Advantech PCA-6005 User Manual

Full-sized pci-bus socket 478 pentium 4/celeron processor-based cpu card
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PCA-6005
Full-sized PCI-bus
socket 478 Pentium 4/Celeron
processor-based CPU card
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Advantech PCA-6005

Summary of Contents for Advantech PCA-6005

  • Page 1 PCA-6005 Full-sized PCI-bus socket 478 Pentium 4/Celeron processor-based CPU card User’s Manual...
  • Page 2 PCA-6005 User’s Manual...
  • Page 3 Copyright This document is copyrighted, 2002. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmit- ted in any form or by any means without the prior written permission of the original manufacturer.
  • Page 4 Our dealers are well trained and ready to give you the support you need to get the most from your Advantech products. In fact, most prob- lems reported are minor and are able to be easily solved over the phone.
  • Page 6 PCA-6005 User’s Manual...
  • Page 7 Product warranty Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products...
  • Page 8 6005 mechanically and electrically before shipment. It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the PCA-6005, check it for signs of shipping damage. (For exam- ple, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales repre- sentative immediately.

  • Page 9: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 Features ................3 General Specifications............4 1.3.1 System................4 1.3.2 Memory................4 1.3.3 Input/Output..............4 1.3.4 VGA interface..............4 1.3.5 Ethernet LAN..............5 1.3.6 Ultra 160 SCSI..............5 1.3.7 Industrial features ............5 1.3.8 Mechanical and environmental specifications....
  • Page 10 3.4.14 Video BIOS Shadow............. 32 Advanced Chipset Features..........33 Figure 3.3:Advanced chipset features screen ....33 3.5.1 Advanced DRAM control 1.......... 34 3.5.2 Prefetch Caching............34 3.5.3 System BIOS Cacheable..........34 3.5.4 Memory Hole..............35 3.5.5 AGP Aperture Size ............35 PCA-6005 User’s Manual...
  • Page 11 Integrated Peripherals............35 Figure 3.4:Integrated peripherals........35 3.6.1 SiS OnChip IDE Device ..........36 3.6.2 SiS OnChip PCI Device..........37 3.6.3 Onboard Super IO Device..........38 3.6.4 USB controller .............. 39 3.6.5 USB Keyboard Support ..........39 3.6.6 USB Mouse Support ............. 39 3.6.7 IDE HDD Block Mode ..........
  • Page 12 Reset Connector (CN18) ..........110 B.13 HDD LED Connector (CN19)........110 B.14 ATX Feature Connector (CN20)........111 B.15 ATX Soft Power Switch (CN21) ........111 B.16 SM Bus Connector (CN29) ........... 112 B.17 System I/O Ports............112 PCA-6005 User’s Manual...
  • Page 13 B.18 DMA Channel Assignments.......... 114 B.19 Interrupt Assignments ........... 114 B.20 1st MB Memory Map............ 115 B.21 PCI Bus Map ..............115...
  • Page 14 PCA-6005 User’s Manual...
  • Page 15 General Information This chapter gives background infor- mation on the PCA-6005. It then shows you how to configure the card to match your application and prepare it for installation into your PC. Sections include: • Introduction • Features • Specifications •...

  • Page 16: Chapter 1 General Information

    Ultra 160 SCSI, and two 184-pin DIMM slots for a total of 2 GB DDR SDRAM memory. The remote management inter- face enables the PCA-6005 to be managed through Ethernet when it is connected to the SNMP-1000 Remote HTTP/SNMP System Manager.

  • Page 17: Features

    CPU fan, CPU temperature and system voltages levels are moni- tored to ensure stable operation. proper system configuration and management. A remote monitoring interface is reserved for remote management through Ethernet by using Advantech's SNMP-1000 system management module. ATX soft power switch: Through the BIOS, the power button can be defined as the "Standby"...

  • Page 18: General Specifications

    • ISA bus: No ISA bus support 1.3.4 VGA interface • Controller: SiS 650/651 chipset integrated, AGP 4X • Display memory: Share system memory up to 64 MB, BIOS selectable • Resolution up to 2048x1536 16M colors PCA-6005 User’s Manual...

