SETUP

NOTE: The end user must follow the proper sequences to
activate their desired input device.
Programming Hand Control Driving Parameters
Adjusting drive parameters in the Econ-W, similar to Q-Logic
3, are performed in real time. Real time programming allows
you to adjust while the client is driving without the need to
reboot to save these changes to the system. Q-Logic 3 offers
a wireless programming option through Bluetooth. This
allows you to make the changes while the client is driving
and not be tethered to them by a cable.
1. Parameter Settings/Program Adjustments
2. User Drive Profiles
3. Hand Control Profiles
„
Click on the parameter that needs changing. By
double clicking on the parameter box, the parameter
can be typed in or the slide bar can be used to
change the parameter.
Programming Parameters Labels
Similar to Q-Logic 2, Q-Logic 3 has the ability to customize
how the drive profiles will show up on the Hand Control or
Enhanced Display.
1. Parameter Settings/Program Adjustments
2. User Drive Profiles
3. Hand Control Profiles
4. Click on Profile Label Type to change the following:
„
Text
„
Icon
„
Symbol
Programming Parameters Labels (Text or Icon
& Symbol)
Similar to Q-Logic 2, Q-Logic 3 has the ability to customize
how the drive profiles will show up on the Hand Control or
Enhanced Display
1. Parameter Settings/Program Adjustments
2. User Drive Profiles
3. Hand Control Profiles
„
If Text or Icon is chosen in Profile Label Type,
select from the drop-down in Text & Icon.
„
If Symbol is chosen from Profile Label Type, select
from the drop-down menu from Symbol.
WARNING!
The controller program can affect speed, acceleration,
deceleration, dynamic stability, and braking. If the
controller is programmed incorrectly or outside of the
safe limits as determined by the healthcare professional,
it can create a dangerous situation. Only the power chair
manufacturer or a Quantum Rehab Provider should
program the controller.
Programming Startup Configuration — Input
Device Selection Screen
Programming the Input Device Selection will tell the system
how the power chair will power up. There are 3 options.
1. Parameter Settings/Program Adjustments
2. Startup Configuration
3. Input Device Selection: There are 3 options:
„
Default Input Device: The same input device
powers up the chair regardless of which power
button is used.
„
Last Device Used: The device that powered off the
chair.
„
Input Device Selection Screen: If multiple inputs
are on the power chair, this gives the end user a way
to choose which input device they wish to use.
„
Power on Device: Similar to with Q-Logic 2, the
device that powers on the power chair is the device
that is in charge.
Startup Configuration — Input Device Selection
Screen
If the Input Device Selection is set to Input Device Selection
Screen, then the input direction would need to be set.
1. Parameter Settings/Program Adjustments
2. Startup Configuration
3. Input Device Selection: Choose from one of the
following directions:
„
Left
„
Right
„
Left - Right - Left
„
Right - Left - Right
Startup Configuration — Default Input Device
If the Default Input Device is chosen for the startup
configuration, the input device needs to be selected from the
Default Input Device menu.
1. Parameter Settings/Program Adjustments
2. Startup Configuration
3. Default Input Device: Choose which input device will
be the default:
„
Enhanced Display
„
Hand Control
„
SCIM
„
Stand-alone Joystick
„
SPM (Sip & Puff Module)
„
1-Switch Scanner
