gr oß pac kenpr ess en/Stör ung en-Urs achen-Behebung Zentr alsc hmierung T 1 @ 25\mod_1242051129385_78.doc x @ 249717 @ @ 1 Malfunction Cause and/or remedy Blockage in the system or...

  • Page 370: Placing In Storage

    Placing in Storage Pos : 162.1 /Ü bersc hriften/Ü berschriften 1/A-E/Einl ager ung @ 0\mod_1197385459120_78.doc x @ 19966 @ 1 @ 1 Placing in Storage Pos : 162.2 /BA/Sic herheit/2. Voranges tellte Warnhinweise/WARNUN G - Nic htbeac htung der grundl egenden Sic herheits hinweise alte For m @ 254\mod_1397485793575_78.doc x @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 371: At The End Of The Harvest Season

    Perform the necessary repair tasks during the time immediately after the harvest season. Draw up a list of all spare parts you will need. This will make it easier for your KRONE dealer to process your orders and you will be certain that your machine will be ready for use at the beginning of the next season.

  • Page 372: Before The Start Of The New Season

    Placing in Storage Pos : 162.9 /Ü bersc hriften/Ü berschriften 2/U-Z/VVor Begi nn der neuen Saison @ 0\mod_1197386024448_78.doc x @ 20081 @ 2 @ 1 29.2 Before the Start of the New Season Pos : 162.10 /BA/Sic her hei t/2. Vor ang estellte War nhi nweis e/WARNUNG - Nichtbeac htung der grundlegenden Sic her heitshi nweis e alte F or m @ 254\mod_1397485793575_78.doc x @ 1953347 @ @ 1 WARNING! If the basic safety instructions are not followed, people may be seriously injured or killed.

  • Page 373: Overload Coupling On Flywheel

    Placing in Storage Pos : 162.14 /Ü bers chriften/Ü bersc hriften 3/U-Z/Ü berl astkuppl ung am Schwungrad @ 46\mod_1282047883734_78.doc x @ 445914 @ 3 @ 1 29.2.1 Overload coupling on flywheel Pos : 162.15 /BA/Ei nlager ung/Groß pac kenpres se/Überlas tkupplung am Sc hwungrad Hi nweis @ 46\mod_1282048018156_78.doc x @ 445940 @ @ 1 Note After the machine has been idle for long periods of time, the linings of the overload coupling (1) may adhere to friction surfaces.

  • Page 374: Disposal Of The Machine

    Disposal of the machine Pos : 164 /Übersc hriften/Ü berschriften 1/A-E/Ents orgung der Mas chi ne @ 274\mod_1404207309028_78.doc x @ 2060455 @ 1 @ 1 Disposal of the machine Pos : 165 /BA/Entsorgung der M asc hine/Di e M asc hine entsorgen @ 274\mod_1404207434449_78.doc x @ 2060544 @ 2 @ 1 30.1 Disposal of the machine After the service life of the machine has expired, the individual components of the machine must...

  • Page 375: Appendix

    Appendix Pos : 167 /Übersc hriften/Ü berschriften 1/A-E/Anhang @ 1\mod_1202278612285_78.doc x @ 58360 @ 1 @ 1 Appendix Pos : 168 /Übersc hriften/Ü berschriften 2/P-T/SSc haltpl an @ 322\mod_1424929681192_78.doc x @ 2483325 @ 2 @ 1 31.1 Diagram Pos : 169 /BA/Anhang/Gr oß pac kenpress e/Bor dhydr auli k für Medium-El ektr oni k HS Baureihe @ 194\mod_1383644199349_78.doc x @ 1651623 @ 2 @ 1 31.2 On-Board Hydraulic System for Medium Version Electronics Fig.

  • Page 376: On-Board Hydraulic System For Comfort Version Electronics

    Appendix Pos : 171 /BA/Anhang/Gr oß pac kenpress e/Bor dhydr auli k für Komfort-El ektroni k H S Baurei he @ 195\mod_1383644714292_78.doc x @ 1651824 @ 2 @ 1 31.3 On-Board Hydraulic System for Comfort Version Electronics Fig. 259 1. Main gearbox 2.

