  • Page 1 GV-IP Camera User's Manual GV-EBD Series GV-ABL / TBL Series GV-ADR / TDR Series GV-AVD / TVD Series Before attempting to connect or operate this product, UBN-UM-O please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Preface Welcome to the GV-EBD Series IR Eyeball IP Dome, GV-ABL Series Bullet IP Camera, GV-ADR / TDR Series Mini Fixed Rugged IP Dome and GV-AVD Series Vandal Proof IP Camera User’s Manual. This Manual is designed for the following models: Model Model Number GV-EBD2702...

  • Page 4: Table Of Contents

    Contents Naming Definition..............vi Note for Connecting to GV-VMS / DVR / NVR ......vii Note for Installing Camera Outdoor ........vii Note for Powering the Camera ..........vii Note for Face Detection ............viii Note for People Counting ............ix Chapter 1 Introduction ............1 1.1 GV-EBD Series...................... 1 1.1.1 Packing List....................
  • Page 5 1.2.5.3 GV-Mount420 + GV-Mount503 ............39 1.3 GV-ADR / TDR Series ..................41 1.3.1 Packing List....................42 1.3.2 Optional Accessories ................43 1.3.3 Overview....................45 1.3.4 Installation....................46 1.3.5 Optional Installation ...................49 1.3.5.1 GV-Mount211P ..................49 1.4 GV-AVD / TVD Series...................53 1.4.1 Packing List....................54 1.4.2 Optional Accessories ................55 1.4.3 Overview....................57 1.4.4 Installation....................58 1.4.5 Optional Installation...................60...
  • Page 6 Chapter 3 Administrator Mode ...........80 3.1 Common .......................80 3.1.1 Basic Info ....................80 3.1.2 Local Settings ...................81 3.2 Network ........................83 3.2.1 Ethernet ....................83 3.2.2 DNS ......................84 3.2.3 Port ......................85 3.2.4 DDNS......................86 3.2.5 E-mail......................88 3.2.6 SNMP .......................89 3.2.7 802.1x .......................90 3.2.8 QoS ......................91 3.3 Video &...
  • Page 7 Events ........................118 3.6.1 Motion Detection ..................118 3.6.2 Tampering Alarm ..................120 3.6.3 Audio Detection..................121 3.6.4 Alarm Input....................122 3.6.5 Alarm Output...................123 3.7 Storage .......................124 3.7.1 Storage ....................124 3.7.2 FTP .......................126 3.8 Security.......................127 3.8.1 User ......................127 3.8.2 Network Security..................128 3.9 System........................131 3.9.1 Time......................131 3.9.2 Maintenance ...................133 Chapter 4 Advanced Applications ........134 4.1 Upgrading System Firmware................134...

  • Page 8: Naming Definition

    Naming Definition GV-DVR / NVR GeoVision Analog and Digital Video Recording Software. The GV- DVR also refers to GV-Multicam System or GV-Hybrid DVR. GV-VMS GeoVision Video Management System for IP cameras.

  • Page 9: Note For Connecting To Gv-Vms / Dvr / Nvr

    Note for Connecting to GV-VMS / DVR / NVR The GV-IPCAM in this Manual is designed to work with and record on GV-VMS / DVR / NVR, a video management system.  Once the camera is connected to the GV-VMS / DVR / NVR, the resolution set on the GV-VMS / DVR / NVR will override the resolution set on the camera’s Web interface.

  • Page 10: Note For Face Detection

    GV-ABL2701 series / 2703 series / 4701 series / 4703, GV-ADR2701 / 2702 / 4701 / 4702, GV-TBL series, GV-TDR2702 / 4702 and GV-TVD series, it is recommended to install the camera according to the criteria listed below: Surveillance Condition ...

  • Page 11: Note For People Counting

    GV-ABL2701 series / 2703 series / 4701 series / 4703, GV-ADR2701 / 2702 / 4701 / 4702, GV-TBL series, GV-TDR2702 / 4702 and GV-TVD series, it is recommended to install the camera according to the criteria listed below: Surveillance Condition ...

  • Page 12: Chapter 1 Introduction

    Introduction Chapter 1 Introduction 1.1 GV-EBD Series The H.265 Target Eyeball Dome is an outdoor, network camera equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. The camera adheres to IP67 standards for dust / water protection and supports H.265 video codec to achieve better compression ratio while maintaining high quality image at reduced network bandwidths.

  • Page 13: Packing List

    1.1.1 Packing List  H.265 Target Eyeball Dome   Screw Kit Drill Template Paster   Waterproof Rubber Set Download Guide  Warranty Card 1.1.2 Optional Accessories Optional accessories can expand the capabilities and versatility of your camera. Contact your dealer for more information.
  • Page 14 Introduction Dimensions: 137 x 233 x 160 mm GV-Mount300-2 Convex Corner Mount (5.4” x 9.17” x 6.3”) Weight: 1.65 kg (3.64 lb) GV-Mount310-2 Concave Corner Mount Dimensions: 111.2 x 369.9 x 210 mm (2.6” x 11.4” x 6.6”) Weight: 1.65 kg (3.64 lb) GV-Mount420 Pole Mount Bracket Dimensions: Ø...

  • Page 15: Overview

    1.1.3 Overview 1.1.3.1 GV-EBD2702 / 4700 / 8700 Figure 1-1 Description Bottom ring Housing Lens Infrared indicator Power connector (DC 12 V) Ethernet connector / PoE...

  • Page 16: Gv-Ebd4711 / 8711

    Introduction 1.1.3.2 GV-EBD4711 / 8711 Figure 1-2 Description Bottom ring Housing Microphone Lens Power connector (DC 12 V) Ethernet connector / PoE Micro SD card slot and default button compartment Default button Micro SD card slot Note: If the default button doesn’t respond after pressing for 15 seconds, reboot the camera and try again within 10 minutes of rebooting.

  • Page 17: Installation

    1.1.4 Installation The Target Eyeball Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Alternatively, you can purchase optional mounting accessories to mount the dome on a wall. Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount: Concealed Installation and Open Installation.
  • Page 18 Introduction 3. Remove the bottom ring by turning it anticlockwise. Figure 1-5 4. Connect the cables and secure the camera. Figure 1-6 5. Adjust the monitoring direction. Figure 1-7...
  • Page 19 6. Mount the bottom ring. Figure 1-8 For Open Installation Lead the cables out from the open slot on the bottom ring before screwing the camera to the ceiling as shown in Figure 1-6.   Figure 1-9...