  • Page 19: Ethernet Lan

    • Board weight: 0.6 kg (1.2 lb) 1.4 Jumpers and Connectors Connectors on the PCA-6005 board link it to external devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your application. The tables below list the function of each of the board jumpers and connectors.
  • Page 20 Extension I/O board connector CN29 External SM bus connector CN30 External PCI extension connector CN33 PS/2 mouse connector CN34 10/100Base-T Ethernet connector 2 CN43 AC-97 audio extension interface CN46 Auxiliary power input ATX1 ATX12V auxiliary power input PCA-6005 User’s Manual...
  • Page 21 Table 1.3: SCSI Daughter board: CN50 68-pin U160 SCSI connector CN51 68-pin U 160 wide SCSI Connector CN52 50-pin Ultra Wide SCSI Connector...

  • Page 22: Board Layout: Jumper And Connector Locations

    1.5 Board Layout: Jumper and Connector Locations Figure 1.1: Board Layout: Jumper and Connector Locations PCA-6005 User’s Manual...
  • Page 23 Figure 1.2: SCSI daughter board layout Figure 1.3: I/O connectors on bracket...

  • Page 24: Safety Precautions

    OFF) a jumper, you remove the clip. Sometimes a jumper consists of a set of three pins, labeled 1, 2, and 3. In this case you connect either pins 1 and 2, or 2 and 3. A pair of needle-nose pliers may be useful when setting jumpers. PCA-6005 User’s Manual...

  • Page 25: Cmos Clear (J1)

    * default setting 1.7.3 Watchdog timer output (J2) The PCA-6005 contains a watchdog timer that will reset in case the soft- ware fails to reset the watchdog timer. The J2 jumper settings control the outcome of what the computer will do in the event the watchdog timer is tripped.

  • Page 26: System Memory

    1.8 System Memory The PCA-6005 has two sockets for 184-pin dual inline memory modules (DIMMs). All these sockets use 2.5 V unbuffered double data rate syn- chronous DRAMs (DDR SDRAM). are available in capacities of 128, 256, 512 and 1024 MB. The sockets can be filled in any combination with DIMMs of any size, giving a total memory size between 128 MB and 2 GB.

  • Page 27: Memory Installation Procedures

    1.9 Memory Installation Procedures To install DIMMs, first make sure the two handles of the DIMM socket are in the "open" position. i.e. The handles lean outward. Slowly slide the DIMM module along the plastic guides on both ends of the socket. Then press the DIMM module right down into the socket, until you hear a click.
  • Page 28 CPU is installed, the lever should snap into place at the side of the socket. Note: To remove a CPU, pull the lever out to the side a little and raise it as far as it will go. Lift out the CPU. PCA-6005 User’s Manual...
  • Page 29 Peripherals This chapter tells how to connect peripherals, switches and indicators to the PCA-6005 board. You can access most of the connectors from the top of the board while it is installed in the chassis. If you have a number of cards...

  • Page 30: Chapter 2 Connecting Peripherals

    1 on the hard drive connector, which is labeled on the drive circuit board. Check the documentation that came with the drive for more information. Connect the second hard drive to the remaining connector (CN2 or CN1), in the same way as described above. PCA-6005 User’s Manual...

  • Page 31: Floppy Drive Connector (Cn3)

    2.2 Floppy Drive Connector (CN3) You can attach up to two floppy disk drives to the onboard connector. You can use any combination of 5.25" (360 KB / 1.2 MB) and/or 3.5" (720 KB / 1.44/2.88 MB) drives. The card comes with a 34-pin daisy-chain drive connector cable.

  • Page 32: Usb Port (Cn6)

    The USB interface can be disabled in the system BIOS setup. 2.5 VGA Connector (CN7) The PCA-6005 includes an AGP SVGA interface that can drive a stan- dard CRT display. CN7 is a standard 15-pin D-SUB connector commonly PCA-6005 User’s Manual...

  • Page 33: 10/100Base-T Ethernet Connector (Cn8 And Cn34)

    Appendix B. 2.6 10/100Base-T Ethernet Connector (CN8 and CN34) The PCA-6005 is equipped with dual high-performance 32-bit PCI-bus Ethernet interface, which is fully compliant with IEEE 802.3/u 10/100 Mbps CSMA/CD standards. It is supported by all major network operat- ing systems and is 100% Novell NE-2000 compatible. An onboard RJ-45...

