Technical Specification

Physical Data
Width* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .240 mm (9.5 in)
Height* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .180 mm (7.1 in)
Length* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54 mm (2.1 in)
Weight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2 kg (2.6 lb)
*Excluding controls/connectors.
Environmental Data
Operating temperature range . . . . . . . .5°C to +40°C (41°F to +104°F)
Storage temperature range. . . . . . . . -20°C to +60°C (-4°F to +140°F)
Electrical Data
Video inputs . . . . . . . . . . . . . . . . . . Auto-sensing PAL/NTSC (2), VGA
DC Power input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12V DC
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18W (1.5A)
Display Data
Backlight technology. . . . . . . . . . . . . . . . . . . . . . .High brightness LED
Brightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1700 nits
Contrast ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .500:1
Resolution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800 x 600 (XGA)
Viewing angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160°(H), 130°(V)
Diagonal screen size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203.2 (8 in)
Display area . . . . . . . . . . . . . . . . . . . . . . 162 x 121.5 mm (6.4 x 4.8 in)
Reading range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 m (9 ft, 10 in)
22
Connections Data
DC Power Socket
Connector type: 4 pin XLR plug.
Pin
1 GROUND (connected to monitor chassis)
2 TALLY LOGIC INPUT (>2.5V DC in = Tally light ON, <2V
DC in = Tally light OFF)
4 +12V DC
Composite Video In (1 and 2)
Connector type: 75Ω BNC socket.
Pin
Centre Composite Video In (PAL or NTSC)
Outer GROUND (Cable screen)
Opto Sensor Input
Connector type: 3.5 mm mono jack socket.
Connection for an external Autoscript opto sensor to activate the built-
in tally light on the monitor. The sensor is attached to the camera tally
light and allows the monitor to mimic the operation of the camera tally.
Signal
Signal
Pin Signal
Tip HOT
Sleeve GROUND