  • Page 377: Work Hydraulics Medium Version Electronics

    Appendix Pos : 173 /Übersc hriften/Ü berschriften 2/A-E/AArbeits hydr auli k für Medium- Elektroni k @ 280\mod_1405583937453_78.doc x @ 2156301 @ 2 @ 1 31.4 Work Hydraulics Medium Version Electronics Pos : 174 /BA/Anhang/Gr oß pac kenpress e/Arbeits hydraulik für Medi um- Elektroni k H S Baurei he Bil d @ 368\mod_1441700579778_78.doc x @ 2700894 @ @ 1 Fig.
  • Page 378 Appendix Pos : 177 /Übersc hriften/Ü berschriften 2/A-E/AArbeits hydr auli k für Komfort-El ektr oni k @ 280\mod_1405574137485_78.doc x @ 2155721 @ 2 @ 1 31.5 Work Hydraulics Comfort Version Electronics Pos : 178 /BA/Anhang/Gr oß pac kenpress e/Arbeits hydraulik für Komfort-El ektr oni k HS Baur eihe Bild @ 446\mod_1460959778016_78.doc x @ 3041991 @ @ 1 201 409 09 Fig.
  • Page 379 Pos : 181 /Übersc hriften/Ü berschriften 2/P-T/S/Stroml aufpl an [Medi um-/Komfort-El ektr oni k] @ 429\mod_1455523960410_78.doc x @ 2967199 @ 2 @ 1 31.6 Circuit Diagram [Medium/Comfort Version Electronics] === Ende der Liste für T extmar ke Inhalt ===...
  • Page 402 Connect the machine to the tractor ....20, 97 Attaching Hydraulic Parking Jack ....... 83 Connecting External ISOBUS-Terminal... 110 Attaching Safety Labels and Information Labels 43 Connecting KRONE ISOBUS-Terminal ... 106 Automatic bale ejection........152 Connecting lower twine ......232, 238 Automatic centralised lubrication system (optional) Connecting the hydraulic lines ......
  • Page 403 Customer counter ........184, 186 Filling Quantities and Lubrication Designations for Gearboxes ............. 78 Cutting Length ............ 63 Finishing Tying Process Manually ....251 Cutting system ............ 63 Fire extinguisher ..........44 Cutting System Drive .......... 61 Flywheel brake ........... 46 Cutting system drive gear .........
  • Page 404 Locking self-steering axle ......... 150 Menu 4 Bale scales .......... 177 Locking Steering Axle ........150 Menu 5 Moisture measurement ....... 179 Locking the tying process ......... 274 Menu 5-1 Alarm message for moisture measurement ..........180 Logical Alarms ..........218 Menu 5-2 Correction value for moisture Lower the bale chute ........
  • Page 405 Overload coupling on flywheel ......378 Safety stickers on the machine ......33 Overload protection ..........75 Scope of Document ........... 14 Overload Protections .......... 60 Secure knotter shaft ......... 230 Securing guide wheels ........129 Securing side guard ......... 128 Packer gearbox ..........
  • Page 406 Stopping and securing the machine ....30 Terminal – Machine Functions (Medium/Comfort) ..............139 Stowing the compressed air hoses ....127 Terminal – Menus (Medium Plus/Comfort Plus Structural changes to the machine ..... 20 Version Electronics) ........226 Supporting lifted machine and machine parts Terminal –...
  • Page 407 Supplement to Operating Instructions Document no.: 150000774_00 _en    V.2 Large Square Baler BiG Pack 870 HDP, BiG Pack 870 HDP XC From machine no.: 940085...
  • Page 408 Changing to manual mode...................... 33 Switching the warning beacon on/off .................. 34 7.10 Selecting other functions ...................... 34 7.11 Switching the working light on/off .................... 34 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 409 General input/output error 521100 - 521299 ................ 83 8.16.1.5 Logical errors 522000 – 522099 .................... 84 8.16.1.6 Error message from sensors 522100 – 522299 ................  90 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 410 Contents 8.16.1.7 Error message from actuators 522300 – 522499 .............. 90 Circuit diagram [Medium Plus/Comfort Plus Electronics] ...........  92 Index............................ 158 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 411: Cross References

    • For further information, please refer to the operating instructions of the universal shaft manufacturer. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 412: How To Use This Document

    Position of a part (e.g. move from pos. I to pos. II) Dimensions (e.g. B = width, H = height, L = length) Tighten screws with specified tightening torque using torque wrench. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 413 WARNING The signal word WARNING warns of a hazardous situation which will result in serious injuries or death if the warning sign is ignored. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 414 Example: INFORMATION Each safety label is provided with an order number and can be ordered directly from the manufacturer or from the authorized specialist dealer. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 415: Intended Use