  • Page 34: Serial Ports (Cn9: Com1; Cn10: Com2)

    2.7 Serial Ports (CN9: COM1; CN10: COM2) CN10 The PCA-6005 offers two serial ports, CN9 as COM1 and CN10 as COM2. These ports can connect to serial devices, such as a mouse or printers, or to a communication network Table 2.1: Serial port connections (COM1, COM2)

  • Page 35: Ps/2 Keyboard And Mouse Connector (Cn11 And Cn33)

    PS/2 mouse. 2.9 External Keyboard Connector (CN12) CN12 In addition to the PS/2 mouse/keyboard connector on the PCA-6005's rear plate, there is also an extra onboard external keyboard connector. This gives system integrators greater flexibility in designing their sys-...

  • Page 36: Cpu Fan Connector (Cn14)

    2.11 Front Panel Connectors (CN16, CN17, CN18, CN19, CN21 and CN29) There are several external switches to monitor and control the PCA-6005. 2.11.1 Keyboard lock and power LED (CN16) CN16 is a 5-pin connector for the power on LED. Refer to Appendix B for detailed information on the pin assignments.

  • Page 37: External Speaker (Cn17)

    2.11.2 External speaker (CN17) CN17 is a 4-pin connector for an extenal speaker. If there is no external speaker, the PCA-6005 provides an onboard buzzer as an alternative. To enable the buzzer, set pins 3-4 as closed. 2.11.3 Reset (CN18) Many computer cases offer the convenience of a reset button.

  • Page 38: Connecting To Snmp-1000 Remote Manager

    2.12.1 ATX feature connector (CN20) and soft power switch connector (CN21) The PCA-6005 can support an advanced soft power switch function if an ATX power supply is used. To enable the soft power switch function: Take the specially designed ATX-to-PS/2 power cable out of the accessory bag.

  • Page 39: Controlling The Soft Power Switch

    LED (see Section 2.13.1). 2.13 Auxiliary power input (CN46 & ATX1) To supply adequate 12V power to the CPU card, the PCA-6005 provides two auxiliary power connectors, CN46 and ATX1. CN46 accepts a stan- dard device power connector, and ATX1 accepts 4-pin ATX 12V connec- tor.
  • Page 40 PCA-6005 User’s Manual...
  • Page 41 Award BIOS Setup This chapter describes how to set the- card’s BIOS configuration data.

  • Page 42: Chapter 3 Award Bios Setup

    Turn on the computer and check for the “patch code”. If there is a number assigned to the patch code, it means that the BIOS supports your CPU. If there is no number assigned to the patch code, please contact Advantech’s applications engineer to obtain an up-to-date patch code file. This will ensure that your CPU’s system status is valid.

  • Page 43: Standard Cmos Setup

    3.3 Standard CMOS Setup Choose the “Standard CMOS Features” option from the “Initial Setup Screen” menu, and the screen below will be displayed. This menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory. 3.3.1 CMOS RAM backup The CMOS RAM is powered by an onboard button cell battery.

  • Page 44: Advanced Bios Features

    3.4.2 CPU L1 & L2 Cache Enabling this feature speeds up memory access. The commands are “Enabled” or “Disabled.” 3.4.3 CPU L2 Cache ECC Checking Enabling allows CPU L2 cache checking. The commands are “Enabled” or “Disabled.” PCA-6005 User’s Manual...

  • Page 45: First/Second/Third/Other Boot Device

    3.4.4 First/Second/Third/Other Boot Device The BIOS tries to load the OS with the devices in the sequence selected. Choices are: Floppy, LS/ZIP, HDD, SCSI, CDROM, LAN, Disabled. 3.4.5 Swap Floppy Drive Logical name assignments of floppy drives can be swapped if there is more than one floppy drive.

  • Page 46: Os Select For Dram > 64Mb

    3.4.13 OS Select for DRAM > 64MB This setting allows selecting an OS with greater than 64MB of RAM. Commands are “Non-OS2” or “OS2.” 3.4.14 Video BIOS Shadow Enable copies video BIOS to sharow RAM for performnace improving. Choices are Enable, Disable. PCA-6005 User’s Manual...

  • Page 47: Advanced Chipset Features

    3.5 Advanced Chipset Features By choosing the “Advanced Chipset Features ”option from the “Initial Setup Screen” menu, the screen below will be displayed. This sample screen contains the manufacturer’s default values for this CPU card, as shown in Figure 3-5: . Note: DRAM default timings have been carefully cho- sen and should ONLY be changed if data is...

