New Image CYCLONE X3 Assembly And User's Manual page 16

4 Cycle time counts down from 3 to 0 then console start, meanwhile buzzer beeps
once per second and READY flashes once per second, counting displays '00/
XX'(Figure 31).
5 Cycle time counts down from the pre-set total time and WORK flashes once per
second. Then TOTAL TIME, DISTANCE, CALORIES, WATTS, SPEED & RPM start
calculating, counting displays '01 XX'(Figure 32).
6 Cycle time counts down from and REST flashes once per second along with
buzzer beeps(Figure 33), meanwhile READY will flash in the last 3sec(Figure 34).
7 The above 3 & 4 continue cycle counting and add 1 per each cycle, until the
WORK setting value is finished. It will then go to the end page.
8 In WORK mode, the buzzer beeps for 1sec then enters into sleep mode if there are
no any signal inputs within 30sec.
9 Press START button once the display enters pause mode. The buzzer will sound
for 0.5sec in every 30sec. All values are displaying on the display and are flashing
every 4sec. If training stops for 5 minutes, buzzer sounds for 2sec and enter sleep
mode. Press START to resume workout.
10 Pressing STOP or ending training, the buzzer beeps for 1sec then displays TOTAL
TIME, DISTANCE, CALORIES for 30s, and WATT, SPEED & RPM will switch to
display AVG. & MAX. (Figure 18~19) each for 5sec.
11 Press any PROGRAM key then perform the program accordingly.
Figure 28 Figure 29
Figure 32 Figure 33
Figure 30 Figure 31
Figure 34
