Vertiv Liebert Mini-Mate2 MMD24E Technical Data Manual page 47

Table 9.3 Direct drive split system evaporator or chilled water electrical data, 50Hz
Base Evaporator Model Number
Cooling Only
FLA
with Electric Reheat
FLA
4
with SCR Reheat
FLA
with Humidifier
FLA
with Electric Reheat and Humidifier
FLA
with SCR Reheat and Humidifier
FLA
* Specify disconnect or no disconnect
Notes:
1. Use MM*35E electrical data for MM*39C chilled water units.
2. For units with Hot Water Reheat (available only on MM*39C units), use appropriate values from "Cooling only" or "with
Humidifier" categories.
3. Use MM*35E for MM*35K, except with SCR reheat.
4. SCR Reheat not available with MM*35K or MM*39C.
Table 9.4 Belt drive split system evaporator or chilled water electrical data, 50Hz
Base Evaporator Model Number
Cooling Only
FLA
with Electric Reheat
FLA
5
with SCR Reheat
FLA
with Humidifier
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual |
220 - 1Ph - 50Hz
MM*35E
2.8
27.8
44.6
9.2
34.2
4
50.9
220 - 1 Ph - 50Hz
MM*35E
7.0
32.0
48.7
380/415 - 3Ph-50Hz
MM*35E
1.4
11.1
15.3
5.1
14.8
19.0
380/415 - 3 Ph - 50Hz
MM*35E
2.6
12.3
16.5
47
