Technical Specification

Physical Data
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 mm (7.1 in.)
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260 mm (10.2 in.)
Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 mm (1.2 in.)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Kg (2.2 lb)
*Excluding controls and connectors.
Environmental Data
Operating temperature range . . . . . . +5°C to +40°C (+41°F to +104°F)
Storage temperature range . . . . . . . .-20°C to +60°C (-4°F to +140°F)
Electrical Data
AC power input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90-260V AC
DC power input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12V DC
DC power output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12V DC, 1A
AC power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.1A
DC power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1A
Connections Data
DC Power In Socket
Connector type: 4 pin XLR plug.
DC Power Out Socket
Connector type: 3.5 mm mono jack socket.
Serial Connection
Connector type: 9-way D socket.t
Data format is standard RS232 voltage
levels, 8 data, 1 stop, no parity, 2400 baud.
ControlNet Connection
Connector type: BNC Connector.
USB Connection
Conforms to USB 2.0 standard.
Pin Signal
Video Out Sockets
Connector type: 75Ω BNC socket.
1 GROUND
4 +12V DC
Pin Signal
Tip +12V DC
Sleeve GROUND
Pin Signal
Centre Composite Video In (PAL or NTSC)
Outer GROUND (Cable screen)
Technical specifications are subject to change without notice.
Pin Signal
1 TX
5 GROUND
8 RX
9 +12 VDC
Pin Signal
Tip Data
Sleeve Ground
