Advantech PCA-6277 Startup Manual

PCA-6277 Dual Socket 370 Pentium
with AGP/VGA, Dual Ethernet, and SCSI
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCA-6277 socket 370 Pentium
based single board computer
• 2 SCSI driver disks (optional)
• 1 FDD cable
• 2 Ultra ATA 66 HDD cables
• 1 printer (parallel port) and
COM port cable kit
• 1 ATX-to-AT power cable
• 1 ivory cable for PS/2
keyboard and PS/2 mouse
• 1 USB cable (optional)
• SCSI cable (optional)
• 1 single-slot bracket
• 1 PCA-6277 startup manual
• CD disc and manual (in PDF format)
• Warranty certificate
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the PCA-6277,
please refer to the enclosed CD Disc or disk
(in PDF format).
Note 2: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/
readstep.html
(Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/nc
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCA-6277 series Rev. A1
Part No. 2006627701
Printed in Taiwan
® III processor-
p/n: 1701340703
p/n: 1701400452
p/n: 1701260305
p/n: 1700000450
p/n: 1700060202
p/n: 1700100170
p/n: 1701060000
p/n: 1962159010
1st Edition
Apr. 2001

Specifications

Standard SBC Functions
• CPU: Dual socket 370 for Intel
processor, FSB 66/100/133
• BIOS: Award 2 Mb Flash memory BIOS
• Chipset: VIA Apollo Pro 133A
• System memory: Four 168-pin DIMM sockets
accepts up to 2 GB SDRAM
• Enhanced IDE interface: Supports up to four EIDE
devices. BIOS auto-detect, PIO Mode 4, Ultra ATA 100/
66/33 transfer
• FDD interface: Supports up to two FDDs
• Serial ports: Two serial RS-232 ports
• Parallel port: One parallel port, supports
SPP/EPP/ECP mode
• Keyboard/mouse connector: Supports a standard
PS/2 keyboard and a PS/2 mouse
• Watchdog timer: 63 level timer intervals
• USB: Four Universal Serial Bus ports
VGA/LCD Interface
• Chipset: ATI 3D Rage 128 Pro 4XL, 32 MB SDRAM
• Interface: AGP 4x
Ethernet Interface
• Chipset: Realtek 8139C
• Ethernet interface: Dual PCI 10/100 Mbps Ethernet,
IEEE 802.3U protocol compatible
• Connection: On-board RJ-45 connector x 2
SCSI Interface
• Chipset: AIC-7892
• Interface: Ultra 160 SCSI supports data transfer up to
160 MB/sec.
PCA-6277 Startup Manual
®
III SBC
® Pentium ® III