  • Page 48: Advanced Dram Control 1

    3.5.3 System BIOS Cacheable Selecting Enabled allows caching of the system BIOS ROM at F0000h- FFFFFh, resulting in better system performance. However, if any pro- gram writes to this memory area, a system error may result. The choice: Enabled, Disabled. PCA-6005 User’s Manual...

  • Page 49: Memory Hole

    3.5.4 Memory Hole In order to improve performance, certain space in memory is reserved for ISA cards. This memory must be mapped into the memory space below 16MB. The Choice: 15M-16M, Disabled. 3.5.5 AGP Aperture Size Select the size of Accelerated Graphics Port (AGP) aperture. The aperture is a portion of the PCI memory address range dedicated for graphics memory address space.

  • Page 50: Sis Onchip Ide Device

    IDE devices possible. Because each IDE device may have a differ- ent Mode timing (0, 1, 2, 3, 4), it is necessary for these to be independent. The default setting “Auto” will allow autodetection to ensure optimal per- formance. PCA-6005 User’s Manual...

  • Page 51: Sis Onchip Pci Device

    3.6.2 SiS OnChip PCI Device Press Enter to set the on-chip PCI devices. 3.6.2.1 SiS-7012 AC-97 Audio If the AC-97 audio function is required, set this item to Enabled. 3.6.2.2 System Share Memory Size This item is used to set the shared size of system memory for VGA display.

  • Page 52: Onboard Super Io Device

    I/O card with a parallel port, make sure there is no conflict in the address assignments. The CPU card can support up to three parallel ports, as long as there are no conflicts for each port. PCA-6005 User’s Manual...

  • Page 53: Usb Controller

    3.6.3.6 Onboard Parallel Port Mode (ECP + EPP) This field allows you to set the operation mode of the parallel port. The setting “Normal” allows normal speed operation, but in one direction only. “EPP” allows bidirectional parallel port operation at maximum speed.

  • Page 54: Power Management Setup

    Power Management (ACPI). The choice: Enabled, Disabled. 3.7.2 Power Management This category allows you to select the type (or degree) of power saving and is directly related to the following modes: 1. HDD Power Down 2. Doze Mode 3. Suspend Mode PCA-6005 User’s Manual...

  • Page 55: Video Off Option

    There are four selections for Power Management, three of which have fixed mode settings. Disable (Default) No power management. Disables all four modes. Min. Power Saving Minimum power management. Doze Mode=1 hr. Standby Mode=1 hr., Suspend Mode=1 hr., and HDD Power Down=15 min. Max Power Saving Maximum power management.

  • Page 56: Power State Resume Control

    PC will not boot when power system is working again. The Choice: Off, On, Auto. 3.7.9 PM Wake Up Events Users can enable some system events to wake up the system. Figure 3.6: Wake Up Events PCA-6005 User’s Manual...

  • Page 57: Pnp/Pci Configurations

    3.8 PnP/PCI Configurations 3.8.1 Reset Configuration Data. Note: This is left “Disabled.” Select “Enabled” to reset Extended System Configuration Data (ECSD) if you have installed a new add-on and your OS won’t boot and you need to reconfigure Figure 3.7: PnP/PCI configurations screen...

  • Page 58: Pc Health Status

    This shows CPU1 core voltage. 3.10.4 +2.5/ +3.3V/ + 5V/ +12V. This shows you the voltage of +2.5/ +3.3V/ + 5V/ +12V 3.10 Load Optomized Defaults “LOAD SETUP DEFAULTS” loads the values required by the system for maximum performance. PCA-6005 User’s Manual...

  • Page 59: Set Password

    3.11 Set Password To change the password: Choose the “Set Password” option from the “Initial Setup Screen” menu and press <Enter>. The screen will display the following message: Enter Password: Press <Enter>. If the CMOS is good or if this option has been used to change the default password, the user is asked for the password stored in the CMOS.
  • Page 60 PCA-6005 User’s Manual...
  • Page 61 AGP SVGA Setup The PCA-6005 features an integrated high performance VGA interface. This chapter provides instructions for installing and operating the software drivers on the display driver CD included in your package. Chapter 4...

  • Page 62: Chapter 4 Agp Svga Setup

    The enhanced display drivers for the PCA-6005 board are located on the software installation CD. You must install the drivers and utility software by using the supplied SETUP pro- gram for DOS drivers.