  • Page 20: Gv-Ebd4711 / 8711 Standard Installation

    Introduction 1.1.4.2 GV-EBD4711 / 8711 Standard Installation For Concealed Installation 1. Stick the drill template paster to the ceiling and drill three holes according to the drill template. Figure 1-10 2. Insert the screw anchors.   Figure 1-11 3. Loosen the fixing screw and remove the housing by turning it to the position as shown. Figure 1-12...
  • Page 21 4. Secure the bottom ring to the ceiling with 3 supplied screws and connect the cable. Figure 1-13 5. Mount the housing by adjusting to the position as shown and press and turn to anywhere but . Figure 1-14 6. Adjust the monitoring direction. Then tighten the screw. Figure 1-15...
  • Page 22 Introduction WARNING: Make sure the housing is not dismounted from the bottom ring when adjusting the monitoring direction. Unintentional removal of the housing may result in circumstantial damages. For Open Installation Lead the cables out from the open slot on the bottom ring before mounting the housing as shown in Figure 1-14.

  • Page 23: Optional Installation

    1.1.5 Optional Installation You can optionally purchase the following accessories to fit your mounting environment: GV-Mount211P / GV-Mount212P for Wall Box Mount: see section 1.1.5.1 and 1.1.5.2.  GV-Mount420 + GV-Mount211P for Pole Box Mount: see section 1.1.5.3.  GV-Mount212P + GV-Mount107 for Pendant Tube Mount: see section 1.1.5.4. ...
  • Page 24 Introduction Unscrew the bracket. Figure 1-18 Loosen the indicated area by turning it anticlockwise. Figure 1-19 Stick the drill template paster to the wall with the arrow pointing up. Drill 4 holes according to the sticker and insert the 4 screw anchors to the 4 holes. Secure the power box to the wall with 4 long screws Figure 1-20...
  • Page 25 Remove the bottom ring by turning it anticlockwise. Figure 1-21 Secure the camera to the wall mount bracket with the provided short screws according to the screw position for each model: GV-EBD4700 / 4711 / 8700 / 8711 Figure 1-22...
  • Page 26 Introduction GV-EBD2702 Figure 1-23 GV-ADR2701 / 4701 Figure 1-24 GV-ADR2702 / ADR4702 / TDR2700 / TDR2702 / TDR4700 / TDR4702 Figure 1-25...
  • Page 27 Thread the Ethernet cable through the PG21 conduit connector and the power box as shown in No. 8, Figure 1-26. Then connect the cable to the camera. To waterproof the cable, see 1.6 Waterproofing the Cable. Rotate the plastic ring to secure the conduit connector to the power box. Screw in the cap as shown in No.

  • Page 28: Gv-Mount212P

    Introduction 1.1.5.2 GV-Mount212P GV-Mount212P Figure 1-28 GV-Mount212P Packing List   GV-Mount212P Long Screw x 3   Short Screw x 3 Screw Anchor x 3...
  • Page 29 Standard Installation Attach the wall box to the wall and use a marker to mark the location for the center socket and the screws. Make sure the knob points down. Long Screw This knob points down Figure 1-29 Drill 3 holes according to the screw location. Then, drill a bigger hole at the center socket location for the Ethernet cable.
  • Page 30 Introduction Thread the Ethernet cable through the center socket and waterproof the Ethernet cable. For details, see 1.6 Waterproofing the Cable. Figure 1-31 Fit the cable into the wall box. Secure the camera by locking the provided short screws to the screw position for each model: GV-EBD2702 Figure 1-32...
  • Page 31 Note: In addition to the Standard Installation, you can also choose to run the Ethernet cable through a corrugated tube. To do this, you will have to purchase your own conduit connector and corrugated tube. 3/4” NPS is the recommended type of connector. After you secure the wall box to the desired location, remove the knob at the bottom and connect the conduit connector with a self-prepared corrugated tube to the wall box.

  • Page 32: Gv-Mount420 + Gv-Mount211P

    Introduction 1.1.5.3 GV-Mount420 + GV-Mount211P Figure 1-35 GV-Mount420 Packing List   GV-Mount420 M4 Screw x 4  Additional Screw Kit M6 Screw x 4 M6 Nut x 4 M6 Plain Washer x 4 M6 Split Washer x 4 Note: For GV-ADR / TDR / EBD Series, GV-Mount420 can only be used in conjunction with GV-Mount211P.
  • Page 33 1. Unscrew the bracket. Figure 1-36 2. Loosen the indic ated area by t urning it anticlockwise. Figure 1-37 3. Align and attach the p ower box to the back plate using the 4 supplied M4 screws as indicated. Figure 1-38 ote: Make sure the direction of the “up ↑”...
  • Page 34 Introduction . Thread the 3 steel straps onto the back plate. Figure 1-39 5. Follow Step 6 ~ 12 in 1.1.5. 1 GV-Mount211P. 6. Secure the camera onto the desired pole by tig htening the steel straps.

  • Page 35: Gv-Mount212P + Gv-Mount107

    1.1.5.4 GV-Mount212P + GV-Mount107 GV- Mount107 GV- Mount212P Figure 1-40 GV-Mount107 Packing List   Pendant Bracket Pendant Tube   Tube Connector Torx Wrench Note: Before installing GV-Mount107, note the following.  Install your GV-EBD Series camera on a GV-Mount212P by cutting a hole in the center of the mount and thread the camera wires through.
  • Page 36 Introduction Place GV-Mount107 on the ceiling and mark the location for the center socket and the 3 screws. Drill the marks and secure the Pendant Bracket onto the ceiling. Figure 1-41 Attach one end of the Pendant Tube to the Pendant Bracket, and the other end to the Tube Connector.

  • Page 37: Gv-Abl / Tbl Series

    1.2 GV-ABL / TBL Series The Bullet IP Camera is an outdoor, fixed, network camera equipped with an automatic IR- cut filter and an IR LED for day and night surveillance. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality image at reduced network bandwidths.

  • Page 38: Packing List

    Introduction Model No. Specifications Description 4 MP, H.265 GV-ABL4712 Low Lux, WDR Pro Motorized Fixed Iris, f: 2.8~12 mm, F/1.4, varifocal lens Ø14 mm Lens Mount 8 MP, H.265 GV-ABL8712 Super Low Lux, WDR Pro Fixed Iris, f: 4.0 mm, F/2.0, 2 MP, H.265 Low GV-TBL2703-0F M12 Lens Mount...

  • Page 39: Optional Accessories

    1.2.2 Optional Accessories Optional accessories can expand the capabilities and versatility of your camera. Contact your dealer for more information. Model Number Name Details GV-Mount502 (for GV- Wall Mount Bracket Dimensions: 93 x 93 x 39 mm ABL2701 Series / 2703 (3.66”...

