Table of Contents

Advertisement

Quick Links

Download this manual
BiG PACK 890
BiG PACK 890 XC
BiG PACK 1270
BiG PACK 1270 XC
(from serial no.: 883 288)
Order no.: 150 000 137 03 en
BiG PACK Baler
BiG PACK 1290
BiG PACK 1290 XC
BiG PACK 1290 HDP
BiG PACK 1290 HDP XC
05.11.2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Big Pack 890 and is the answer not in the manual?

Questions and answers

Related Manuals for Krone Big Pack 890

Summary of Contents for Krone Big Pack 890

  • Page 1 BiG PACK Baler BiG PACK 890 BiG PACK 1290 BiG PACK 890 XC BiG PACK 1290 XC BiG PACK 1270 BiG PACK 1290 HDP BiG PACK 1270 XC BiG PACK 1290 HDP XC (from serial no.: 883 288) Order no.: 150 000 137 03 en...
  • Page 2 Krone Big Pack Baler Machine: Type/types: Big Pack 890; Big Pack 1270; Big Pack 1290; Big Pack 1290 HDP Big Pack 890 XC; Big Pack 1270 XC; Big Pack 1290 XC; Big Pack 1290 HDP XC to which this declaration refers is in compliance with the relevant provisions of EC Directive 2006/42/EC (Machinery) and EC Directive 2004/108/EC (EMC) The signing Managing Director is authorised to compile the technical documents.

  • Page 3: Table Of Contents

    Table of Contents Pos: 3 /Überschriften/Überschriften 1/F-J/Inhaltsverzeichnis @ 31\mod_1251969952727_78.docx @ 302165 @ 1 @ 1 Table of Contents Pos: 4 /BA/Inhaltsverzeichnis Sprachenneutral @ 10\mod_1221574899104_0.docx @ 135495 @ @ 1 Table of Contents ........................... 3     Foreword ............................... 11    ...
  • Page 4 Table of Contents Drives ............................... 45     5.7.1 Main drive ............................ 45     Overload Protections on the Machine ..................... 47     5.8.1 Main drive ............................ 47     5.8.2 Feeder Packer ..........................48     5.8.3 Cutting System Drive for the Design with XC Cutting System ............ 49  ...
  • Page 5   8.4.1 Parking brake ..........................123     8.4.2 Wheel chocks ..........................124     KRONE ISOBUS-Terminal CCI 100 ....................125     Installing the terminal into cabin ....................126     ISOBUS Short Cut Button ......................127    ...
  • Page 6 Connection terminal to tractor....................208     10.1.2 Connection tractor to machine ....................208     10.2 Differing functions to KRONE ISOBUS terminal CCI ..............209     10.2.1 Menu 4-6 “Diagnostics driving speed display/direction of travel display” ......210     10.2.2 Menu 4-7 “Diagnostics Auxiliary (AUX)”...
  • Page 7 Table of Contents 11.5 Operating Bale Ejector ........................240     11.6 Parking Jack ..........................242     11.7 Hydraulic parking jack ........................243     11.8 Bale brake ............................244     11.8.1 Working floodlight ........................245     11.9 Initiating the Tying Process Manually ....................
  • Page 8     12.15.5 Setting the spring of the zero adjuster ................... 288     12.16 Setting the flywheel cleaning (only on BiG PACK 890) ............. 289     12.17 Basic setting of the band brake (flywheel) ................. 289    ...
  • Page 9     19.6 Lubrication points ........................... 332     19.6.1 Lubrication points BiG PACK 890 (XC), 1270 (XC), 1290 (XC) ..........332     19.6.2 Lubrication points BiG PACK 1290 HDP (XC) ............... 334     Maintenance – Central Lubrication....................340  ...
  • Page 10 Table of Contents 23.3.2 Double knotter ........................359     23.4 Troubleshooting in the central lubrication ..................370     Appendix ............................. 372     24.1 Hydraulic System Circuit Diagrams ....................372     24.2 On-Board Hydraulic System for Medium Version Electronics ............372  ...

  • Page 11: Foreword

    Pos: 6.2 /BA/Vorwort/Großpackenpressen/Verehrter Kunde BiG Pack @ 17\mod_1236162357058_78.docx @ 201236 @ @ 1 Dear Customer! By purchasing your BiG PACK baler, you have acquired a quality product from KRONE. We are grateful for the confidence you have invested in us in buying this machine.
  • Page 12 Foreword Pos: 8 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ @ 1 This page has been left blank deliberately!! Pos: 9 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...

  • Page 13: To This Document

    These operating instructions apply to Big Pack Square Balers of the following types: BiG PACK 890 BiG PACK 1270 BiG PACK 1290 BiG PACK 1290 HDP BiG PACK 890 XC BiG PACK 1270 XC BiG PACK 1290 XC BiG PACK 1290 HDP XC In the HighSpeed design.

  • Page 14: Safety

    Pos: 19 /BA/Einleitung/Maschinenübersicht/Großpackenpressen/Verwendungszweck BiG Pack HS Baureihe @ 93\mod_1327323688288_78.docx @ 786957 @ @ 1 KRONE Big Pack square balers are machines for collecting and baling cut crops (grass, hay, leguminous vegetation and straw, etc.) on farms. They are towed behind agricultural tractors of sufficient power that are also equipped with suitable interfaces for the installation and operation of the machine (see the introductory chapter "Technical Data"...

  • Page 15: Personnel Qualification And Training

    Safety Pos: 23.1 /BA/Sicherheit/Personalqualifikation und -schulung @ 0\mod_1195639383185_78.docx @ 1136 @ 3 @ 1 4.2.1 Personnel Qualification and Training The machine may be used, maintained and repaired only by persons who are familiar with it and have been instructed about the dangers connected with it. The operator must define areas of responsibility and monitoring of personnel.

  • Page 16: Safety Instructions And Accident Prevention Regulations

    Safety Pos: 23.5 /BA/Sicherheit/Sicherheits- und Unfallverhütungs-Vorschriften Swadro_Ladewagen_EasyCut @ 73\mod_1308298589597_78.docx @ 655493 @ 2 @ 1 Safety Instructions and Accident Prevention Regulations Please follow all generally applicable safety and accident prevention regulations in addition to the safety instructions contained in these operating instructions! The attached warning and safety signs provide important information for safe operation.

  • Page 17: Hitched Implements

    Safety Parts operated by external power (e.g. hydraulically) can cause crushing and shearing injuries! Before leaving the tractor, lower the implement onto the ground, apply the parking brake, switch off the engine and remove the ignition key! Pos: 23.6 /BA/Sicherheit/Angehängte Geräte/Geräte angehängt @ 0\mod_1199699679381_78.docx @ 33245 @ 22 @ 1 Hitched Implements 1...

  • Page 18: Pto Operation

    Safety Pos: 23.8 /BA/Sicherheit/Zapfwellenbetrieb Traktor @ 0\mod_1199699899350_78.docx @ 33264 @ 2 @ 1 PTO operation 1 Use only PTO shafts specified by the manufacturer! 2 The guard tube and guard cone of the PTO shaft and the PTO guard must be attached and in good working condition (on the implement side, too)! 3...

  • Page 19: Hydraulic System

    Safety Pos: 23.12 /BA/Sicherheit/Hydraulikanlage @ 2\mod_1203503691986_78.docx @ 66225 @ 2 @ 1 Hydraulic system 1 The hydraulic system is pressurised! 2 When connecting hydraulic cylinders and motors, make sure the hydraulic hoses are connected as specified! 3 When connecting the hydraulic hoses to the tractor hydraulics, make sure that the hydraulics of both the tractor and the implement have been depressurized! 4...

  • Page 20: Maintenance

    8 Replacement parts must at least comply with the technical requirements set by the manufacturer of the implements! This is guaranteed by original KRONE spare parts! Pos: 23.20 /BA/Sicherheit/Wartung/Wartung Zusatz Bei Gasspeicherung/Schneidwekzeuge @ 2\mod_1203504102830_78.docx @ 66265 @ @ 1 9...

  • Page 21: Introduction

    4.12 Introduction The KRONE BiG PACK baler is equipped with all safety devices (protective equipment). However, it is not possible to eliminate all potential hazards on this machine as this would impair its full functional capability. Hazard warnings are attached to the machine in the relevant areas to warn against any dangers.

  • Page 22: Position Of The Adhesive Safety Stickers On The Machine

    Safety Pos: 28 /Überschriften/Überschriften 2/K-O/Lage der Sicherheitsaufkleber an der Maschine @ 0\mod_1195634967326_78.docx @ 1020 @ 2 @ 1 4.13 Position of the Adhesive Safety Stickers on the Machine Pos: 29 /BA/Sicherheit/Aufkleber/Großpackenpresse/Sicherheitsaufkleber BiG Pack 890_1270_1290 HS Baureihe @ 134\mod_1351145087023_78.docx @ 1194755 @ @ 1 BPHS0006_1 Fig.
  • Page 23 Safety Before starting the machine, The P.T.O. speeds must not exceed 1000 rpm! read and follow the operating The operating pressure of the hydraulic system instructions and safety must not exceed 200 bar /2900 PSI! instructions. 939 101-4 1000/ MAX. Order No.
  • Page 24 Safety BPHS0115 Fig. 2 Right-hand side of the machine...
  • Page 25 Safety Danger from rotating auger. Never reach into the working area of the pick-up as long as Order No. 939 520 1 (1x) the machine is running. Order No. 939 407-1 (1x) 939 520-1 Before start-up, close the protective equipment! While parts are moving, never reach into areas where there is a risk of being crushed.

  • Page 26: Position Of The General Information Labels On The Machine

    Safety Pos: 32 /Überschriften/Überschriften 2/K-O/Lage der allgemeinen Hinweisaufkleber an der Maschine @ 0\mod_1195635067920_78.docx @ 1039 @ 33 @ 1 4.14 Position of the General Information Labels on the Machine Pos: 33 /BA/Sicherheit/Aufkleber/Großpackenpresse/Hinweisaufkleber BiG Pack 890_1270_1290 HS Baureihe @ 63\mod_1299667053910_78.docx @ 574530 @ @ 1 RH+LH RH+LH BPHS0023...

  • Page 27: Re-Ordering The Adhesive Safety And Information Labels

    The surface for affixing the adhesive label must be clean and free of dirt, oil and grease. Pos: 36 /Überschriften/Überschriften 3/A-E/Ansprechpartner @ 0\mod_1195569394286_78.docx @ 839 @ 33 @ 1 4.14.3 Contact Pos: 37 /Adressen/Adresse Maschinenfabrik KRONE Spelle @ 0\mod_1195568531083_78.docx @ 734 @ @ 1 Maschinenfabrik Bernard Krone GmbH Heinrich-Krone-Strasse 10 D-48480 Spelle (Germany) Telephone: + 49 (0) 59 77/935-0 (Head Office) Fax.: + 49 (0) 59 77/935-339 (Head Office)

  • Page 28: Safety Equipment

    Safety Pos: 41.1 /Überschriften/Überschriften 2/P-T/Sicherheitsausstattung @ 17\mod_1236613960651_78.docx @ 205812 @ 232 @ 1 4.15 Safety Equipment Pos: 41.2 /Überschriften/Überschriften 3/A-E/Aufstiegsleiter @ 17\mod_1236246728956_78.docx @ 203788 @ 3 @ 1 4.15.1 Ladder Pos: 41.3 /BA/Sicherheit/Aufstiegsleiter/Aufstiegsleiter Gefahr Zugang zur Maschine @ 17\mod_1236246891378_78.docx @ 203814 @ @ 1 DANGER! –...
  • Page 29 Safety Pos: 41.9 /BA/Sicherheit/Aufstiegsleiter/Hinweis Verriegelung bei Straßen- / Aufstiegs und Abstiegsposition sichern @ 32\mod_1253610307024_78.docx @ 315184 @ @ 1 Note Make sure that the lock on the ladder is always properly engaged at every position (road/climbing/dismounting position). Pos: 41.10 /BA/Sicherheit/Aufstiegsleiter/Aufstieg HS Baureihen einschiebbare Aufstiegleiter @ 192\mod_1381989250958_78.docx @ 1635493 @ 3 @ 1 Ascending The ladder (1) must be pulled down for ascending to the top of the machine.

  • Page 30: Fire Extinguisher

    Safety Pos: 41.16 /Überschriften/Überschriften 3/F-J/Feuerlöscher @ 17\mod_1236247698456_78.docx @ 203839 @ 3 @ 1 4.15.2 Fire extinguisher Pos: 41.17 /BA/Sicherheit/Feuerlöscher/Feuerlöscher Big Pack Bild HS Baureihe @ 62\mod_1299480241001_78.docx @ 571585 @ 3 @ 1 BPHS0008 Fig.7 Pos: 41.18 /BA/Sicherheit/Feuerlöscher/Feuerlöscher Text BiG Pack @ 62\mod_1299479944306_78.docx @ 571558 @ @ 1 The machine is equipped with a fire distinguisher (1) ex works.

  • Page 31: Parking Brake

    Safety Pos: 41.24 /Überschriften/Überschriften 2/P-T/Standbremse / Feststellbremse @ 17\mod_1236322437416_78.docx @ 204755 @ 22 @ 1 4.16 Parking brake Pos: 41.25 /BA/Inbetriebnahme/Feststellbremse/Gefahr vor dem Abkuppeln Feststellbremse aktivieren @ 12\mod_1224070212321_78.docx @ 150212 @ 3 @ 1 Danger! - Unexpected movements of the machine Effect: Danger to life, serious injuries or damage to the machine Always engage the parking brake as soon as the machine is disconnected from the tractor.

  • Page 32: Flywheel Brake

    Safety Pos: 41.31.1 /Überschriften/Überschriften 2/P-T/Schwungradbremse @ 71\mod_1305785577816_78.docx @ 639924 @ 32 @ 1 4.17 Flywheel brake Pos: 41.31.2 /BA/Inbetriebnahme/Erstinbetriebnahme/Großpackenpressen/Schwungradbremse/Warnung Schwungradbremse @ 71\mod_1305786703933_78.docx @ 639964 @ 3 @ 1 WARNING! - Unexpected movements parts of the baler! Effect: Danger to life or serious injuries •...

  • Page 33: Parking Jack

    Safety Pos: 41.33 /Überschriften/Überschriften 2/P-T/Stützfuß @ 175\mod_1372676754261_78.docx @ 1502329 @ 2 @ 1 4.18 Parking Jack Pos: 41.34 /BA/Erstinbetriebnahme/Großpackenpressen/Abstellstütze/Abstellstütze Standfläche vergrößern @ 17\mod_1236319619729_78.docx @ 204459 @ @ 1 Note If the ground is soft, enlarge the footprint of the parking jack by placing a wooden plank underneath.

  • Page 34: Hydraulic Parking Jack (Optional)

    Safety Pos: 41.38 /Überschriften/Überschriften 3/F-J/Hydraulischer Stützfuß (optional) @ 17\mod_1236320698604_78.docx @ 204559 @ 313 @ 1 4.18.1 Hydraulic parking jack (optional) Pos: 41.39 /BA/Erstinbetriebnahme/Großpackenpressen/Abstellstütze/Abstellstütze Standfläche vergrößern @ 17\mod_1236319619729_78.docx @ 204459 @ 3 @ 1 Note If the ground is soft, enlarge the footprint of the parking jack by placing a wooden plank underneath.

  • Page 35: Shut-Off Valve Pick-Up

    Safety Pos: 41.49 /Überschriften/Überschriften 2/A-E/Absperrhahn Pick-up @ 155\mod_1363682265328_78.docx @ 1373791 @ 2 @ 1 4.19 Shut-Off Valve Pick-up Pos: 41.50 /BA/Erstinbetriebnahme/Großpackenpressen/Absperrhahn Pick-up Bild mit Legende @ 155\mod_1363682181297_78.docx @ 1373728 @ 2 @ 1 Fig. 14 Position (a) pick-up released Position (b) pick-up locked Pos: 41.51 /BA/Erstinbetriebnahme/Großpackenpressen/Absperrhahn Pick-up sperren Text @ 152\mod_1362738275226_78.docx @ 1357414 @ 1 @ 1 Always lock the pick-up via shut-off valve (1) when transporting the machine or when working under the baler.

  • Page 36: Machine Description

    Machine Description Pos: 43.1 /Überschriften/Überschriften 1/K-O/Maschinenbeschreibung @ 107\mod_1334231806004_78.docx @ 965201 @ 1 @ 1 Machine Description Pos: 43.2 /Überschriften/Überschriften 2/K-O/Maschinenübersicht @ 0\mod_1195565731130_78.docx @ 555 @ 2 @ 1 Machine overview Pos: 43.3 /BA/Einleitung/Maschinenübersicht/Großpackenpressen/Maschinenübersicht linke Seite mit Tandemachse Bild BP 890_1270_1290 HS Baureihe @ 190\mod_1381732621836_78.docx @ 1628834 @ 23 @ 1 5.1.1 Left Side of the BiG Pack Baler with Tandem Axle 9 10...
  • Page 37 Machine Description Pos: 43.5 /BA/Einleitung/Maschinenübersicht/Großpackenpressen/Maschinenübersicht linke Seite mit Tandemachse BP 890_1270_1290 HS @ 191\mod_1381732849098_78.docx @ 1628893 @ 2 @ 1 Wide-angle universal shaft Hydraulic oil storage tank Fire extinguisher Compressed air reservoir for the compressed air brake version Control valve block (work hydraulics) Job computer for comfort version electronics design only...
  • Page 38 Machine Description Pos: 43.7 /BA/Einleitung/Maschinenübersicht/Großpackenpressen/Maschinenübersicht rechte Seite mit Tandemachse Bild BP 890_1270_1290 HS Baureihe @ 191\mod_1381736430462_78.docx @ 1629035 @ @ 1 Right-hand Side of the Machine BPHS0003_2 Fig. 16 Pos: 43.8 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ 22 @ 1...
  • Page 39 Machine Description Pos: 43.9 /BA/Einleitung/Maschinenübersicht/Großpackenpressen/Maschinenübersicht rechte Seite Nachlauf-Lenkachse Text BP 890_1270_1290 HS @ 191\mod_1381736499559_78.docx @ 1629074 @ @ 1 Moisture measurement (optional) Central lubrication (grease) Twine brake Twine box right Compressed air reservoir (knotter Stopcock caster axle (optional) cleaning) Drawbar Pick-up drive Cutting system drive Variable filling system (VFS)

  • Page 40: Identification Plate

    Authentic KRONE spare parts and accessories authorised by the manufacturer help to ensure safety. The use of spare parts, accessories and other devices which are not manufactured, tested or approved by KRONE will result in the revoking of the liability for damages resulting thereof.

  • Page 41: Description Of The Baling Process

    Machine Description Pos: 43.17 /BA/Einleitung/Maschinenübersicht/Großpackenpressen/Beschreibung Pressvorgang @ 153\mod_1363008350826_78.docx @ 1359371 @ 2 @ 1 Description of the Baling Process When switching on the terminal, the terminal shows at first the manual mode basic screen. Starting with an empty bale channel In manual mode, pre-set the target bale channel flap pressure to 50 bar / 725 PSI (in case of dry crops, e.

  • Page 42: Compacting The Big Bale

    Machine Description Pos: 43.19 /BA/Einleitung/Maschinenübersicht/Großpackenpressen/Verdichten des Großpackens BP 1290 HDP II @ 151\mod_1362137260923_78.docx @ 1345221 @ 2233 @ 1 Compacting the BiG Bale The machine enables pressing hay and straw to a highly compacted big bale (square balers). The square baler is compacted in eight steps. The crop is picked up by the pick-up.

  • Page 43: Multibale Design

    Therefore, the set number of small bales depends on the bale length and the minimum length of the small bales. If you want to increase the number of small bales to max. 9 units, please contact your KRONE dealer. In case of 9 small bales, the variable length of the small bales is 30 cm to 135 cm.
  • Page 44 Machine Description Fig. 19 a) Big bale / length of the big b) Small bale / length of the c) Layer thickness of the bale small bale small bale / number of layers The bale length and the number of small bales (from 2 to 9) must only be set at the beginning of a bale to get ideal small bales.

  • Page 45: Drives

    Machine Description Pos: 43.24 /Überschriften/Überschriften 2/A-E/Antriebe @ 20\mod_1238751478183_78.docx @ 225045 @ 2 @ 1 Drives Pos: 43.25 /Überschriften/Überschriften 3/F-J/Hauptantrieb @ 20\mod_1238751529465_78.docx @ 225070 @ 22 @ 1 5.7.1 Main drive Pos: 43.26 /BA/Bedienung /Großpackenpresse/Antriebe/Hauptantrieb allgemein 1000 U/min HS Typen T1 @ 191\mod_1381825794687_78.docx @ 1631289 @ @ 1 Fig.
  • Page 46 Machine Description Pos: 43.30 /Überschriften/rechte Maschinenseite @ 60\mod_1297935179130_78.docx @ 562741 @ @ 1 Right-hand Side of the Machine Pos: 43.31 /Abkürzungen /Bei Ausführung mit Schneidwerk @ 157\mod_1364379388830_78.docx @ 1387653 @ @ 1 Design with cutting system Pos: 43.32 /BA/Bedienung /Großpackenpresse/Antriebe/Hauptantrieb allgemein 1000 U/min HS Typen T3 @ 192\mod_1382020204775_78.docx @ 1636720 @ @ 1 Fig.

  • Page 47: Overload Protections On The Machine

    Fig. 24 Pos: 43.41 /BA/Bedienung /Großpackenpresse/Überlastsicherungen / Kupplungen / Sternratsche / Scherschraube/Überlastsicherung am Schwungrad nur BiG PACK 890 @ 191\mod_1381836224357_78.docx @ 1632032 @ 2 @ 1 There are a friction clutch (1) and a cam-type clutch (2) on the flywheel.

  • Page 48: Feeder Packer

    Machine Description Pos: 43.44 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1270 HS / 1270 XC HS /1290 HS / 1290 XC HS / 1290 HDP HS / 1290 HDP XC HS @ 191\mod_1381835593370_0.docx @ 1631999 @ @ 1 BiG PACK 1270 HS (XC) / BiG PACK 1290 HS (XC) / BiG PACK 1290 HDP HS (XC) Pos: 43.45 /BA/Bedienung /Großpackenpresse/Überlastsicherungen / Kupplungen / Sternratsche / Scherschraube/Überlastsicherung am Schwungrad Bild 1270/1290/1290 HDP/4x4 HS Baureihe @ 191\mod_1381830017074_78.docx @ 1631697 @ 3 @ 1 Fig.

  • Page 49: Cutting System Drive For The Design With Xc Cutting System

    Machine Description Pos: 43.53 /Überschriften/Überschriften 3/P-T/Schneidwerkantrieb @ 192\mod_1382011621479_78.docx @ 1635994 @ 3 @ 1 5.8.3 Cutting System Drive for the Design with XC Cutting System Pos: 43.54 /BA/Bedienung /Großpackenpresse/Überlastsicherungen / Kupplungen / Sternratsche / Scherschraube/Überlastsicherung des Schneidwerks und der Pick-up, Ausführung HS mit Schneidwerk @ 136\mod_1353063267793_78.docx @ 1213945 @ 3 @ 1 Fig.

  • Page 50: Needle Yoke

    Machine Description Pos: 43.61 /Überschriften/Überschriften 3/K-O/Nadelschwinge @ 158\mod_1365140055004_78.docx @ 1405035 @ 23 @ 1 5.8.5 Needle Yoke Pos: 43.62 /BA/Bedienung /Großpackenpresse/Überlastsicherungen / Kupplungen / Sternratsche / Scherschraube/Überlastsicherung der Nadelschwinge / Scherschraube Bild alle HS-Typen außer 1290 HDP II @ 192\mod_1382077992442_78.docx @ 1637526 @ @ 1 Fig.

  • Page 51: Roller Crop Guide

    Machine Description Pos: 43.69 /Überschriften/Überschriften 2/P-T/Rollenniederhalter @ 0\mod_1201163046930_78.docx @ 51122 @ 21 @ 1 5.10 Roller crop guide Pos: 43.70 /BA/Maschinenbeschreibung/Maschinenübersicht/Funktionsweise/Rollenniederhalter mit Einzugwalze Funktionsbeschreibung Bild 1290 HDP II @ 157\mod_1364304469520_78.docx @ 1385728 @ 2 @ 1 Fig. 31 Feed drive roller Holding-down device roller Roller crop guide Retaining chain...