  • Page 63: Vga Installation

    4.3 VGA Installation First, insert CD drive. Then follow the Icons for your PCA Series model number. Click on the right driver for the auto-installation. The installation programm will guide you through the whole installation process. Follow the instruction when necessary. Chapter 4...
  • Page 64 PCA-6005 User’s Manual...
  • Page 65 LAN Configuration The PCA-6005 features an onboard LAN interface. This chapter gives detailed information on Ethernet con- figuration. It shows you how to config- ure the card to match your application requirements. Chapter 5...

  • Page 66: Chapter 5 Lan Configuration

    Chapter 5 LAN Configuration 5.1 Introduction The PCA-6005 features an optional single/dual 32-bit 10/100 Mbps Ethernet network interface. This interface supports bus mastering archi- tecture and auto-negotiation features. Therefore standard twisted-pair cabling with RJ-45 connectors for both 10 Mbps and 100 Mbps connec- tions can be used.

  • Page 67: Driver Installation

    5.3 Driver Installation The PCA-6005's onboard Ethernet interface supports all major network operating systems. The BIOS automatically detects the LAN while booting, and assigns an IRQ level and I/O address. No jumpers or switches are required for user configuration. The drivers and installation instructions are located in the following directories of the utility CD: •...

  • Page 68: Windows 9X Drivers Setup Procedure

    Note 2: The CD-ROM drive is designated as "D" throughout this section. In the "Windows" screen, click on "Start" and select "Settings". Then click on the "Control Panel" icon to select "System". PCA-6005 User’s Manual...
  • Page 69 In the "System Properties" window, select the "Device Manager" tab. Select "View devices by type", and navigate to: Com- puter\Other devices\PCI Ethernet Controller. Highlight "PCI Ether- net Controller" and click on "Properties". In the "PCI Ethernet Controller Properties" window, select the "Driver"...
  • Page 70 In the "Update Device Driver Wizard" window, click on "Next". Click "Next". PCA-6005 User’s Manual...
  • Page 71 In the following "Update Device Driver Wizard" window, select"Specify a location:". Type in: "D:\Drv_LAN\RTL8139C\WIN98".Then click on "Next". In the following "Update Device Driver Wizard" window, select "The updated driver ...". Then click on "Next". Chapter 5...
  • Page 72 In the following "Update Device Driver Wizard" window, click on "Next". When the "Insert Disk" window appears, insert the utility CD into the CD-ROM drive. Then click on "OK". PCA-6005 User’s Manual...
  • Page 73 When the "Update Device Driver Wizard" window shows, click on finish. In the "System Settings change" window, select click on "Yes". Chapter 5...

  • Page 74: Windows Nt Drivers Setup Procedure

    5.5 Windows NT Drivers Setup Procedure Note: The CD-ROM drive is designated as "E" throughout this section. In the "Windows NT" screen, click on "Start" and select "Settings". Then click on the "Control Panel" icon to select "Network". PCA-6005 User’s Manual...
  • Page 75 In the "Network" window, select the "Adapters" tab. Then click on "Add...". In the "Select Network Adapter" window, click on "Have Disk...". Chapter 5...
  • Page 76 When the "Insert Disk" window appears, insert the utility CD into the CD-ROM drive. The correct file path is; D:\Drv_LAN\RTL8139C\WINNT4. When you have the correct file path, click on "OK". In the "Select OEM Option" window, click on "OK". In the "Duplex mode", click "OK". PCA-6005 User’s Manual...
  • Page 77 In the "Network" window, select the "Adapters" tab. Under "Net- work Adapters:", highlight "Realtek RTL8139CA/B/C(8130). In the "Microsoft TCP/IP Properties" window, select the "IP Address" tab. Then select "Specify an IP address". Type in the IP Address and Subnet Mask details. Then click on "OK". Chapter 5...
  • Page 78 In the "Network Settings Change" window, click on "Yes". PCA-6005 User’s Manual...

  • Page 79: Windows 2000 Drivers Setup Procedure

    5.6 Windows 2000 Drivers Setup Procedure Note: The CD-ROM drive is designed as "E" through- out this section. In the "Windows 2000" screen, click on " Start" and select " set- tings". Then click on the " Control Panel" icon to select "system". Chapter 5...
  • Page 80 In the " System Properties" window, select the " Device Manager". In "Device Manager" screen, follow the screen instructions, to click on "Properties". PCA-6005 User’s Manual...
  • Page 81 In the following screen, to click on "Update Driver". Click on "Next". Chapter 5...
  • Page 82 Following the highlighted item, and click on "Next". Click on "Have Disk". PCA-6005 User’s Manual...
  • Page 83 Key in "E:\Drv__LAN\RTL8139C\WIN2000", then click on "OK". To highlight the following item, and click "Next". Click "Next". Chapter 5...
  • Page 84 Click "Finish" to complete the installation. PCA-6005 User’s Manual...
  • Page 85 SCSI Setup and Con- figuration The PCA-6005 features an onboard SCSI interface. This chapter provides basic SCSI concepts and instructions for installing the software drivers with the SCSI driver disks/CD included in your package...