  • Page 40: Overview

    Introduction 1.2.3 Overview 1.2.3.1 GV-ABL2701 / 2703 / 4701 / 4703 & TBL2703 / 4703 Figure 1-43 No. Description No. Description Power connector (DC 12 V) Ethernet connector / PoE Load Default Button (for GV-ABL2703 / 4703 & TBL2703 / 4703 only) Figure 1-44 No.

  • Page 41: Gv-Abl2702 / 4712 / 8712 & Tbl4710 / 8710

    1.2.3.2 GV-ABL2702 / 4712 / 8712 & TBL4710 / 8710 Figure 1-45 Description Power connector (DC 12 V) Audio input / Audio output / GND Alarm input (IN, GND) / Alarm output (N,P) Ethernet connector / PoE Video Output (GV-ABL8712 / TBL8710 Only)

  • Page 42: Installation

    Introduction 1.2.4 Installation The Bullet IP Camera is designed for outdoors. With the standard package, you can install the camera on the wall or ceiling. Or, you can purchase optional mounting accessories to mount your camera on a wall. Below are the instructions for Wall Mount. There are two kinds of Wall Mount: Concealed Installation and Open Installation.
  • Page 43 Drill four 30-mm deep holes according to the drill template. Figure 1-48 Insert the screw anchors. Figure 1-49 Screw the locknut and loosen the universal joint before attaching the camera to the wall. Figure 1-50...
  • Page 44 Introduction Secure the camera to the wall and connect all cables. Lead tapping screws through  the guide holes in the base  and fix them on the wall by  using a screwdriver. Figure 1-51 Adjust the monitoring direction. Figure 1-52 For Open Installation Lead the cables out from the open slot on the base before screwing the camera to the wall as shown in Figure 1-51.

  • Page 45: Optional Installation

    1.2.5 Optional Installation For GV-ABL2701 Series / 2703 Series / 4701 Series / 4703 & TBL2703 Series / 4703, you can optionally purchase the following accessories to fit your mounting environment: GV-Mount502 for Wall Box Mount: see section 1.2.5.1.  For GV-ABL2702 / 4712 / 8712 / TBL Series, you can optionally purchase: GV-Mount503 for Wall Box Mount: see section 1.2.5.2.

  • Page 46: Gv-Mount502

    Introduction 1.2.5.1 GV-Mount502 GV-Mount502 Packing List   GV-Mount502 M3 25 mm Screw x 4   M3 12 mm Screw x 4 Screw Anchor x 4  Plastic PG21 Conduit Connector 1. Unscrew the box cover. Figure 1-56...
  • Page 47 2. Loosen the knob by turning it anticlockwise. Figure 1-57 3. Attach the box to the wall with the knob pointing down and use a marker to mark 4 dots. 4. Drill 4 holes according to the marks. 5. Insert the 4 screw anchors to the holes and secure the box to the wall with 4 long screws. 6.

  • Page 48: Gv-Mount503

    Introduction 1.2.5.2 GV-Mount503 GV-Mount503 Packing List   GV-Mount503 Long Screw x 4   Short Screw x 4 Screw Anchor x 4  Waterproof Rubber Plug Plastic PG21 Conduit Connector  1. 1. Unscrew the box cover. Figure 1-59...
  • Page 49 2. Loosen the knobs by turning it anticlockwise. Figure 1-60 3. Attach the box to the wall with the knobs pointing down and use a marker to mark 4 dots. 4. Drill 4 holes according to the marks. 5. Insert 4 screw anchors to the holes and secure the to the wall with 4 long screws. 6.

  • Page 50: Gv-Mount420 + Gv-Mount503

    Introduction 1.2.5.3 GV-Mount420 + GV-Mount503 GV-Mount420 Packing List   GV-Mount420 M4 Screw x 4  Additional Screw Kit M6 Screw x 4 M6 Nut x 4 M6 Plain Washer x 4 M6 Split Washer x 4 Note: For GV-ABL2702 / 4712 / 8712 and TBL Series, GV-Mount420 can only be used in conjunction with GV-Mount503.
  • Page 51 3. Thread the 3 steel straps onto the back plate. Figure 1-63 4. Follow Step 6 ~ 10 in 1.2.5.2 GV-Mount503. 5. Secure the camera onto the desired pole by tightening the steel straps.

  • Page 52: Gv-Adr / Tdr Series

    Introduction 1.3 GV-ADR / TDR Series The IR Mini Fixed Rugged IP Dome is an outdoor, fixed, network camera equipped with an automatic IR-cut filter and an IR LED for day and night surveillance. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality image at reduced network bandwidths.

  • Page 53: Packing List

    Fixed Iris, f: 4 mm, 2 MP, H.265, Low GV-TDR2702-1F Lux, WDR F/2.0, M12 Lens Mount Fixed Iris, f: 2.8 mm, GV-TDR4700-0F F/2.0, M12 Lens Mount 4 MP, H.265, Low Lux, WDR Pro Fixed Iris, f: 3.6 mm, Fixed lens GV-TDR4700-1F F/2.0, M12 Lens Mount Fixed Iris, f: 2.8 mm,...

  • Page 54: Optional Accessories

    Introduction 1.3.2 Optional Accessories Optional accessories can expand the capabilities and versatility of your camera. Contact your dealer for more information. Model Number Name Details GV-Mount107 Pendant Bracket Dimensions: Ø 120 x 334 mm (Ø (must be used with 4.72” x 13.15”) GV-Mount213) Weight: 0.74 kg (1.63 lb) GV-Mount211P...
  • Page 55 Power over Ethernet (PoE) GV-PA191 is a Power over Ethernet GV-PA191 Adapter (PoE) adapter designed to provide power to the IP device through a single Ethernet cable. GV-POE Switch GV-POE Switch is designed to provide power along with network connection for IP devices. GV-POE Switch is available in various models with different numbers and types of ports.

  • Page 56: Overview

    Introduction 1.3.3 Overview Figure 1-64 Description Ethernet connector / PoE Power connector (DC 12 V) Transparent Dome Cover For GV-TDR2700 / 4700 only, see the table below. Wire Definition Wire Definition Green Audio in Blue Yellow Alarm Out White Alarm Out Orange Alarm Input Blue...