  • Page 52: Cutting System

    The cutting cylinder then takes over the function of a conveyor between the pick-up and the pre-baling channel. Pos: 43.75 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 890 HS BiG PACK 890 XC HS @ 190\mod_1381478581743_0.docx @ 1628239 @ @ 1 BiG PACK 890 HS / BiG PACK 890 XC HS Pos: 43.76 /BA/Einstellungen/Schneidwerk/Schnittlänge BigPack BiG PACK 890 HS mit 16 Messer @ 192\mod_1382080824345_78.docx @ 1637759 @ 3 @ 1...

  • Page 53: Cutting Length

    Machine Description Pos: 43.80 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1270 XC HS / 1290 XC HS / 1290 HDP XC HS @ 192\mod_1382081008983_0.docx @ 1637788 @ @ 1 BiG PACK 1270 HS XC / BiG PACK 1290 HS XC / BiG PACK 1290 HDP HS XC Pos: 43.81 /BA/Einstellungen/Schneidwerk/Schnittlänge BigPack mit 26 Messer @ 192\mod_1382079661221_78.docx @ 1637730 @ 3 @ 1 5.11.3 Cutting Length...

  • Page 54: Pressure Limiting Valve Block (On-Board Hydraulic System)

    Machine Description Pos: 43.85 /BA/Maschinenbeschreibung/BiG PAck/Preßkraftregulierung / Druckbegrenzungsventil-Block 890/1270/1290/1290 HDP (HS) @ 194\mod_1383579575073_78.docx @ 1650652 @ 22 @ 1 5.12 Pressure Limiting Valve Block (On-Board Hydraulic System) Fig. 32 Comfort version electronics design Medium version electronics design Depending on the equipment of the machine, the following valves are located on the pressure limiting valve block: Pressure gauge Pressure limiting valve to adjust the...

  • Page 55: Twine

    To ensure sufficient tying safety, you must be careful only to use synthetic twines with a running length of 100-130 m/kg. Pos: 43.93 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Hinweis Verwenden Sie nur KRONE Original Bindegarn @ 32\mod_1253083955561_78.docx @ 308448 @ @ 1 Note Only use original KRONE twine...
  • Page 56 Pos: 43.95 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Doppelknoter @ 20\mod_1239010038066_78.docx @ 226971 @ @ 1 Double knotter Pos: 43.96 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 890 HS BiG PACK 890 XC HS @ 190\mod_1381478581743_0.docx @ 1628239 @ @ 1 BiG PACK 890 HS / BiG PACK 890 XC HS Pos: 43.97 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 4 Doppelknoter 890 HS/Bidegarn verbinden im Garnkasten 4 Doppelknoter Bild 16 Rollen 2 Ober-/ Unterfäden @ 191\mod_1381843513756_78.docx @ 1632263 @ @ 1...
  • Page 57 To ensure sufficient tying safety, you must be careful only to use synthetic twines with a running length of 100-130 m/kg. Pos: 43.104 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Hinweis Verwenden Sie nur KRONE Original Bindegarn @ 32\mod_1253083955561_78.docx @ 308448 @ @ 1 Note Only use original KRONE twine...

  • Page 58: Electrical Twine Empty Display Lower Twine

    An error message appears in the display. Note To turn off the audio warning signal while twine is being fed in, refer to chapter KRONE ISOBUS terminal CCI 100 “Alarm Message”. Pos: 43.107 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ 3 @ 1...

  • Page 59: Twine Motion Indicator Upper Twine (Double Knotter)

    Machine Description Pos: 43.108 /BA/Bedienung /Großpackenpresse/Garnlaufanzeige Oberfaden (Doppelknoter) @ 20\mod_1238741788902_78.docx @ 224916 @ 3 @ 1 5.13.2 Twine motion indicator upper twine (double knotter) Fig. 37 The upper twine motion is monitored by reflectors (twine motion indicator) positioned above the machine.

  • Page 60: Knotter Gear

    Machine Description Pos: 43.112 /BA/Bedienung /Großpackenpresse/Knotergetriebe / Ruhestellung / Bindevorgang von Hand auslösen @ 168\mod_1367993844032_78.docx @ 1452575 @ 332 @ 1 5.14 Knotter Gear Fig. 39 Knotter gear in idle position The knotter gear is in idle position if the trigger roller (1) is located in the recess of the cam disc (2) of the knotter gear.

  • Page 61: Bale Ejector / Bale Chute

    Machine Description Pos: 43.114 /BA/Maschinenbeschreibung/Maschinenübersicht/Funktionsweise/Ballenausschieber / Rollenschurre betätigen Einführtext BP 890_1270_1290_1290 HDP_4x4 @ 173\mod_1371025842883_78.docx @ 1484464 @ 23 @ 1 5.15 Bale Ejector / Bale Chute BPHS0252 Fig. 40 Bale ejector (1) The operation of the bale ejector or the bale chute depends on the machine design (medium version electronics or comfort version electronics), refer to chapter Operation “Operating the Bale Chute”.

  • Page 62: For Comfort Version Electronics Design

    Machine Description Pos: 43.117 /BA/Maschinenbeschreibung/Maschinenübersicht/Funktionsweise/Ballenausschieber / Rollenschurre betätigen bei Ausführung Komfort-Elektronik @ 157\mod_1364316843931_78.docx @ 1386057 @ 3 @ 1 5.15.2 For Comfort Version Electronics Design: Fig. 42 On machines with comfort version electronics, external buttons (1, 2) are installed on the rear left machine side.

  • Page 63: Technical Data

    Pos: 46.1 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 890 HS BiG PACK 890 XC HS @ 190\mod_1381478581743_0.docx @ 1628239 @ @ 1 BiG PACK 890 HS / BiG PACK 890 XC HS Pos: 46.2 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 890 HS/Technische Daten: Abmessungen in Transportstellung BiG PACK 890 HS @ 136\mod_1353058807299_78.docx @ 1213628 @ 2 @ 1 Dimensions...
  • Page 64 Setting the baling density control (can be set from the tractor). Pos: 46.12 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 890 HS/Technische Daten: Preßkanal BiG PACK 890 HS @ 136\mod_1353327304941_78.docx @ 1215725 @ 2 @ 1 Bale channel / bale dimensions Height...
  • Page 65 Pos: 46.15 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 890 HS BiG PACK 890 XC HS @ 190\mod_1381478581743_0.docx @ 1628239 @ 2 @ 1 BiG PACK 890 HS / BiG PACK 890 XC HS Pos: 46.16 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/Technische Daten: Überlastsicherung / Scherschraube BiG PACK 890/1270/1290 HS @ 136\mod_1353327752664_78.docx @ 1215901 @ @ 1 Overload protection...
  • Page 66 BiG PACK 890 HS / BiG PACK 890 XC HS Pos: 46.22 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 890 HS/Technische Daten: Mindestanforderung an den Traktor BiG PACK 890 HS @ 137\mod_1353328597458_78.docx @ 1216075 @ 3 @ 1 Minimum tractor requirements...
  • Page 67 Pos: 46.27 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 890 HS BiG PACK 890 XC HS @ 190\mod_1381478581743_0.docx @ 1628239 @ @ 1 BiG PACK 890 HS / BiG PACK 890 XC HS Pos: 46.28 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 890 HS/Technische Daten: Bereifung 890 HS @ 192\mod_1382336084813_78.docx @ 1638957 @ @ 1 Tyre designation...
  • Page 68 Machine Description Pos: 50.1 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1270 HS BiG PACK 1270 XC HS @ 190\mod_1381479540345_0.docx @ 1628268 @ @ 1 BiG PACK 1270 HS / BiG PACK 1270 XC HS Pos: 50.2 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 1270 HSTechnische Daten: Abmessungen in Transportstellung BiG PACK1270 HS @ 190\mod_1381409127594_78.docx @ 1626491 @ @ 1 Dimensions Height 2875 mm...
  • Page 69 Machine Description Pos: 50.8 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1270 HS BiG PACK 1270 XC HS @ 190\mod_1381479540345_0.docx @ 1628268 @ @ 1 BiG PACK 1270 HS / BiG PACK 1270 XC HS Pos: 50.9 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/Technische Daten: Schneidwerk (XC) BiG PACK 1270/1290/1290 HDP HS @ 190\mod_1381411074266_78.docx @ 1626607 @ 2 @ 1 XC cutting system Number of blades Blade group control system...
  • Page 70 Pos: 50.15 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1270 HS BiG PACK 1270 XC HS @ 190\mod_1381479540345_0.docx @ 1628268 @ 3 @ 1 BiG PACK 1270 HS / BiG PACK 1270 XC HS Pos: 50.16 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/Technische Daten: Überlastsicherung / Scherschraube BiG PACK 890/1270/1290 HS @ 136\mod_1353327752664_78.docx @ 1215901 @ @ 1 Overload protection...
  • Page 71 Machine Description Pos: 50.21 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1270 HS BiG PACK 1270 XC HS @ 190\mod_1381479540345_0.docx @ 1628268 @ @ 1 BiG PACK 1270 HS / BiG PACK 1270 XC HS Pos: 50.22 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 1270 HSTechnische Daten: Mindestanforderung an den Traktor BiG PACK 1270 HS @ 190\mod_1381411584312_78.docx @ 1626753 @ @ 1 Minimum tractor requirements Power requirement without cutting system 85 kW (116 HP)
  • Page 72 Machine Description Pos: 50.27 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1270 HS BiG PACK 1270 XC HS @ 190\mod_1381479540345_0.docx @ 1628268 @ @ 1 BiG PACK 1270 HS / BiG PACK 1270 XC HS Pos: 50.28 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 1270 HS/Technische Daten: Bereifung 1270/1290 @ 192\mod_1382340182762_78.docx @ 1639384 @ 2 @ 1 Tyre designation Minimum Maximum...
  • Page 73 Machine Description Pos: 54.1 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1290 HS BiG PACK 1290 XC HS @ 190\mod_1381479610042_0.docx @ 1628297 @ @ 1 BiG PACK 1290 HS / BiG PACK 1290 XC HS Pos: 54.2 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 1290 HSTechnische Daten: Abmessungen in Transportstellung BiG PACK1290 HS @ 190\mod_1381411891693_78.docx @ 1626811 @ @ 1 Dimensions Height 3075 mm...
  • Page 74 Machine Description Pos: 54.8 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1290 HS BiG PACK 1290 XC HS @ 190\mod_1381479610042_0.docx @ 1628297 @ @ 1 BiG PACK 1290 HS / BiG PACK 1290 XC HS Pos: 54.9 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/Technische Daten: Schneidwerk (XC) BiG PACK 1270/1290/1290 HDP HS @ 190\mod_1381411074266_78.docx @ 1626607 @ @ 1 XC cutting system Number of blades Blade group control system...
  • Page 75 Pos: 54.15 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1290 HS BiG PACK 1290 XC HS @ 190\mod_1381479610042_0.docx @ 1628297 @ @ 1 BiG PACK 1290 HS / BiG PACK 1290 XC HS Pos: 54.16 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/Technische Daten: Überlastsicherung / Scherschraube BiG PACK 890/1270/1290 HS @ 136\mod_1353327752664_78.docx @ 1215901 @ @ 1 Overload protection...
  • Page 76 Machine Description Pos: 54.21 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1290 HS BiG PACK 1290 XC HS @ 190\mod_1381479610042_0.docx @ 1628297 @ @ 1 BiG PACK 1290 HS / BiG PACK 1290 XC HS Pos: 54.22 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 1290 HSTechnische Daten: Mindestanforderung an den Traktor BiG PACK 1290 HS @ 190\mod_1381412344708_78.docx @ 1626898 @ @ 1 Minimum tractor requirements Power requirement without cutting system 90 kW (122HP)
  • Page 77 Machine Description Pos: 54.27 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1290 HS BiG PACK 1290 XC HS @ 190\mod_1381479610042_0.docx @ 1628297 @ 3 @ 1 BiG PACK 1290 HS / BiG PACK 1290 XC HS Pos: 54.28 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 1270 HS/Technische Daten: Bereifung 1270/1290 @ 192\mod_1382340182762_78.docx @ 1639384 @ @ 1 Tyre designation Minimum Maximum...
  • Page 78 Machine Description Pos: 58.1 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1290 HDP HS BiG PACK 1290 HDP XC HS @ 190\mod_1381479648371_0.docx @ 1628326 @ @ 1 BiG PACK 1290 HDP HS / BiG PACK 1290 HDP XC HS Pos: 58.2 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 1290 HDP HSTechnische Daten: Abmessungen in Transportstellung BiG PACK 1290 HDP HS @ 190\mod_1381412556174_78.docx @ 1626986 @ @ 1 Dimensions Height 3110 mm...
  • Page 79 Machine Description Pos: 58.8 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1290 HDP HS BiG PACK 1290 HDP XC HS @ 190\mod_1381479648371_0.docx @ 1628326 @ @ 1 BiG PACK 1290 HDP HS / BiG PACK 1290 HDP XC HS Pos: 58.9 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/Technische Daten: Schneidwerk (XC) 1270/1290/1290HDP/1290 HDP II @ 166\mod_1367237578206_78.docx @ 1442379 @ @ 1 XC cutting system Number of blades 26 units...
  • Page 80 Machine Description Pos: 58.15 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1290 HDP HS BiG PACK 1290 HDP XC HS @ 190\mod_1381479648371_0.docx @ 1628326 @ @ 1 BiG PACK 1290 HDP HS / BiG PACK 1290 HDP XC HS Pos: 58.16 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 1290 HDP HSTechnische Daten: Überlastsicherung / Scherschraube BiG PACK 1290 HDP HS @ 190\mod_1381417263184_78.docx @ 1627161 @ 2 @ 1 Overload protection Friction clutch drive 3000 Nm...
  • Page 81 Machine Description Pos: 58.21 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1290 HDP HS BiG PACK 1290 HDP XC HS @ 190\mod_1381479648371_0.docx @ 1628326 @ 2 @ 1 BiG PACK 1290 HDP HS / BiG PACK 1290 HDP XC HS Pos: 58.22 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/Technische Daten: Mindestanforderung an den Traktor BiG PACK 1290 HDP HS @ 190\mod_1381417967120_78.docx @ 1627277 @ @ 1 Minimum tractor requirements Power requirement without cutting system 130 kW (177 HP)
  • Page 82 Machine Description Pos: 58.27 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1290 HDP HS BiG PACK 1290 HDP XC HS @ 190\mod_1381479648371_0.docx @ 1628326 @ @ 1 BiG PACK 1290 HDP HS / BiG PACK 1290 HDP XC HS Pos: 58.28 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/BiG PACK 1290 HDP HSTechnische Daten: Bereifung 1290 HDP @ 190\mod_1381414172547_78.docx @ 1627132 @ @ 1 Tyre designation Minimum Maximum...

  • Page 83: Lubricants

    Pos: 62.4 /BA/Einleitung/Technische Daten/Grosspackenpresse/BiG PACK 890_1270_1290 HS_1290 HDP HS/Technische Daten: Betriebsstoffe Getriebe BiG Pack 890_1270_1290 HS Baureihe @ 191\mod_1381739919969_78.docx @ 1629690 @ @ 1 Designation Filling Bio-degradable Filtered lubricants quantity lubricants [litres] Main gearbox BiG PACK 890 HS 15.5 l Main gearbox BiG PACK 1270 HS 16.7 l Main gearbox BiG PACK 1290 HS 16.7 l SAE 90 GL 4 or Esso-Spartan...

  • Page 84: Oil Quantities And Designations For The On-Board Hydraulic System

    Machine Description Pos: 62.6 /Überschriften/Überschriften 3/F-J/Füllmenge und Ölbezeichnung der Bordhydraulik @ 17\mod_1236177374918_78.docx @ 201862 @ 33 @ 1 5.17.2 Oil quantities and designations for the on-board hydraulic system Pos: 62.7 /BA/Wartung/Umwelt/Hinweis Entsorgen / Lagern von Öle und Ölfilter Umwelt @ 32\mod_1253101375171_78.docx @ 311770 @ 33 @ 1 ENVIRONMENT! - Disposal and storage of used lubricants and oil filters Effect: Environmental damage Store or dispose used oil and oil filters according to statutory provisions.
  • Page 85 Machine Description Pos: 64 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ 1 @ 1 This page has been left blank deliberately!! Pos: 65 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...

  • Page 86: Commissioning

    Commissioning Pos: 66.1 /Überschriften/Überschriften 1/A-E/Erstinbetriebnahme @ 0\mod_1196314201498_78.docx @ 5855 @ 1 @ 1 Commissioning Pos: 66.2 /BA/Sicherheit/Gefahrenhinweise/Inbetriebnahme/Gefahr - Unvorhergesehene Inbetriebnahme_3 BiG Pack @ 17\mod_1236250951722_78.docx @ 204008 @ 3 @ 1 DANGER! - Accidental start-up of the machine, moving parts of the machine and / or unexpected movement of the machine! Effect: Danger to life, injuries or damage to the machine.

  • Page 87: Attaching Hydraulic Parking Jack

    Commissioning Pos: 66.6 /Überschriften/Überschriften 2/F-J/Hydraulischen Stützfuß anbauen @ 193\mod_1383215414302_78.docx @ 1646685 @ 2 @ 1 Attaching Hydraulic Parking Jack Pos: 66.7 /BA/Erstinbetriebnahme/Großpackenpressen/Bei Ausführung hydraulischer Stützfuß @ 193\mod_1383214866332_78.docx @ 1646602 @ @ 1 With hydraulic parking jack design. Pos: 66.8 /BA/Erstinbetriebnahme/Großpackenpressen/Hydraulischen Stützfuß anbauen Bild @ 193\mod_1383214808495_78.docx @ 1646573 @ @ 1 Fig.
  • Page 88 Commissioning Pos: 66.11 /BA/Erstinbetriebnahme/Großpackenpressen/Hydraulischen Stützfuß anbauen T2 @ 169\mod_1369381329007_78.docx @ 1464043 @ @ 1 Attaching hydraulic hoses. Fig. 44 Retracting parking jack connection Extending parking jack connection Collect escaping oil in a suitable container. • Screw provided unions (8) in the parking jack. •...

  • Page 89: Electrical Power Supply

    Commissioning Pos: 66.13 /Überschriften/Überschriften 2/P-T/Spannungsversorgung @ 28\mod_1250578107003_78.docx @ 275490 @ 22 @ 1 Electrical power supply Pos: 66.14 /BA/Erstinbetriebnahme/Spannungsversorgung/Dauerstromsteckdose Bild @ 36\mod_1260454934575_78.docx @ 336632 @ 2 @ 1 SW2000058 Fig. 45 Pos: 66.15 /BA/Erstinbetriebnahme/Spannungsversorgung/Steckdose an die 12V Batterie des Schleppers anschließen @ 36\mod_1260450375075_78.docx @ 336557 @ @ 1 The machine requires a voltage source for the power supplyof the on-board computer (control unit).

  • Page 90: Adjusting The Drawbar Height

    Commissioning Pos: 66.17 /Überschriften/Überschriften 2/F-J/Höhenanpassung der Deichsel @ 17\mod_1236255816988_78.docx @ 204061 @ 2 @ 1 Adjusting the drawbar height Pos: 66.18 /BA/Sicherheit/Gefahrenhinweise/Inbetriebnahme/Gefahr - Unvorhergesehene Inbetriebnahme_2 BiG Pack @ 17\mod_1236255571519_78.docx @ 204032 @ 2 @ 1 DANGER! - Unexpected movements of the machine! Effect: Danger to life, injuries or damage to the machine.

  • Page 91: Adjusting The Height Of The Drive Train

    Commissioning If the adjustment of the towing ring is not adequate, adjust the side parts (4). To do this: • Unscrew the screws (3) • Adjust the height of the front parts of the drawbar (4) to the height of the tractor hitch •...

  • Page 92: Pto Shaft

    Commissioning Pos: 66.23 /Überschriften/Überschriften 2/F-J/Gelenkwelle @ 0\mod_1199781879794_78.docx @ 34542 @ 22 @ 1 PTO shaft Pos: 66.24 /Überschriften/Überschriften 3/K-O/Längenanpassung @ 1\mod_1201687632810_78.docx @ 53589 @ 3 @ 1 6.5.1 Length adjustment Pos: 66.25 /BA/Sicherheit/Gelenkwelle/Gefahr - Sich drehende Gelenkwelle_3 @ 17\mod_1236258086816_78.docx @ 204184 @ @ 1 DANGER! - Rotating universal shaft! Effect: Danger to life or serious injuries •...
  • Page 93 Commissioning Pos: 66.28 /BA/Inbetriebnahme/Erstinbetriebnahme/Gelenkwelle/Großpackenpressen/Gelenkwelle kürzen Teil 2 @ 170\mod_1369728951081_78.docx @ 1467935 @ @ 1 X+2cm Fig. 49 • Connect the machine without universal shaft to the tractor • Move the machine to the narrowest position (driving around curves). • Switch off the engine of the tractor, remove the ignition key and secure the tractor and the machine from rolling away.
  • Page 94 Commissioning Pos: 66.30 /BA/Inbetriebnahme/Erstinbetriebnahme/Gelenkwelle/Großpackenpressen/Mit innerer Schmierleitung @ 170\mod_1369728863034_78.docx @ 1467827 @ @ 1 With inner lubrication line The inner lubrication lines may be cut when shortening the section tube inside. If this is the case, the lubrication lines must be removed and adjusted and a new access hole must be drilled.
  • Page 95 Commissioning Pos: 66.32 /BA/Inbetriebnahme/Erstinbetriebnahme/Gelenkwelle/Großpackenpressen/Gelenkhälften montieren @ 170\mod_1369728798111_78.docx @ 1467799 @ @ 1 Installing the PTO shaft halves Fig. 51 Inner PTO shaft half Outer PTO shaft half Section tube inside Raceway inside Fastening screw Guard tube inside Guard tube outside Protective sleeve Section tube outside Raceway outside...
  • Page 96 Commissioning Pos: 66.34 /BA/Inbetriebnahme/Erstinbetriebnahme/Gelenkwelle/Großpackenpressen/Verschiebeweg (Überlappung) ermitteln @ 170\mod_1369728715377_78.docx @ 1467771 @ @ 1 Determining the displacement path (overlapping) Fig. 52 • Lay the both PTO shaft halves in front of one another, the outer section tube is in front of the inner section tube.

  • Page 97: Adjusting The Hydraulic System

    Commissioning Pos: 66.36 /Überschriften/Überschriften 2/A-E/Anpassen des Hydrauliksystems @ 1\mod_1201241743588_78.docx @ 52013 @ 2 @ 1 Adjusting the hydraulic system Pos: 66.37 /BA/Wartung/Load-Sensing/Großpackenpresse/Bild Load-Sensing Anschluss HS Baureihe @ 64\mod_1300278753983_78.docx @ 582789 @ @ 1 Fig.53 Pos: 66.38 /BA/Wartung/Load-Sensing/Das Hydrauliksystem der Maschine ist werksseitig auf Dauerumlauf @ 121\mod_1343828402858_78.docx @ 1108849 @ @ 1 The hydraulic system of the machine is designed ex works for continuous circulation (the system screw (1) is completely screwed out).

  • Page 98: Setting The Bale Chute

    If the inclination of the bale chute is changed, the bale scale must be recalibrated if the machine has one (see chapter on KRONE ISOBUS terminal CCI "Calibrating the Bale Scale"). Pos: 67 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...

  • Page 99: Start-Up

    Start-up Pos: 68.1 /Überschriften/Überschriften 1/F-J/Inbetriebnahme @ 0\mod_1196327075811_78.docx @ 6375 @ 1 @ 1 Start-up Pos: 68.2 /BA/Sicherheit/Gefahrenhinweise/Inbetriebnahme/Gefahr - Unvorhergesehene Inbetriebnahme_3 BiG Pack @ 17\mod_1236250951722_78.docx @ 204008 @ 2 @ 1 DANGER! - Accidental start-up of the machine, moving parts of the machine and / or unexpected movement of the machine! Effect: Danger to life, injuries or damage to the machine.

