WHAT'S IN THE BOX: Fixings & tools
Adjustable Spring
Seat post knob x1
Lock x1
M8 Nut x4
Allen Key x1
Note: Some additional fixing components come preassembled with the product.
QUICK-START GUIDE:
Step 1
Attach front and rear stabilty legs (01) using the supplied fixing components M8 Nuts,
M8 Spring washer, M8 Curved washer & M8 Carriage bolt (02,03,04 & 05).
Ensure the stability leg with with wheels is positioned at the front side of the bike.
01
M8 Curved washer x4
M12 Flat Washer
Multi Wrench x1
M8 Spring washer x4
M8 Carriage Bolt x4
02
03
04
05