    For this reason, unauthorized modifications shall exclude any liability of the manufacturer for consequential damage. The intended use shall also include the adherence to the operating, maintenance and repair conditions set by the manufacturer. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 416: Service Life Of The Machine

    • Theoretically, the service life of this machine is unlimited as all worn or damaged parts can be replaced. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 417: Basic Safety Instructions

    When tractor and machine are connected incorrectly, dangers are caused which could lead to severe accidents. „ When connecting, observe all the operating instructions: • The operating instructions of the tractor • The operating instructions of the machine, Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 418: Structural Modifications On The Machine

    Thus there is a risk of serious injuries or death. The following parts of the machine are of special importance for safety: • Brakes • Steering • Safety devices • Connection fittings Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 419: Danger Zones

    „ Keep people away from the danger zone of the tractor and the machine. „ Do not switch on the drives and engine until there is nobody in the danger zone. The safety clearance is: Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 420 „ Before starting the machine, instruct all persons to leave the danger zone of the machine. „ In case of dangerous situations, immediately switch off drives and instruct persons to leave the danger zone. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 421: Ensuring Functionality Of Safety Devices

    „ Make sure every time after cleaning the safety labels that they are complete and legible. „ Immediately replace missing, damaged and unrecognizable safety labels. „ Provide spare parts with intended safety labels. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 422: Road Safety

    „ Before adjusting, repairing, servicing and cleaning the machine, ensure that it is securely positioned. „ Note section “Parking the machine” in chapter Driving and Transport, . Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 423: Consumables

    „ Warn persons: Do not approach the machine. Electrical voltage on the ground may lead to severe electric shocks. „ Wait for help from professional rescue teams. The overhead line must be switched off. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 424: Sources Of Danger On The Machine

    The following components may become hot during operation: • Capacitor (optional) „ Maintain a sufficient distance from hot surfaces. „ Allow machine parts to cool down and wear protective gloves. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 425: Dangers In Connection With Certain Activities: Climbing Up And Down

    „ Before performing any work on or under the raised machine or machine parts, secure the machine or machine parts with rigid safety support or with hydraulic shut-off device or by supporting against lowering. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 426: Dangers In Connection With Certain Activities: Working On Wheels And Tyres

    Wheel assembly and tyre assembly require sufficient knowledge and prescribed mounting tool. „ If there is a lack of knowledge, have the wheels and tyres fitted by the KRONE dealer or by a qualified tyre service.

  • Page 427: Safety Routines

    Therefore they must not be used. „ Car jacks are also not suitable for safely supporting the machine and machine parts. They must not be used, as well. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 428: Safely Perform Oil Level Check, Oil And Filter Element Change

    „ The actuator test must only be performed from a safe position outside the area that is affected by machine parts moved by the actuators. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 429: Foreign Isobus Terminal

    When using terminals and other operation units which have not been delivered by KRONE mind that the user: ü assumes the responsibility for the use of KRONE machines when using the machine on operation units (terminal / other operating elements) which have not been delivered by KRONE.

  • Page 430: Scroll Wheel

    Only the functions which differ from the KRONE ISOBUS terminal are described below. 6.2.1 Scroll wheel The scroll wheel is used to set the following values on the KRONE ISOBUS terminal • Target bale channel flap pressure/target bale channel flap force •...

  • Page 431: Terminal - Machine Functions [Medium Plus/Comfort Plus Electronics]

    „ When alarm message is displayed, remedy the malfunction, refer to page 79. „ If the malfunction cannot be remedied, contact KRONE customer service. Status line INFORMATION Using a terminal with a resolution of less than 480x480 pixels.

  • Page 432: Keys

    The available icons comply with the equipment of the machine. The following represented icons are not always available. Icon Designation Explanation Switch off warning beacon refer to page 34 Switch on warning beacon refer to page 34 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 433 When the speed of the starting aid is reached, the system switches off the starting aid. refer to page 35 Select the machine menu refer to page 36 level Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 434 Raise blade cassette refer to page 37 Lower blade cassette refer to page 37 Close bale channel flaps refer to page 36 Open bale channel flaps refer to page 36 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 435: Displays On The Working Screen

    1 arrow: Low change in direction required. • 3 flashing arrows: Greater change in direction required. • The direction display can be set, refer to page 52 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 436 When the knotter signal is activated, a horn sounds for approx. 1 s, refer to page 48. Bale ejector active Self-steering axle locked Warning beacon switched Warning beacon switched Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 437: Displays On The Information Bar

    In min Operating hours counter Counts only when PTO shaft is running. The adjacent number indicates the selected customer counter (customer counter 19 in the example). Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 438: Selecting Working Screens