  • Page 57: Installation

    1.3.4 Installation The IR Mini Fixed Rugged IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount: Concealed Installation and Open Installation. In Concealed Installation, the cables are hidden in the ceiling.
  • Page 58 Introduction Unscrew the transparent dome cover with the supplied torx wrench. Connect the cables and secure the camera. Figure 1-67 Adjust the monitoring direction and tighten the screws after vertically adjusting the lens. Figure 1-68...
  • Page 59 Secure the transparent dome cover with the supplied torx wrench. Figure 1-69 Note: Before securing the transparent dome cover, make sure the waterproof rubber strip is tightly held by the six retainers on the bottom ring. Figure 1-70 For Open Installation Lead the cables out from the open slot on the camera base before screwing the camera to the ceiling as shown in Figure 1-67.

  • Page 60: Optional Installation

    Introduction 1.3.5 Optional Installation You can optionally purchase the following accessories to fit your mounting environment: GV-Mount211P for Wall Mount: see section 1.1.5.1.  GV-Mount213 for Wall / Ceiling Box Mount: see section 1.3.5.1  GV-Mount420 + GV-Mount211P for Pole Box Mount: see section 1.1.5.3. ...
  • Page 61 1. Attach the GV-Mount213 to the wall / ceiling and use a marker to mark the location for the center socket and the 3 screws. Figure 1-72 Note: To prevent rain from getting into GV-ADR2701 / 2702 / 4701 / 4702 & TDR2702 / 4702, ...
  • Page 62 Introduction 3. Insert 3 screw anchors to the screw locations and secure the GV-Mount213 to the wall / ceiling with 3 long screws. 4. Thread the Ethernet cable through the center socket and waterproof the Ethernet cable. For details, see 1.6 Waterproofing the Cable. Figure 1-74 5.
  • Page 63 GV-ADR2702 / ADR4702 / TDR2700 / TDR2702 / TDR4700 / TDR4702 Figure 1-76 7. Secure the camera cover. Note: In addition to the Standard Installation, you can also choose to run the Ethernet cable through a corrugated tube. To do this, see Figure 1-34 and its related Note.

  • Page 64: Gv-Avd / Tvd Series

    Introduction 1.4 GV-AVD / TVD Series The Vandal Proof IP Dome is an outdoor camera designed with IK10 vandal resistance and IP67 ingress protection. The camera is equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. Adjustable in 3 axes (pan, tilt and rotate), it offers an entry- level surveillance solution with all the essential features and excellent image quality.

  • Page 65: Packing List

    1.4.1 Packing List  IR Vandal Proof IP Dome  Waterproof Rubber Set   Screw Kit Drill Template Paster   Torx Wrench Download Guide  Warranty Card...

  • Page 66: Optional Accessories

    Introduction 1.4.2 Optional Accessories Optional accessories can expand the capabilities and versatility of your camera. Contact your dealer for more information. Model Number Name Details GV-Mount107 Dimensions: Ø 120 x 334 mm (Ø Pendant Bracket (must be used with 4.72” x 13.15”) GV-Mount212-2) Weight: 0.74 kg (1.63 lb) GV-Mount211-2...
  • Page 67 GV-Mount704 Dimensions: Ø 3.5 x 10 or 20 or 30 Extension Tube (must be used with or 50 cm (Ø 1.38 x 3.9 or 7.9 or GV-Mount107) 11.8 or 19.7”) Weight: 225g or 360g or 500g or 780g (0.5 lb or 0.79 lb or 1.1 lb or 1.72 lb) Power over Ethernet (PoE) GV-PA191 is a Power over...

  • Page 68: Overview

    Introduction 1.4.3 Overview Figure 1-77 Description Power connector (DC 12 V) Ethernet connector / PoE Video output Audio input / Audio output / GND Alarm input (IN,GND) / Alarm output (N,P) Default button Micro SD card slot Note: If the default button doesn’t respond after pressing for 15 seconds, reboot the camera and try again within 10 minutes of rebooting.

  • Page 69: Installation

    1.4.4 Installation The Target Vandal Proof Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Alternatively, you can purchase optional mounting accessories to mount the camera on a wall. Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount: Concealed Installation and Open Installation.
  • Page 70 Introduction 4. Connect the camera cables and secure the camera. Figure 1-80 5. Insert a SD card into the slot. 6. Adjust the monitoring direction and tighten the screws after vertically adjusting the lens. Figure 1-81 7. Secure the transparent dom e cover with the supplied torx wrench.

  • Page 71: Optional Installation

    1.4.5 Optional Installation You can optionally purchase the following accessories to fit your mounting environment: GV-Mount211-2 for Wall Mount: see section 1.4.5.1.  GV-Mount212-2 for Wall / Ceiling Box Mount: see section 1.4.5.2.  GV-Mount420 + GV-Mount211-2 for Pole Box Mount: see section 1.4.5.3. ...
  • Page 72 Introduction 1. To install the power box from the wall mount bracket on the wall, follow steps 1 to 5 in 1.1.5.1 GV-Mount211P. 2. Unscrew the transparent dome cover with the supplied torx wrench. Figure 1-83 3. Optionally insert a SD card into the slot. 4.
  • Page 73 6. Thread the Ethernet cable through the PG21 conduit connector and the power box, as shown in No 6, Figure 1-85. Then connect the cable to the camera. 7. Rotate the plastic ring to secure the conduit connector to the power box. Screw in the cap shown in No 7, Figure 1-85.

  • Page 74: Gv-Mount212-2

    Introduction 1.4.5.2 GV-Mount212-2 GV-Mount212-2 Figure 1-86 GV-Mount212-2 Packing List   GV-Mount212-2 Long Screw x 3   Short Screw x 3 Screw Anchor x 3...
  • Page 75 1. Attach the ceiling box to the ceiling and use a marker to mark the location for the center socket and the screws. Make sure the knob points inwards. Figure 1-87 2. Drill 3 holes according to the screw location. Then, drill a bigger hole at the center socket location for the Ethernet cable.
  • Page 76 Introduction 6. Secure the camera to the ceiling box. Figure 1-89 Note: In addition to the Standard Installation, you can also choose to run the Ethernet cable through a corrugated tube. To do this, see Figure 1-34 and its related Note.

  • Page 77: Gv-Mount420 + Gv-Mount211-2

    1.4.5.3 GV-Mount420 + GV-Mount211-2 Figure 1-90 GV-Mount420 Packing List   GV-Mount420 M4 Screw x 4  Additional Screw Kit M6 Screw x 4 M6 Nut x 4 M6 Plain Washer x 4 M6 Split Washer x 4 Note: For GV-AVD Series, GV-Mount420 can only be used in conjunction with GV- Mount211-2.

