Vertiv Liebert Mini-Mate2 MMD24E Technical Data Manual page 40

Table 8.1 Chilled water data, 60 and 50Hz (continued)
CW Model, 50 & 60Hz
2 2
Face Area ft (m )
Coil Rows
HWRH supply and return connections, in (mm) OD
Humidifier Data - Steam Generator Type
Steam capacity - lbs/hr (kg/hr)
Electrical Input Power, kW
Unit Connection Sizes
CW supply and return connections, in (mm) OD
Humidifier Supply
Evaporator/Condensate Drain
Unit Internal Fluid Volume, gal (l)
MERV 8 Filter, External Filter Box, qty (1), Nom. Size, in. (mm)
MERV 8 Filter, Air Distribution Plenum, qty (1), Nom. Size, in. (mm)
Unit Operating Weight
Unit Valve Types
Valve Size
Valve Cv
Max. Static Operating Pressure, psi (kPa)
Close-Off Pressure, psi (kPa)
The net capacity data has fan motor heat factored in for all ratings and the entering air conditions of 75°F (23.9°C), 45%RH, is the standard rating
condition for ASHRAE 127-2007. All capacities are nominal values; actual performance will be ±5%.
Table 8.2 Capacity Correction Factors
(based on 10°F (5.6°C) water rise)
72°F (22.2°C) /50%
EWT
TCC
42°F (5.6°C) 1.25
43°F (6.1°C) 1.15
44°F (6.7°C) 1.07
45°F (7.2°C) 1.00
46°F (7.8°C) 0.92
47°F (8.3°C) 0.85
48°F (8.9°C) 0.78
49°F (9.4°C) 0.74
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual |
75°F (23.9°C) /45%RH
SCC TCC SCC
1.13 1.23 1.12
1.09 1.14 1.08
1.04 1.07 1.04
1.00 1.00 1.00
0.96 0.94 0.96
0.91 0.87 0.92
0.85 0.82 0.88
0.81 0.77 0.83
MMD40C/MMD39C
3.1 (0.29)
1
5/8 (15.9)
4.3 (2.0)
1.5
7/8 (22.2)
1/4" OD Copper Compression Fitting
3/4" NPT-Female
2.0 (7.6)
4x20x20 (102x508x508)
4x16x25 (102x406x635)
230 (104)
On/Off Slow Close: 2- & 3-Way
1"
7.0
300 (2068)
60 (414)
40