    Road travel screen Example menu EQ000-011 / EQ000-157 From each menu ü A menu has been selected. „ Press longer. From the road travel screen „ Press Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 439: Calling Up Road Travel Screen

    „ Press AUTO Æ The display shows the icon (automatic mode). Changing to manual mode AUTO „ Press Æ The display shows the icon (manual mode). Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 440: Switching The Warning Beacon On/Off

    Æ The display switches from 7.11 Switching the working light on/off Switching ON „ Press Æ The display switches from Switching off „ Press Æ The display switches from Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 441: Releasing/Locking Self-Steering Axle

    When the speed of the starting aid is reached, the system switches off the starting aid. Switching off „ To switch off the starting aid, press Æ The display switches from Æ The starting aid is switched off. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 442: Opening/Closing Bale Channel Flaps

    „ To bring up the menu level from the working screen, press Æ The display indicates the menu level. 7.19 Reset bale length to zero „ Press for approx 2 s. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 443: Trigger Knotter

    The bale channel flap pressure is displayed in bar or PSI depending on selected system of units. 38 % 94 / 4 cm EQG000-030 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 444: Setting Target Baling Force (Automatic Mode)

    38 % 94 / 4 cm EQG000-032 Value (1) and the bar display = actual bale length Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 445: Setting The Target Number Of Multibales

    The following functions are available in the “Auxiliary” (AUX) menu: auxiliary Function Raise blade cassette Lower blade cassette Increase baling pressure/baling force Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 446: Auxiliary Configuration Of A Joystick

    For further information, please refer to the operating instructions of the used terminal. 7.26.2 Auxiliary configuration of a joystick Recommended configuration of a Fendt joystick EQ001-018 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 447 Terminal – machine functions [Medium Plus/Comfort Plus Electronics] Operating machine via joystick 7.26 Recommended configuration of a WTK joystick EQ001-019 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 448: Terminal - Menus [Medium Plus/Comfort Plus Electronics]

    Alarm message for moisture measurement, refer to page 56 Correction value for moisture measurement, refer to page 56 Silage additive system, refer to page 58 Counter, refer to page 58 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 449: Recurring Icons

    Move up in order to select something. Arrow pointing down Move down in order to select something. Arrow pointing to the right Move to the right in order to select something. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 450: Bring Up Menu Level

    Depending on how the machine is equipped, the menu level 4 is divided into the following menus: Icon Designation Menu 1 "Knotter", refer to page 47 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 451: Selecting Menu

    „ Select the desired menu by means of scroll wheel. ð The selected menu is highlighted in colour. „ To call up the menu, press the scroll wheel. Æ The menu opens. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 452: Changing Value

    Æ The setting is saved and the input mask closes. By means of value „ Tip the value. ð An input mask opens. „ Increase or reduce value. „ Press to save the value. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 453: Changing Mode

    Menu 1-3 "Knotter monitoring", refer to page 49 Menu 1-4 "Blowing interval", refer to page 50 Menu 1-5 "Blowing time", refer to page 50 Menu 1-9 "Calibrate MultiBale", refer to page 51 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 454: Menu 1 "Knotter

    ü Menu 1 "Knotter" has been selected, refer to page 47. „ To open the menu, press Æ The display shows the "Knotter signal" menu. Recurring icons refer to page 43. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 455: Menu 1-3 "Knotter Monitoring

    Icon Designation Explanation Knotter monitoring The upper twines are individually activated monitored. Mode 1/2 Knotter monitoring The upper twines are not monitored. deactivated Mode 2/2 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 456: Menu 1-4 "Blow Interval

    EQ001-005 / EQ001-063 ü Menu 1 "Knotter" has been selected, refer to page 47. „ To open the menu, press Æ The display shows the "Blowing time" menu. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 457: Menu 1-9 "Calibrate Multibale

    Moving lock to "MultiBale" position 4,9V 4,9V 1,1V EQ001-082 / BP000-389 „ Press and hold down until the centre bar and the left bar are the same height. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 458: Menu 2 "Sensitivity Of Direction Display

    EQ001-003 / EQ001-064 ü The menu level is called, refer to page 44. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 459: Menu 3 "Central Lubrication

    Factory setting: 20 min Lubrication pause • Not adjustable • Factory setting: 5 min Manually actuate The central lubrication is switched off. intermediate lubrication Actuating intermediate lubrication „ Press Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 460: Menu 4 "Bale Scales

    Æ If the displayed value corresponds to the weight of the test weight, it is not necessary to adjust the bale scales. Æ If the displayed value differs from the weight of the test weight, the bale scales must be adjusted. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 461: Menu 5 "Moisture Measurement

    Æ The icon is briefly displayed and the value is saved. INFORMATION „ If the limit range is not adequate to adjust the bale scales, contact KRONE customer service. Zeroising bale scales If there is no bale (weight) on the bale scales, but a value (2) is displayed, when the bale chute is lowered, the sensors B55 "Bale chute at rear"...

