Smart Combiner Box
The smart combiner box has a serial out connector. This can be used
to connect it directly to the control system.
Power Connections
Hand Controller
12VDC
Foot Controller
12VDC
Desk Controller
The desk controller receives DC
power via the RJ11 serial
connection, and does not require
a separate connection.
Smart Combiner Box
100-240VAC
Installation
13
