iBoard
by APS
READ INSTRUCTIONS CAREFULLY BEFORE START ING
INSTALLATION. REMOVE CONTENTS FROM BOX AND
VERIFY ALL PARTS ARE PRESENT. ASSISTANCE IS
RECOMMENDED.
*ROCKER PANEL MOUNT
*DRILLING IS REQUIRED
Item
QTY
1#
8
Mounting Brackets
2#
12
M8X1.25-20mm Hex Flange Bolts
3#
20
M8 Flat Washers
4#
8
M8 Nylon Lock Nuts
2 #
iBoard
Description
3 #
4 #
Customer Support: info@iboardauto.com
Fastener Size
Tightening Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
Item
QTY
ST6.3-25mm Hex Self Tapping Screws
5#
8
M6X1-20mm Square Head Bolts
6#
16
7#
16
M6 Large Flat Washers
8#
16
M6 Nylon Lock Nuts
6 #
5 #
1
®
PART#: IB-R001
Required
6-7
16-18
31-32
56-58
92-94
Description
7 #
Rev. 20211001
√
√
X
X
X
8 #
Advertisement
Related Manuals for APS iBoard IB-R001
Summary of Contents for APS iBoard IB-R001
- Page 1 ® iBoard ® iBoard by APS PART#: IB-R001 Fastener Size Tightening Torque (ft-lbs) Required READ INSTRUCTIONS CAREFULLY BEFORE START ING INSTALLATION. REMOVE CONTENTS FROM BOX AND √ VERIFY ALL PARTS ARE PRESENT. ASSISTANCE IS 16-18 √ RECOMMENDED. 10mm 31-32 12mm...
- Page 2 ® iBoard Front Driver Passenger Customer Support: info@iboardauto.com Rev. 20211001...
- Page 3 ® iBoard STEP 1 STEP 2 Use the Mounting Bracket as template, mark and drill (4) 8mm Starting on the Driver side of the vehicle. Select (1) Mounting holes in pinch weld. If necessary, remove the brackets from the Bracket, attach to the 1st and 2nd rocker panel with (1) rocker panel for drilling (Fig 3).
- Page 4 ® iBoard STEP 5 M6X1-20mm Square Head Bolts Level and adjust the Running Board and fully tighten all hard- ware. Important: Please follow the recommended Tightening Tor- ques shown in the table on page 1. Don’t over tighten, or the nuts/bolts will be damaged. (Fig 4) Slip M6X1-20mm Square Head Bolts Into STEP 6 The Bottom Channels...