  • Page 100: Mounting Onto The Tractor

    Start-up Pos: 68.5 /Überschriften/Überschriften 2/A-E/Anbau an den Traktor @ 0\mod_1199717845194_78.docx @ 34039 @ 2 @ 1 Mounting onto the Tractor Pos: 68.6 /BA/Sicherheit/Gefahrenhinweise/Großpackenpresse/Gefahr - An-/ Abau der Maschine BiG Pack @ 17\mod_1236256986675_78.docx @ 204111 @ 3 @ 1 DANGER! - Attaching / removing the machine Effect: Danger to life or serious injuries.

  • Page 101: Install The Pto Shaft

    Start-up Pos: 68.10 /Überschriften/Überschriften 3/F-J/Gelenkwelle montieren @ 11\mod_1223358863095_78.docx @ 145571 @ 3 @ 1 7.1.1 Install the PTO shaft Pos: 68.11 /BA/Sicherheit/Gelenkwelle/Gefahr - Sich drehende Gelenkwelle_4 @ 17\mod_1236258545347_78.docx @ 204209 @ @ 1 DANGER! - Rotating universal shaft! Effect: Danger to life or serious injuries •...
  • Page 102 Start-up Fig. 57 • Make certain there is sufficient free room in the swivel range of the universal shaft in all operating states. Contact with parts of the tractor or device may result in destruction. Pos: 68.17 /BA/Sicherheit/Gelenkwelle/Achtung - Schwenkbereich/Freiraum überprüfen @ 9\mod_1220536308930_78.docx @ 126898 @ 3 @ 1 Caution! - Swivel range of the PTO shaft Effect: Damage to the tractor or the machine •...

  • Page 103: Hydraulics

    Start-up Pos: 68.19 /Überschriften/Überschriften 2/F-J/Hydraulik @ 0\mod_1199776034950_78.docx @ 34205 @ 2 @ 1 Hydraulics Pos: 68.20 /Überschriften/Überschriften 3/P-T/Spezielle Sicherheitshinweise @ 0\mod_1197301069931_78.docx @ 17662 @ 3 @ 1 7.2.1 Special Safety Instructions Pos: 68.21 /BA/Sicherheit/Hydraulik/Warnung - Anschluss der Hydraulikleitungen @ 0\mod_1199776548685_78.docx @ 34225 @ @ 1 Warning ! - Connection of the hydraulic line Effect: severe injuries due to penetration of hydraulic oil under the skin.

  • Page 104: Connecting The Hydraulic Lines

    Start-up Pos: 68.26 /Überschriften/Überschriften 3/A-E/Anschluss der Hydraulikleitungen @ 0\mod_1199777037794_78.docx @ 34244 @ 3 @ 1 7.2.2 Connecting the hydraulic lines Pos: 68.27 /BA/Inbetriebnahme/Großpackenpresse/Hydraulik/Hydraulikanschluss Bild BiG Pack @ 17\mod_1236332366948_78.docx @ 204875 @ @ 1 Fig. 58 Pos: 68.28 /BA/Inbetriebnahme/Großpackenpresse/Hydraulik/Hydraulikanschluss allgemein Big Pack HS Baureihe @ 62\mod_1299495881531_78.docx @ 572211 @ @ 1 Depending on the version supplied a varying number of control units are required on the tractor to operate the machine.
  • Page 105 Start-up Pos: 68.34 /BA/Inbetriebnahme/Großpackenpresse/Hydraulik/Hydraulikanschlüsse an den Traktor ankuppeln Möglichkeit 3 Big Pack 1290 HDP II @ 151\mod_1362473189144_78.docx @ 1349420 @ @ 1 Tractor with constant current pump or Load Sensing system without Power Beyond: • Connect the pressure line (P/red1) to a single-acting control unit of the tractor. •...

  • Page 106: Hydraulic Brake (Export)

    Start-up Pos: 68.40 /Überschriften/Überschriften 2/F-J/Hydraulische Bremse (Export) @ 17\mod_1236332990291_78.docx @ 204927 @ 2 @ 1 Hydraulic brake (Export) Pos: 68.41 /BA/Inbetriebnahme/Hydraulische Bremse/Hydraulische Bremse Export Bild BiG Pack @ 17\mod_1236333975729_78.docx @ 204999 @ 33 @ 1 Fig. 59 Pos: 68.42 /BA/Inbetriebnahme/Hydraulische Bremse/Hydraulische Bremse (Export) @ 17\mod_1236333662166_78.docx @ 204952 @ @ 1 A hydraulic brake is provided for certain export versions.

  • Page 107: Hydraulic Brake (Export France)

    Start-up Pos: 68.44 /Überschriften/Überschriften 2/F-J/Hydraulische Bremse (Export Frankreich) @ 129\mod_1346767988893_78.docx @ 1155782 @ 33 @ 1 Hydraulic Brake (Export France) Pos: 68.45 /BA/Sicherheit/Bremsen/Warnung - hydraulische Bremse Frankreichausstattung Sicherheitskette zu kurz @ 129\mod_1346767273286_78.docx @ 1155665 @ @ 1 WARNING! Risk of injury and serious material damages due to unintentional braking of the machine If the safety chain is too short, it can tear off and lead to an emergency braking.

  • Page 108: Hydraulic Connection To Block The Coaster/Steering Axle (Special Equipment)

    Start-up Pos: 68.50 /BA/Inbetriebnahme/Großpackenpresse/Hydraulik/Hydraulischer Anschluß zur Sperrung der Nachlauf-Lenkachse @ 17\mod_1236334343354_78.docx @ 205027 @ 32 @ 1 Hydraulic connection to block the coaster/steering axle (special equipment) Connect the separate hydraulic hose from the locking cylinder of the steering axle (red 7) onto the single-acting control unit on the tractor.

  • Page 109: Supports For Compressed Air Hoses

    Start-up Pos: 68.56 /BA/Inbetriebnahme/Druckluftbremse/Halterungen der Druckluftschläuche BiG Pack @ 17\mod_1236339327416_78.docx @ 205147 @ 333 @ 1 7.6.1 Supports for compressed air hoses Fig. 62 Couple the compressed air hoses (1) into the corresponding supports (2) on the top of the drawbar.

  • Page 110: Electrical Connections

    Note The terminal is connected to the tractor via a special cable set (5) which can be ordered by stating the KRONE article no. 20 081 223 0. • Connect plug (2) of cable set (5) with socket (1) (CAN1-IN) of the terminal.

  • Page 111: Connecting The Terminal (On Tractors Without Isobus System)

    Start-up Pos: 68.61 /BA/Info-Center/CCI-ISOBUS-Terminal/Terminal anschließen (ohne ISO Schlepper) @ 43\mod_1274882231640_78.docx @ 387925 @ 43 @ 1 7.7.2 Connecting the terminal (on tractors without ISOBUS system) Fig. 64 Connection terminal to machine Note The connection of terminal to machine takes place via a provided cable set (5) (article no. 20 081 224 0).

  • Page 112: Lighting

    Start-up Pos: 68.63 /Überschriften/Überschriften 2/A-E/Beleuchtung @ 0\mod_1195658399935_78.docx @ 1881 @ 32 @ 1 Lighting Pos: 68.64 /BA/Inbetriebnahme/Großpackenpresse/Beleuchtung/Beleuchtung anschließen Bild HDP II @ 171\mod_1370344610812_78.docx @ 1475988 @ @ 1 BPHS0216 Fig. 65 Pos: 68.65 /BA/Inbetriebnahme/Schwader/Anschluss Beleuchtung/Anschluss Beleuchtung Text SW 2000/ 700_800_900/ 807-1 bis 810-1, 850, 900# @ 36\mod_1260783798936_78.docx @ 336718 @ 2 @ 1 The lighting system is connected via the 7-pin connection cable (1).
  • Page 113 Start-up Pos: 68.67.7 /Beipacks/Allgemein/Sicherheitskette 178 kN/Sicherungskette an den Traktor montieren Bild @ 147\mod_1361181563288_78.docx @ 1319688 @ 3 @ 1 Fig. 67 Pos: 68.67.8 /Beipacks/Allgemein/Sicherheitskette 89kN/Sicherheitskette am Traktor montieren Text @ 150\mod_1362048347829_78.docx @ 1343318 @ 1 @ 1 • Install safety chain (1) on an eligible position (for example: a or b) on the tractor. Pos: 69 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ 44 @ 1...

  • Page 114: Driving And Transport

    Driving and Transport Pos: 70.1 /Überschriften/Überschriften 1/F-J/Fahren und Transport @ 0\mod_1196330049217_78.docx @ 6553 @ 1 @ 1 Driving and Transport Pos: 70.2 /Überschriften/Überschriften 2/U-Z/Vorbereitungen zur Straßenfahrt @ 25\mod_1244092605963_78.docx @ 254666 @ 44 @ 1 Preparations for road travel Pos: 70.3 /BA/Sicherheit/Fahren und Transport/Warnung! Straßenfahrt,Mitfahren,Fahrverhalten BiG Pack @ 157\mod_1364375055813_78.docx @ 1386796 @ @ 1 Warning! –...

  • Page 115: Roller Chute Hydraulically Activated

    Driving and Transport Pos: 70.7 /BA/Fahren und Transport/Großpackenpresse/Folgende Arbeitsschritte werden in diesem Kapitel beschrieben Fahren und Transport @ 157\mod_1364375905147_78.docx @ 1387035 @ @ 1 The following work steps are described in this chapter: – Checking the lighting system. – Releasing the parking brake. –...

  • Page 116: Checking The Lighting System

    Driving and Transport Pos: 70.13 /Überschriften/Überschriften 3/A-E/Beleuchtungsanlage prüfen @ 25\mod_1244090937463_78.docx @ 254566 @ 33 @ 1 8.1.3 Checking the lighting system Pos: 70.14 /BA/Fahren und Transport/Großpackenpresse/Beleuchtungsanlage prüfen Bild BP 890_1270_1290 Hs Baureihe @ 62\mod_1299574637575_78.docx @ 572905 @ 4 @ 1 BPHS0011 Fig.70 Pos: 70.15 /BA/Fahren und Transport/Großpackenpresse/Beleuchtungsanlage prüfen Text @ 17\mod_1236588258401_78.docx @ 205489 @ @ 1...

  • Page 117: Handling The Coaster/Steering Axle (Special Equipment)

    Driving and Transport Pos: 70.20 /Überschriften/Überschriften 2/F-J/Handhabung der Nachlauf-Lenkachse (Sonderausstattung) @ 0\mod_1201167915356_78.docx @ 51383 @ 2 @ 1 Handling the Coaster/Steering Axle (Special Equipment) Pos: 70.21 /BA/Fahren und Transport/Nachlauf-Lenkachse/Nachlauflenkachse AX und MX Ladewagen/Vor Rückwärtsfahrt Nachlauf-Lenkachse in Geradeausstellung bringen und verriegeln @ 60\mod_1297781900981_78.docx @ 561023 @ @ 1 Before reversing, move coaster/steering axle to a straight position and lock.
  • Page 118 Driving and Transport Pos: 70.26 /BA/Einleitung/Maschinenübersicht/Großpackenpressen/Medium - Elektronik @ 61\mod_1299223169539_78.docx @ 570971 @ @ 1 Medium Version Electronics Pos: 70.27 /BA/Fahren und Transport/Nachlauf-Lenkachse/Nachlauflenkachse AX und MX Ladewagen/Verriegeln der Nachlauf-Lenkachse bei einfachwirkendem Hydraulik-Anschluss @ 60\mod_1297838187149_78.docx @ 561432 @ @ 1 With single action hydraulic connection •...

  • Page 119: Operating The Machine Via Ls (Load-Sensing Connection)

    Driving and Transport Pos: 70.33 /BA/Einleitung/Maschinenübersicht/Großpackenpressen/Komfort - Elektronik @ 61\mod_1299223046976_78.docx @ 570919 @ @ 1 Comfort - Electronic Pos: 70.34 /Überschriften/Überschriften 3/A-E/Betrieb der Maschine über LS (Load-Sensing-Anschluss) @ 91\mod_1326699464848_78.docx @ 780190 @ 3 @ 1 8.2.1 Operating the Machine via LS (Load-Sensing Connection) Pos: 70.35 /BA/Fahren und Transport/Nachlauf-Lenkachse/Nachlauf-Lenkachse Big Pack/Nachlauf-Lenkachse verriegeln Komfort Elektronik über Load Sensing @ 91\mod_1326702544634_78.docx @ 780363 @ 3 @ 1 •...

  • Page 120: Moving The Machine Without Hydraulic Connections

    Driving and Transport Pos: 70.45 /BA/Fahren und Transport/Nachlauf-Lenkachse/Nachlauf-Lenkachse Big Pack/Bei Option Nachlauf-Lenkachse rangieren HS Baureihe @ 62\mod_1299593571338_78.docx @ 573301 @ 3 @ 1 8.2.3 Moving the machine without hydraulic connections In order to be able to move the machine even when the hydraulic lines are not connected, the locking cylinder of the coaster/steering axle must be supplied with pressure before disconnection and the steered wheels aligned by driving straight ahead.

  • Page 121: Moving

    Driving and Transport Pos: 70.48.1 /Überschriften/Überschriften 2/P-T/Rangieren @ 13\mod_1225364693769_78.docx @ 155850 @ 2 @ 1 Moving Pos: 70.48.2 /Abkürzungen /Bei Ausführung Druckluftbremse @ 168\mod_1368456181882_78.docx @ 1456665 @ @ 1 With compressed air brake design Pos: 70.48.3 /BA/Sicherheit/Fahren und Transport/Rangieren @ 13\mod_1225361578519_78.docx @ 155656 @ @ 1 Danger! - Transport / road travel Effect: Danger to life, serious injuries or serious damage to the machine.

  • Page 122: Parking

    Driving and Transport Pos: 70.50 /Überschriften/Überschriften 2/A-E/Abstellen @ 0\mod_1199801980622_78.docx @ 35320 @ 2 @ 1 Parking Pos: 70.51 /BA/Sicherheit/Gefahrenhinweise/Großpackenpresse/Warnug - Maschine abstellen BiG Pack @ 172\mod_1370424957819_78.docx @ 1477885 @ 3 @ 1 WARNING! - Unexpected movements of the machine! Effect: Danger to life, serious injuries •...

  • Page 123: Parking Brake

    Driving and Transport Pos: 70.54 /Überschriften/Überschriften 3/P-T/Standbremse / Feststellbremse @ 25\mod_1242719474426_78.docx @ 253706 @ 3 @ 1 8.4.1 Parking brake Pos: 70.55 /BA/Inbetriebnahme/Feststellbremse/Gefahr vor dem Abkuppeln Feststellbremse aktivieren @ 12\mod_1224070212321_78.docx @ 150212 @ @ 1 Danger! - Unexpected movements of the machine Effect: Danger to life, serious injuries or damage to the machine Always engage the parking brake as soon as the machine is disconnected from the tractor.

  • Page 124: Wheel Chocks

    Driving and Transport Pos: 70.60 /Überschriften/Überschriften 3/U-Z/Unterlegkeile @ 33\mod_1254202555660_78.docx @ 318451 @ 3 @ 1 8.4.2 Wheel chocks Pos: 70.61 /BA/Fahren und Transport/Großpackenpresse/Unterlegkeile Bild BP 890_1270_1290 HS Baureihe @ 63\mod_1299668510278_78.docx @ 574581 @ @ 1 BPHS0024 Fig.76 Pos: 70.62 /BA/Fahren und Transport/Großpackenpresse/Unterlegkeile Text BP HS Baureihe @ 71\mod_1305799627493_78.docx @ 640727 @ 1 @ 1 The wheel chocks (1) are located at the rear on the right and left next to the bale channel chamber •...

  • Page 125: Krone Isobus-Terminal Cci 100

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.1 /Überschriften/Überschriften 1/K-O/KRONE ISOBUS-Terminal CCI 100 @ 43\mod_1274786526625_78.docx @ 387485 @ 13 @ 1 KRONE ISOBUS-Terminal CCI 100 Pos: 72.2 /BA/Info-Center/CCI-ISOBUS-Terminal/Hinweis Im weiteren Verlauf Terminal auch als Bedieneinheit bezeichnet @ 46\mod_1281680416671_78.docx @ 445465 @ @ 1 Note In the operating instructions which follow, the terminal will also be referred to as the "control...

  • Page 126: Installing The Terminal Into Cabin

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.6 /Überschriften/Überschriften 2/P-T/Terminal in Kabine einbauen @ 47\mod_1285163419265_78.docx @ 455855 @ 2 @ 1 Installing the terminal into cabin Pos: 72.7 /BA/Info-Center/CCI-ISOBUS-Terminal/Hinweis für den Anbau des Terminals, in die Traktorkabine... @ 47\mod_1285163596984_78.docx @ 455881 @ 2 @ 1...

  • Page 127: Isobus Short Cut Button

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.9.1 /Überschriften/Überschriften 2/F-J/ISOBUS Short Cut Button @ 47\mod_1285564773000_78.docx @ 456410 @ 2 @ 1 ISOBUS Short Cut Button Pos: 72.9.2 /BA/Info-Center/CCI-ISOBUS-Terminal/Module für Beipack/ISOBUS Short Cut ButtonISOBUS Short Cut Button_2 Gefahr @ 46\mod_1282643782875_78.docx @ 447376 @ @ 1 DANGER! –...
  • Page 128 KRONE ISOBUS-Terminal CCI 100 Pos: 72.9.5 /BA/Info-Center/CCI-ISOBUS-Terminal/Module für Beipack/ISOBUS Short Cut ButtonISOBUS Short Cut Button_wird gelöst @ 120\mod_1342516466580_78.docx @ 1088224 @ @ 1 If the ISOBUS short cut button is deactivated again, the following message will appear in the display: CC000071 Fig.

  • Page 129: Connecting The Terminal (On Tractors With Integrated Isobus System)

    Note The terminal is connected to the tractor via a special cable set (5) which can be ordered by stating the KRONE article no. 20 081 223 0. • Connect plug (2) of cable set (5) with socket (1) (CAN1-IN) of the terminal.

  • Page 130: Connecting The Terminal (On Tractors Without Isobus System)

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.13 /BA/Info-Center/CCI-ISOBUS-Terminal/Terminal anschließen (ohne ISO Schlepper) @ 43\mod_1274882231640_78.docx @ 387925 @ 3 @ 1 9.2.2 Connecting the terminal (on tractors without ISOBUS system) Fig. 82 Connection terminal to machine Note The connection of terminal to machine takes place via a provided cable set (5) (article no.

  • Page 131: Connecting The Multi-Function Lever To The Cci Terminal (On Tractors Without Isobus System)

    The terminal is connected to the multi-function lever via a special cable set (9) which can be ordered by stating the Krone product no. 20 081 676 0. Pos: 72.18 /BA/Info-Center/CCI-ISOBUS-Terminal/Multifunktionshebel an CCI Terminal anschließen (Traktor ohne ISOBUS System) Text @ 150\mod_1361884014200_78.docx @ 1340973 @ 2 @ 1 •...

  • Page 132: Switching The Terminal On / Off When The Machine Is Not Connected

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.20 /Überschriften/Überschriften 3/A-E/Ein- Ausschalten des Terminals bei nicht angeschlossener Maschine @ 43\mod_1275290766562_78.docx @ 389835 @ 3 @ 1 9.2.4 Switching the terminal on / off when the machine is not connected Pos: 72.21 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Ein- Ausschalten Bild mit nicht angeschlossener Maschine @ 43\mod_1275291241781_78.docx @ 389860 @ 3 @ 1 Fig.

  • Page 133: Switching The Terminal On / Off When The Machine Is Connected

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.25 /Überschriften/Überschriften 3/A-E/Ein- Ausschalten des Terminals bei angeschlossener Maschine @ 43\mod_1274866210140_78.docx @ 387724 @ 3 @ 1 9.2.5 Switching the terminal on / off when the machine is connected Pos: 72.26 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Ein- Ausschalten Bild mit angeschlossener Maschine BiG Pack @ 43\mod_1274866563531_78.docx @ 387748 @ @ 1 CC000011 Fig.

  • Page 134: Function Keys

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.33.1 /Überschriften/Überschriften 2/F-J/Funktionstasten @ 63\mod_1299828646311_78.docx @ 576509 @ 2 @ 1 Function keys Pos: 72.33.2 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Funktionstasten allgemein @ 63\mod_1299761216053_78.docx @ 576176 @ 3 @ 1 Various machine functions can be activated via the function keys F1 to F12. Each function is represented by a certain symbol.
  • Page 135 KRONE ISOBUS-Terminal CCI 100 Pos: 72.33.8 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Funktionstasten F1 bis F 12/Softkey Arbeitsscheinwerfer ein/aus @ 63\mod_1299854724342_78.docx @ 577418 @ @ 1 Working floodlight ON / OFF. The current status is displayed. Working floodlight ON Working floodlight OFF Pos: 72.33.9 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Funktionstasten F1 bis F 12/Seite 1/2 F5 Anlaufhilfe aktiviert/deaktiviert @ 63\mod_1299854598970_78.docx @ 577391 @ @ 1 Start-up aid activated / deactivated The active status is displayed.
  • Page 136 KRONE ISOBUS-Terminal CCI 100 Pos: 72.33.12 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Grundbild für die Funktionstasten Seite 1/2 @ 99\mod_1329890979022_78.docx @ 883611 @ 3 @ 1 Fig.89 Pos: 72.33.13 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Funktionstasten F1 bis F 12/Beschreibung der Grafiken (II) für die erste Seite der Funktionstasten (F7 bis F12) @ 63\mod_1299770154674_78.docx @ 576202 @ @ 1...
  • Page 137 KRONE ISOBUS-Terminal CCI 100 Pos: 72.33.18 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Funktionstasten F1 bis F 12/Seite 1/2 F11 Ballenausschieberautomatik @ 63\mod_1299853874571_78.docx @ 577229 @ @ 1 Automatic bale ejector • Press function key (pressure flaps are released). • Press function key again. The symbol is highlighted in grey. 10 bale ejection operations are carried out.
  • Page 138 KRONE ISOBUS-Terminal CCI 100 Pos: 72.33.21 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Grundbild für die Funktionstasten Seite 2/2 @ 99\mod_1329891781016_78.docx @ 883639 @ @ 1 CC000073_1 Fig.90 Pos: 72.33.22 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Funktionstasten F1 bis F 12/Beschreibung der Grafiken (II) für die zweite Seite der Funktionstasten (F1 bis F6) @ 63\mod_1299853742960_78.docx @ 577176 @ @ 1...
  • Page 139 KRONE ISOBUS-Terminal CCI 100 Pos: 72.33.26 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Funktionstasten F1 bis F 12/Seite 2/2 F5 aktuelle Ballenlänge auf Null zurücksetzen @ 63\mod_1299853399571_78.docx @ 577069 @ @ 1 Setting the current bale length to zero • Keep function key pressed down for about 2 seconds.

  • Page 140: Manual Mode

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.35.1 /Überschriften/Überschriften 2/F-J/Handbetrieb @ 43\mod_1275029013625_78.docx @ 389186 @ 2233 @ 1 Manual mode Pos: 72.35.2 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Grundbild Handbetrieb HS Baureihe @ 99\mod_1329892134758_78.docx @ 883667 @ 3 @ 1 9.4.1 Manual mode basic screen CC000073_1 Fig.91...
  • Page 141 KRONE ISOBUS-Terminal CCI 100 Pos: 72.35.5 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Anzeigen im Hauptfenster (III) (Je nach Ausstattung der Maschine) @ 146\mod_1360144455754_78.docx @ 1307775 @ @ 1 Displays in the main window (III) (depending on how the machine is equipped) Pos: 72.35.6 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Anzeigen im Hauptfenster (III) linke Spalte HS Baureihe @ 146\mod_1360061307841_78.docx @ 1306579 @ @ 1 Left column (A): Current baling force as a % (100% = max.)
  • Page 142 KRONE ISOBUS-Terminal CCI 100 Pos: 72.35.10 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Handbetrieb Pressklappendruck/Multibale Bild @ 43\mod_1275040657421_78.docx @ 389514 @ @ 1 Fig. 92 Pos: 72.35.11 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Handbetrieb Pressklappendruck (in bar) @ 43\mod_1275040654296_78.docx @ 389489 @ 23 @ 1 Bale channel flap pressure (in bar or PSI according to unit of measurement Metric or US) The value under the bar display and the height of the bar (1) show the current actual bale channel flap pressure.

