Quantum Q614 Specifications

QuaNtuM ® 614 QuaNtuM ® 6000z
Drive wheels 14" 14"
OMNi-casters Front: 6" solid Front: 6" solid
Rear: 6" solid Rear: 6" solid
suspeNsiON ATX Suspension Active-Trac ® ATX Suspension with
(Active-Trac with integrated rear dual-strut suspension
®
extra stability) and articulating caster beam
MaxiMuM speeD Up to 5 mph 1 Up to 6 mph 1 / Up to 8 mph
Brakes Intelligent Braking (electronic, Intelligent Braking (electronic,
regenerative disc brakes) regenerative disc brakes)
GrOuND clearaNce 2.25" 3.5"
turNiNG raDius 20" 22.5"
Overall size Length: 35.5" 3 Length: 36" 3
Width: 25.125" Width: 25.875"
seatiNG Synergy Seat Synergy Seat
® ®
Adjustable Width: 10"-22" Adjustable Width: 10"-24"
Adjustable Depth: 10"-22" Adjustable Depth: 10"-24"
TRU-Balance ® 2 TRU-Balance ® 2
Adjustable Width: 14"-22" Adjustable Width: 14"-24"
Adjustable Depth: 14"-20" Adjustable Depth: 14"-24"
Specialty Seat Kit Specialty Seat Kit
Contoured Seating Contoured Seating
Drive traiN Two-motor, Mid-Wheel 6 Two-motor, Mid-Wheel 6
®
Batteries Two 12 volt, deep cycle Two 12 volt NF-22
NF-22 or Group 24
raNGe per charGe Up to 13 miles 1 Up to 20 miles 1
Battery charGer 5A, off-board 8A off-board
availaBle electrONics 75A, Q-Logic NE 100A, Q-Logic 5
75A, Q-Logic NE+ 70A, PG VR2
75A, Q-Logic Drive Control System
weiGht capacity 300 lbs. (user weight) 300 lbs. (user weight)
Base weiGht 121.5 lbs. 147 lbs.
11
Battery weiGht 38 lbs. (each) 38.5 lbs. / 53.5 lbs. (each)
cOlOrs availaBle ON Q614, Q600 aND Q610
Candy Viper Onyx Champagne Sunburst
Apple Red Blue Black
cOlOrs availaBle ON Q6000 aND Q6000z
Metallic Metallic Metallic Metallic Sunburst
Red Blue Black Silver Orange
FOOtNOtes
1) Range and speed vary with user 6) Requires solid tires
weight, terrain type, battery charge, 7) Only available with high-speed motors
battery condition and tire pressure. 8) Only available with Glide motors
2) Off-board charger required 9) Also available on the Q614
3) Without front riggings 10) Up to 24" x 24" with XL versions
4) Optional (standard with Group 4 units) 11) Battery weight may vary based
5) Required with high-speed motors on manufacturer
Due to manufacturing tolerances and continual product improvement, length, width,
turning radius and ground clearance can be subject to variance of + or – 3 %
Q6-10-1-08
QuaNtuM ® 600 QuaNtuM ® 6000
14" 14"
Front: 5" solid Front: 5" solid
Rear: 6" solid Rear: 6" solid
ATX Suspension Active-Trac ® ATX Suspension with
(Active-Trac with integrated rear dual-strut suspension
®
extra stability) and articulating caster beam
4 Up to 5 mph 1 / Up to 6 mph 4,6 Up to 6.5 mph 1 / Up to 8 mph 4
Intelligent Braking (electronic, Intelligent Braking (electronic,
regenerative disc brakes) regenerative disc brakes)
3" 3"
20" 22"
Length: 36.5" 3 Length: 37" 3
Width: 23" Width: 25.875"
Synergy Seat 10 Synergy Seat 10
® ®
Adjustable Width: 10"-20" Adjustable Width: 10"-22"
Adjustable Depth: 10"-20" Adjustable Depth: 10"-20"
10 10
TRU-Balance ® 2 TRU-Balance ® 2
Adjustable Width: 14"-20" Adjustable Width: 14"-22"
Adjustable Depth: 14"-20" Adjustable Depth: 14"-20"
Specialty Seat Kit Specialty Seat Kit
Contoured Seating Contoured Seating
Two-motor, Mid-Wheel 6 Two-motor, Mid-Wheel 6
® ® ®
Two 12 volt, deep cycle Two 12 volt, deep cycle
NF-22 Group 24
Up to 20 miles 1 Up to 20 miles 1
5A, off-board 8A, off-board
70A, PG VR2 7 100A, Q-Logic
8
70A, Q-Logic
100A, Q-Logic 7
300 lbs. (user weight) 300 lbs. (user weight)
129 lbs. 170 lbs.
38 lbs. (each) 53.5 lbs. (each)
cOlOrs availaBle ON Q600 aND Q610
Mariner Cardinal Spring Violet
Orange Blue Red Green
cOlOrs availaBle ON Q600
Emerald Pewter Silver Kelly Graphite
Green Green Blue
Lifetime limited warranty on frame; 2-year warranty on electronics;
18-month warranty on drive motor
(US) 866-800-2002
Visit us on the web at: www.quantumrehab.com
QuaNtuM ® 610
10"
Front: 5" solid
Rear: 6" solid
ATX Suspension
(Active-Trac with
®
extra stability)
Up to 4 mph 1
Intelligent Braking (electronic,
regenerative disc brakes)
2.5"
21.25"
Length: 34.75" 3
Width: 23.25"
Synergy Seat
®
Adjustable Width: 10"-20"
Adjustable Depth: 10"-20"
2
TRU-Balance ® 2
Adjustable Width: 14"-20"
Adjustable Depth: 14"-20"
Specialty Seat Kit
Contoured Seating
Two-motor, Mid-Wheel 6
®
Two 12 volt, deep cycle
U-1
Up to 15 miles 1
5A, off-board
70A PG VR2
70A, Q-Logic
300 lbs. (user weight)
112 lbs.
24.5 lbs. (each)
Solar Pearl
Yellow Pink
Sapphire Tangerine
Blue
warraNty
(Canada) 888-570-1113
■
Bryan Anderson
Quantum Rehab ® Spokesperson
and Iraq War Veteran
