SIP-N-PUFF

Programming Sip N Puff Driving Parameters
Adjusting drive parameters in the Econ-W, are done in real
time; however, you need to be connected to the chair via
PC Programming Cable. In Q-Logic 3, once paired via
Bluetooth, those changes can be done more easily.
1. Parameter Settings/Program Adjustments
2. User Drive Profiles
3. Sip N Puff Profiles
4. Click on the parameter that needs changing. By double
clicking on the parameter box, the parameter can be
typed in or the slide bar can be used to change the
parameter.
The Sip N Puff can be programmed to operate as a 2-
pressure or 4-pressure system.
1. Parameter Settings/Program Adjustments
2. Sip N Puff
3. Input Configuration
„
SNP Input Configuration
„
2-Pressure: Double Puff and hold is forward, Puff is
right, Double Sip and hold is reverse, and Sip is left.
„
4-Pressure: Hard Puff is forward, Hard Sip is Re-
verse, Soft Puff is Right and Soft Sip is left.
Programming Sip N Puff — Setting Up
Pressures Manually
There are two options to set the pressures for the end user:
Four Pressure Quick Setup or manually setting the
pressures.
1. Parameter Settings/Program Adjustments
2. Sip N Puff
3. Pressure Fine Adjustment
„
Four Pressure Quick Setup: Allows the end user
to give the pressure they can comfortably do without
fatigue.
„
Manual Setup is completed by selecting each slide
bar of the 4-pressure or 2-pressure adjustment
boxes and manually adjusting.
Programming Sip N Puff — Sampling Delay
Sampling Delay Sip and Puff parameters are how long the
command must be provided before the system will recognize
the command.
1. Parameter Settings/Program Adjustments
2. Sip N Puff
3. Pressure Fine Adjustment
4. Sampling Delay Puff: Click on the sliding bar and move
it until the desired time is reached.
5. Sampling Delay Sip: Click on the sliding bar and move
it until the desired time is reached.
Programming Sip N Puff — Assign Direction
Pressure Direction Assignment can be changed if a end
user has an easier time performing a hard sip instead of a
hard puff for a forward command.
1. Parameter Settings/Program Adjustments
2. Sip N Puff
3. Pressure Direction Assignment
4. Depending on whether the system is programmed for a
2 pressure or a 4 pressure will determine which settings
are used.
Programming Sip N Puff — Latch Driving
Latch driving is very common with sip n puff users. Latch
allows the user to provide a forward command and then
release the pressure and the chair continues to drive.
1. Parameter Settings/Program Adjustments
2. User Drive Profiles
3. Sip N Puff Profiles
4. Forward Latch and set to one of the following options:
„
Cruise
„
3 Step
„
1 Step
Programming Sip N Puff — Latch Braking
Options
Decel/Braking Option: This option allows you to set the
way that a latched power chair stops.
Decel Stop: When a reverse command over 50% is given,
the chair will come to a soft stop using the deceleration that
is set in the driving.
Quick Stop: When a reverse command over 50% is given,
the chair will come an quick stop.
Speed/Step Reduce: When a reverse command over 50%
is given when Cruise is in use, the speed of the power chair
will reduce. A long reverse command will stop the power
chair.
When 3 Step is in use, and a reverse command over 50% is
given the speed will step down. A full stop can be done with
a long reverse command.
Programming Sip N Puff — Latch Driving/
Braking
1. Parameter Settings/Program Adjustments
2. User Drive Profiles
3. Sip N Puff Profiles
4. Latch Decel/Braking
„
Decel Stop
„
Quick Stop
„
Speed/Step Reduce