  • Page 78: Gv-Mount606

    Introduction 1.4.5.4 GV-Mount606 Figure 1-91 GV-Mount606 Packing List   In-Ceiling Mount Bracket In-Ceiling Cover   In-Ceiling Plate Drill Template Paster  Screw Kit : M4 Screw (8 mm) x 3 M4 Screw (40 mm) x 2...
  • Page 79 Paste the drill template to the ceiling and drill the ceiling to the size of the drill template. Place the In-Ceiling Plate behind the ceiling with the flat side facing down. Loosen the knob on the side of the camera and thread the camera wires through. Thread the camera wires through the side of the In-Ceiling Mount Bracket and place the camera in the Mount Bracket.

  • Page 80: System Requirements

    Introduction 1.5 System Requirements Intel Core i5-4670, 3.40 GHz Memory DDR3 8 GB RAM On Board Graphics Intel HD Graphics 4600 (Versions of driver from year 2014 or later required)  Web Browsers Internet Explorer 11.0 or above  Google Chrome ...

  • Page 81: Waterproofing The Cable

    1.6 Waterproofing the Cable Waterproof the Ethernet cable by using the supplied waterproof rubber set. 1. Attach the seal ring to the RJ-45 plug. Seal ring Figure 1-95 2. Insert the waterproof components through the Ethernet cable as shown below. 2      Insert in order Figure 1-96 3.
  • Page 82 Introduction 4. Insert the cable into the RJ-45 plug and screw the waterproof bolt in. Figure 1-98 5. Screw in the waterproof bolt lid. Bolt lid Figure 1-99 6. Finish the waterproof installation. Figure 1-100 IMPORTANT: After installing the camera, it is required to use waterproof tapes to cover and protect any of the tail cables and connection points that are exposed, see Note for Installing Camera Outdoor at the beginning of the manual.

  • Page 83: Chapter 2 Accessing The Camera

    Chapter 2 Accessing the Camera Once installed, the IP camera is accessible on a network. Follow these steps to configure the network settings and access your surveillance images. 2.1 Installing on a Network These instructions describe the basic connections to install the camera on the network. 1.

  • Page 84: Checking The Dynamic Ip Address

    Accessing the Camera 2.1.1 Checking the Dynamic IP Address Follow the steps below to look up the IP address and access the Web interface. Download and install the GV-IP Device Utility program from the company website. Note: The PC installed with GV-IP Device Utility must be under the same LAN as the camera you wish to configure.

  • Page 85: Assigning An Ip Address

    2.1.2 Assigning an IP Address To assign a new static IP address, log in the Web interface and access the network setting page. The following instructions are illustrated using GV-EBD4711. Note: If your router does not support DHCP, the default IP address is set as 192.168.0.10.

  • Page 86: Accessing Live View

    Accessing the Camera 2.2 Accessing Live View After logging into the camera, you will see the Home page as shown below: 10 11 12 13 14 15 Figure 2-4 No. Name Function Set the display ratio of the image.  Scale: display images by 16:9.

  • Page 87: The Live View Window

    Play/Stop Play or stop live video. Only for the audio-supporting models, adjust the audio output Video Volume volume on the PC. Only for audio-supporting models, enable or disable Microphone microphone. Only for audio-supporting models, adjust the microphone Microphone volume on the PC during audio communication between the PC Volume and the camera.

  • Page 88: Starting Recording

    Accessing the Camera 2.2.1 Digital Zoom To use the digital zoom function, follow these steps: 1. Click (No. 10, Figure 2-4) on the toolbar. 2. Click and drag the mouse button in any direction to specify an area. 3. To restore the original image size, right click on the enlarged area. 4.

  • Page 89: Playing Back Recorded Videos

    2.4 Playing Back Recorded Videos Note this function is only applicable to models with SD card slot for local storage. To play back recorded videos from the camera’s local storage, click Playback at the top of the Web interface. Figure 2-6 No.

  • Page 90: The Playback Window

    Accessing the Camera Timeline Users can select the desired time to play back the video from Note: To store and play back recorded videos to and from the camera’s local storage, make sure to configure the storage settings in Storage. For more detailed instructions, refer to 3.7.1 Storage.

  • Page 91: Chapter 3 Administrator Mode

    Chapter 3 Administrator Mode The Administrator can access and configure the GV-IP Camera through the network. Click Setup at the top of the Web interface to access the following configuration tabs: Common, Network, Video & Audio, Image, Intelligent, Events, Storage, Security and System. Figure 3-1...
  • Page 92 Administrator Mode List of Options See the table below for the settings available on the Web interface. Find the topic of interest by referring to the section number prefixed to each option. IMPORTANT: The available options may vary among camera models and firmware versions. 3.1.1 Basic Info 3.1 Common 3.1.2 Local Settings...

  • Page 93: Common

    3.1 Common Under the Common tab, the Administrator can find the general settings of the camera, as well as shortcuts to the following setting pages.  Ethernet: See 3.2.1 Ethernet for details.  Time: See 3.9.1 Time for details.  OSD: See 3.4.2 OSD for details ...

  • Page 94: Local Settings

    Administrator Mode 3.1.2 Local Settings You can set the local parameters for your PC. Figure 3-3 [Intelligent Mark]  Untriggered Target: Displays the detection lines / areas defined by Smart Settings on Live View. You must set up Smart Settings first for this function to work, see 3.5.1 Smart Settings.
  • Page 95 [Video]  Processing Mode  Real-Time Priority: Select this if the network is in good condition.  Fluency Priority: Select this if you want short time lag for live video.  Ultra-low Latency: Select this if you want the minimum time lag for live video. ...

  • Page 96: Network

    Administrator Mode 3.2 Network The network section allows you to configure the network settings, modify ports, configure FTP server, and set up e-mail for notification. 3.2.1 Ethernet Figure 3-4  Obtain IP Address: Select Static IP or DHCP according to your network environment. ...

  • Page 97: Dns

     PPPoE: The network environment is xDSL connection. Type the Username and Password provided by ISP to establish the connection. If you use the xDSL connection with dynamic IP addresses, first use the DDNS function to obtain a domain name linking to the camera’s changing IP address. ...

  • Page 98: Port

    Administrator Mode 3.2.3 Port Port You can modify the default HTTP port, HTTPS port and RTSP port if necessary. Figure 3-6 Port Mapping This function can automatically forward and open certain ports on your router, allowing connection to your camera from the Internet. Figure 3-7 1.

  • Page 99: Ddns

    1. Click On to enable DDNS Service. 2. Select the DDNS service provider you have registered with. If you chose DynDNS, skip to Step 5. 3. Copy the website address http://ns.gvdip.com/register.aspx to a browser to access Geovision DDNS service. Figure 3-9...
  • Page 100 Administrator Mode 4. In the Geovision DDNS Server page, type a desired Hostname and Password. Re-type Password and type the verification letters shown in the image. Click Send. 5. In the Web interface of your camera, type Username. The username is the hostname registered in DDNS Server.

