Figure 9.1 Single-point power kit - optional
Table 9.7 Electrical data, 60Hz air-cooled systems using single-point power kit, evaporator with
direct-drive blowers and indoor condensing unit
Base Evaporator Model Number
Condensing Unit Model Number
Cooling Only
FLA
WSA
OPD
with Electric Reheat
FLA
WSA
OPD
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual |
208/230 - 1 Ph - 60Hz 277 - 1 Ph - 60Hz
MM*24E MM*36E MM*24E
MC*24A MC*36A MC*24A
17.1 23.6 15.0
20.1 27.9 17.6
30 40 25
42.1 48.6 36.7
51.4 59.1 44.7
60 60 45
208/230 - 3 Ph - 60Hz
MM*36E MM*24E MM*36E
MC*36A MC*24A MC*36A
18.9 — 18.5
22.5 — 21.5
35 — 30
40.6 — 35.3
49.6 — 42.5
50 — 50
460 - 3 Ph - 60Hz
MM*24E MM*36E
MC*24A MC*36A
— 9.2
— 10.8
— 15
— 17.6
— 21.3
— 25