  • Page 462: Menu 5-1 "Alarm Message For Moisture Measurement

    In this menu a correction value can be set for the moisture measurement if the displayed value deviates from the value of an external measuring system. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 463 (1) matches the measured value. „ To save the value, press Æ The icon is displayed briefly. Æ The value is saved. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 464: Menu 6 "Silage Additive System

    Mode 3/3 Changing mode „ Call up and save mode, refer to page 47. 8.13 Menu 13 "Counters" EQ001-003 / EQ001-008 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 465: Menu 13-1 "Customer Counter

    Tap the icon to select the detail counter, refer to page 60. Recurring icons refer to page 43. Icon Designation Explanation Display detail counter Displays counter information for the selected customer counter. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 466 Selecting the customer counter ü The detail counter has been selected. „ To return to the customer counter, press Keys Icon Designation Increase number of bales Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 467 „ To select the customer counter, press „ Press ð The selected customer counter is reset to zero. ð The designation of the customer counter is not deleted. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 468: Menu 13-2 "Total Counter

    For the "bale scales" version: the "Average weight" counter 8.13.2 Menu 13-2 "Total counter" 13-2 EQ001-008 / EQ001-072 ü The main menu 13 "Counter" has been selected, Menu 13 “Counters”. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 469 Can be deleted Season counter 2 Can be deleted Recurring icons refer to page 43. Resetting season counter „ Press Æ The season counter is reset to zero. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 470: Menu 14 "Isobus

    The joystick icon is shown in the display. When functions are operated via joystick, the display lists the icons of these functions. The functions are not executed in this menu. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 471: Menu 14-2 "Driving Speed Display Diagnostics/Direction Display Diagnostics

    The direction of travel of the tractor is If the evaluation of the ISOBUS data not evaluated for locking the steering from the tractor has not been axle. activated. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 472: Menu 14-3 "Configuring Main Window

    In min Operating hours counter Counts only when PTO shaft is running. The adjacent number indicates the selected customer counter (customer counter 19 in the example). Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 473: Menu 14-4 "Set Background Colour

    Æ The display shows menu “Background Colour “. Recurring icons refer to page 43. Display range One of three modes can be selected. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 474: Menu 14-9 "Switching Between The Terminals

    The loading process may take a few minutes. EQG000-013 ü Menu 14 “ISOBUS” is called, refer to page 64. „ To change to the next terminal, press Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 475: Menu 15 "Settings

    There is no guarantee the machine is working correctly until after the sensors have been adjusted. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 476 Sensor Designation Flywheel brake Blade cassette up Monitoring lubricant flow Baling ram at rear (measure) Baling ram at front (calibrate) Speed of packer Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 477 Pick-up speed Position of needle connecting rod Bale on chute Pick-up position Blade cassette active Pressure sensor cutting rotor Speed sensor cardan shaft Cutting rotor speed Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 478 Bale scales at front Speed of knotter cleaning Twine box on left locked Twine box on right locked Twine box on left maintenance Twine box on right maintenance Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 479 0,6V 3,1V EQ000-042 Possible pushbuttons (depending on the machine configuration) Pushbutto Designation "Raise blade cassette" pushbutton "Lowerblade cassette" pushbutton "Move in residual bale ejector" pushbutton Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 480: Checking/Adjusting Sensor B22 "Bale On Chute

    Sensor B22 has been preset in the works of the manufacturer. Due to high operational demands and settling of components, the sensor may have to be adjusted. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 481 ü The machine is shut down and safeguarded, refer to page 21. „ Check dimension X, measured between the signal sheet (3) and the sensor (4). Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 482: Menu 15-2 "Actuator Test

    Bale chute valve ring side Residual bale ejector piston side Residual bale ejector ring side Blade cassette valve ring side Blade cassette valve piston side Open bale channel flaps Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 483 Knotter cleaning valve 1 Knotter cleaning valve 2 Engine lubricants Knotter triggering engine Working lights Working lights H105 H105 Twine box horn K100 Warning beacon Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 484: Menu 15-3 "Software Info

    „ Press to open the menu. Æ The display shows menu “Error List”. Meaning, cause and elimination of error messages refer to page 79. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 485: Alarm Messages

    „ When alarm message is displayed, remedy the malfunction, refer to page 79. „ If the malfunction cannot be remedied, contact KRONE customer service. KMC - 522064- 7 EQG000-034 The display shows an alarm message if a malfunction occurs on the machine. At the same time an audio signal will be heard (continuous horn sound).