  • Page 143: Setting The Target Bale Channel Flap Pressure

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.35.14 /BA/Info-Center/Großpackenpresse/Grundbild Handbetrieb/Einstellen des Soll-Pressklappendrucks @ 18\mod_1237390053275_78.docx @ 210173 @ 32 @ 1 9.4.2 Setting the target bale channel flap pressure Pos: 72.35.15 /BA/Info-Center/Großpackenpresse/Grundbild Handbetrieb/Warnung zu hoher Druck @ 18\mod_1237389601150_78.docx @ 210149 @ @ 1 WARNING! –...

  • Page 144: Setting The Bale Length

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.35.22 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Einstellen der Ballenlänge Handbetrieb Bild HS Baureihe @ 99\mod_1329894194876_78.docx @ 883945 @ @ 1 Fig.94 Pos: 72.35.23 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Einstellen der Ballenlänge Handbetrieb HS Baureihe @ 63\mod_1299852886404_78.docx @ 576958 @ 3 @ 1 9.4.3...
  • Page 145 KRONE ISOBUS-Terminal CCI 100 Pos: 72.35.27 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Einstellen der Multibaleanzahl Handbetrieb Bild HS Baureihe @ 99\mod_1329897393476_78.docx @ 884193 @ @ 1 Fig.95 Pos: 72.35.28 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Einstellen der Multibaleanzahl Handbetrieb @ 43\mod_1275295579953_78.docx @ 390084 @ 2 @ 1 Setting the number of MultiBales (MultiBale only) CAUTION! - Mixture of total bale and MultiBale The MultiBale number should only be changed at the beginning of a bale.

  • Page 146: Automatic Mode

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.37 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Automatikbetrieb/Grundbild Automatikbetrieb Bild HS Baureihe @ 99\mod_1329898695425_78.docx @ 884231 @ 2 @ 1 Automatic Mode Fig.96 Pos: 72.38 /BA/Info-Center/Großpackenpresse/Grundbild Automatikbetrieb/Hinweis Unterschiede zum Handbetrieb @ 18\mod_1237464371115_78.docx @ 210705 @ 3 @ 1 Note For general description see chapter “Manual mode”...
  • Page 147 KRONE ISOBUS-Terminal CCI 100 Pos: 72.42 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Automatikbetrieb/Einstellen des Soll-Presskraft Bild @ 43\mod_1275297944000_78.docx @ 390420 @ @ 1 Fig. 97 Pos: 72.43 /BA/Info-Center/Großpackenpresse/Grundbild Automatikbetrieb/Automatikbetrieb Presskraft (in %) @ 18\mod_1237464672365_78.docx @ 210754 @ 2 @ 1 Pressing force (in %) The value under the bar display and the height of the bar (1) indicate the current target pressing force as a percentage rate.

  • Page 148: Buttons On The Machine

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.46 /BA/Info-Center/Großpackenpresse/Taster an der Maschine/Taster an der Maschine HS @ 112\mod_1337598399218_78.docx @ 994229 @ 332 @ 1 Buttons on the machine WARNING! - Unexpected actions on the machine! Effect: Injuries or damage to the machine.

  • Page 149: Description Of Baling Process

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.48 /BA/Info-Center/Großpackenpresse/Beschreibung Pressvorgang/Presskanal leer @ 18\mod_1237458084755_78.docx @ 210552 @ 2332 @ 1 Description of baling process Bale channel chamber empty When the control unit is switched on, the display remains in Manual Mode. Note The bale channel chamber must first be filled to a pressure of about 50 bar / 725 PSI for straw and 25 bar / 362,5 PSI for silage there to prevent the bale channel flaps from bending out of shape.

  • Page 150: Menu Level

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.51 /Überschriften/Überschriften 2/K-O/Menüebene @ 80\mod_1315900872940_78.docx @ 708317 @ 333 @ 1 Menu level Pos: 72.52 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Menüebene Kurzüberblick Maschine HS Baureihe @ 134\mod_1351065965711_78.docx @ 1193709 @ 33 @ 1 9.9.1 Short Overview 1-1-1 1-1-2 1-1-3 CHECK 1..n...

  • Page 151: Calling Up The Menu Level

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.54 /Überschriften/Überschriften 2/K-O/Menüebene aufrufen @ 44\mod_1275977054046_78.docx @ 394176 @ 3 @ 1 9.9.2 Calling up the menu level Pos: 72.55 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Menüebene aufrufen Bild HS Baureihe @ 99\mod_1329901887761_78.docx @ 884502 @ @ 1 CC000086_1 CC000028 Fig.100...

  • Page 152: Main Menu 1 "Settings

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.59 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Hauptmenü „Einstellungen“ HS Baureihe @ 146\mod_1360046180125_78.docx @ 1305594 @ 2 @ 1 9.10 Main Menu 1 "Settings" CC000054_1 CC000028 Fig. 101 • Press function key to access the menu level via the basic screen •...

  • Page 153: Menu 1-1 „Knotter Settings

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.61 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-1 „Knotereinstellungen“ HS Baureihe @ 99\mod_1329907098199_78.docx @ 884813 @ 3 @ 1 9.10.1 Menu 1-1 „Knotter Settings“ CC000054_1 Fig. 102 Calling the Menu Main menu 1 “Settings” is called. •...

  • Page 154: Menu 1-1-1 „Correction Value For Bale Length

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.63 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-1-1 „Korrekturwert Ballenlänge“ HS Baureihe @ 99\mod_1329994073656_78.docx @ 886978 @ 3 @ 1 9.10.2 Menu 1-1-1 „Correction Value for Bale Length“ CC0000100 Fig. 103 Because of different properties of materials (for example straw or silage), the actual bale length can differ from the pre-set setpoint.

  • Page 155: Menu 1-1-2 „Knotter Signal

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.65 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-1-2 Knotersignal @ 99\mod_1330000507245_78.docx @ 887432 @ 33 @ 1 9.10.3 Menu 1-1-2 „Knotter Signal“ Fig. 104 Activation/deactivation of the audio signal when a knot has been completed. Calling the Menu The main menu 1-1 “Knotter Settings”...

  • Page 156: Menu 1-1-3 „Knotter Monitoring

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.67 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-1-3 „Knoterkontrolle“ @ 99\mod_1330001612225_78.docx @ 887653 @ 22 @ 1 9.10.4 Menu 1-1-3 „Knotter Monitoring“ With comfort version electronics design, the machine is serially equipped with an electronic knotter monitoring. Each knotter is in this process monitored individually by one sensor. If an error occurs on the knotter, the appropriate error message appears in the display of the operation terminal.

  • Page 157: Menu 1-1-5 „Bales / Blow

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.69 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-1-5 „Ballen / Blasen“ @ 99\mod_1330002387961_78.docx @ 887677 @ 4 @ 1 9.10.4.1 Menu 1-1-5 „Bales / Blow“ 1-1-5 CC0000103 Fig. 106 (For machines with electronic knotter triggering) Dust and accumulated crop material is removed from the knotters by compressed air at regular intervals (depending on the number of bales produced).

  • Page 158: Menu 1-1-6 „Blow Time

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.71 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-1-6 „Blaszeit“ @ 99\mod_1330004064344_78.docx @ 887794 @ 33 @ 1 9.10.4.2 Menu 1-1-6 „Blow Time“ Fig. 107 The blowing time on the knotter is set in this menu. Calling the Menu The main menu 1-1 “Knotter Settings”...

  • Page 159: Menu 1-2 Silage Agents / Optional

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.73 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Ladewagen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-2 Silagemittel @ 50\mod_1287564144906_78.docx @ 473259 @ 22333 @ 1 9.10.5 Menu 1-2 silage agents / optional CC000423_1 CC000424 Fig. 108 Note The connection (max. 2 amperes) for the silage agent device is located close to the job computer.

  • Page 160: Menu 1-3 „Sensitivity Of The Direction Display

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.75 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-3 „Empfindlichkeit-Richtungsanzeige“ @ 99\mod_1330004944548_78.docx @ 887919 @ 3 @ 1 9.10.6 Menu 1-3 „Sensitivity of the Direction Display“ CC000107 Fig. 109 Setting the sensitivity of the direction display. Calling the Menu Main menu 1 “Settings”...
  • Page 161 KRONE ISOBUS-Terminal CCI 100 Pos: 72.77 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ @ 1 This page has been left blank deliberately!! Pos: 72.78 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...

  • Page 162: Menu 1-4 „Central Lubrication

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.79 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-4 „Zentralschmierung“ T1/2 HS Baureihe @ 99\mod_1330005723595_78.docx @ 888108 @ 333 @ 1 9.10.7 Menu 1-4 „Central Lubrication“ Fig. 110 (For machines with central lubrication) Setting of the lubrication intervals and the lubrication duration.
  • Page 163 KRONE ISOBUS-Terminal CCI 100 Pos: 72.81 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü „Zentralschmierung“ T2/2 @ 44\mod_1275371639750_78.docx @ 391129 @ @ 1 • Set the lubrication duration with the function key , the symbol in the top line goes out • Press the function key .

  • Page 164: Menu 1-5 „Moisture Measuring

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.83 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-5 „Feuchtigkeitsmessung“ @ 120\mod_1342617756034_78.docx @ 1092801 @ 233 @ 1 9.10.8 Menu 1-5 „Moisture Measuring“ CC000556 Fig. 111 In the menu 1-5 “Moisture Measuring” the value is set starting at which the message “136 crop too moist”...
  • Page 165 KRONE ISOBUS-Terminal CCI 100 Pos: 72.85 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ 2 @ 1 This page has been left blank deliberately!! Pos: 72.86 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ 34 @ 1...

  • Page 166: Menu 1-6 „Bale Balance

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.87 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-6 „Ballenwaage“ T1 @ 109\mod_1335347896210_78.docx @ 976087 @ 43 @ 1 9.10.9 Menu 1-6 „Bale Balance“ CC000558 Fig. 112 Calling the Menu Main menu 1 “Settings” is called. • By pressing the function key...

  • Page 167: Adjusting The Bale Balance

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.89 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-6 „Ballenwaage“ T2 justieren @ 109\mod_1335353555144_78.docx @ 976146 @ 34 @ 1 9.10.9.1 Adjusting the Bale Balance The bale balance can be readjusted in the limit range from 95% to 105% To do this: •...
  • Page 168 KRONE ISOBUS-Terminal CCI 100 Pos: 72.92 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ @ 1 This page has been left blank deliberately!! Pos: 72.93 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ 3 @ 1...

  • Page 169: Main Menu 2 „Counters

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.94 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 2 Zähler/Hauptmenü 2 Zähler @ 44\mod_1275385420046_78.docx @ 391433 @ 32 @ 1 9.11 main menu 2 „counters“ CC000036 Fig. 113 Calling the main menu • By pressing the function key in the basic screen you get into the menu level of the machine •...

  • Page 170: Menu 2-1 „Customer Counter

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.96 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 2 Zähler/Menü 2-1 Kundenzähler HS Baureihe @ 109\mod_1335422368783_78.docx @ 976715 @ 23 @ 1 9.11.1 Menu 2-1 „Customer Counter“ CC000062 Fig. 114 Calling the Menu Main menu 2 “Counter” is called •...
  • Page 171 KRONE ISOBUS-Terminal CCI 100 Pos: 72.98 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 2 Zähler/Kundenzähler aktivieren Seite 1 T1 HS Baureihe @ 109\mod_1335422968371_78.docx @ 976784 @ @ 1 The activated customer counter (in this case customer counter 2) is highlighted in colour. The selected customer counter (in this case customer counter 3) is between the two crossbars).

  • Page 172: Menu 2-1-1

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.104 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 2 Zähler/Symbolbedeutung Seite 2 mit Ballenwaage Kundenzähler @ 109\mod_1335427139817_78.docx @ 976823 @ 4 @ 1 9.11.1.1 Menu 2-1-1 2-1-1 CC000037_1 Fig. 115 Meaning of the Symbols Page 1: = Total number of bales...
  • Page 173 KRONE ISOBUS-Terminal CCI 100 Pos: 72.106 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 2 Zähler/Ballenanzahl verändern @ 111\mod_1337006487911_78.docx @ 989786 @ 22 @ 1 Changing the Bale Number • Press function key to select the desired customer counter (A) (the customer counter must not be activated) •...

  • Page 174: Menu 2-2 „Total Bale Counter

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.109 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 2 Zähler/Menü 2-2 „Gesamtballenzähler“ @ 109\mod_1335431017537_78.docx @ 977112 @ 22 @ 1 9.11.2 Menu 2-2 „Total Bale Counter“ CC000063 Fig. 116 Calling the Menu Main menu 2 “Counter” is called • By pressing function key...
  • Page 175 KRONE ISOBUS-Terminal CCI 100 Pos: 72.111 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 2 Zähler/Gesamtballenzähler bei Ausführung Ballenwaage @ 109\mod_1335431929332_78.docx @ 977175 @ @ 1 Total Bale Counter for Bale Balance Design Fig. 117 For bale balance design, the total bale counter is divided into two pages. The second page of the total bale counter is displayed by pressing the function key for .

  • Page 176: Main Menu 4 "Service

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.115 /Überschriften/Überschriften 2/F-J/Hauptmenü 4 Service @ 34\mod_1255339497523_78.docx @ 322336 @ 32 @ 1 9.12 Main menu 4 "Service" Pos: 72.116 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 4 Service/Hauptmenü 4 Service 4 Untermenüs @ 109\mod_1335271291270_78.docx @ 974949 @ 2 @ 1...

  • Page 177: Menu 4-2 „Manual Sensor Test

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.118 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 4 Service/Menü 4-2 Sensortest Hand @ 44\mod_1275483833375_78.docx @ 391921 @ 33 @ 1 9.12.1 Menu 4-2 „Manual sensor test“ BPK40190_1 CC000040 Fig. 119 In the manual sensor test, the sensors that are installed on the machine are checked for errors.
  • Page 178 KRONE ISOBUS-Terminal CCI 100 Pos: 72.121 /BA/Info-Center/Sensoren/Diagnose Namursensoren @ 19\mod_1238072125300_78.docx @ 214095 @ @ 1 Diagnostics – Namur sensors Pos: 72.122 /BA/Info-Center/Sensoren/Mögliche Sensoren (je nach Ausstattung der Maschine) @ 19\mod_1238071336628_78.docx @ 214010 @ @ 1 Possible sensors (depending on how the machine is equipped) Pos: 72.123 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü...
  • Page 179 KRONE ISOBUS-Terminal CCI 100 Pos: 72.128 /BA/Info-Center/Sensoren/Diagnose Taster @ 19\mod_1238078012972_78.docx @ 214752 @ @ 1 Diagnostics for buttons Pos: 72.129 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 4 Service/Diagnose Taster Bild @ 44\mod_1275563738453_78.docx @ 393135 @ 3 @ 1 CC000042 Fig. 120 Pos: 72.130 /BA/Info-Center/Sensoren/Einstellwerte Tastertest Hand @ 19\mod_1238078727722_78.docx @ 214806 @ @ 1 Setting values: When the button is pressed, the bar must be in the lower marked area of the bar display.
  • Page 180 KRONE ISOBUS-Terminal CCI 100 Pos: 72.136 /BA/Info-Center/Sensoren/Diagnose analoge Sensoren @ 19\mod_1238132263369_78.docx @ 214965 @ @ 1 Diagnostics – analogue sensors Pos: 72.137 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 4 Service/Diagnose analoge Sensoren Bild HS Baureihe @ 64\mod_1300107364514_78.docx @ 579589 @ @ 1 CC000079 Fig.121 Pos: 72.138 /BA/Info-Center/Sensoren/Einstellwerte analoge Sensoren Hand @ 19\mod_1238132357119_78.docx @ 214994 @ @ 1...
  • Page 181 KRONE ISOBUS-Terminal CCI 100 Pos: 72.143 /BA/Info-Center/Großpackenpresse/Hauptmenüs/Hauptmenü 4 Service/Einstellwert Sensor B 38 (Beschleunigungssensor) für HS BAureihe @ 64\mod_1300101141100_78.docx @ 579167 @ @ 1 Sensor B 38 (acceleration sensor) The sensor B38 for detecting acceleration is pre-set in the factory. The two bars (1, 2) must be inside the marked area (3) of the bar display.
  • Page 182 KRONE ISOBUS-Terminal CCI 100 Pos: 72.147 /BA/Info-Center/Sensoren/Diagnose Kraftsensoren @ 19\mod_1238136713228_78.docx @ 215126 @ @ 1 Diagnostics – force sensors Pos: 72.148 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 4 Service/Diagnose Kraftsensoren Bild HS Baureihe @ 64\mod_1300109741270_78.docx @ 579782 @ @ 1 CC000080 Fig.122 Pos: 72.149 /BA/Info-Center/Sensoren/Einstellwerte Kraftsensoren Hand HS Baureihe @ 64\mod_1300108375627_78.docx @ 579650 @ @ 1 Setting values: The bar must be inside the marked area of the bar display.
  • Page 183 KRONE ISOBUS-Terminal CCI 100 Pos: 72.154 /BA/Info-Center/Großpackenpresse/Hauptmenüs/Hauptmenü 4 Service/Einstellwert Sensor B 55/56 (Kraftsensor) für HS BAureihe @ 64\mod_1300109830543_78.docx @ 579813 @ @ 1 Sensor B55 / B56 The sensors B55 / B56 for weighing the bale on the chute are pre-set in the factory. The two bars (1, 2) must be inside the marked area (3) of the bar display.
  • Page 184 KRONE ISOBUS-Terminal CCI 100 Pos: 72.158 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 4 Service/Diagnose Versorgungsspannungen @ 44\mod_1275633269890_78.docx @ 393329 @ 3 @ 1 Diagnostics power supply voltages CC000045 Fig. 123 Sensor symbol Description Supply voltage Nominal voltages: • 12V Ges: 12 - 14.5 V •...

  • Page 185: Actuator Test

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.161 /Überschriften/Überschriften 3/A-E/Aktortest @ 0\mod_1200916990791_78.docx @ 47833 @ 3 @ 1 9.12.2 Actuator test Pos: 72.162 /BA/Sicherheit/Gefahrenhinweise/Gefahr - Aktortest @ 47\mod_1285134152781_78.docx @ 455729 @ @ 1 Danger! - Unexpected actions on the machine. Effect: Danger to life or serious injuries.
  • Page 186 KRONE ISOBUS-Terminal CCI 100 Pos: 72.169 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 4 Service/Diagnose digitale Aktoren @ 44\mod_1275889088109_78.docx @ 393610 @ @ 1 Diagnostics – digital actuators Errors are only displayed if the actuator is turned on and a test is possible for the actuator (see the table called "Possible digital actuators").
  • Page 187 KRONE ISOBUS-Terminal CCI 100 Pos: 72.174 /BA/Info-Center/Sensoren/Statusanzeige digitaler Aktoren (1,2,3,4) @ 19\mod_1238477852587_78.docx @ 218655 @ 3 @ 1 State: Actuator on Actuator off General actuator error No power supply; fuse is probably defective Pos: 72.175 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/ESC drücken um Menü Service 4 zu schließen bzw. zum Grundbild zugelangen @ 44\mod_1275893530687_78.docx @ 393687 @ @ 1 •...
  • Page 188 KRONE ISOBUS-Terminal CCI 100 Pos: 72.177 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 4 Service/Diagnose analoge Aktoren HS Baureihe @ 64\mod_1300169028051_78.docx @ 580255 @ 2 @ 1 Diagnostics analogue actuators PWM: CC000047 Fig.125 A current (in mA) can be created with the PWM value (in parts per thousand).
  • Page 189 KRONE ISOBUS-Terminal CCI 100 Pos: 72.180 /BA/Info-Center/Sensoren/Diagnose Drucksensor @ 115\mod_1339653067227_78.docx @ 1011904 @ @ 1 Diagnostics Pressure Sensors Pos: 72.181 /BA/Info-Center/Sensoren/Mögliche Sensoren (je nach Ausstattung der Maschine) @ 19\mod_1238071336628_78.docx @ 214010 @ 2 @ 1 Possible sensors (depending on how the machine is equipped) Pos: 72.182 /BA/Info-Center/Sensoren/Drucksensor Achse gesperrt B36 @ 120\mod_1342685713553_78.docx @ 1093155 @ 3 @ 1...

  • Page 190: Menu 4-6 „Diagnostics Driving Speed / Motion Direction Display

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.185 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 4-6 Diagnose Fahrgeschw/Fahrtrichung/Menü 4-6 Diagnose Fahrgeschwindigkeits- /Fahrtrichtungsanzeige T1 @ 109\mod_1335273978199_78.docx @ 975069 @ 333 @ 1 9.12.4 Menu 4-6 „Diagnostics Driving Speed / Motion Direction Display“ The tractor must transfer the driving speed and the direction of travel onto the ISO-Bus.

  • Page 191: Menu 4-7 „Diagnostics Auxiliary (Aux)

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.188 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 4-7 Diagnose Auxiliary (AUX)/Menü 4-7 Diagnose Auxiliary (AUX) T1 @ 109\mod_1335433715718_78.docx @ 977292 @ 3332 @ 1 9.12.5 Menu 4-7 „Diagnostics Auxiliary (AUX)“ CC000555 ZX400058 Fig. 127 Calling the Menu Main menu 4 “Serice” is called •...

  • Page 192: Main Menu 5 'Information

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.191 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 5 Info/Hauptmenü 5 Info HS Baureihe @ 64\mod_1300112474713_78.docx @ 580091 @ 232 @ 1 9.13 Main menu 5 'Information' 1290 HS 200812870 1:150200445_0 2:150200446_00 CC000050 CC000081 Fig.128 Calling the main menu •...

  • Page 193: Main Menu 6 Technician

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.194 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 6 Monteur/Hauptmenü 6 Monteur @ 135\mod_1351678746690_78.docx @ 1203319 @ 2 @ 1 9.14 Main Menu 6 Technician Calling the Main Menu 0000 054536 CC000051 CC000052 Fig. 129 • By pressing function key in the basic screen you get into the menu level •...

  • Page 194: Main Menu 9 "Virtual Terminal (Vt)

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.196 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 9 ISO-Einstellungen/Hauptmenü 9 Virtual Terminal/Hauptmenü 9 VT @ 80\mod_1315399643122_78.docx @ 704281 @ 2 @ 1 9.15 Main menu 9 "Virtual Terminal (VT)" CC000474 Fig. 130 Calling the main menu • Press function key to access the menu level via the basic screen •...

  • Page 195: Menu 9-2 „Switching Between The Terminals

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.202 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 9 ISO-Einstellungen/Menü 9-2 Terminalwechsel @ 119\mod_1342087866195_78.docx @ 1070148 @ 43 @ 1 9.15.1 Menu 9-2 „Switching Between the Terminals“ Note • Menu 9-2 appears only if several ISO terminals are connected. • Changing to the next connected terminal is possible via menu 9-2 (depending on how many terminals are connected).

  • Page 196: Menu 9-3 „Configuration Main Window

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.204 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 9 ISO-Einstellungen/Menü 9-3 Konfiguration Hauptfenster aufrufen @ 146\mod_1360049968330_78.docx @ 1306011 @ 3 @ 1 9.15.2 Menu 9-3 „Configuration Main Window“ In menu 9-3 you can determine which displays shall be shown in the main window (left column).
  • Page 197 KRONE ISOBUS-Terminal CCI 100 Pos: 72.207 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 9 ISO-Einstellungen/Menü 9-3 Mögliche Auswahlelemente für das Hauptfenster (je nach Ausstattung der Maschine) @ 146\mod_1360146285555_78.docx @ 1308004 @ 2 @ 1 Possible selection elements for the main window (depending on how the machine is equipped) Pos: 72.208 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Grundbild Handbetrieb/Anzeigen im Hauptfenster (III) linke Spalte HS Baureihe @ 146\mod_1360061307841_78.docx @ 1306579 @ 2 @ 1...

  • Page 198: Alarm Message

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.210 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Alarmmeldungen/Alarmeldung allgemein @ 189\mod_1381224126492_78.docx @ 1622617 @ 2 @ 1 9.16 Alarm Message CC000053_1 Fig. 133 Alarm message If a malfunction occurs on the machine, an alarm message appears in the display and an audio signal is heard at the same time (constant horn signal).

