ELECTRICAL CONNECTIONS

The gas cooler complies with the safety regulations in force in the European Union and therefore bears the CE mark. The
manufacturer declines all responsibility for damage to persons or property resulting from connection of the gas cooler to an
electrical supply that does not comply with the regulations and legislation in force in the country in which the gas cooler is
installed. In particular, the mains supply to which you connect your gas cooler must be equipped with a high-sensitivity residual
current device (circuit breaker) with an intervention current of no more than 30mA and an earthing system that complies with
current regulations and legislation.
In any case it must be ensured that the characteristics of the mains power supply comply with those of the gas cooler, as shown
in the technical data sheet. If the power cable is damaged, it must be replaced with a new one with similar characteristics. It
is forbidden to attempt to repair it.
When making electrical connections, observe the general rules for the installation, preparation and commissioning of electrical
systems applicable in the country where the appliance is installed. Pay particular attention to the earthing system.
In order to ensure the safety of persons and the appliance, the following rules must be observed.
WARNING: Check that the characteristics of the mains supply are compatible with the technical data of the appliance.
It is forbidden to use extensions, adapters or to splice the cable.
Once you have checked that the characteristics of the electrical system comply with the manufacturer's instructions and
safety standards, proceed as described:
Connect the plug of the supplied electrical cable to your properly protected mains socket.

TEMPERATURE SETTING

The temperature of the water supplied by the appliance can be adjusted
(depending on the ambient temperature and the temperature of the
water to be treated) by means of an ADJUSTABLE THERMOSTAT positioned
according to the model, also inside the technical compartment of the
appliance.
CO PRESSURE REGULATION
After opening the CO cylinder completely and checking that there are no leaks, use a screwdriver to turn the adjustment screw
or the handwheel depending on the model of CO pressure reducer until the pressure gauge reads 3.5–4.0 bar.
It is advisable not to exceed these values; lower values result in proportionally lighter carbonation.
The pressure reducer is not included in the equipment.

USE OF EQUIPMENT

FIRST START FILLING BATHTUB (with machine not running and electrical plug disconnected):
WARNING: The appliance's tank must be filled with clean, fresh water.
The appliance cannot be operated with an empty tank. Do not use other liquids or additives for filling.
Before connecting the machine to the water mains, the tank containing the ice bank must be filled. Fill the tank, taking care not
to get the electrical parts wet. Fill the tank with water either through the opening behind the front panel or at the rear of the
machine by removing the rear panel.
Fill the tank until the water starts to flow out of the overflow pipe whose connection is located behind the machine.
Top opening for filling water into the tank. (top cover)
The machine is equipped with a discharge connection for the overflow from the ice bank tank. Outgoing water must be
channelled directly into the sewage system or collected in a container placed near the machine.
Drain connection
After all connections have been made, the appliance is started up. After start-up, the
appliance switches off automatically when the formation of the internal ice bank is
complete or when the set temperature is reached.
Caution! The absence of ice eliminates the refrigeration stock and lowers the
carbonation level of the water. The maximum noise level of the appliance, if installed
correctly, is less than 70 dB.
After the compressor has stopped for the first time the unit is ready to operate.
WARNING: Do not stop operation of the appliance at night.
Frost can damage the appliance if left idle and with a full tank at temperatures
below 0 °C.
Do not expose CO2 cylinders to high temperatures (in the sun) or too low
temperatures (in cold rooms).
1 0 G E N E R A L I N S T R U C T I O N S (all models)
BWT AQA DRINK maxi pressure reducer with
double pressure gauge
