Technical Specification - Autoscript Control Net HC-1 User Manual

Physical Data
Hand Foot
Controller Controller
133 mm 206 mm
Width*
(5.2 in) (8.1 in)
127 mm 256 mm
Length*
(5 in) (10.1 in)
42 mm 73 mm
Height*
(1.7 in) (2.9 in)
1 kg 2.35 kg
Weight
(2.2 lb) (5.18 lb)
*Excluding controls and connectors.
Environmental Data (All Products)
Operating temperature range . . . . . . -10°C to +50°C (14°F to +122°F)
Storage temperature range . . . . . . . .-20°C to +60°C (-4°F to +140°F)
Electrical Data
Hand Foot
Controller Controller
Supply
12 VDC 12 VDC
Voltage
10 mA,
Current
(3 mA in 40 mA
(max)
standby)
Desk Smart
Controller Combiner
133 mm 180 mm
(5.2 in) (7.1 in)
124 mm 260 mm
(4.9 in) (10.2 in)
53 mm 31 mm
(2.1 in) (1.2 in)
0.6 kg 1 kg
(1.32 lb) (2.2 lb)
Desk Smart
Controller Combiner
100-240
12 VDC
VAC
30 mA 0.1 A

Technical Specification

Connections Data
DC Power Socket (Hand and foot controller)
Connector type: Hirose DC socket.
Serial Connection (Hand controller, foot controller and Smart
Combiner)
Connector type: 9-way D socket.
Data format is standard RS232 voltage
levels, 8 data, 1 stop, no parity, 2400 baud.
Control Net Connection
(Receiver Unit and Smart Combiner)
Connector type: BNC Connector.
Technical specifications are subject to change without notice.
Pin Signal
1 GROUND
4 +12 VDC
Pin Signal
1 TX
5 GROUND
8 RX
9 +12 VDC
Pin Signal
Tip Data
Sleeve Ground
25