  • Page 199: Alarm Messages

    KRONE ISOBUS-Terminal CCI 100 Pos: 72.212 /Überschriften/Überschriften 3/A-E/Alarmmeldungen @ 34\mod_1255441373066_78.docx @ 323566 @ 3 @ 1 9.16.1 Alarm messages Pos: 72.213 /BA/Info-Center/Großpackenpresse/Hauptmenüs/Alarmmeldungen/1) Alarmmeldungen Tabelle allgemein A01 - A17 HS Baureihe @ 64\mod_1300112639026_78.docx @ 580114 @ @ 1 Screen Description Possible cause...
  • Page 200 KRONE ISOBUS-Terminal CCI 100 Pos: 72.215 /BA/Info-Center/Großpackenpresse/Hauptmenüs/Alarmmeldungen/2) Alarmmeldungen Tabelle allgemein 0 - 9 @ 19\mod_1238504387040_78.docx @ 220236 @ 3 @ 1 No. Image Description Possible cause Remedy - Twine torn Checking the twine and twine Twine monitoring - Twine end...
  • Page 201 KRONE ISOBUS-Terminal CCI 100 Pos: 72.217 /BA/Info-Center/Großpackenpresse/Hauptmenüs/Alarmmeldungen/3) Alarmmeldungen Tabelle allgemein 10-37 HS Baureihe @ 192\mod_1382344116641_78.docx @ 1639667 @ 3 @ 1 Figure Possible cause Remedy – An error on the pressure limiting – Switch off the PTO shaft. valve. –...
  • Page 202 KRONE ISOBUS-Terminal CCI 100 Possible cause Remedy Figure – The knotter is not functioning – Check knotter and knotter properly. triggering. – The sensor is not adjusted – Adjust the knotter incorrectly. monitoring sensor correctly. – Add grease. The central lubrication –...
  • Page 203 KRONE ISOBUS-Terminal CCI 100 Pos: 72.219 /BA/Info-Center/Großpackenpresse/Hauptmenüs/Alarmmeldungen/4) Alarmmeldungen Tabelle allgemein 101-113 @ 19\mod_1238506114415_78.docx @ 220281 @ 3 @ 1 No. Image Description Possible cause Remedy Twine monitoring sensor Packer monitoring sensors Packer feed sensor Upper blade bar sensor, top Cutter sensor...
  • Page 204 KRONE ISOBUS-Terminal CCI 100 Pos: 72.221 /BA/Info-Center/Großpackenpresse/Hauptmenüs/Alarmmeldungen/5) Alarmmeldungen Tabelle allgemein 114-125 HS Baureihe @ 64\mod_1300117151504_78.docx @ 580168 @ 3 @ 1 No. Screen Description Possible cause Remedy - Perform a sensor test Hydraulic Sensor or supply line defective - Check the sensor and line for pressure sensor damage.
  • Page 205 KRONE ISOBUS-Terminal CCI 100 Pos: 72.223 /BA/Info-Center/Großpackenpresse/Hauptmenüs/Alarmmeldungen/6) Alarmmeldungen Tabelle allgemein 126-149 HS Baureihe @ 64\mod_1300117366608_78.docx @ 580195 @ @ 1 No. Screen Description Possible cause Remedy Sensor knotter 1 Sensor knotter 2 Sensor knotter 3 Sensor knotter 4 Sensor knotter 5...
  • Page 206 KRONE ISOBUS-Terminal CCI 100 Pos: 74 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ 1 @ 1 This page has been left blank deliberately!! Pos: 75 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ 3 @ 1...

  • Page 207: Isobus Operation

    The operation of this machine requires at least implementation level 3 of the ISOBUS system. Pos: 76.3 /BA/Info-Center/Iso-Bedienung/Gefahr durch nicht von KRONE gelieferte Terminals / Bedieneinheiten @ 48\mod_1286197403750_78.docx @ 459766 @ 3 @ 1 DANGER! When using terminals and other control units which have not been delivered by KRONE mind that the user: •...

  • Page 208: Attaching The Isobus Terminal

    ISOBUS operation Pos: 76.5 /BA/Info-Center/Iso-Bedienung/BigPack/ISO-Bedienung_Anbau @ 48\mod_1286438957000_78.docx @ 461353 @ 233 @ 1 10.1 Attaching the ISOBUS terminal Fig. 134 CAUTION! Failure of control unit. When attaching the control unit, take care that the connection cables are not stretched and cannot come in contact with the tractor wheels.

  • Page 209: Differing Functions To Krone Isobus Terminal Cci

    The values for “Bale channel flap pressure/force”, “Bale length” and “Number of MultiBales” which are set by the scroll wheel in the basic screen on the KRONE ISOBUS terminal CCI, are set on the ISO terminal with the selection key predetermined by the ISO terminal (refer to the operating instructions of the ISO terminal manufacturer).

  • Page 210: Menu 4-6 "Diagnostics Driving Speed Display/Direction Of Travel Display

    ISOBUS operation Pos: 76.11 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 4-6 Diagnose Fahrgeschw/Fahrtrichung/Menü 4-6 Diagnose Fahrgeschwindigkeits- /Fahrtrichtungsanzeige Ladewagen @ 49\mod_1286952423531_78.docx @ 463801 @ 3 @ 1 10.2.1 Menu 4-6 “Diagnostics driving speed display/direction of travel display” The tractor must transfer the travelling speed and direction of travel on the ISO bus. ZX400056_1 ZX400057_1 Fig.

  • Page 211: Menu 4-7 "Diagnostics Auxiliary (Aux)

    ISOBUS operation Pos: 76.13 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 4-7 Diagnose Auxiliary (AUX)Menü 4-7 Diagnose Auxillary Belegung am Multifunktionshebel_Lad @ 48\mod_1286350819750_78.docx @ 461253 @ 3 @ 1 10.2.2 Menu 4-7 “Diagnostics Auxiliary (AUX)” ZX400058 Fig. 136 Call up main menu "Maintenance" with the key •...

  • Page 212: Main Menu 9 "Iso Settings Info

    ISOBUS operation Pos: 76.15 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 9 ISO-Einstellungen/Hauptmenü 9 ISO-Einstellungen @ 83\mod_1317125969482_78.docx @ 727355 @ 32 @ 1 10.3 Main menu 9 "ISO settings info" CC000484 Fig. 137 Calling the main menu • Press function key to access the menu level via the basic screen •...

  • Page 213: Menu 9-1 "Softkeys Iso Terminal

    ISOBUS operation Pos: 76.17 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 9 ISO-Einstellungen/Menü 9-1 Softkeys ISO-Terminal weniger 10 Tasten @ 83\mod_1317116511667_78.docx @ 727008 @ 333 @ 1 10.3.1 Menu 9-1 "Softkeys ISO terminal" Note The menu 9-1 only appears on ISO terminals with less than 10 keys In menu 9-1, the basic screen (for ISO terminals with less than 10 keys) is set to 5 or 10 softkey buttons.

  • Page 214: Menu 9-2 „Switching Between The Terminals

    ISOBUS operation Pos: 76.20 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 9 ISO-Einstellungen/Menü 9-2 Terminalwechsel @ 119\mod_1342087866195_78.docx @ 1070148 @ 3 @ 1 10.3.2 Menu 9-2 „Switching Between the Terminals“ Note • Menu 9-2 appears only if several ISO terminals are connected. • Changing to the next connected terminal is possible via menu 9-2 (depending on how many terminals are connected).

  • Page 215: Isobus „Auxiliary"-Function (Aux)

    ISOBUS operation Pos: 76.22 /Überschriften/Überschriften 1/A-E/ISOBUS „Auxiliary“-Funktion (AUX) @ 48\mod_1286278825265_78.docx @ 460508 @ 23 @ 1 10.4 ISOBUS „Auxiliary“-function (AUX) Pos: 76.23 /BA/Info-Center/Iso-Bedienung/Hinweis Terminal die Auxilliary unterstützen @ 48\mod_1286278420671_78.docx @ 460483 @ @ 1 Note There are terminals which support the additional function “auxiliary” (AUX). With this function, programmable keys of the peripheral equipment (e.g.

  • Page 216: Example Of A Joystick Assignment For Fendt (Default Setting)

    ISOBUS operation Pos: 76.28 /Überschriften/Überschriften 3/A-E/Beispiel einer Joystick-Belegung bei Fendt (Default-Einstellung) @ 117\mod_1341214720469_78.docx @ 1021106 @ 3 @ 1 10.4.1 Example of a joystick assignment for Fendt (default setting) Pos: 76.29 /BA/Info-Center/Iso-Bedienung/Achtung - weiter Vorgehensweise Betriebsanleitung @ 117\mod_1341215429970_78.docx @ 1021135 @ 33 @ 1 CAUTION! For the remainder of the procedure, refer to the operating instructions of the operating terminal manufacturer.

  • Page 217: Recommended Assignment Of A Wtk- Multi-Function Lever

    ISOBUS operation Pos: 76.32 /Überschriften/Überschriften 3/A-E/Empfohlene Belegung eines WTK- Multifunktionshebel @ 117\mod_1341221253128_78.docx @ 1021492 @ 33 @ 1 10.4.2 Recommended assignment of a WTK- multi-function lever Pos: 76.33 /BA/Info-Center/Iso-Bedienung/Achtung - weiter Vorgehensweise Betriebsanleitung @ 117\mod_1341215429970_78.docx @ 1021135 @ 3 @ 1 CAUTION! For the remainder of the procedure, refer to the operating instructions of the operating terminal manufacturer.
  • Page 218 ISOBUS operation Pos: 78 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ 21 @ 1 This page has been left blank deliberately!! Pos: 79 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...

  • Page 219: Operation

    Operation Pos: 80.1 /Überschriften/Überschriften 1/A-E/Bedienung @ 0\mod_1199789505403_78.docx @ 34825 @ 312 @ 1 Operation Pos: 80.2 /BA/Sicherheit/Großpackenpressen/Gefahr - Wartungs-, Montage-, Reparatur- und Einstellarbeiten @ 19\mod_1238574929963_78.docx @ 221252 @ 2 @ 1 DANGER! - Maintenance, assembly, repair and adjustment work Effect: Danger to life, injuries or damage to the machine. The following general rules apply to all maintenance, assembly, repair and adjustment work: •...
  • Page 220 Operation Pos: 80.5 /BA/Bedienung /Großpackenpresse/Mit dem Pressen beginnen / nach dem Pressen @ 166\mod_1367223499536_78.docx @ 1441233 @ 32 @ 1 Starting baling Prerequisite: – The conditions mentioned in “Preparation for Baling” and “Before starting baling, check to make certain ...” are fulfilled. Baling •...

  • Page 221: Tying Unit

    Operation Pos: 80.7 /Überschriften/Überschriften 2/A-E/Bindeeinrichtung @ 20\mod_1239003005331_78.docx @ 225610 @ 2 @ 1 11.2 Tying unit Pos: 80.8 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindegarn einlegen @ 20\mod_1239009720863_78.docx @ 226898 @ 32 @ 1 11.2.1 Inserting the twine Insertion of the twine is identical for the right hand and left hand sides of the baler. The procedure of insertion of the twines described in the following does apply for both sides of the baler.
  • Page 222 Operation Pos: 80.13 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Alte Ausführungen/Enfachknoter @ 20\mod_1239009990035_78.docx @ 226947 @ @ 1 Single knotter Pos: 80.14 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1270 HS BiG PACK 1270 XC HS @ 190\mod_1381479540345_0.docx @ 1628268 @ @ 1 BiG PACK 1270 HS / BiG PACK 1270 XC HS Pos: 80.15.1 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Unterfaden verbinden (2) @ 154\mod_1363266953393_78.docx @ 1367551 @ @ 1 Connecting lower twine (2) Pos: 80.15.2 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 6 Einfachknoter/Bidegarn verbinden im Garnkasten 6 Einfachknoter Bild 16 Rollen 3 Unterfäden @ 191\mod_1381926060679_78.docx @ 1633968 @ 2 @ 1...
  • Page 223 Operation Pos: 80.15.6 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 6 Einfachknoter/Garnrollen Unterfaden verbinden 3a ,3b, 3c und 3d Einfachknoter @ 192\mod_1381933223598_78.docx @ 1634501 @ 33 @ 1 Connecting twine rolls 3a, 3b, 3c and 3d with each other Guide the beginning of the twine of twine roll (3a) over the blue eye above through the twine brake out of the twine box.

  • Page 224: Threading In The Lower Twine

    Operation Pos: 80.15.9 /Überschriften/Überschriften 3/U-Z/Unterfaden einfädeln @ 154\mod_1363274391674_78.docx @ 1369094 @ 334 @ 1 11.2.2 Threading in the Lower Twine Pos: 80.15.10 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Unterfaden vom Garkasten zur unteren Garnführung weiterführen. @ 154\mod_1363274502562_78.docx @ 1369122 @ 4 @ 1 Then guide the lower twine from the twine box to the lower twine guide. Pos: 80.15.11 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 6 Doppelknoter/Unterfaden einfädeln Bild 1 BiG PACK 1270 HS/1290 HS/ 1290 HDP HS @ 176\mod_1372839792475_78.docx @ 1505347 @ @ 1 BPHS0251 Fig.
  • Page 225 Pos: 80.17 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Doppelknoter @ 20\mod_1239010038066_78.docx @ 226971 @ @ 1 Double knotter Pos: 80.18 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 890 HS BiG PACK 890 XC HS @ 190\mod_1381478581743_0.docx @ 1628239 @ 3 @ 1 BiG PACK 890 HS / BiG PACK 890 XC HS Pos: 80.19.1 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 4 Doppelknoter 890 HSBindegarn verbinden allgemeine Beschreibung 4 Doppelknoter @ 191\mod_1381844742544_78.docx @ 1632370 @ @ 1...
  • Page 226 Operation Pos: 80.19.7 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Unterfaden verbinden (2) @ 154\mod_1363266953393_78.docx @ 1367551 @ @ 1 Connecting lower twine (2) Pos: 80.19.8 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 4 Doppelknoter 890 HSBidegarn verbinden im Garnkasten 4 Doppelknoter Bild 16 Rollen 2 Ober-/ Unterfäden @ 191\mod_1381843513756_78.docx @ 1632263 @ 3 @ 1 Fig.

  • Page 227: Threading In The Lower Twine

    Operation Pos: 80.19.13 /Überschriften/Überschriften 3/U-Z/Unterfaden einfädeln @ 154\mod_1363274391674_78.docx @ 1369094 @ 33 @ 1 11.2.3 Threading in the Lower Twine Pos: 80.19.14 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Unterfaden vom Garkasten zur unteren Garnführung weiterführen. @ 154\mod_1363274502562_78.docx @ 1369122 @ @ 1 Then guide the lower twine from the twine box to the lower twine guide. Pos: 80.19.15 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 4 Doppelknoter 890 HSUnterfaden einfädeln Bild 1 890 HS @ 191\mod_1381901560187_78.docx @ 1632716 @ @ 1 BPHS0233 Fig.

  • Page 228: Threading In The Upper Twine

    Operation Pos: 80.19.21 /Überschriften/Überschriften 3/K-O/Oberfaden einfädeln @ 154\mod_1363276173731_78.docx @ 1369401 @ 33 @ 1 11.2.4 Threading in the Upper Twine Pos: 80.19.22 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Oberfaden vom Garkasten zur oberen Garnführung weiterführen @ 154\mod_1363276378790_78.docx @ 1369487 @ @ 1 Then guide the upper twine from the twine box to the upper twine guide. Pos: 80.19.23 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 4 Doppelknoter 890 HSOberfaden einfädeln Bild 1 (2Oberfäden) @ 191\mod_1381902155004_78.docx @ 1632834 @ @ 1 BPHS0235 Fig.
  • Page 229 Operation Pos: 80.19.29 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Oberfaden einfädeln Bild 3 @ 155\mod_1363329246968_78.docx @ 1369890 @ @ 1 BPHS0127 Fig. 152 Pos: 80.19.30 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Oberfaden einfädeln T3 @ 155\mod_1363329332881_78.docx @ 1369919 @ 3 @ 1 • Guide the upper twine from the twine brake (9) through the eye (10) of the tensioning arm (11).
  • Page 230 Operation Pos: 80.21 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ 3 @ 1 This page has been left blank deliberately!! Pos: 80.22 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
  • Page 231 Operation Pos: 80.23 /Abkürzungen /Abkürzungen sprachneutral/Großpackenpresse/BiG PACK 1270 HS / 1270 XC HS /1290 HS / 1290 XC HS / 1290 HDP HS / 1290 HDP XC HS @ 191\mod_1381835593370_0.docx @ 1631999 @ 2 @ 1 BiG PACK 1270 HS (XC) / BiG PACK 1290 HS (XC) / BiG PACK 1290 HDP HS (XC) Pos: 80.24.1 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 6 Doppelknoter/Bindegarn verbinden allgemeine Beschreibung 6 Doppelknoter @ 175\mod_1372829465941_78.docx @ 1504555 @ @ 1 Connecting twine Each of the front six twine rolls (1) provides three upper twines.
  • Page 232 Operation Pos: 80.24.8 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Unterfaden verbinden (2) @ 154\mod_1363266953393_78.docx @ 1367551 @ @ 1 Connecting lower twine (2) Pos: 80.24.9 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 6 Doppelknoter/Bidegarn verbinden im Garnkasten6 Doppelknoter Bild 16 Rollen 3 Ober-/ Unterfäden @ 173\mod_1371027684789_78.docx @ 1484682 @ @ 1 Fig.
  • Page 233 Operation Pos: 80.24.13 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 6 Doppelknoter/Garnrollen Unterfaden verbinden 3a, 3b und 3c (3 Unterfäden) @ 176\mod_1372838381524_78.docx @ 1505318 @ 33 @ 1 Connecting twine rolls 3a, 3b, and 3c with each other Guide the beginning of the twine of twine roll (3a) over the blue eye above and further to the front to the next blue eye.

  • Page 234: Threading In The Lower Twine

    Operation Pos: 80.24.16 /Überschriften/Überschriften 3/U-Z/Unterfaden einfädeln @ 154\mod_1363274391674_78.docx @ 1369094 @ 3323 @ 1 11.2.5 Threading in the Lower Twine Pos: 80.24.17 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Unterfaden vom Garkasten zur unteren Garnführung weiterführen. @ 154\mod_1363274502562_78.docx @ 1369122 @ @ 1 Then guide the lower twine from the twine box to the lower twine guide. Pos: 80.24.18 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 6 DoppelknoterUnterfaden einfädeln Bild 1 BiG PACK 1270 HS/1290 HS/ 1290 HDP HS @ 176\mod_1372839792475_78.docx @ 1505347 @ 2 @ 1 BPHS0251 Fig.

  • Page 235: Threading In The Upper Twine

    Operation Pos: 80.24.24 /Überschriften/Überschriften 3/K-O/Oberfaden einfädeln @ 154\mod_1363276173731_78.docx @ 1369401 @ 23 @ 1 11.2.6 Threading in the Upper Twine Pos: 80.24.25 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Oberfaden vom Garkasten zur oberen Garnführung weiterführen @ 154\mod_1363276378790_78.docx @ 1369487 @ @ 1 Then guide the upper twine from the twine box to the upper twine guide. Pos: 80.24.26 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Bindeeinrichtung 6 Doppelknoter/Oberfaden einfädeln Bild 1 (3Oberfäden) @ 176\mod_1372849007329_78.docx @ 1506263 @ @ 1 BPHS0226 Fig.
  • Page 236 Operation Pos: 80.24.32 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Oberfaden einfädeln Bild 3 @ 155\mod_1363329246968_78.docx @ 1369890 @ 2 @ 1 BPHS0127 Fig. 159 Pos: 80.24.33 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Oberfaden einfädeln T3 @ 155\mod_1363329332881_78.docx @ 1369919 @ @ 1 • Guide the upper twine from the twine brake (9) through the eye (10) of the tensioning arm (11).

  • Page 237: Pick-Up

    Operation Pos: 80.26 /Überschriften/Überschriften 2/P-T/Pick up @ 1\mod_1201791975201_0.docx @ 54586 @ 22 @ 1 11.3 Pick-up Pos: 80.27 /BA/Erstinbetriebnahme/Großpackenpressen/Absperrhahn Pick-up Bild mit Legende @ 155\mod_1363682181297_78.docx @ 1373728 @ 2 @ 1 Fig. 160 Position (a) pick-up released Position (b) pick-up locked Pos: 80.28 /BA/Bedienung /Großpackenpresse/Pick-up/Bedienung Pick-up heben / senken @ 152\mod_1362669449546_78.docx @ 1356754 @ 2 @ 1 •...

  • Page 238: Lifting / Lowering Bale Chute

    Operation Pos: 80.31.1 /BA/Bedienung /Großpackenpresse/Hydraulisch klappbare Rollenschurre/Bedienung Rollenschurre heben /Bedienung Rollenschurre heben / senken Einführtext @ 157\mod_1364366813421_78.docx @ 1386205 @ 22 @ 1 11.4 Lifting / Lowering Bale Chute The operation of the bale chute (1) depends on the version you have (medium version electronics or comfort version electronics).
  • Page 239 Operation Pos: 80.31.4 /BA/Bedienung /Großpackenpresse/Hydraulisch klappbare Rollenschurre/Bedienung Rollenschurre heben/senken (bei Ausführung Komfort) Text @ 152\mod_1362670859498_78.docx @ 1356898 @ 33 @ 1 Comfort Design Via the terminal BPHS0138 Fig. 162 Via the terminal, the bale chute can be lowered merely into working position. •...

  • Page 240: Operating Bale Ejector

    Operation Pos: 80.33 /Überschriften/Überschriften 2/A-E/Ballenausschieber bedienen @ 168\mod_1368535471051_78.docx @ 1458201 @ 222 @ 1 11.5 Operating Bale Ejector Pos: 80.34 /BA/Bedienung /Großpackenpresse/Ballenausschieber/Ballenausschieber bedienen Medium-Elektronik @ 152\mod_1362731209452_78.docx @ 1357360 @ @ 1 Operating the bale ejector (medium version electronics design) Fig. 164 Position a = move bale ejector forward Position b = move bale ejector backward •...
  • Page 241 Operation Pos: 80.37 /BA/Bedienung /Großpackenpresse/Ballenausschieber/Ballenausschieber bedienen, bei Ausführung Komfort Text @ 152\mod_1362731210093_78.docx @ 1357385 @ 22 @ 1 Operating the bale ejector via the operation terminal, for comfort version electronics design BPHS0138 When activating the bale ejector, 10 bales are always ejected via the terminal. •...

  • Page 242: Parking Jack

    Operation Pos: 80.40 /Überschriften/Überschriften 2/P-T/Stützfuß @ 175\mod_1372676754261_78.docx @ 1502329 @ 22 @ 1 11.6 Parking Jack Pos: 80.41 /BA/Erstinbetriebnahme/Großpackenpressen/Abstellstütze/Abstellstütze Standfläche vergrößern @ 17\mod_1236319619729_78.docx @ 204459 @ 22 @ 1 Note If the ground is soft, enlarge the footprint of the parking jack by placing a wooden plank underneath.

  • Page 243: Hydraulic Parking Jack

    Operation Pos: 80.46 /Überschriften/Überschriften 2/F-J/Hydraulischer Stützfuß @ 108\mod_1335163952883_78.docx @ 972995 @ 22 @ 1 11.7 Hydraulic parking jack Pos: 80.47 /BA/Erstinbetriebnahme/Großpackenpressen/Abstellstütze/Abstellstütze Standfläche vergrößern @ 17\mod_1236319619729_78.docx @ 204459 @ 3 @ 1 Note If the ground is soft, enlarge the footprint of the parking jack by placing a wooden plank underneath.

  • Page 244: Bale Brake

    Operation Pos: 80.56 /BA/Bedienung /Großpackenpresse/Ballenbremse/Ballenbremse @ 90\mod_1323357448359_78.docx @ 770823 @ 32322 @ 1 11.8 Bale brake Only in connection with bale scale BPHS0068 Fig. 169 The bale brake (1) is used to lock the first two rollers of the roller chute. This is necessary to achieve accurate weight recording of bales.

  • Page 245: Working Floodlight

    Operation Pos: 80.58 /BA/Inbetriebnahme/Großpackenpresse/Arbeitsscheinwerfer HS Baureihe @ 168\mod_1368521414653_78.docx @ 1457150 @ 2323 @ 1 11.8.1 Working floodlight The working floodlight is switched on and off via the operating terminal. The activated state is indicated on the display. Switching the working floodlight on Press the function key for Switching the working floodlight off Press the function key for...

