iACCESS

iAccess
iAccess is a programmable module that can operate a wide
range of functions, (seating, Bluetooth mouse click, etc).
iAccess can be programmed up to 19 functions and have up
to 5 pages programmed.
Figure 13. iAccess Programming Module
iAccess Programming — Single Page Mode
1. Click/Tap on the Mapped I/O icon.
2. Click/Tap on the iAccess button.
The screen will change, showing a picture of the iAccess
module. From here, click and drag or tap the function
(Econ-W) then tap on the iAccess button(s) you wish to pro-
gram that function to (Econ-I).
On Single Page Mode you can use all 4 buttons to program
the iAccess.
3. Make sure you click/tap on the Save icon
2 Buttons
Figure 14. iAccess Single Page Mode
.
Delete
iAccess Programming — Single Page Mode
(HHP)
Program Adjustments/iAccess
1/1
iAcess Configurator
Add to Mx0 x100
Press the left soft key to
change from 1 Button and
2 Button.
Use the + and - keys to
select the function you wish
those buttons to have.
Press the right arrow to
change to the next button
set.
When completed, press the
right soft key twice. Press
the soft key under Save and
the configuration will save.
Figure 15. iAccess Single Page Mode
Program Adjustments
15/15
System
Display
Audio
Battery
Error History
Seat Configuration
Seat Presets
iACCESS
Add to x10 x100
Seat Tilt Up
Seat Tilt Down
2 Buttons Delete
Mode Next
Mode Brochure
iAccess Configuration
Changes in iAccess configuration
successfully saved
Add to Mx0 x100
