3.3.8 SIM Card Socket (SCN2)

The system has SCN2 socket on the bottom side for inserting SIM Card. In order to work
properly, the SIM Card must be used together with 3G/LTE module which is inserted to SCN1
or SCN3. It is mainly used in 3G/LTE wireless network application.
Pin Signal
1 PWR
2 RST
3 CLK
4 NC
5 GND
6 VPP
7 I/O
8 NC
Jumper Setting & Connector