  • Page 246: Initiating The Tying Process Manually

    Operation Pos: 80.61 /BA/Bedienung /Großpackenpresse/Bindevorgang von Hand auslösen @ 170\mod_1369744285660_78.docx @ 1468817 @ 2323 @ 1 11.9 Initiating the Tying Process Manually Fig. 170 It is only necessary to trigger the tying process manually when performing maintenance, adjustment and repair tasks. Prerequisite: –...

  • Page 247: Removing Blockages

    Operation Pos: 80.64 /BA/Einstellungen/Schneidwerk/Verstopfungen entfernen Big Pack @ 20\mod_1238654439288_78.docx @ 224033 @ 231 @ 1 11.11 Removing blockages • Wait until all moving components stop • Apply the flywheel brake • Lower the cutting system with the tractor hydraulics (with the Comfort electronics system: Activate the tractor hydraulics and hold down “Lower blade bar”...

  • Page 248: Settings

    Settings Pos: 82.1 /Überschriften/Überschriften 1/A-E/Einstellungen @ 0\mod_1199868783862_78.docx @ 36141 @ 31 @ 1 Settings Pos: 82.2 /BA/Sicherheit/Großpackenpressen/Gefahr - Wartungs-, Montage-, Reparatur- und Einstellarbeiten an der Bindung @ 20\mod_1239002475628_78.docx @ 225581 @ 22 @ 1 DANGER! - Maintenance, assembly, repair and adjustment work Effect: Danger to life, injuries or damage to the machine.

  • Page 249: Pick-Up

    Settings Pos: 82.5 /Überschriften/Überschriften 2/P-T/Pick up @ 1\mod_1201791975201_0.docx @ 54586 @ 22 @ 1 12.1 Pick-up Pos: 82.6 /BA/Sicherheit/Pick-up / Rollenniederhalter/Gefahr - Arbeiten an bzw. unter der Pick-up @ 19\mod_1238575749713_78.docx @ 221447 @ 3 @ 1 DANGER! - Working on or under the Pick-up! Effect: Danger to life or serious injuries To work on or under the Pick-up, always secure it against unintentional lowering by moving the shut-off valve on the left side of the machine.

  • Page 250: Setting The Ground Pressure Of The Guide Wheels

    Settings Pos: 82.11 /Überschriften/Überschriften 3/A-E/Auflagedruck der Tasträder einstellen @ 157\mod_1364377544872_78.docx @ 1387272 @ 3 @ 1 12.2.1 Setting the Ground Pressure of the Guide Wheels Pos: 82.12 /Abkürzungen /Bei Ausführung ohne Schneidwerk @ 157\mod_1364379318831_78.docx @ 1387595 @ @ 1 Design without cutting system Pos: 82.13 /BA/Einstellungen/Pick-up / Rollenniederhalter/Auflagedruck der Tasträder 1290 HDP II Bild Ausführung ohne Schneidwerk @ 157\mod_1364377057422_78.docx @ 1387153 @ @ 1 Fig.

  • Page 251: Driving With Pick-Up In Fixed Position

    Settings Pos: 82.21 /Überschriften/Überschriften 3/F-J/Fahren mit feststehender Pick-up @ 71\mod_1305804535480_78.docx @ 640896 @ 32 @ 1 12.2.2 Driving with Pick-up in fixed position Pos: 82.22 /BA/Einstellungen/Pick-up / Rollenniederhalter/Fahren mit feststehender Pick-up Bild 4x4 @ 71\mod_1305805323853_78.docx @ 640982 @ 2 @ 1 Fig.

  • Page 252: Roller Crop Guide

    Settings Pos: 82.25 /Überschriften/Überschriften 2/P-T/Rollenniederhalter @ 0\mod_1201163046930_78.docx @ 51122 @ 2 @ 1 12.3 Roller crop guide Pos: 82.26 /BA/Sicherheit/Pick-up / Rollenniederhalter/Gefahr - Abbau des Rollenniederhalters @ 20\mod_1238580223182_78.docx @ 222168 @ 2 @ 1 DANGER! - Operation of the machine without roller crop guide! Effect: Danger to life or serious injuries The roller crop guide is used for accident protection and must not be removed during operation.

  • Page 253: Setting The Needles

    Settings Pos: 82.31 /BA/Einstellungen/Großpackenpresse/Nadeleinstellungen/Nadeleinstellung ÜS @ 21\mod_1239103867040_78.docx @ 229569 @ 232 @ 1 12.4 Setting the needles Pos: 82.32 /BA/Einstellungen/Großpackenpresse/Nadeleinstellungen/Seitliche Einstellung der Nadeln ÜS @ 25\mod_1242369497056_78.docx @ 253521 @ 322 @ 1 12.4.1 Lateral setting of the needles Pos: 82.33 /BA/Einstellungen/Großpackenpresse/Nadeleinstellungen/Achtung Einstellungen der Nadel / Nadelschwinge nicht überprüft @ 21\mod_1239103937727_78.docx @ 229593 @ 23 @ 1 CAUTION! –...

  • Page 254: Setting The Height Of The Needles On The Knotter

    Settings Pos: 82.36 /Überschriften/Überschriften 3/F-J/Höhe der Nadeln am Knoter einstellen @ 26\mod_1245326395230_78.docx @ 260901 @ 23 @ 1 12.4.2 Setting the height of the needles on the knotter Pos: 82.37 /BA/Einstellungen/Großpackenpresse/Nadeleinstellungen/Höhe der Nadeln am Knoter Bild Einfachknoter und Doppelknoter @ 26\mod_1245326467168_78.docx @ 260925 @ 32 @ 1 BPXC0154 Fig.

  • Page 255: Top Dead Centre Of The Needles

    Settings Pos: 82.40 /BA/Einstellungen/Großpackenpresse/Nadeleinstellungen/Oberer Totpunkt der Nadeln @ 21\mod_1239093619118_78.docx @ 228856 @ 32 @ 1 12.4.3 Top dead centre of the needles To be able to check the upper dead point of the needles, turn the needle yoke up to its highest position (dead centre point) (II).

  • Page 256: Setting The Needle Yoke Brake

    Settings Pos: 82.44 /BA/Einstellungen/Großpackenpresse/Nadeleinstellungen/Einstellung der Nadelschwingenbremse 890_1270_1290 @ 21\mod_1239104796102_78.docx @ 229724 @ 322 @ 1 12.5 Setting the needle yoke brake Fig. 181 Note • The needle yoke brake should not be set until the height of the needle on the knotter and the upper dead point of the needle have previously been checked and set, if necessary! •...

  • Page 257: Checking / Adjusting Position Of Needles - Baling Ram

    Settings Pos: 82.46 /BA/Einstellungen/Großpackenpresse/Nadeleinstellungen/Position Nadeln – Preßkolben prüfen @ 150\mod_1362057381079_78.docx @ 1343393 @ 3322 @ 1 12.6 Checking / adjusting position of needles – baling ram Fig. 182 Check: • Completely release spring tension of the needle yoke brake • Manually actuate the tying process while the machine is at a standstill •...

  • Page 258: Checking / Setting Upper Needle

    Settings Pos: 82.48 /BA/Einstellungen/Großpackenpresse/Nadeleinstellungen/Obernadel prüfen / einstellen @ 169\mod_1369631728553_78.docx @ 1464745 @ 23222 @ 1 12.7 Checking / Setting Upper Needle Fig. 183 • Make a catch hook (1). • In order to simulate a tied bale, pull the twine (2) with the catch hook out of the bale channel and fix it on the top on the bale channel flap with a shaft (3) (screwdriver).

  • Page 259: Checking / Setting Twine Bar

    Settings Pos: 82.50 /BA/Einstellungen/Großpackenpresse/Garnriegel/Garnriegel prüfen einstellen Einführtext @ 170\mod_1369723043694_78.docx @ 1467443 @ 2232 @ 1 12.8 Checking / Setting Twine Bar The twine bar moves the twine away from the needle and pushes it against the knotter hook. If the twine is not grasped by the twine bar, the knotter hook cannot pick-up the twine. Pos: 82.51 /BA/Einstellungen/Großpackenpresse/Garnriegel/Garnriegels zur Unternadel prüfen / einstellen BiG PACK 1290 HDP II @ 169\mod_1369643661123_78.docx @ 1465679 @ 323 @ 1 12.8.1 Checking / Setting the Twine Bar to the Lower Needle (Needle Yoke)

  • Page 260: Checking / Setting Twine Bar To The Channel Slot

    Settings Pos: 82.53 /BA/Einstellungen/Großpackenpresse/Garnriegel/Garnriegel zum Kanalschlitz prüfen / einstellen BiG PACK 1290 HDP II @ 170\mod_1369665315981_78.docx @ 1466997 @ 32 @ 1 12.9 Checking / Setting Twine Bar to the Channel Slot Fig. 186 Prerequisite: – The machine is disconnected from the tractor. –...
  • Page 261 Settings Pos: 82.55 /BA/Einstellungen/Großpackenpresse/Garnriegel/Garnriegel Übergriff am 2ten Knoten prüfen HDP II @ 170\mod_1369666372743_78.docx @ 1467026 @ 322 @ 1 Checking the overreach of the twine bars on the second knot Fig. 187 Prerequisite: – The first knot (closing knot) must have been made manually. Checking •...

  • Page 262: Tightening / Releasing Twine Bar Shaft

    Settings Pos: 82.57 /BA/Einstellungen/Großpackenpresse/Garnriegel/Garnriegelwelle spannen / entspannen BiG PACK 1290 HDP II @ 170\mod_1369665183011_78.docx @ 1466968 @ 222 @ 1 12.10 Tightening / Releasing Twine Bar Shaft Fig. 188 The twine bar shaft (1) is tightened or released via spring (2). Prerequisite: The knotter gear is in idle position;...

  • Page 263: Setting The Twine Brake

    Settings Pos: 82.60 /Überschriften/Überschriften 2/F-J/Garnbremse einstellen @ 127\mod_1346138729566_78.docx @ 1147164 @ 22 @ 1 12.11 Setting the Twine Brake Pos: 82.61 /BA/Einstellungen/Großpackenpresse/Garnbremse/Garnbremse Bild alle HS-Typen außer HDP II @ 192\mod_1382085040686_78.docx @ 1638076 @ @ 1 Fig. 190 Pos: 82.62 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Alte Ausführungen/Enfachknoter @ 20\mod_1239009990035_78.docx @ 226947 @ @ 1 Single knotter Pos: 82.63 /BA/Einstellungen/Großpackenpresse/Garnbremse/Garnbremse Einführtext Einfachknoter HS Baureihe @ 192\mod_1382085308600_78.docx @ 1638185 @ 2 @ 1 The twine brakes (2) can be found in the twine boxes.

  • Page 264: Setting The Twine Tension On The Upper Twine Strand (Double Knotter)

    Settings Pos: 82.70 /BA/Einstellungen/Großpackenpresse/Garnbremse/Garnspannung am oberen Garnstrang (Doppelknoter) @ 24\mod_1240995388836_78.docx @ 241628 @ 33 @ 1 12.11.1 Setting the twine tension on the upper twine strand (double knotter) Fig. 191 The upper strands of twine (1) should be held by the brakes (2) up to a tensile force of 100 - 120 N.

  • Page 265: Setting The Twine Tension Of The Lower Twine Strand (Double Knotter)

    Settings Pos: 82.72 /BA/Einstellungen/Großpackenpresse/Garnbremse/Garnspannung am unteren Garnstrang Doppelknoter @ 24\mod_1240996666196_78.docx @ 241703 @ 223 @ 1 12.11.2 Setting the twine tension of the lower twine strand (double knotter) Fig. 192 The twine brakes (1) for the lower twine strand are behind the packer under the bale channel chamber.

  • Page 266: Knotter

    Settings Pos: 82.74 /Überschriften/Überschriften 2/K-O/Knoter @ 24\mod_1241083059412_78.docx @ 242902 @ 233 @ 1 12.12 Knotter Pos: 82.75 /BA/Sicherheit/Gefahrenhinweise/Großpackenpresse/Gefahr - Reparatur_Wartungs_Einstellarbeiten am Knoter @ 24\mod_1241081243490_78.docx @ 242756 @ @ 1 DANGER! - Maintenance, setting and repair work on the knotter Effect: Danger to life, serious injuries •...

  • Page 267: Start-Up

    Settings Pos: 82.79 /BA/Einstellungen/Großpackenpresse/Knoter/Inbetriebnahme Knoter @ 24\mod_1241083585365_78.docx @ 242950 @ 333 @ 1 12.12.2 Start-up The knotter has been set and tested by the manufacturer. It should work properly without requiring any further settings. If there are problems with tying when it is placed in service for the first time, the mechanisms should not be set immediately, since this is usually caused by errors that are caused by paint, rust and bare spots.

  • Page 268: Setting Of Twine Retainer

    Settings Pos: 82.80.5 /Überschriften/Überschriften 3/A-E/Einstellung Garnhalter @ 47\mod_1285054111875_78.docx @ 455539 @ 3 @ 1 12.12.5 Setting of twine retainer Pos: 82.80.6 /BA/Einstellungen/Großpackenpresse/Knoter/Einfachknoter Raspe/Garnhalter Einachknoter Raspe Bild @ 47\mod_1285055172921_78.docx @ 455565 @ 43 @ 1 Fig. 195 Pos: 82.80.7 /BA/Einstellungen/Großpackenpresse/Knoter/Garnhalter Text Einfachknoter / Doppelknoter Raspe @ 47\mod_1285053711171_78.docx @ 455513 @ @ 1 Setting the twine driver The function of the twine driver (5) depends on the position of its indentation opposite the twine disc cleaner (7).

  • Page 269: Setting The Holding Force Of The Twine Retainer (6)

    Settings Pos: 82.80.9 /BA/Einstellungen/Großpackenpresse/Knoter/Einfachknoter Raspe/Einstellung der Haltekraft des Garnhalters Doppelknoter @ 47\mod_1285056343218_78.docx @ 455591 @ 34 @ 1 12.12.5.1 Setting the holding force of the twine retainer (6) Fig. 196 The holding force has been preset ex works. Note The type and moisture content of baling material and its baling density as well as the tying twine that is selected all require different settings, which have to be determined by trial and error under actual working conditions.

  • Page 270: Setting Of Blade Lever (Single Knotter)

    Settings Pos: 82.80.11 /BA/Einstellungen/Großpackenpresse/Knoter/Einfachknoter Raspe/Messerhebel Einfachknoter Raspe Bild @ 47\mod_1285059753453_78.docx @ 455643 @ 33 @ 1 12.12.6 Setting of blade lever (single knotter) Fig. 197 Pos: 82.80.12 /BA/Einstellungen/Großpackenpresse/Knoter/Messerhebel Text Einfachknoter / Doppelknoter Raspe @ 47\mod_1285058951359_78.docx @ 455617 @ 3 @ 1 The blade lever (1) must be aligned so that the knotter hook (2) can turn freely without touching the blade lever at any point on the blade lever.

  • Page 271: Double Knotter

    Settings Pos: 82.82.1 /Überschriften/Überschriften 3/A-E/Doppelknoter @ 24\mod_1241099544678_78.docx @ 243310 @ 3 @ 1 12.12.7 Double knotter Pos: 82.82.2 /BA/Einstellungen/Großpackenpresse/Knoter/Doppelknoter/Knüpferhaken Doppelknoter Bild @ 24\mod_1241099865006_78.docx @ 243331 @ 33 @ 1 12.12.8 Knotter hook (double knotter) Fig. 199 Pos: 82.82.3 /BA/Einstellungen/Großpackenpresse/Knoter/Knüpferhaken Text Doppelknoter / Einfachknoter Raspe @ 47\mod_1285046930718_78.docx @ 455408 @ @ 1 The knotter tongue (5) of the knotter hook (2) is tensioned by the leaf spring (3) on the closer (1).

  • Page 272: Setting Of Twine Retainer

    Settings Pos: 82.82.5 /Überschriften/Überschriften 3/A-E/Einstellung Garnhalter @ 47\mod_1285054111875_78.docx @ 455539 @ 3 @ 1 12.12.9 Setting of twine retainer Pos: 82.82.6 /BA/Einstellungen/Großpackenpresse/Knoter/Doppelknoter/Garnhalter Doppelknoter Bild @ 24\mod_1241416073040_78.docx @ 243437 @ 43 @ 1 Fig. 200 Pos: 82.82.7 /BA/Einstellungen/Großpackenpresse/Knoter/Garnhalter Text Einfachknoter / Doppelknoter Raspe @ 47\mod_1285053711171_78.docx @ 455513 @ @ 1 Setting the twine driver The function of the twine driver (5) depends on the position of its indentation opposite the twine disc cleaner (7).

  • Page 273: Setting The Holding Force Of The Twine Retainer (6)

    Settings Pos: 82.82.9 /BA/Einstellungen/Großpackenpresse/Knoter/Doppelknoter/Einstellung der Haltekraft des Garnhalters Doppelknoter @ 24\mod_1241416439493_78.docx @ 243462 @ 134 @ 1 12.12.9.1 Setting the holding force of the twine retainer (6) Fig. 201 The holding force has been preset ex works. Note The type and moisture content of baling material and its baling density as well as the tying twine that is selected all require different settings, which have to be determined by trial and error under actual working conditions.

  • Page 274: Setting The Blade Lever (Double Knotter)

    Settings Pos: 82.82.11 /BA/Einstellungen/Großpackenpresse/Knoter/Doppelknoter/Messerhebel (Doppelknoter) Bild @ 24\mod_1241416794165_78.docx @ 243513 @ 32 @ 1 12.12.10 Setting the blade lever (double knotter) Fig. 202 Pos: 82.82.12 /BA/Einstellungen/Großpackenpresse/Knoter/Messerhebel Text Einfachknoter / Doppelknoter Raspe @ 47\mod_1285058951359_78.docx @ 455617 @ @ 1 The blade lever (1) must be aligned so that the knotter hook (2) can turn freely without touching the blade lever at any point on the blade lever.

  • Page 275: Baling Ram Setting

    The baling ram (3) of the BiG PACK 1270 / 1290 / 4x4 is equipped with seven blades (5) • The baling ram (3) of the BiG PACK 890 is only equipped with 5 blades (5) because of the small width of the bale channel chamber Pos: 82.84.5 /BA/Einstellungen/Großpackenpresse/Presskolbeneinstellung/Einstellung der Preßkolbenmesser ÜS mit Einführtext @ 172\mod_1370430153723_78.docx @ 1478090 @ 33 @ 1...

  • Page 276: Cleaning The Running Rails

    Settings Pos: 82.84.10 /BA/Einstellungen/Großpackenpresse/Presskolbeneinstellung/Laufschienenreinigung @ 24\mod_1241423347774_78.docx @ 243762 @ 323 @ 1 12.13.2 Cleaning the running rails Fig. 205 The cleaning rails (2) are positioned on the four rollers (3). They remove dirt deposits from the running rails of the baling ram. To adjust, loosen the screws (1) and adjust the cleaning rails to the dimension a = 1 - 2 mm.

  • Page 277: Adjusting The Packer Relative To The Plunger

    Settings Pos: 82.84.13 /Überschriften/Überschriften 2/P-T/Raffer zum Presskolben einstellen @ 107\mod_1334638713108_78.docx @ 968035 @ 322 @ 1 12.14 Adjusting the Packer Relative to the Plunger Pos: 82.84.14 /Überschriften/Überschriften 3/A-E/Baugruppenbeschreibung @ 107\mod_1334639066023_78.docx @ 968123 @ 33 @ 1 12.14.1 Description of components Pos: 82.84.15 /BA/Einstellungen/Großpackenpresse/Presskolbeneinstellung/Raffer zum Presskolben alle HS TYpen außer 1290 HDP II Bild mit Legende @ 192\mod_1382087044802_78.docx @ 1638478 @ 3 @ 1 Fig.
  • Page 278 Settings Pos: 82.84.17 /BA/Einstellungen/Großpackenpresse/Presskolbeneinstellung/Raffer zum Preßkolben Vorgehensweise alle HS TYpen außer 1290 HDP @ 192\mod_1382092377530_78.docx @ 1638885 @ 32 @ 1 Adjusting packer to baling ram is only necessary if the following parts have been disassembled: – Packer coupling (7), packer gearbox (8), chain coupling (9), –...

  • Page 279: Checking Packer Coupling

    Settings Pos: 82.84.19 /BA/Einstellungen/Großpackenpresse/Presskolbeneinstellung/Rafferkupplung überprüfen Einrastung der BP 4x4 Baureihe @ 74\mod_1308666241589_78.docx @ 657137 @ 332 @ 1 12.14.2 Checking packer coupling Fig. 208 Note The packer coupling is correctly engaged when the outer marks (1) on the packer coupling are aligned with the mark (2) on the inner ring of the packer coupling. Pos: 82.84.20 /Überschriften/Überschriften 3/P-T/Rafferleiste in Position bringen @ 171\mod_1369995210446_78.docx @ 1473367 @ 321 @ 1 12.14.3 Moving Packer Strip into Position...

  • Page 280: Moving Baling Ram Into Position

    Settings Pos: 82.84.24 /BA/Einstellungen/Großpackenpresse/Presskolbeneinstellung/Presskolben in Position bringen alle HS TYpen außer 1290 HDP T2 @ 192\mod_1382092469255_78.docx @ 1638910 @ 232 @ 1 12.14.4 Moving Baling Ram into Position Fig. 210 Prerequisite: – The packer strip is in position, refer to chapter Settings “Moving Packer Strip into Position”...
  • Page 281 Settings Pos: 82.86 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ 232 @ 1 This page has been left blank deliberately!! Pos: 82.87 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...

  • Page 282: Variable Filling System (Vfs)

    Settings Pos: 82.88.1 /Überschriften/Überschriften 2/U-Z/Variables Füllsystem (VFS) @ 24\mod_1241431500540_78.docx @ 244244 @ 322 @ 1 12.15 Variable filling system (VFS) Pos: 82.88.2 /BA/Einstellungen/Großpackenpresse/Variables Füllsystem VFS/Einstellen des VFS-Systems HS Baureihe T1 @ 63\mod_1299772271423_78.docx @ 576225 @ @ 1 When modifications are made to the variable filling system, especially: •...

  • Page 283: Adjusting The Variable Filling System (Vfs)

    Settings Pos: 82.88.8 /Überschriften/Überschriften 3/A-E/Einstellen des Variablen Füllsystems (VFS) @ 63\mod_1299824731811_78.docx @ 576265 @ 32 @ 1 12.15.2 Adjusting the Variable Filling System (VFS) Pos: 82.88.9 /Überschriften/Überschriften 4/K-O/Nullstellung @ 63\mod_1299835268928_78.docx @ 576643 @ 4 @ 1 12.15.2.1 Zero position Pos: 82.88.10 /BA/Einstellungen/Großpackenpresse/Variables Füllsystem VFS/Einstellen des VFS-Systems Bild T1 HS Baureihe @ 63\mod_1299825528742_78.docx @ 576315 @ @ 1 Fig.212 Pos: 82.88.11 /BA/Einstellungen/Großpackenpresse/Variables Füllsystem VFS/Nullstellung @ 63\mod_1299834497383_78.docx @ 576617 @ 2 @ 1 Turn the packer in the working direction manually by turning the flywheel until the roller (8)
  • Page 284 Settings Pos: 82.88.13 /BA/Einstellungen/Großpackenpresse/Variables Füllsystem VFS/Einstellen des VFS-Systems Bild T2 HS Baureihe @ 63\mod_1299826567593_78.docx @ 576370 @ 2 @ 1 Fig.213 Pos: 82.88.14 /BA/Einstellungen/Großpackenpresse/Variables Füllsystem VFS/Einstellen des VFS-Systems HS Baureihe T2 @ 63\mod_1299826648478_78.docx @ 576397 @ 33 @ 1 • Pull the feeler rocker (1) backwards to trigger the VFS.

  • Page 285: Absorbing Mechanism

    Settings Pos: 82.88.16 /BA/Einstellungen/Großpackenpresse/Variables Füllsystem VFS/Anschlag der Tastschwinge prüfen HS Baureihe @ 63\mod_1299826779699_78.docx @ 576428 @ 4 @ 1 Fig.214 Checking the stopper (10). After the VF system has been triggered the displacement 'E' between the stopper (10) (LHS of machine) and the swivelled feeler rocker (1) must be checked.