  • Page 86: Chapter 6 Scsi Setup And Configuration

    Chapter 6 SCSI Setup and Configuration 6.1 Introduction The PCA-6005 is equipped with an Adaptec AIC-7899 single-chip PCI- to-SCSI host adapter which provides a dual channel Ultra 160 multi- tasking interface between your computer.s PCI bus and SCSI devices (disk drives, CD-ROM drives, scanners, tape backups, removable media drives, etc.).

  • Page 87: Scsi Ids

    A SCSI bus is an electrical pathway that consists of a SCSI interface installed in a computer and one or more SCSI devices. SCSI cables are used to connect the devices to the SCSI interface. For the SCSI bus to function properly, a unique SCSI ID must be assigned to the SCSI inter- face and each SCSI device connected to it, and the SCSI bus must be properly terminated.

  • Page 88: Terminating The Scsi Bus

    (the preferred method). We recommend that you do not change this default setting. 6.5 Configuring the SCSI interface with SCSISelect SCSISelect, included with the CPU card, enables you to change SCSI set- tings without opening the computer. SCSISelect also enables you to low- PCA-6005 User’s Manual...

  • Page 89: Configuring The Scsi Interface With Scsiselect

    level format or verify the disk media of your SCSI hard disk drives. The following table lists the available and default settings for each SCSISelect option. Note: The default settings are appropriate for most systems. Run SCSISelect if you need to change or view current settings, or if you would like to run the SCSI disk utilities.
  • Page 90 Host Adapter BIOS Enabled Enabled Disabled : Not Scan Disabled: Scan Bus Domain Validation2 Enabled, Disabled Enabled Support Removable Disabled Disabled Disks Under BIOS as Boot Only, Fixed Disks2 All Disks BIOS Support for Enabled, Disabled Enabled Bootable CD_ROM2 PCA-6005 User’s Manual...

  • Page 91: Starting Scsiselect

    BIOS Support for Enabled, Disabled Enabled Int 13 Extensions2 1 Setting is valid only if Multiple LUN Support is enabled. 2 Settings are valid only if host adapter BIOS is enabled. 6.6 Starting SCSISelect Follow these steps to start SCSISelect: Turn on or restart your system.
  • Page 92 160 MBytes/sec. • Initiate Wide Negotiation-(Default: Yes) When set to Yes, the SCSI card attempts 16-bit data transfer (wide negotiation.) When set to No, the SCSI card uses 8-bit data transfer unless the SCSI device requests wide negotiation. PCA-6005 User’s Manual...
  • Page 93 Note: Set Initiate Wide Negotiation to NO if you are using an 8-bit SCSI device that hangs or exhib- its other performance problems with 16-bit data transfer rate enabled. • Enable Disconnection-(Default: Yes) When set to Yes, allows the SCSI device to disconnect from the SCSI bus. Leave the setting at Yes if two or more SCSI device is connected, changing the setting to No results in slightly better performance.
  • Page 94 SCSI bus and sets transfer rates accordingly. Displays the resulting data transfer rate. • Support Removable Disks Under BIOS as Fixed Disks. (Default: Disabled) Determines which removable-media drives are supported by the SCSI card BIOS. Choices are as follows: PCA-6005 User’s Manual...

  • Page 95: Using Scsi Disk Utilities

    • Disabled. No removable-media drives are treated as hard disk drives. Software drivers are required because the drives are not controlled by the BIOS. • Boot Only.Only the removable-media drive designated as the boot device is treated as a hard disk drive. •...