  • Page 101: E-Mail

    3.2.5 E-mail After the configuration of E-mail, you will be able to send messages to the specified E-mail address(s) when alarms are triggered. 1. Type the Name and Address of the sender. 2. Type the SMTP Server. 3. Type the SMTP Port number. 4.

  • Page 102: Snmp

    Administrator Mode 3.2.6 SNMP Users can transfer the configurations of the device through SNMP protocol to communicate with and/or integrate it into a central server. Note this function is not supported by GV- ABL2701 series / 2703 series / 4703, GV-ADR2701 / 2702 / 4702, GV-TBL2703 series / 4703 and TDR2702 / 4702.
  • Page 103 3.2.7 802.1x IEEE 802.1x is an IEEE standard for port-based Network Access Control. It provides an authentication mechanism to devices wishing to attach to a LAN or WLAN. Note this function is only applicable to GV-EBD2702 / 4700 / 4711 / 8700 / 8711, GV-ABL2702 / 4712 / 8712, GV-AVD2700 / 4710 / 8710, GV-TBL4710 / 8710, GV-TDR2700 / 4700 and GV-TVD4710 / 8710.

  • Page 104: Qos

    Administrator Mode 3.2.8 QoS QoS is the prioritization of network traffic used to ensure resource reservation under abundant data flow. Note this function is not supported by GV-ABL2701 series and GV- ADR2701. Figure 3-13  Audio & Video: Optionally modify the priority of value of Audio & Video. The higher the value, the higher the priority.

  • Page 105: Video & Audio

    3.3 Video & Audio This section allows you to configure the three video streams and audio input. The audio function is only applicable to GV-EBD2702 / 4711 / 8711, GV-ABL2702 / 4712 / 8712, GV- AVD2700 / 4710 / 8710. 3.3.1 Video You can set video parameters that your camera supports.
  • Page 106 Administrator Mode The following options are available for the main, sub and third streams.  Video Compression: Set the codec type to H.265, H.264 or MJPEG.  Resolution: You may select different resolutions for each stream, except for Main Stream, which corresponds to that selected in the Capture Mode dropdown list. ...

  • Page 107: Snapshot

    3.3.2 Snapshot Using the Snapshot function, when an alarm is triggered, the camera will automatically upload the captured snapshots to the FTP server and/or send snapshots to the specified e- mail address(s). Figure 3-15 Select On to enable Snapshot. Select Resolution. Choose the Image Quality.

  • Page 108: Audio

    Administrator Mode 3.3.3 Audio Note this function is only applicable to audio-supporting models. You can configure the audio settings of the camera. Figure 3-16  Audio Input: Select On to enable audio input.  Input Gain: Set the audio signal amplification for sampling. The greater the gain, the greater amplification.

  • Page 109: Roi

    3.3.4 ROI When Region of Interest (ROI) is enabled, the system ensures image quality for ROI first if the bit rate is insufficient. Figure 3-17 Click to enable and add ROI. Click and drag on the image to specify an area. To add additional ROI areas, repeat steps 1 and 2.

  • Page 110: Media Stream

    Administrator Mode 3.3.5 Media Stream Media Stream By configuring media stream, you can set the camera to transmit code streams by UDP or TCP protocol to a specified IP address and port number. The settings can be saved and take effect after the camera is rebooted.
  • Page 111 RTSP Multicast Address After an RTSP multicast address is configured, the third-party player can request for the RTSP multicast media stream from the camera through RTSP protocol. Figure 3-19 1. Type the Multicast Address (224.0.1.0 to 239.255.255.255) and Port number (0 to 65535).

  • Page 112: Image

    Administrator Mode 3.4 Image This section introduces the Image Settings, On-screen Display and Privacy Mask. 3.4.1 Image This page allows you to adjust image settings such as brightness, exposure, IR illumination and white balance. Figure 3-20 [Scene]  Current: Indicates the scene that is being used. ...
  • Page 113 Figure 3-21 [Image Enhancement]  Brightness: Adjust the degree of brightness of the image.  Saturation: Adjust the amount of hue contained in a color.  Contrast: Set the degree of difference between the blackest pixel and the whitest pixel. ...
  • Page 114 Administrator Mode [Exposure]  Exposure Mode: Select the correct exposure mode to achieve the desired exposure effect. The default setting is Outdoor.  Low Motion Blur: Improve image quality by reducing motion blur in low light conditions.  Shutter(s): The length of time that allows light to enter into the lens. You can set a shutter speed when Exposure Mode is set to Manual (Custom).
  • Page 115  Day/Night Switching(s): Set the length of time before the camera switches between day mode and night mode after the conditions for switching are met.  WDR: Enable WDR to distinguish the bright and dark areas in the same image. ...
  • Page 116 Administrator Mode Figure 3-24 [White Balance]  White Balance: Adjust the red or blue offset of the image.  Auto: Adjust the red and blue offset automatically according to the light condition (the color tends to be blue).  Outdoor: It is recommended for outdoor scenes with a wide range of color temperature variation.

  • Page 117: Osd

    3.4.2 OSD On Screen Display (OSD) is the text displayed on the screen of video images and may include the date and time and other customized contents. Note GV-ABL2703 series / 4703, GV-ADR2702 / 4702, GV-TBL2703 series / 4703 and GV-TDR2702 / 4702 only support up to 4 OSD.
  • Page 118 Administrator Mode 3.4.2.2 For GV-EBD2702 Figure 3-27 1. Click Overlay OSD Content to select the content or type a self-defined text to be displayed on the screen. 2. Click Position and select from Areas 1 to 8 to specify the position of the OSD on the image.

  • Page 119: Privacy Mask

    3.4.3 Privacy Mask On certain occasions, you may need to set a mask area to block out parts of the camera image to protect privacy, for example, the keyboard of an ATM machine. When PTZ changes its position or zooms, the Privacy Mask will be adjusted accordingly to protect the area all along.

  • Page 120: Intelligent

    Administrator Mode 3.5 Intelligent Under Intelligent, users can set the camera to detect for a number of video-analytic events, which can be used to send FTP and/or e-mail alerts, based on the parameters set. Note this function is not supported by GV-ABL2701 series / 2703 series / 4701 series / 4703, GV- ADR2701 / 2702 / 4701 / 4702, GV-TBL2703 series / 4703 and GV-TDR2702 / 4702.