  • Page 286: Checking The Setting

    Settings Pos: 82.88.21 /BA/Einstellungen/Großpackenpresse/Variables Füllsystem VFS/Dämpungseinrichtung prüfen der Einstellung @ 24\mod_1241438940993_78.docx @ 244770 @ 433 @ 1 12.15.3.1 Checking the setting Pull the anvil (4) through the feeler rocker into the rear position. Measure dimension A
 between the edge of the anvil and the brake plate (3). Now pull the anvil (4) through the feeler rocker into the forwardmost position.

  • Page 287: Setting The Triggering Sensitivity

    Settings Pos: 82.88.23 /Überschriften/Überschriften 3/A-E/Einstellung der Auslöseempfindlichkeit @ 24\mod_1241436809555_78.docx @ 244518 @ 33 @ 1 12.15.4 Setting the triggering sensitivity Pos: 82.88.24 /BA/Einstellungen/Großpackenpresse/Variables Füllsystem VFS/Einstellung der Auslöseempfindlichkeit Bild HS Baureihe @ 63\mod_1299737209712_78.docx @ 575205 @ @ 1 Fig.216 Pos: 82.88.25 /BA/Einstellungen/Großpackenpresse/Variables Füllsystem VFS/Einstellung der Auslöseempfindlichkeit Allgemein HS Baureihe @ 63\mod_1299827375507_78.docx @ 576478 @ @ 1 The purpose of the spring (8) is to pre-tension the feeler rocker via the anvil (4) and the threaded spindle (2) and move it back into the swivelled-in position after the fodder has been pushed in.

  • Page 288: Setting The Spring Of The Zero Adjuster

    Settings Pos: 82.88.31 /Überschriften/Überschriften 3/A-E/Einstellung der Feder des Nullstellers @ 74\mod_1308658231304_78.docx @ 656856 @ 23 @ 1 12.15.5 Setting the spring of the zero adjuster Pos: 82.88.32 /BA/Einstellungen/Großpackenpresse/Variables Füllsystem VFS/Einstellung der Feder des Nullstellers Bild BP 12130 HS Baureihe @ 74\mod_1308661296567_78.docx @ 656884 @ 32 @ 1 Fig.

  • Page 289: Setting The Flywheel Cleaning (Only On Big Pack 890)

    Settings Pos: 82.90 /BA/Einstellungen/Großpackenpresse/Einstellung der Schwungradreinigung (nur bei Big Pack 890) @ 24\mod_1241439733852_78.docx @ 244873 @ 32 @ 1 12.16 Setting the flywheel cleaning (only on BiG PACK 890) Fig. 218 Even minor accumulations of dirt inside the flywheel (1) can result in imbalances. For this reason, you should regularly check the setting of the plastic rail (2).

  • Page 290: Setting The Multibale

    Settings Pos: 82.93.1 /Überschriften/Überschriften 3/A-E/Einstellung Multi-Bale @ 24\mod_1241443710211_78.docx @ 244999 @ 3332 @ 1 12.17.1 Setting the MultiBale Pos: 82.93.2 /BA/Einstellungen/Großpackenpresse/MutiBale/Position zweite Nadelschwinge / Anschlag Bild @ 24\mod_1241443960165_78.docx @ 245076 @ 332 @ 1 Fig. 220 Pos: 82.93.3 /BA/Einstellungen/Großpackenpresse/MutiBale/Einstellung Position zweite Nadelschwinge @ 24\mod_1241444369290_78.docx @ 245100 @ 33233 @ 1 12.17.2 Setting the position of the second needle yoke The tube (2) of the needle yoke (3) has to be located in the trough (4).

  • Page 291: Setting The Locking (Frame)

    Settings Pos: 82.93.7 /BA/Einstellungen/Großpackenpresse/MutiBale/Einstellung Verriegelung (Rahmen) @ 24\mod_1241498609820_78.docx @ 245279 @ 3434 @ 1 12.17.5 Setting the locking (frame) Fig. 222 • Set the support tube (10) so that the distance between the locking (11) and the support tube (10) is Z = 15-35 mm Pos: 82.93.8 /BA/Einstellungen/Großpackenpresse/MutiBale/Einstellung Verriegelungen der Nadelschwingen @ 24\mod_1241501736055_78.docx @ 245306 @ 3334431 @ 1 12.17.6 Setting the lockings of the needle yoke...

  • Page 292: Setting The Rubber Pad Between The Needle Yokes

    Settings Pos: 82.93.10 /BA/Einstellungen/Großpackenpresse/MutiBale/Einstellung Gummipuffer zwischen den Nadelschwingen @ 24\mod_1241501934539_78.docx @ 245332 @ 2341 @ 1 12.17.7 Setting the rubber pad between the needle yokes Fig. 224 Setting the distance U By adding or removing compensation washers (16) between the rubber pad (17) and the needle yoke (18) the spacing is increased or decreased.

  • Page 293: Maintenance

    Effect: Danger to life, serious injuries or loss of warranty claims as well as exclusion of liability • Use only authentic KRONE spare parts and accessories authorised by the manufacturer. The use of spare parts, accessories or additional equipment not manufactured, tested or approved by KRONE will exclude any liability for consequential damage.

  • Page 294: Maintenance Table

    Maintenance Pos: 85.10 /Überschriften/Überschriften 2/U-Z/Wartungstabelle @ 65\mod_1300369413064_78.docx @ 583966 @ 222 @ 1 14.3 Maintenance table Pos: 85.11 /BA/Wartung/Großpackenpressen/Wartungstabelle 1290 HDP II T1 @ 158\mod_1364472985841_78.docx @ 1390724 @ @ 1 Maintenance Work Maintenance interval Tightening screws / nuts All screws Main gearbox Oil level check Oil change...
  • Page 295 Maintenance Pos: 85.13 /BA/Wartung/Großpackenpressen/Wartungstabelle 1290 HDP II T2 @ 171\mod_1370243929901_78.docx @ 1473813 @ 22 @ 1 Maintenance work Maintenance interval Tyres Tighten wheel nuts Check tyre pressure Check tyres visually for cuts and breaks Compressor Clean suction air filter Oil level check Oil change Brake Check the functionality of the brake system...

  • Page 296: Tightening Torques

    Maintenance 14.4 Tightening Torques Pos: 85.16 /BA/Wartung/Drehmomente / Anzugsmomente/Drehmomente @ 45\mod_1277102920578_78.docx @ 410945 @ 2 @ 1 A = Thread size The tightening torque M is stated in Nm (The stability class can be seen on the head of the (unless otherwise indicated).

  • Page 297: Tightening Torques (Countersunk Screws)

    Maintenance Pos: 85.18 /Überschriften/Überschriften 2/A-E/Anzugsdrehmomente über Innensechskant @ 45\mod_1277106415765_78.docx @ 411230 @ 222 @ 1 14.5 Tightening Torques (Countersunk Screws) Pos: 85.19 /BA/Wartung/Drehmomente / Anzugsmomente/Drehmomente über Innensechskant @ 45\mod_1277106232328_78.docx @ 411205 @ @ 1 A = Thread size The tightening torque M is stated in Nm (The stability class can be seen on the head of the (unless otherwise indicated).

  • Page 298: Blade Changing

    Maintenance Pos: 85.21 /Überschriften/Überschriften 2/K-O/Messerwechsel @ 8\mod_1219657285958_78.docx @ 119937 @ 2 @ 1 14.6 Blade Changing Pos: 85.22 /BA/Sicherheit/Schneidwerk/Warnung - Messerwechsel Handschuhe tragen @ 20\mod_1238595345166_78.docx @ 223904 @ @ 1 WARNING! - Blade changing Effect: Severe injuries to fingers and hands •...

  • Page 299: Unlocking The Blade Shaft

    Maintenance Pos: 85.27 /BA/Einstellungen/Schneidwerk/Schneidwerk absenken T2 @ 62\mod_1299595998856_78.docx @ 573432 @ 33 @ 1 Releasing the individual knife retention • Use the special tool (4) to turn the upper (1) and the lower (2) blade control system far enough so that the cams of the blade control system move from position (I) to position (II).

  • Page 300: Lifting

    Maintenance Pos: 85.31 /Überschriften/Überschriften 2/A-E/Anheben @ 33\mod_1254380091415_78.docx @ 319041 @ 22 @ 1 14.7 Lifting Pos: 85.32 /BA/Wartung/Großpackenpressen/Anheben der Maschine BigPack @ 64\mod_1300169259139_78.docx @ 580278 @ 323 @ 1 14.7.1 Lifting eyes The baler is equipped with four suspension points: •...

  • Page 301: Cleaning

    Maintenance Pos: 85.34 /Überschriften/Überschriften 2/P-T/Reinigung @ 24\mod_1241504803133_78.docx @ 245455 @ 2 @ 1 14.8 Cleaning Pos: 85.35 /BA/Sicherheit/6. Überarbeitete Warnhinweise/Warnung - Reinigung mit Druckluft (2012-08-10 09:00:02) @ 0\mod_1196770018125_78.docx @ 13211 @ 23 @ 1 Warning! - Cleaning with compressed air! Effect: Loss of eyesight! •...

  • Page 302: Drive Chains

    Maintenance Pos: 85.38 /Überschriften/Überschriften 2/A-E/Antriebsketten @ 27\mod_1246355234599_78.docx @ 267399 @ 3323 @ 1 14.9 Drive chains Pos: 85.39 /BA/Wartung/Antriebsketten (Ketten)/Antriebsketten allgemein @ 107\mod_1334563877892_78.docx @ 966387 @ 3 @ 1 • Regularly check the pretension of the drive chains (especially on new drive chains) •...

  • Page 303: Pick-Up Drive (Iii)

    Maintenance 14.9.3 Pick-up drive (III) Fig. 229 Right and left sides of the machine At the factory the spring has been preset (1) to a = 60 mm. • Open the protective cover on the right or left side of the machine •...

  • Page 304: Conveyor Roller (I)

    Maintenance Pos: 85.45 /Abkürzungen /Bei Ausführung mit Schneidwerk @ 157\mod_1364379388830_78.docx @ 1387653 @ 32 @ 1 Design with cutting system Pos: 85.46 /BA/Wartung/Antriebsketten (Ketten)/Förderwalze (I) bei Ausführung mit Schneidwerk @ 158\mod_1365078238940_78.docx @ 1404345 @ 33 @ 1 14.9.4 Conveyor Roller (I) Fig.

  • Page 305: Pick-Up Drive (Iii)

    Maintenance 14.9.6 Pick-up Drive (III) Fig. 232 Right and left sides of the machine The spring (1) is preset to a = 60 mm in the factory. • Open the protective cover on the right or left machine side. • Loosen counter nut (2).

  • Page 306: Tyres

    If tyres are not correctly fitted, it could explode when pumped up. This can cause serious injury. If you do not have sufficient experience of fitting tyres, have tyres fitted by the KRONE dealer or a qualified tyre specialist. •...

  • Page 307: Checking And Maintaining Tyres

    Maintenance Pos: 85.54 /Überschriften/Überschriften 3/P-T/Reifen prüfen und pflegen @ 0\mod_1197358037214_78.docx @ 18094 @ 3 @ 1 14.10.1 Checking and maintaining tyres Pos: 85.55 /BA/Wartung/Reifen/Reihenfolge Bild 6-Loch @ 4\mod_1213086131413_78.docx @ 86197 @ 1 @ 1 KS-0-034 Fig. 233 Pos: 85.56 /BA/Wartung/Reifen/Reifen prüfen und pflegen nach Wartungstabelle @ 134\mod_1350480797454_78.docx @ 1187905 @ 2 @ 1 When loosening and tightening the wheel nuts, observe the order indicated in the illustration.

  • Page 308: Maintenance - Hydraulic System

    Ensure that all line connections are tight before the pressure in the system builds up again. • Repair work on the hydraulic system must only be performed by authorised KRONE professional workshops. Pos: 89 /BA/Wartung/Großpackenpressen/Hydraulikanlage / Bordhydraulik/Hinweis zu Hydraulikarbeiten @ 24\mod_1241518053726_78.docx @ 245734 @ @ 1 Note •...

  • Page 309: On-Board Hydraulic System

    Maintenance - hydraulic system Pos: 91 /Überschriften/Überschriften 3/A-E/Bordhydraulik @ 24\mod_1241518305195_78.docx @ 245758 @ 32 @ 1 15.1.1 On-board hydraulic system Pos: 92 /BA/Wartung/Umwelt/Hinweis Entsorgen / Lagern von Öle und Ölfilter Umwelt @ 32\mod_1253101375171_78.docx @ 311770 @ 2 @ 1 ENVIRONMENT! - Disposal and storage of used lubricants and oil filters Effect: Environmental damage Store or dispose used oil and oil filters according to statutory provisions.

  • Page 310: High-Pressure Filter

    Maintenance - hydraulic system Pos: 98.1 /Überschriften/Überschriften 2/F-J/Hochdruckfilter @ 26\mod_1245836423991_78.docx @ 264126 @ 222 @ 1 15.2 High-pressure filter Pos: 98.2 /BA/Wartung/Hochdruckfilter/Mitteldruckfilter optische Verschmutzungsanzeige @ 32\mod_1253092558858_78.docx @ 309853 @ 2 @ 1 The filter takes up depositions of solid particles of the hydraulic system. The filtering of the hydraulic circuit serves as a prevention of damages on components of the circuit.

  • Page 311: Emergency Manual Activation

    Maintenance - hydraulic system Pos: 100 /BA/Wartung/Load-Sensing/Großpackenpresse/Not-Handbetätigung HS Baureihe @ 63\mod_1299838530165_78.docx @ 576700 @ 22 @ 1 15.3 Emergency Manual Activation The electromagnetic valve block for the In-cab Comfort kitis located at the front on the left under the side cover next to the electronics box. In the event the electrical system should fail completely, the valves are equipped with an <<Emergency manual activation>>.

  • Page 312: Comfort Hydraulic Block Diagram

    Maintenance - hydraulic system Pos: 102 /BA/Wartung/Load-Sensing/Großpackenpresse/Schaubild Hydraulikblock-Komfort 890_1270_1290 HS Baureihe @ 63\mod_1299743229919_78.docx @ 575452 @ 22 @ 1 15.4 Comfort Hydraulic Block Diagram Funktionsschaubild Magnetventile Fkt.1 Fkt.2 Funktionen Y4 Y5 Y6 Y7 Not-Handbetätigung 27 008 228 0 Fig.236 Raise/lower Y7,Y8 Cutting system Raise/lower...

  • Page 313: Examples Of Emergency Manual Activation

    Maintenance - hydraulic system Pos: 104 /Überschriften/Überschriften 2/A-E/Beispiele zur Not-Hand-Betätigung @ 0\mod_1199946148163_78.docx @ 36985 @ 223 @ 1 15.5 Examples of Emergency Manual Activation Pos: 105 /BA/Sicherheit/Gefahrenhinweise/Ladewagen/Gefahr Not-Hand-Betätigung @ 0\mod_1199945455397_78.docx @ 36965 @ @ 1 Danger! - Unexpected actions on the machine. Effect: Danger to life or serious injuries.

  • Page 314: Pressing Force Control (With Emergency Manual Activation)

    Maintenance - hydraulic system Pos: 108.1 /Überschriften/Überschriften 2/P-T/Presskraftregelung (bei Not-Hand-Betätigung) @ 24\mod_1241612862815_78.docx @ 246772 @ 32 @ 1 15.6 Pressing force control (with emergency manual activation) Pos: 108.2 /BA/Wartung/Großpackenpressen/Hydraulikanlage / Bordhydraulik/Gefahr - Presskraftregelung im Notbetrieb @ 24\mod_1241608452018_78.docx @ 246649 @ 3 @ 1 DANGER! –...

  • Page 315: Maintenance - Gearbox

    Maintenance - Gearbox Pos: 110.1 /Überschriften/Überschriften 1/U-Z/Wartung - Getriebe @ 2\mod_1203058202823_78.docx @ 64495 @ 12 @ 1 Maintenance - Gearbox Pos: 110.2 /BA/Wartung/Ölkontrolle_Wechsel/Großpackenpresse/waagerechte Stellung @ 172\mod_1370436011231_78.docx @ 1478697 @ @ 1 Note When checking the oil level on the gearboxes, make sure that the big pack baler is in horizontal position.

  • Page 316: Packer Gearbox

    Maintenance - Gearbox Pos: 110.10 /Überschriften/Überschriften 2/P-T/Raffergetriebe @ 24\mod_1241584428737_78.docx @ 245996 @ 2 @ 1 16.2 Packer gearbox Pos: 110.11 /BA/Wartung/Ölkontrolle_Wechsel/Großpackenpresse/Raffergetriebe Anbringungsort @ 24\mod_1241585198221_78.docx @ 246121 @ @ 1 The packer gearbox (3) is located on the left side of the machine. Pos: 110.12 /BA/Wartung/Ölkontrolle_Wechsel/Großpackenpresse/Raffergetriebe Bild mit Legende 1290 HDP II @ 158\mod_1364484537954_78.docx @ 1391829 @ @ 1 Fig.

  • Page 317: Transfer Gearbox

    Maintenance - Gearbox Pos: 110.18 /Überschriften/Überschriften 2/U-Z/Verteilergetriebe @ 2\mod_1202991526780_78.docx @ 64104 @ 2 @ 1 16.3 Transfer gearbox Pos: 110.19 /BA/Wartung/Ölkontrolle_Wechsel/Großpackenpresse/Verteilergetriebe Anbringungsort @ 24\mod_1241586943378_78.docx @ 246170 @ @ 1 The transfer gearbox (3) is located on the left side of the machine. Pos: 110.20 /BA/Wartung/Ölkontrolle_Wechsel/Großpackenpresse/Verteilergetriebe Bild mit Legende 1290 HDP II @ 158\mod_1364967330135_78.docx @ 1394795 @ @ 1 Fig.

  • Page 318: Pick-Up Gearbox

    Maintenance - Gearbox Pos: 110.26 /Überschriften/Überschriften 2/P-T/Pick-up Getriebe @ 24\mod_1241589499831_78.docx @ 246271 @ 2 @ 1 16.4 Pick-up gearbox Pos: 110.27 /Abkürzungen /Bei Ausführung ohne Schneidwerk @ 157\mod_1364379318831_78.docx @ 1387595 @ @ 1 Design without cutting system Pos: 110.28 /BA/Wartung/Ölkontrolle_Wechsel/Großpackenpresse/Pick-up Getriebe Anbringungsort @ 24\mod_1241589606081_78.docx @ 246295 @ @ 1 The upper (4a) and lower (4b) Pick-up gearboxes are located on the right side of the machine.

  • Page 319: Cutting System Drive Gear

    Maintenance - Gearbox Pos: 110.35 /Überschriften/Überschriften 2/P-T/Schneidwerksantriebsgetriebe @ 24\mod_1241595072471_78.docx @ 246450 @ 2 @ 1 16.5 Cutting system drive gear Pos: 110.36 /Abkürzungen /Bei Ausführung mit Schneidwerk @ 157\mod_1364379388830_78.docx @ 1387653 @ @ 1 Design with cutting system Pos: 110.37 /BA/Wartung/Ölkontrolle_Wechsel/Großpackenpresse/Schneidwerkgetriebe Anbringungsort @ 193\mod_1383224898575_78.docx @ 1646771 @ @ 1 The cutting system gear is located on the right-hand side of the machine.
  • Page 320 Maintenance - Gearbox Pos: 110.45 /BA/Wartung/Ölkontrolle_Wechsel/Großpackenpresse/Schneidwerkgetriebe Zwischenüberschrift @ 193\mod_1383225102226_78.docx @ 1646814 @ @ 1 Cutting system gear Pos: 110.46 /BA/Wartung/Ölkontrolle_Wechsel/Großpackenpresse/Pick-up Schneidwerksantriebsgetriebe 4x4 Bild @ 175\mod_1372685595789_78.docx @ 1503003 @ @ 1 Fig. 243 Inspection screw / control hole Drain plug Filler plug / oil filling hole Angular gearbox Cutting system gear Pos: 110.47 /BA/Wartung/Ölkontrolle_Wechsel/Ölkontrolle / Ölwechsel Intervall: siehe Kapitel Wartung „Wartungstabelle“...

  • Page 321: Maintenance - Brake System

    • Irregularities or malfunctions in the brake system must be eliminated immediately. • No changes may be made to the brake system without the approval of KRONE. • Have the brakes checked regularly by a specialist workshop. •...

  • Page 322: Compressed-Air Reservoir

    Maintenance - Brake System Pos: 112.5 /Überschriften/Überschriften 2/A-E/Druckluftbehälter @ 12\mod_1224144256075_78.docx @ 150965 @ 2 @ 1 17.2 Compressed-air reservoir Pos: 112.6 /BA/Wartung/Druckluftbehälter/Druckluftbehälter Bild BP 890/1270/1290 HS Baureihe @ 62\mod_1299662280569_78.docx @ 574094 @ 3 @ 1 BPHS0018 Fig.244 Pos: 112.7 /BA/Wartung/Druckluftbehälter/Druckluftbehälter Text Zusatz Big Pack HS Baureihe @ 62\mod_1299662408501_78.docx @ 574121 @ @ 1 •...

  • Page 323: Setting The Transfer Mechanism

    Maintenance - Brake System Pos: 112.11 /BA/Wartung/Bremsanlage/Einstellen der Übertragungseinrichtung @ 0\mod_1200291286726_78.docx @ 39204 @ 3 @ 1 17.2.1 Setting the Transfer Mechanism After the first few kilometres of driving, the transfer mechanisms and the brake linings of the brake drum will have adjusted. The play resulting from this must be compensated for. Pos: 112.12 /BA/Wartung/Bremsanlage/Einstellung am Gestängesteller_BigPack @ 24\mod_1241614590081_78.docx @ 246921 @ 3 @ 1 Checking the adjustments on the linkage setter Fig.

  • Page 324: Pneumatic Brake Cylinders

    Maintenance - Brake System Pos: 112.14.1 /Überschriften/Überschriften 3/P-T/Pneumatische Bremszylinder @ 24\mod_1241618324893_78.docx @ 246996 @ 23 @ 1 17.2.2 Pneumatic brake cylinders Pos: 112.14.2 /BA/Wartung/Bremsanlage/Pneumatische Bremszylinder/WARNUNG! – Unter Druck stehendes Pneumatiksystem! @ 24\mod_1241618383315_78.docx @ 247020 @ 2 @ 1 WARNING! - Pneumatic system under pressure! Effects: Serious injuries, serious material damages.

  • Page 325: Air Filter For Pneumatic Cylinder (Only Multibale)

    Maintenance - Brake System Pos: 114 /BA/Wartung/Großpackenpressen/Luftfilter für Pneumatikzylinder @ 24\mod_1241674208133_78.docx @ 247225 @ 12 @ 1 17.3 Air filter for pneumatic cylinder (only MultiBale) Fig. 247 The air filter (1) for pneumatic cylinders is on the left in the twine box (as seen facing direction of travel).

  • Page 326: Maintenance Compressor

    Maintenance Compressor Pos: 117 /Überschriften/Überschriften 1/U-Z/Wartung-Kompressor @ 193\mod_1382686806036_78.docx @ 1642725 @ 1 @ 1 Maintenance Compressor Pos: 118 /Überschriften/Überschriften 2/K-O/Kompressor @ 24\mod_1241673489914_78.docx @ 247170 @ 2 @ 1 18.1 Compressor Pos: 119 /BA/Wartung/Kompressor/Kompressor BiG PACK @ 24\mod_1241619350753_78.docx @ 247117 @ @ 1 Fig.
  • Page 327 Maintenance Compressor Pos: 121 /BA/Wartung/Kompressor/Kompressor-Ölstand Bild @ 193\mod_1382683006840_78.docx @ 1642404 @ @ 1 Fig. 250 1) Oil dip stick / oil filling hole 2) Drain plug Pos: 122 /BA/Wartung/Ölkontrolle_Wechsel/Ölkontrolle / Ölwechsel Intervall: siehe Kapitel Wartung „Wartungstabelle“ @ 134\mod_1350483605921_78.docx @ 1188115 @ @ 1 Interval for oil level check and oil change: refer to chapter Maintenance “Maintenance Table”...