  • Page 96: Windows 9X Driver Setup Procedure

    Then it enter SCSI installation. Please insert SCSI driver floppy disk. 6.9 Windows 9X Driver setup procedure In the window 9x screen, click on “start” and select “setting”. Then click on the “Control Panel” icon to select .System. PCA-6005 User’s Manual...
  • Page 97 In the “System properties”, choose “PCI SCSI Bus Controller.” Then click on “Properties.” Click on "Update Driver"...
  • Page 98 Click on “Next” Recommend to search for a better driver PCA-6005 User’s Manual...
  • Page 99 If the SCSI driver is supplied in floppy disk, click on “Floppy disk drives.” Then, click on “Next.” If the SCSI driver is supplied in CD-ROM disk, click on “Specify a location:" then enter "E:\Drv_SCSI\AIC7899\Windows\Win9X" In the "Update Device Driver Wizard" click on "Next."...
  • Page 100 The installation is completed. Click on "Finish." Click on "Yes" to restart the system. PCA-6005 User’s Manual...

  • Page 101: Windows Nt Driver Setup Procedure

    6.10 Windows NT Driver Setup Procedure In the Windows NT screen, click on “Start” and select “Setting.” Then click on the “Control Panel” icon to select “SCSI Adapter.” In the SCSI Adapter, choose “Drivers.” Click on “Add to install SCSI driver.”...
  • Page 102 Click on "Have Disk." Click on “Browse. to select the drivers.” If the SCSI driver is sup- plied in floppy disk, choose the directory A:1. PCA-6005 User’s Manual...
  • Page 103 Click the SCSI driver, and then click “OK.” The installation of SCSI Driver is completed. Click on "OK."...
  • Page 104 PCA-6005 User’s Manual...
  • Page 105 Programming the Watchdog Timer The PCA-6005 is equipped with a watchdog timer that resets the CPU if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 106: Appendix A Programming The Watchdog

    Appendix A Programming the watchdog A.1 Programming the watchdog The PCA-6005's watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function after the programmed period. This section describes the operation of the watchdog timer and how to program it.

  • Page 107: Lock The Super I/O It8705F

    A.1.6 Lock the Super I/O IT8705F After setting the WDT and game port, lock it back to prevent unintended access. A.1.7 Resetting the Watchdog Timer Any read or write action from/to the game port will reset the watchdog timer. Unlock IT8705F Select WDT (Logical Device Number = 5) Enable and set time to WDT...

  • Page 108: List Of Registers

    Game Port Base Address MSB Register (Index = 60h, Default = 02h) Description Read only with "0h" for Base Address [15:12] Game Port Base Address MSBRead/Write, mapped as Base Address [11:8] Game Port Base Address LSB Register (Index = 61h, Default = 01h) Description PCA-6005 User’s Manual...
  • Page 109 Game Port Base Address LSBRead/Write, mapped as Base Address [7:0] Programming Examples ;-------------------------------------- ;Input :(AH) - register index (AL) - Value to write ;-------------------------------------- Set_8705_Reg proc near push dx, 2Eh al, ah dx, al 80h, al ; for I/O delay dx, al Set_8705_Reg endp ;--------------------------------------------...
  • Page 110 5 ; Select watchdog function call Select_Logic_Device ah, 30h ; Enable watchdog function al, 1 call Set_8705_Reg ah, 0FBh ; Set counter unit (second) l, 00011000b call Set_8705_Reg ah, 0FCh ; Use GP67 (pin 85) al, 37h PCA-6005 User’s Manual...
  • Page 111 call et_8705_Reg ah, 0FDh ; Set time-out value al, 10 call Set_8705_Reg al, 6 ; Select game port function call Select_Logic_Device ah, 30h ; Enable game port function al, 1 call Set_8705_Reg ah, 60h ; Set game port address 201h al, 02h call Set_8705_Reg...
  • Page 112 1 call Set_8705_Reg ah, 60h ; Set game port address 201h al, 02h call Set_8705_Reg ah, 61h al, 01h call Set_8705_Reg call Lock_8705 ; Lock 8705 ; To reset the watchdog timer before the interval expires dx,201h PCA-6005 User’s Manual...
  • Page 113 al,dx...
  • Page 114 PCA-6005 User’s Manual...
  • Page 115 I/O Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • IDE Hard Drive Connector • Floppy Drive Connector • Parallel Port Connector • SCSI Connector • USB Connector • VGA Connector • Ethernet 10/100Base-T RJ-45 Connector •...

  • Page 116: Appendix B Pin Assignments

    DATA 0 DATA 15 SIGNAL GND DISK DMA REQUEST IO WRITE IO READ IO CHANNEL READY HDACKO* IRQ14 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0* HARD DISK SELECT 1* IDE ACTIVE* * low active PCA-6005 User’s Manual...

