6
HAND CONTROL
Programming Hand Control Options — Input
Configuration
Configuring the Hand Control
1. Parameter Settings/Program Adjustments
2. Hand Control
3. Input Configuration
4. HC Input Configuration (Hand Control can be configured
in 4 ways)
„
Proportional: Default Programming
„
Switch Operation: Joystick will operate with a 4-
switch system.
„
3-Direction prop: Forward is disabled on the
hand control; reverse toggles between forward and
reverse.
„
3-Direction Switch op: Forward is disabled on the
hand control; reverse toggles between forward and
reverse.
Programming Hand Control Options — Joy-
stick Setup
1. Parameter Settings/Program Adjustments
2. Hand Control
3. Joystick Setup
„
Center Deadband: Defines how far from center the
joystick must be moved for the system to take as a
drive command.
„
Tremor Suppression: Suppresses a tremor on the
joystick
„
Assign Direction: Allows you to assign directions.
Keep in mind that forward must be opposite of
reverse and left must be opposite of right.
„
Throw: Defines how far the joystick must be deflected
forward/reverse/left/right to be at full speed.
Programming Hand Control Options — Button
Operation
1. Parameter Settings/Program Adjustments
2. Hand Control
3. Button Operation
„
Toggle Mode: Allows the toggle function of the on/
off toggle to be disabled.
„
Horn Button: Allows the horn button to be enabled/
disabled.
„
Key I & II: Can be set to Disabled, Drive 1, Seat, Aux
Menu and Custom MIO.
„
Home Button: Allows the Home Button to be
enabled/disabled.
Programming Hand Control Options — Button
Operation
1. Parameter Settings/Program Adjustments
2. Hand Control
3. Button Operation
„
Toggle Mode: Allows the toggle function of the on/
off toggle to be disabled.
„
Horn Button: Allows the horn button to be enabled/
disabled.
„
Key I & II: Can be set to Disabled, Drive 1, Seat, Aux
Menu and Custom MIO.
„
Home Button: Allows the Home Button to be
enabled/disabled.
Programming Hand Control Options — Custom
MIO
1. Parameter Settings/Program Adjustments
2. Hand Control
3. Button Operation
4. Key I and Key II
„
Disabled
„
Drive I
„
Seat
„
Aux Menu
„
Custom MIO
Programming Hand Control Options — Custom
MIO
Programming the Mapped IO in the Econ-W requires going
to MIO Support which is located on the top tool bar of the
programming station. This is where custom electronics can
be done to better fit the end user's needs.
1. MIO Support
2. MIO
„
Click on the
sign to start a new mapping.
„
Select Device.
„
Select Input (which will be Key I or Key II).
„
Select Output (which will be the custom function).
„
Click on the Save Icon
Programming Device Double Command
Device Double Command allows the end user to use a
double left or double right command on their hand control
and it will change the mode.
1. Parameter Settings/Program Adjustments
2. Hand Control
3. Button Operation
„
Device Double Command: There will be a drop
down menu. From there, either Enable Left or
Enable Right can be selected.
.
