Adding Additional Smart Combiner Boxes

Additional hand, foot and desk controllers can be added into a system
by looping more smart combiner boxes onto the Control Net.
Control Net
loop in from
previous smart
combiner box
When three or more smart combiners are connected in
one installation, response time delays may be incurred
when operating the controllers.

Powering Up

The hand, foot and desk controllers are automatically powered up when
DC power is connected.
Smart combiner box
To power up the smart combiner box, operate the power switch on the
rear of the product.
Control Net loop
out to next smart
combiner box
Four Control Net
inputs available
for additonal
controllers
