Table 6.2 Air-cooled data, 50Hz (continued)
Evaporator Model
Condensing Unit Type
75°F DB, 61°F WB (23.9°C DB,
16.1°C WB) 45%RH
72°F DB, 60°F WB (22.2°C DB,
15.5°C WB) 50%RH
Fan Data - Evaporator
CFM (CMH) - High Speed
CFM (CMH) - Low Speed
Fan Motor HP (W)
External Static Pressure, in (mm) water gauge
Evaporator Coil - Copper Tube/Aluminum Fin
2 2
Face Area, ft (m )
Coil Rows
Max Face Velocity, fmp (m/s)
Unit Refrigerant Charge, oz. (kg)
Unit Operating Weight, lb (kg)
Electric Reheat Capacity (Includes Fan Motor)-kW (Btuh)
Input Voltage 220-1-50
Input Voltage 380-3-50
SCR Reheat Capacity (Includes Fan Motor)-kW (Btuh)
Input Voltage 220-1-50
Input Voltage 380-3-50
Humidifier Data - Steam Generator Type
Steam capacity lb/hr (kg/hr)
Electrical Input Power, kW
Evaporator Connection Sizes
Liquid line Diameter - Aeroquip Coupling Size
Suction Line Diameter - Aeroquip Coupling Size
Humidifier Supply
Evaporator/Condensate Drain
MERV 8 Filter, External Filter Box, qty (1), Nom. Size, in. (mm)
MERV 8 Filter, Air Distribution Plenum, qty (1), Nom. Size, in. (mm)
Condensing Unit Model Number
Condensing Unit Rating Conditions
2 2
Coil Face Area, ft (m )
Rows of Coil
CMF (CMH)
Motor, Hp (W)
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual |
Total
Sensible
Total
Sensible
MMD35E or MMD35K
PFH - Outdoor
9.60 (32,700)
8.35 (28,500)
9.35 (31,900)
7.70 (26,200)
1250 (2124)
1000 (1699)
0.5 (0.38)
0.3 (8)
3.1 (0.29)
3
394 (2.0)
7 (0.20)
225 (102)
5.3 (18090)
7.3 (24900)
8.7 (29700)
10.3 (35100)
4.3 (2.0)
1.5
3/8" - #6 Female
7/8" - #11 Female
1/4" OD Copper Compression Fitting
3/4" NPT-Female
4x20x20 (102x508x508)
4x16x25 (102x406x635)
PFH036A-_L7
95°F (35°C) Ambient
7.7 (0.72)
2
2500 (4248)
0.20 (149)
MCD - Indoor
9.10 (31,100)
8.15 (27,800)
8.90 (30,400)
7.45 (25,500)
MCD35AL_H7
4.6 (0.43)
3
1430 (2429)
0.5 (373)
