New Image CYCLONE X3 Assembly And User's Manual page 12

Operating Instructions
1. When powering on the LCD Display will show all icons in full for 2 seconds
(Figure 1), then will display the wheel diameter for 1 second in the distance
section (Figure 2). Finally, it will enter to the Age setting mode in the bottom
right window. To set the age user the up down arrows to toggle through to
the correct age and select enter. The display will then enter the standby mode.
2. The screens for the following functions will flash by sequence every 1
second. If there is no RPM recording (movement of the fan wheel) for 60
seconds, the monitor will enter sleep mode.
Figure 4
Figure 8
Figure 12
Figure 1 Figure 2
Figure 5 Figure 6
Figure 9 Figure 10
Figure 13 Figure 14
Figure 3
Figure 7
Figure 11
Figure 15
