Installation
System Connections - Two Smart Combiner Boxes
Five controllers (mixed)
connected to the first
smart combiner
16
Smart
Combiner Box(1)
Control Net loop
out to second
smart combiner
Smart
Combiner Box(2)
Power Supply
XBox and WinPlus Host PC
Additional five controllers
(mixed) connected to the
second smart combiner
Individual PSU-HRs
are required for all
the controllers.