  • Page 121: Cross Line

    3.5.1.1 Cross Line Cross line detection generates an alarm when a person walks past the detection threshold in the direction you defined. Up to 4 detection lines can be added. Note that when adding multiple detection lines, make sure they do NOT intersect as it may affect the detection results.
  • Page 122 Administrator Mode 6. Optionally select Enable Plan to set the start and end times during which the video analytic monitoring is enabled. You can directly drag the mouse to draw a plan or click Edit to edit time periods in the table. You can set up to four periods for each day, and the time periods cannot overlap.

  • Page 123: Intrusion

    3.5.1.2 Intrusion With Intrusion Detection, an alarm is generated when a person trespasses the boundaries of the detection area. Up to 4 detection areas can be added. Note that it is recommended NOT to overlap the detection areas when adding multiple detection areas. Select the checkbox next to Intrusion to enable and click to configure.

  • Page 124: Object Moving

    Administrator Mode 3.5.1.3 Object Moving Object Moving can generate an alarm when a moving object is detected within the area set. Up to 4 detection areas can be added. Note that it is recommended NOT to overlap the detection areas when adding multiple detection areas. Select the checkbox next to Object Moving to enable and click to configure.

  • Page 125: Object Left

    3.5.1.4 Object Left With Object Left, an alarm can be generated when an existing object is removed from the defined area. Up to 4 detection areas can be added. Note that it is recommended NOT to overlap the detection areas when adding multiple detection areas. Select the checkbox next to Object Left to enable and click to configure.

  • Page 126: Defocus

    Administrator Mode 3.5.1.5 Defocus Defocus generates an alarm to be sent through e-mail whenever the camera’s image is out of focus. Select the checkbox next to Defocus to enable and click to configure. Figure 3-35 Once enabled, drag the slider to adjust the Sensitivity value and select Trigger E-mail to autoammtically send snapshots to the specified e-mail address(es) upon a defocus event.

  • Page 127: Scene Change

    3.5.1.6 Scene Change Scene Change is able to generate an alarm whenever there is a drastic scene change to the image of the camera. Select the checkbox next to Scene Change to enable and click configure. Figure 3-36 Once enabled, drag the slider to adjust the Sensitivity value as desired and follow Step 5 ~ 6, 3.5.1.1 Cross Line.

  • Page 128: Face Detection

    Administrator Mode 3.5.1.7 Face Detection The Face Detection function can detect for and capture face(s) to be sent to an FTP server. Select the checkbox next to Face to enable and click to configure. Figure 3-37 1. Once enabled, define the detecti on area, either b y drawing a desired area on the image or select Full Screen next to Detection Area to set the entire image as detection area.

  • Page 129: People Counting

    3.5.1.8 People Counting The People Counting function can count the number of person(s) entering and leaving the vicinity, which is useful at an entrance/exit setting. Select the checkbox next to People Counting to enable and click to configure. Figure 3-38 1.

  • Page 130: Advanced Settings

    Administrator Mode 3.5.2 Advanced Settings This section allows you to configure the clarity of the snapshots captured by face detect events and choose the detection modes used f or all video-analytic events. Photo Parameters Figure 3-39  Thumbnail Image Clarity: Drag the slider to adjust the clarity of the snapshots captured by face detection events.

  • Page 131: Events

    Events You can set the camera to generate an alarm upon motion detection, tampering alarm and audio detection. 3.6.1 Motion D etection otion detection is used to generate an alarm whenever movement occurs in the specified area. Figure 3-41 1. In the Detection Area, click to add a new detection area.
  • Page 132 Administrator Mode 4. You can use the fo llowing functions to reduce false alarm.  Sensitivity: Move the slider to the right increases detection sensitivity.  Object Size: When the extent of motion within the detection area exceeds the set object siz e, motion detection alarm is triggered.

  • Page 133: Tampering Alarm

    3.6.2 Tampering Alarm e this function is only applicable to GV-EBD2702 / 4700 / 4711 / 8700 / 8711, GV- ABL2702 / 2703 series / 4703 / 4712 / 8712, GV-ADR2702 / 4702, GV-AVD2700 / 4710 / 8710, GV-TBL2703 se ries / 4703 / 4710 / 8710, GV-TDR2700 / 2702 / 4700 / 4702 and GV- TVD4710 / 8710.

  • Page 134: Audio Detection

    Administrator Mode 3.6.3 Audio Detection Note this function is only applicable to audio-in-supporting models. Audio detection is used to detect abnormal audio volume. When the rise, fall, or change of volume exceeds the set limit, or when the input volume reaches the set threshold, an alarm generated.

  • Page 135: Alarm Input

    3.6.4 Alarm Input Note this function is only applicable to GV-ABL2701 Series / 2702 / 4701 Series / 4712 / 712, AVD2700 / 4701 / 8710, GV-TBL4710 / 8710, GV-TDR2700 / 4700 and GV-TVD4710 / 8710. The camera can receive alarm information from a n input device.

  • Page 136: Alarm Output

    Administrator Mode 3.6.5 Alarm Output Note this function is only applicable to GV-ABL2701 Series / 2702 / 4701 Series / 4712 / 8712, AVD2700 / 4701 / 8710, GV-TBL4710 / 8710, GV-TDR2700 / 4700 and GV-TVD4710 / 8710. After alarm output is triggered by a motion detection alarm, tempe rature alarm or input alarm, the camera can trigger an output device.

  • Page 137: Storage

    3.7 Storage This section allows you to configure storage related settings and set up FTP server. 3.7.1 Storage Note this function is only applicable to GV-EBD2702 / 4711 / 8711, GV-ABL2702 / 4712 / 8712, GV-AVD2700 / 4710 / 8710, GV-TBL4710 / 8710, GV-TDR2700 / 4700 and GV- TVD4710 / 8710.
  • Page 138 Administrator Mode  Storage Mediu m: Click the Format button to format the memory card before you start recording and Enabl e the memory card. llocate Capacity]  Video: Set the storage capacity used to store recorded videos. The remaining capacity is used for captu red snapshots.

  • Page 139: Ftp

    3.7.2 FTP After the configuration of FTP, you will be able to upload snapshots from the camera to the specified FTP server. Figure 3-47 1. Type the Server IP address. 2. Change the Port No. of the FTP server if needed. 3.

  • Page 140: Security

    Administrator Mode Note: 1. To upload sn apshots, make sure to enable the Snapshot function. For more detailed instructions, re fer to 3.3.2 Snapshot. 2. If Overwrite Storage is not selected and the storage is full, snapshots can no longer be taken.