  • Page 486: General Information On Error Messages

    The data is not plausible or too low. The conditions of the message have been met. 8.16.1.2 Cable break, short circuit Short circuit to ground Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 487 There is a short circuit. Possible cause: The cable is damaged and the supply lines to the sensors are connected to each other. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 488 BusOff on CAN 1 520193-19 BusOff on CAN 2 520194-19 BusOff on CAN 3 520195-19 BusOff on CAN 4 522535-19 Timeout for the RMC control unit detected. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 489: General Input/Output Error 521100 - 521299

    FMI 5: There is a cable break, general error or overload. Error number Designation Icon 521100-5 Voltage group (UB1) 521101-5 Voltage group (UB2) High 521102-5 Voltage group (UB3) 521103-5 Voltage group (UB4) Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 490: Logical Errors 522000 - 522099

    Switch off the PTO shaft. travel" mode. • Switch the operating mode 522006-0 The cardan shaft is rotating more • Reduce cardan shaft speed. quickly than permitted. ERROR Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 491 The "Raise bale chute" pushbutton is • Eliminate the cause of the sticking. pushbutton sticking. • Replace the pushbutton. 522020-7 The "Lower bale chute" pushbutton is sticking. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 492 522033-0 On the upper twine 1…8 the • Check the knotter and knotter maximum twine length has been triggering. exceeded during knotting. • Set the sensor. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 493 On the upper twine 1…8 the • Set the sensor. minimum twine length for the packer feed has not been reached. 522042-1 522043-1 522044-1 522045-1 522046-1 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 494 2 of the knotter triggering. baling ram strokes. • Check the electronics in the area of the "MulitBale" lock. • Set the sensor. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 495 The "Move out residual bale ejector" pushbutton is sticking. 522073-12 Automatic mode is not possible • Lower the bale chute. because the bale chute at top has been lowered. Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...

  • Page 496: Error Message From Sensors 522100 - 522299

    8.16.1.7 Error message from actuators 522300 – 522499 All error messages from actuators are configured according to the following sample: e.g. error message "522301-6 " Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 497 Icon Designation Explanation SPN (Suspect Parameter Number) Error number Indicates the type of error, refer to page 80. Icon Meaning of the icons, refer to page 76 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 498 Circuit diagram [Medium Plus/Comfort Plus Electronics] Circuit diagram [Medium Plus/Comfort Plus Electronics] >>> 2 150 101 580_en STW-Rechner Stromlaufplan [} 93] Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 564 Circuit diagram [Medium Plus/Comfort Plus Electronics]............ 92 Climbing up and down safely ......19 Connecting the machine........11 Consumables ............. 17 Cross references ..........5 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 565 ..........56 Menu 5-2 "Correction value for moisture Keys ..............26 measurement" ..........56 Menu 6 "Silage additive system" ......58 Menu Structure ........... 42 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 566 Term “machine” ............ 6 Terminal – machine functions [Medium Plus/ Comfort Plus Electronics] ......25 Terminal – menus [Medium Plus/Comfort Plus Electronics]............ 42 Trigger knotter ............ 37 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 567 Unsuitable consumables ........17 Validity ..............5 Varying functions to KRONE ISOBUS terminal.. 23 Warning signs............7 Warnings of property damage and environmental damage ............8 Supplement to Operating Instructions 150000774_00 _en BiG Pack 870 HDP, BiG Pack 870 HDP XC...
  • Page 568 Maschinenfabrik Bernard Krone GmbH & Co. KG * Heinrich-Krone-Straße 10 D-48480 Spelle * Postfach 11 63 D-48478 Spelle ' +49 (0) 59 77 / 935-0 6 +49 (0) 59 77 / 935-339 ü http://wwww.krone.de @ info.ldm@krone.de...

This manual is also suitable for:

870 hdp xcBig pack 1290 hdp iiBig pack 1290 hdp ii (xc)Big pack 890Big pack 890 xcBig pack 1270 ... Show all

Table of Contents
