Table 7.2 Water/glycol data, 50Hz (continued)
Evaporator Model
Condensing Unit Fluid
Flow Rate, GPM (l/m)
Pressure Drop, ft. of H20 (kPa)
Water-Cooled Condensing Temperature
Connection Sizes, in. (mm) OD
Unit Volume, Gal (l)
Unit Refrigerant Charge, oz. (kg)
Unit Operating Weight, lb. (kg)
Free-Cooling Coil Option Net Capacity Data - kW (Btuh) using 45°F EWT
Entering Fluid Conditions
80°F DB, 62.8°F WB (26.7°C DB,
17.1°C WB) 38%RH
75°F DB, 61°F WB (23.9°C DB,
16.1°C WB) 45%RH
72°F DB, 60°F WB (22.2°C DB,
15.5°C WB) 50%RH
Flow Rate - GPM (l/m)
Pressure Drop - ft. water (kPa)
Free-Cooling Coil - Copper Tube/Aluminum Fin
2 2
Face Area, ft (m )
Coil Rows
Max Face Velocity, fpm (m/s)
Internal Fluid Volume, gal (l)
Water supply and return connections, in (mm) OD
The net capacity data has fan motor heat factored in for all ratings and the entering air conditions of 75°F (23.9°C), 45%RH, is the standard rating
condition for ASHRAE 127-2007. All capacities are nominal values; actual performance will be ± 5%.
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual |
Total
Sensible
Total
Sensible
Total
Sensible
MMD35E or MMD35K
Water-Cooled
6.6 (25.0)
11.9 (35.6)
105°F (40.6°C)
7/8 (22.2)
1.2 (4.5)
54 (1.54)
220 (100)
45°F (29.4°C) EWT
9.50 (32,400)
9.05 (30,800)
8.20 (28,000)
7.60 (25,900)
7.45 (25,400)
6.70 (22,900)
5.9 (22.4)
9.1 (27.2)
3.1 (0.28)
3
394 (2.0)
2.0 (7.6)
7/8 (22.2)
Glycol-Cooled
11.9 (45.1)
43.2 (129.2)
N/A
45°F EGT - 40% PG
8.25 (28,000)
8.25 (28,000)
7.00 (23,800)
7.00 (23,800)
6.30 (21,500)
6.30 (21,500)
11.9 (45.1)
44.3 (132.5)