  • Page 328: Maintenance - Lubrication

    Maintenance – lubrication Pos: 127.1 /Überschriften/Überschriften 1/U-Z/Wartung - Schmierung @ 24\mod_1241675457008_78.docx @ 247325 @ 21 @ 1 Maintenance – lubrication Pos: 127.2 /Überschriften/Überschriften 2/P-T/Spezielle Sicherheitshinweise @ 0\mod_1196660495760_78.docx @ 9134 @ 22 @ 1 19.1 Special Safety Instructions Pos: 127.3 /BA/Sicherheit/Großpackenpressen/Gefahr - Wartungs-, Montage-, Reparatur- und Einstellarbeiten an der Bindung @ 20\mod_1239002475628_78.docx @ 225581 @ 2 @ 1 DANGER! - Maintenance, assembly, repair and adjustment work Effect: Danger to life, injuries or damage to the machine.

  • Page 329: Lubricants

    Maintenance – lubrication Pos: 127.6 /Überschriften/Überschriften 2/P-T/Schmierfette / Schmieröle @ 24\mod_1241676102945_78.docx @ 247353 @ 2 @ 1 19.2 Lubricants Pos: 127.7 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Allgemeines wenn nur automatische Zentralschmierung vorhanden @ 92\mod_1326782898523_78.docx @ 781812 @ 2 @ 1 19.3 General All machines are equipped with automatic central lubrication. Soft, supple NLGI Class 2 lithium soap greases in accordance with DIN 51825 should be used as lubricating greases.

  • Page 330: Lubricating The Pto Shaft

    The following table provides information about the number of grams per lubrication point. Follow the directions in the cardan manufacturer's operating instructions. Pos: 127.18 /BA/Wartung/Gelenkwelle schmierenAbschmieren Gelenkwelle in Gramm Tabelle HS Baureihe @ 92\mod_1326795863687_78.docx @ 782240 @ 3 @ 1 BiG Pack 890/1270/1290 BiG Pack 1290 HDP/4x4 22 g...

  • Page 331: Lubricating The Rollers For The Blade Lever

    Maintenance – lubrication Pos: 127.20 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Laufrollen der Messerhebel abschmieren @ 24\mod_1241695903648_78.docx @ 247898 @ 322 @ 1 19.5 Lubricating the rollers for the blade lever Fig. 253 • Lower the cutting system with the tractor hydraulics (with the comfort electronics system: Activate the tractor hydraulics and hold down “Lower blade bar”...

  • Page 332: Lubrication Points

    Lubrication points BiG PACK 890 (XC), 1270 (XC), 1290 (XC) Pos: 127.24 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Big Pack 890,1270,1290 (XC) Schmierstellen (automatische Zentralschmierung) T1 HS Baureihe @ 62\mod_1299662604933_78.docx @ 574175 @ 3 @ 1 Big Pack 890 (XC), 1270 (XC), 1290 (XC)
  • Page 333 Pick-up drive (optional) Knotter drive * Only with braked axle Pos: 127.25 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Big Pack 890,1270,1290 (XC) Schmierstellen (automatische Zentralschmierung) T2 HS Baureihe @ 62\mod_1299662824312_78.docx @ 574202 @ @ 1 Big Pack 890 (XC), 1270 (XC), 1290 (XC) Autom.

  • Page 334: Lubrication Points Big Pack 1290 Hdp (Xc)

    Maintenance – lubrication Pos: 127.27 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Schmierstellen Big Pack 1290 HDP (XC) @ 24\mod_1241705981070_78.docx @ 248069 @ 3 @ 1 19.6.2 Lubrication points BiG PACK 1290 HDP (XC) Pos: 127.28 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Big Pack 1290 HDP (XC) Schmierstellen (automatische Zentralschmierung) HS Baureihe @ 62\mod_1299662932343_78.docx @ 574229 @ @ 1 Big Pack 1290 HDP (XC) lubrication points (automatic central lubrication) Crank journal, baling ram drive...
  • Page 335 Maintenance – lubrication Big Pack 1290 HDP (XC) lubrication points (automatic central lubrication) Double knotter: Needle yoke Knotter bearing on hub Blade lever bearing Knotter hook bearing Twine retainer bearing Twine retainer drive shaft bearing Knotter shaft centre bearing * Only with braked axle Pos: 127.29 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
  • Page 336 Maintenance – lubrication Pos: 127.30 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Schmierstellen links Ausführung mit Schneidwerk XC mit Tandemachse Bild HS Baureihe @ 62\mod_1299663649307_78.docx @ 574256 @ @ 1 Lubrication Points on the Big Pack Baler (Left Side of the Machine) Version with XC cutting system and tandem axle 18 16 BPHS0019 Fig.254...
  • Page 337 Maintenance – lubrication Pos: 127.32 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Schmierstellen rechts Ausführung mit Schneidwerk XC mit Tandemachse Bild HS Baureihe @ 62\mod_1299664531271_78.docx @ 574389 @ @ 1 Lubrication Points on the Big Pack Baler (Right Side of the Machine) Version with XC cutting system and tandem axle BPHS0021 Fig.255 for tandem axle...
  • Page 338 Maintenance – lubrication Pos: 127.34 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Schmierstellen links Ausführung ohne Schneidwerk mit Einfachachse Bild HS Baureihe @ 63\mod_1299665838177_78.docx @ 574444 @ @ 1 Lubrication Points on the Big Pack Baler (Left Side of the Machine) Version without XC cutting system, with single axle 18 16 BPHS0020 Fig.256...
  • Page 339 Maintenance – lubrication Pos: 127.36 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Schmierstellen rechte Ausführung ohne Schneidwerk mit Einfachachse Bild HS Baureihe @ 63\mod_1299666194672_78.docx @ 574499 @ @ 1 Lubrication Points on the Big Pack Baler (Right Side of the Machine) Version without XC cutting system, with single axle BPHS0022 Fig.257 200h...

  • Page 340: Maintenance - Central Lubrication

    Maintenance – Central Lubrication Pos: 129 /Überschriften/Überschriften 1/U-Z/Wartung - Zentralschmierung @ 0\mod_1197378235308_78.docx @ 19471 @ 13 @ 1 Maintenance – Central Lubrication Pos: 130.1 /Überschriften/Überschriften 3/A-E/Automatische Zentralschmierung (optional) @ 24\mod_1241763215353_78.docx @ 248355 @ 3 @ 1 20.1.1 Automatic centralised lubrication system (optional) Pos: 130.2 /BA/Wartung/Zentralschmieranlage/BEKA-MAX/Funktionsbeschreibung der BEKA-MAX-Fett-Zentralschmieranlage @ 24\mod_1241765421322_78.docx @ 248475 @ @ 1 Functional description of the BEKA-MAX grease central lubrication system The BEKA-MAX grease central lubrication system is a progressive system.
  • Page 341 Maintenance – Central Lubrication Pos: 132 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ 2 @ 1 This page has been left blank deliberately!! Pos: 133 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ 23 @ 1...

  • Page 342: Maintenance - Electrical System

    Maintenance – electrical system Pos: 134 /Überschriften/Überschriften 1/U-Z/Wartung - Elektrik @ 0\mod_1197362427261_78.docx @ 18572 @ 421 @ 1 Maintenance – electrical system Pos: 135 /BA/Wartung/Großpackenpressen/Sensoren/Lage der Sensoren rechte Maschinenseite @ 24\mod_1241767026463_78.docx @ 248504 @ 243 @ 1 21.1 Position of the sensors (right hand side of the machine) Fig.
  • Page 343 Maintenance – electrical system 1 Knotter monitor 7 Bale ejector 2 Force sensor right 8 Packer feed 3 Force sensor left 9 Packer monitoring 4 Calibrations 10 Knotter monitoring 5 Measurement 11 Central lubrication 6 Star wheel Pos: 136 /BA/Wartung/Großpackenpressen/Sensoren/Lage der Sensoren linke Maschinenseite @ 24\mod_1241769047228_78.docx @ 248582 @ 4423 @ 1...

  • Page 344: Position Of The Sensors (Left Hand Side Of The Machine)

    Maintenance – electrical system 21.2 Position of the sensors (left hand side of the machine) Fig. 260...
  • Page 345 Maintenance – electrical system 2 Upper blade bar 9 Button blade bar up 3 Bale channel flap pressure blade bar down 4 Twine monitoring 10 MultiBale 5 Needle connecting rod 11 Button bale ejector in 6 Setting down bales bale ejector out 7 Flywheel brake bale chute up 8 Pick-up...

  • Page 346: Adjusting The Sensors

    Maintenance – electrical system Pos: 138 /Überschriften/Überschriften 3/A-E/Einstellung der Sensoren @ 0\mod_1199962173428_78.docx @ 37635 @ 434 @ 1 21.2.1 Adjusting the Sensors Pos: 139 /BA/Wartung/Sensoren/Namursensor d = 08 mm @ 24\mod_1241770312369_78.docx @ 248607 @ 441 @ 1 21.2.1.1 Namur sensor d = 8 mm BP-VFS-088-1 Figure 261: The dimension between the encoder (2) and the sensor (1) must be "a"...

  • Page 347: Namur Sensor D = 30 Mm

    Maintenance – electrical system 21.2.1.3 Namur sensor d = 30 mm BPXC0172 Figure 263 The dimension between the encoder (2) and the sensor (1) must be "a" = 5 mm . Setting • Loosen the nuts on either side of the sensor. •...

  • Page 348: Placing In Storage

    Placing in Storage Pos: 143.1 /Überschriften/Überschriften 1/A-E/Einlagerung @ 0\mod_1197385459120_78.docx @ 19966 @ 1 @ 1 Placing in Storage Pos: 143.2 /Überschriften/Überschriften 2/P-T/Spezielle Sicherheitshinweise @ 0\mod_1196660495760_78.docx @ 9134 @ 22 @ 1 22.1 Special Safety Instructions Pos: 143.3 /BA/Sicherheit/Gefahrenhinweise/Großpackenpresse/Gefahr - Wartung allgemein @ 17\mod_1236580940714_78.docx @ 205248 @ @ 1 DANGER! - When performing repair, maintenance or cleaning work on the machine, or in the case of technical intervention, drive elements may start moving.

  • Page 349: At The End Of The Harvest Season

    Perform the necessary repair tasks during the time immediately after the harvest season. Draw up a list of all replacement parts you will need. This will make it easier for your KRONE dealer to process your orders and you will be certain that your machine will be ready for use at the beginning of the next season.

  • Page 350: Before The Start Of The New Season

    Placing in Storage Pos: 143.9 /Überschriften/Überschriften 2/U-Z/Vor Beginn der neuen Saison @ 0\mod_1197386024448_78.docx @ 20081 @ 2 @ 1 22.3 Before the Start of the New Season Pos: 143.10 /BA/Sicherheit/Gefahrenhinweise/Großpackenpresse/Gefahr - Wartung allgemein @ 17\mod_1236580940714_78.docx @ 205248 @ 3 @ 1 DANGER! - When performing repair, maintenance or cleaning work on the machine, or in the case of technical intervention, drive elements may start moving.

  • Page 351: Overload Coupling On Flywheel

    Vent the overload coupling before use. Pos: 143.15 /BA/Einlagerung/Großpackenpresse/Überlastkupplung am Schwungrad BYPY 890/1270/890 (XC) 16,6 mm @ 92\mod_1326899205089_78.docx @ 783250 @ 2 @ 1 Procedure for types BiG Pack 890 (XC) BiG Pack 1270 (XC) and BiG Pack 1290(XC) Fig. 264 •...

  • Page 352: Malfunctions - Causes And Remedies

    Malfunctions - Causes and Remedies Pos: 145.1 /Überschriften/Überschriften 1/P-T/Störungen - Ursachen und Behebung @ 0\mod_1200296925180_78.docx @ 39459 @ 1 @ 1 Malfunctions - Causes and Remedies Pos: 145.2 /Überschriften/Überschriften 2/P-T/Spezielle Sicherheitshinweise @ 0\mod_1196660495760_78.docx @ 9134 @ 22 @ 1 23.1 Special Safety Instructions Pos: 145.3 /BA/Sicherheit/Gefahrenhinweise/Großpackenpresse/Gefahr - Störung Ursache Behebung @ 25\mod_1242721693832_78.docx @ 253804 @ @ 1 DANGER! - When performing repair, maintenance or cleaning work on the machine, or in...

  • Page 353: General Malfunctions

    Malfunctions - Causes and Remedies Pos: 145.5 /Überschriften/Überschriften 2/A-E/Allgemeine Störungen @ 24\mod_1241775122213_78.docx @ 248807 @ 2 @ 1 23.2 General malfunctions Pos: 145.6 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Tabellarische Auflistung Allgemein @ 24\mod_1241771540713_78.docx @ 248658 @ @ 1 Malfunction Cause and/or remedy Bring the tractor to a stop immediately.
  • Page 354 • Start the engine of the tractor • Should the tractor engine still not start yet, please contact your KRONE dealer or KRONE customer service • Charge the hydraulic system with pressure when the tractor engine starts •...
  • Page 355 Malfunctions - Causes and Remedies Pos: 145.10 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Tabellarische Auflistung Hydraulikblock T2 @ 117\mod_1341229890870_78.docx @ 1021720 @ 3 @ 1 Malfunction Cause and/or remedy Hydraulic functions do not move up to Cause: the final position (for example Some tractors have a compensation bore hole hydraulic parking jack, bale ejector on tractor side for Load Sensing function.

  • Page 356: Malfunctions On The Knotter

    Malfunctions - Causes and Remedies Pos: 145.12 /Überschriften/Überschriften 2/P-T/Störungen am Knoter @ 24\mod_1241775183869_78.docx @ 248831 @ 2 @ 1 23.3 Malfunctions on the knotter Pos: 145.13 /Überschriften/Überschriften 3/A-E/Einfachknoter @ 24\mod_1241083809568_78.docx @ 242978 @ 3 @ 1 23.3.1 Single knotter Pos: 145.14 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Hinweis Knoterstörungen Einfachknoter @ 24\mod_1241774955431_78.docx @ 248783 @ @ 1 Note The most frequent knotter malfunctions are caused by minor problems that you can eliminate yourself in most cases.
  • Page 357 Malfunctions - Causes and Remedies Pos: 145.17 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Tabellarische Auflistung Einfachknoter T2 @ 24\mod_1241775278072_78.docx @ 248859 @ @ 1 Malfunction Cause and/or remedy Incorrect position of knotter needle — change seating of knotter needle on the yoke. Incorrect position of twine bar —...
  • Page 358 Malfunctions - Causes and Remedies Pos: 145.19 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Tabellarische Auflistung Einfachknoter T3 @ 24\mod_1241777135041_78.docx @ 248936 @ @ 1 Malfunction Cause and/or remedy Twine is tearing or shows signs of abrasion in places: Right next to the knot. Rough twine guiding edges on the blade lever —...

  • Page 359: Double Knotter

    Malfunctions - Causes and Remedies Pos: 145.21 /Überschriften/Überschriften 3/A-E/Doppelknoter @ 24\mod_1241099544678_78.docx @ 243310 @ 3 @ 1 23.3.2 Double knotter Pos: 145.22 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Fehlerursache Knoterstörungen Doppelknoter allgemeiner Text @ 24\mod_1241779382291_78.docx @ 248957 @ @ 1 Experience has shown that a majority of tying problems are the result of insufficient twine tension.
  • Page 360 Malfunctions - Causes and Remedies Pos: 145.24 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Doppelknoter T1 @ 24\mod_1242027120229_78.docx @ 249022 @ @ 1 Malfunction Cause and/or remedy Cause: Second knot remains hanging on the knotter Knotter tongue bends or frequent rupture of tongue.
  • Page 361 Malfunctions - Causes and Remedies Pos: 145.26 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Doppelknoter T2 @ 24\mod_1242029551448_78.docx @ 249073 @ @ 1 Malfunction Cause and/or remedy Knot remains hanging on the knotter hook. Cause: Excessive tension on the knotter tongue. Remedy: Undo the knotter tongue (3) in the following way: •...
  • Page 362 Malfunctions - Causes and Remedies Pos: 145.28 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Doppelknoter T3 @ 24\mod_1242030761307_78.docx @ 249150 @ @ 1 Malfunction Cause and/or remedy Knot remains hanging on the knotter hook. Cause: Blade lever too far away from the knotter hook. Remedy: Adjusting the blade lever: •...
  • Page 363 Malfunctions - Causes and Remedies Pos: 145.30 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Doppelknoter T4 @ 25\mod_1242033232885_78.docx @ 249228 @ @ 1 Malfunction Cause and/or remedy First knot: (closing knot): Present only in the Cause: upper twine strand. The twine bar has not caught the lower twine strand.
  • Page 364 Malfunctions - Causes and Remedies Pos: 145.32 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Doppelknoter T5 @ 25\mod_1242035576557_78.docx @ 249567 @ @ 1 Malfunction Cause and/or remedy Second knot: (Starting knot) Knot is present Cause: only on the lower twine strand (no knot on The twine bar is adjusted too far away from the the upper twine strand).
  • Page 365 Malfunctions - Causes and Remedies Pos: 145.34 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Doppelknoter T6 @ 25\mod_1242036861416_78.docx @ 249592 @ @ 1 Malfunction Cause and/or remedy Second knot: (Starting knot) Knot is present Cause: only on the upper twine strand (no knot on The lower twine tension springs are not working the lower twine properly.
  • Page 366 Malfunctions - Causes and Remedies Pos: 145.36 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Doppelknoter T7 @ 25\mod_1242040506416_78.docx @ 249617 @ @ 1 Malfunction Cause and/or remedy Second knot: (Starting knot) Twine winds Cause: around the knotter hook. The upper tensioning arms are not working properly.
  • Page 367 Malfunctions - Causes and Remedies Pos: 145.38 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Doppelknoter T8 @ 25\mod_1242041192745_78.docx @ 249642 @ @ 1 Malfunction Cause and/or remedy No knot present, neither on the upper nor Cause: on the lower twine strand. Twine bar is not activated. Remedy: Check the twine bar mechanism and its settings (refer to chapter Settings "Setting the twine bar (double knotter)”).
  • Page 368 Malfunctions - Causes and Remedies Pos: 145.40 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Doppelknoter T9 @ 25\mod_1242042248604_78.docx @ 249667 @ @ 1 Malfunction Cause and/or remedy Knot ends too short. The knot often gets 10.1 Cause: wound up (generally the second knot). Insufficient tension on the knotter tongue.
  • Page 369 Malfunctions - Causes and Remedies Pos: 145.42 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Doppelknoter T10 @ 25\mod_1242042811416_78.docx @ 249692 @ @ 1 Malfunction Cause and/or remedy Shear screw on the needle connecting rod Cause: breaks frequently. As a result the needle Strong wear of the twine guide eyes.

  • Page 370: Troubleshooting In The Central Lubrication

    Malfunctions - Causes and Remedies Pos: 145.44 /Überschriften/Überschriften 2/F-J/Fehlersuche in der Zentralschmierung @ 25\mod_1242052030604_78.docx @ 249788 @ 12 @ 1 23.4 Troubleshooting in the central lubrication Pos: 145.45 /BA/Störungen - Ursachen und Behebung/Großpackenpressen/Störungen-Ursachen-Behebung Zentralschmierung T1 @ 25\mod_1242051129385_78.docx @ 249717 @ 2 @ 1 Malfunction Cause and/or remedy Blockage in the system or...
  • Page 371 Malfunctions - Causes and Remedies Pos: 147 /BA/Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ 2 @ 1 This page has been left blank deliberately!! Pos: 148 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ 22 @ 1...

  • Page 372: Appendix

    Appendix Pos: 149 /Überschriften/Überschriften 1/A-E/Anhang @ 1\mod_1202278612285_78.docx @ 58360 @ 12 @ 1 Appendix Pos: 150 /Überschriften/Überschriften 2/F-J/Hydraulikschaltplan @ 11\mod_1223527787398_78.docx @ 147580 @ 222 @ 1 24.1 Hydraulic System Circuit Diagrams Pos: 151 /BA/Anhang/Großpackenpresse/Bordhydraulik für Medium-Elektronik HS Baureihe @ 194\mod_1383644199349_78.docx @ 1651623 @ 22 @ 1 24.2 On-Board Hydraulic System for Medium Version Electronics Fig.

  • Page 373: On-Board Hydraulic System For Comfort Version Electronics

    Appendix Pos: 153 /BA/Anhang/Großpackenpresse/Bordhydraulik für Komfort-Elektronik HS Baureihe @ 195\mod_1383644714292_78.docx @ 1651824 @ 22 @ 1 24.3 On-Board Hydraulic System for Comfort Version Electronics Fig. 267 Main gearbox Bale channel Pressure limiting valve Release valve Pos: 154 /BA/---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ 22 @ 1...

  • Page 374: Work Hydraulics Medium Version Electronics

    Appendix Pos: 155 /BA/Anhang/Großpackenpresse/Arbeitshydraulik für Medium-Elektronik HS Baureihe @ 195\mod_1383645406272_78.docx @ 1652017 @ 22 @ 1 24.4 Work Hydraulics Medium Version Electronics Fig. 268 Start-up device Main gearbox flywheel Input block Parking jack up / down Locking the steering axle Blade bar open / closed Retracting / extending bale ejector Roller chute open / closed...

  • Page 375: Work Hydraulics Comfort Version Electronics

    Appendix Pos: 157 /BA/Anhang/Großpackenpresse/Arbeitshydraulik für Komfort-Elektronik HS Baureihe @ 195\mod_1383645852374_78.docx @ 1652046 @ 22 @ 1 24.5 Work Hydraulics Comfort Version Electronics Fig. 269 Start-up device Main gearbox flywheel Comfort block Parking jack up / down Locking the steering axle Blade bar open / closed Retracting / extending bale ejector Roller chute open / closed...

  • Page 376: Electrical Circuit Diagram

    Pos: 159 /Überschriften/Überschriften 2/A-E/Elektroschaltplan @ 11\mod_1223544391539_78.docx @ 147914 @ 2 @ 1 24.6 Electrical circuit diagram Pos: 160 /BA/Anhang/Großpackenpresse/Schaltpläne Im Anhang finden Sie den die Schaltpläne zur Maschine @ 65\mod_1300357621479_78.docx @ 583741 @ @ 1 You will find the electrical circuit diagram for the machine in the appendix. === Ende der Liste für Textmarke Inhalt ===...
  • Page 397 Diagnostics for buttons ........179 Diagnostics power supply voltages ....184 Calling up the menu level ......... 151 Differing functions to KRONE ISOBUS terminal Changing the Bale Number ......173 CCI ..............209 Checking / adjusting position of needles – baling ram ..............
  • Page 398 Direction Information ........... 13 Installing the terminal into the cabin ....126 Double knotter ....56, 225, 263, 271, 359 Intended Use ............14 Drives ..............45 ISOBUS operation ........... 207 Driving and Transport ........114 ISOBUS Short Cut Button ........ 127 Driving with Pick-up in fixed position ....
  • Page 399 Menu 1-1 Knotter Settings ........ 153 Overload protection......65, 70, 75, 80 Menu 1-1-1 Correction Value for Bale Length .. 154 Overload Protections ......... 47 Menu 1-1-2 Knotter Signal ........ 155 P  Menu 1-1-3 Knotter Monitoring ......156 Packer gearbox ..........316 Menu 1-1-5 Bales / Blow ........
  • Page 400 Setting the baling ram blades ......275 Technical data electrical connections ... 66, 71, 76, Setting the blade lever (double knotter) .... 274 technical data hydraulic connections ....81 Setting the flywheel cleaning (only on BiG PACK 890) ..............289 Technical Data Hydraulic Connections .
  • Page 401 Zeros ..............167...
  • Page 402 . . konsequent, kompetent Maschinenfabrik Bernard Krone GmbH Heinrich-Krone-Straße 10, D-48480 Spelle Postfach 11 63, D-48478 Spelle Phone +49 (0) 59 77/935-0 +49 (0) 59 77/935-339 Internet: http://www.krone.de eMail: info.ldm@krone.de...

This manual is also suitable for:

Big pack 1270Big pack 1290Big pack 1290 hdpBig pack 890 xcBig pack 1270 xcBig pack 1290 xc ... Show all

Table of Contents