  • Page 117: Floppy Drive Connector (Cn3)

    B.2 Floppy Drive Connector (CN3) Table B-2: Floppy drive connector (CN3) Signal Signal FDHDIN* FDEDIN* INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * low active...

  • Page 118: Parallel Port Connector (Cn4)

    B.3 Parallel Port Connector (CN4) Table B-3: Parallel port connector (CN4) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active PCA-6005 User’s Manual...

  • Page 119: Usb Connector (Cn6)

    B.4 USB Connector (CN6) Table B-4: USB1/USB2 connector (CN6) USB1 Signal USB2 Signal +5 V +5 V Chassis GND...

  • Page 120: Vga Connector (Cn7)

    B.5 VGA Connector (CN7) Table B-5: VGA connector (CN7) Signal Signal GREEN BLUE H-SYNC V-SYNC PCA-6005 User’s Manual...

  • Page 121: Keyboard And Mouse Connnector Cn11)

    B.6 Keyboard and Mouse Connnector CN11) Table B-6: Keyboard and mouse connector (CN11) Signal KB DATA MS DATA KB CLOCK MS CLOCK B.7 External Keyboard Connector (CN12) Table B-7: External keyboard connector (CN12) Signal DATA...

  • Page 122: Ir Connector (Cn13)

    B.8 IR Connector (CN13) Table B-8: IR connector (CN13) Signal +5 V IR_RX IR_TX B.9 CPU Fan Power Connector (CN14) Table B-9: CPU fan power connector (CN14) Signal +12 V Detect PCA-6005 User’s Manual...

  • Page 123: Power Led (Cn16)

    B.10 Power LED (CN16) You can use an LED to indicate when the CPU card is on. Pin 1 of CN16 supplies the LED's power, and Pin 3 is the ground. Table B-10: Power LED and keylock connector (CN16) Function LED power (+5 V) Reserved B.11 External Speaker Connector (CN17)

  • Page 124: Reset Connector (Cn18)

    B.12 Reset Connector (CN18) Table B-12: Reset connector (CN18) Signal RESET B.13 HDD LED Connector (CN19) Table B-13: HDD LED connector (CN19) Signal LED0 (LED-) Vcc(LED+) PCA-6005 User’s Manual...

  • Page 125: Atx Feature Connector (Cn20)

    B.14 ATX Feature Connector (CN20) Table B-14: ATX feature connector (CN20) Signal PS-ON VCCSB B.15 ATX Soft Power Switch (CN21) Table B-15: ATX soft power switch (CN21) Signal 5VSB PWR-BTN...

  • Page 126: Sm Bus Connector (Cn29)

    Interrupt controller 2 0C0-0DF DMA controller Clear math co-processor Reset math co-processor 0F8-0FF Math co-processor 1F0-1F8 Fixed disk 200-207 Game I/O 278-27F Parallel printer port 2 (LPT3) 290-297 On-board hardware monitor 2F8-2FF Serial port 2 300-31F Prototype card PCA-6005 User’s Manual...
  • Page 127 Table B-17: System I/O ports 360-36F Reserved 378-37F Parallel printer port 1 (LPT2) 380-38F SDLC, bisynchronous 2 3A0-3AF Bisynchronous 1 3B0-3BF Monochrome display and printer adapter (LPT1) 3C0-3CF Reserved 3D0-3DF Color/graphics monitor adapter 3F0-3F7 Diskette controller 3F8-3FF Serial port 1 2E-2F Watchdog timer...
  • Page 128 IRQ12 PS/2 mouse IRQ13 INT from co-processor IRQ14 Fixed disk controller IRQ15 Available IRQ3 Serial communication port 2 IRQ4 Serial communication port 1 IRQ5 Parallel port 2 IRQ6 Diskette controller (FDC) IRQ7 Parallel port 1 (print port) PCA-6005 User’s Manual...
  • Page 129 B.20 1st MB Memory Map Table B-20: 1st MB memory map Addr. range (Hex) Device F0000h - FFFFFh System ROM CC000h - EFFFFh Unused C0000h - CBFFFh VGA BIOS B8000h - BFFFFh CGA/EGA/VGA text B0000h - B7FFFh Unused A0000h - AFFFFh EGA/VGA graphics 00000h - 9FFFFh Base memory...
  • Page 130 PCA-6005 User’s Manual...
