Table 9.4 Belt drive split system evaporator or chilled water electrical data, 50Hz (continued)
Base Evaporator Model Number
FLA
with Electric Reheat and Humidifier
FLA
with SCR Reheat and Humidifier
FLA
* Specify disconnect or no disconnect
Notes:
1. Belt drive data includes externally mounted high static blower box, powered from unit.
2. Use MM*35E electrical data for MM*39C chilled water units.
3. For units with Hot Water Reheat (available only on MM*39C units), use appropriate values from "Cooling only" or "with
Humidifier" categories.
4. Use MM*35E for MM*35K, except with SCR reheat.
5. SCR Reheat not available with MM*35K or MM*39C.
Table 9.5 Indoor condensing unit electrical data, 60 and 50Hz
60Hz
Model
208/230-1ph-60Hz
MC*24A
FLA 14.3
WSA 17.3
OPD 25
MC*36A
FLA 20.8
WSA 25.1
OPD 40
MC*26W
FLA 12.0
WSA 15.0
OPD 25
MC*38W
FLA 17.1
WSA 21.4
OPD 35
* Specify disconnect or no disconnect
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual |
220 - 1 Ph - 50Hz
MM*35E
13.4
38.4
5
55.1
277-1ph-60Hz 208/230-3ph-60Hz
MC*24A MC*24A
12.7 —
15.3 —
25 —
MC*36A MC*36A
16.6 15.7
20.2 18.7
30 30
MC*26W MC*26W
10.4 —
13.0 —
20 —
MC*38W MC*38W
14.3 12.0
17.9 15.0
30 25
380/415 - 3 Ph - 50Hz
MM*35E
6.3
16.0
20.2
50Hz
460-3ph-60Hz 220-1ph-50Hz
MC*24A —
— 13.2
— —
— N/A
MC*36A MC*35A
7.8 20.1
9.4 —
15 —
MC*26W —
— —
— —
— —
MC*38W MC*37W
6.4 17.1
8.0 —
15 —
380/415-3ph-50Hz
—
5.7
—
N/A
MC*35A
7.8
—
—
—
—
—
—
MC*37W
6.4
—
—