  • Page 141: Network Security

    3.8.2 Network Security There are five types of network security settings: HTTPS, Authentication, ARP Protection, IP Address Filtering and Access Policy. TTPS You can enable the H ypertext Transfer Protocol Secure (HTTPS) settings to access the camera through a secure protocol. Click On to enable, and optionally click Browse to locate an SSL certificate from your local computer and click Upload.
  • Page 142 Administrator Mode ARP Protection This function can protect the camera from ARP attacks. When the camera visits an IP of another network segment via a gateway, it can only communicate with the MAC address binding to the gateway address in the same segment. Figure 3-51 1.
  • Page 143 Access Policy Access Policy measures the strength of account passwords upon login. Figure 3-53 By enabling Friendly Password, the camera measures the strength of account passwords upon login but do not force users to change the passwords when they are determined as weak.

  • Page 144: System

    Administrator Mode 3.9 System This section allows you to set the camera time and update the firmware. 3.9.1 Time You can use the following methods to adjust the system time of your camera. Time Figure 3-55 Select a Sync Mode. ...
  • Page 145 To adjust the camera’s time for daylight saving time: Click the DST tab at the top. Figure 3-56 Select On to enable DST. Set a Start Time and End Time for the daylig ht saving time. Select a time period fo r DST Bias.

  • Page 146: Maintenance

    Administrator Mode 3.9.2 Maintenance This section allows you to upgrade the firmware, restart the camera, and backup/import camera configurations. Figure 3-57 [Software Upgrade] For detailed instructions, refer to 4.1 Upgrading System Firmware and 4.1.1 Using the Web Interface. [Device Restart] Click Restart to restart the device after you confirm the operation. [Config Management] Export the current configurations of the camera and save them to the PC or an external storage medium.

  • Page 147: Chapter 4 Advanced Applications

    This chapter introduces more advanced applications. 4.1 Upgrading System Firmware GeoVision periodically releases updated firmware on the company website. The new firmware can be loaded into the camera using the Web interface or GV-IP Device Utility. Important Notes before You Start Before you start updating the firmware, please read these important notes: 1.

  • Page 148: Using The Web Interface

    Advanced Applications 4.1.1 Using the Web Interface Log into the Web interface and follow the steps below to update the firmware. 1. At the top, click Setup. 2. In the left menu, select System and select Maintenance. This page appears. Figure 4-1 3.

  • Page 149: Using Gv-Ip Device Utility

    4.1.2 Using GV-IP Device Utility You can upgrade the camera firmware using GV-IP Device Utility. Note the computer used to upgrade firmware must be under the same network as the camera. 1. Download GV-IP Device Utility from the company website. Then follow the onscreen instructions to install the program.

  • Page 150: Restoring To Factory Default Settings

    Advanced Applications 4.2 Restoring to Factory Default Setti If for any reason the camera is not responding correctly, you can restore the camera back to its factory default settings using the Web interface or the Default Button. Note: 1. Only GV-EBD4711 / 8711, GV-ABL2703 series / 4703, GV-AVD2700 / 4710 / 8710, GV-TBL2703 series / 4703 and GV-TVD4710 / 8710 support a default button.

  • Page 151: Chapter 5 Dvr / Nvr / Vms

    40 Mbps in throughput and a maximum of 20 streams.  When an IP camera is connected to IE browser or any GeoVision CMS application, it takes up 1 stream; when it is connected to GV-VMS / DVR / NVR, it takes up 2 streams.
  • Page 152 DVR /NVR / VMS Double-click your camera and type the camera’s User name and Password. Figure 5-2 Click OK. This dialog box appears. Figure 5-3...
  • Page 153 Click OK. The IP camera is added to the connection list. Click the listed camera and select Display position to map the IP camera to a channel on the GV-DVR / NVR. Figure 5-4 The Statue column should display “Connected”. Click OK.

  • Page 154: Customizing The Basic Settings On Gv-Dvr / Nvr

    DVR /NVR / VMS 5.1.1 Customizing the Basic Settings on GV-DVR / NVR After the camera is connected and assigned with a display position, you can configure the camera’s settings, such as frame rate, codec type and resolution. Right-click the desired camera to see the following list of options: Figure 5-5 ...

  • Page 155: Setting Up Ip Cameras On Gv-Vms

    5.2 Setting Up IP Cameras on GV-VMS Follow the steps below to manually connect your camera to GV-VMS. 1. To access the IP Device Setup page, click Home , select Toolbar , click Configure and select Camera Install. Figure5 -6 2.
  • Page 156 DVR /NVR / VMS 4. Click OK. This dialog box appears. Figure 5-8 5. Click OK to add the camera to the list. 6. To connect the added camera, click the box beside the ID column. Upon successful connection, the Status icon shows green, with the video resolution and bitrate being displayed in the correspondent columns.

  • Page 157: Appendix

    Appendix A. RTSP Multicast Protocol Support The camera can support RTSP multicast protocol for both video and audio streaming. You can use the following RTSP multicast command to access the camera image: Stream 1: rtsp://<IP of the camera>/multicast/video1 Stream 2: rtsp://<IP of the camera>/multicast/video2 For example, rtsp:// 192.168.4.115/multicast/video1 B.

  • Page 158: Compatible Versions Of Gv-Vms / Dvr / Nvr

    Appendix D. Compatible Versions of GV-VMS / DVR / NVR Compatible versions of GV-VMS / DVR / NVR based on camera models listed as follows: Camera Model Compatible GV-DVR / NVR Compatible GV-VMS GV-EBD2702 V8.7.4.0 with patch files or later V17.1 with patch files or later GV-EBD4700 V8.7.3.0 with patch files or later...

  • Page 159: Gv-Mount Dimensions

    GV-TDR4700 V17.1.0.100 with patch files or later Series GV-TDR4702 V17.3.0 with patch files or later GV-TVD4710 V17.1.0.100 with patch files or later GV-TVD8710 E. GV-Mount Dimensions Dimensions of various GV-Mount are illustrated below: GV-Mount Models Dimensions 1"NPT 20mm 20mm (0.3") (0.79") (0.79") GV-Mount107...
  • Page 160 Appendix GV-Mount212-2 GV-Mount212P GV-Mount213 160mm 233mm (9.17") (6.3") 7.5mm (0.3") 20mm (0.79") 15mm GV-Mount300-2 (0.59") 160mm (6.3") 160mm (6.3") 290mm (11.4") 20mm (0.79") GV-Mount310-2 15mm (0.59") 45mm 45mm (1.77") (1.77") 130mm (5.11") 160mm (6.3")
  • Page 161 GV-Mount502 GV-Mount503 GV-Mount606 40mm 100mm (3.94") (1.57") 200mm (7.87") GV-Mount704 300mm (11.8") 10 / 20 / 30 / 50 cm 500mm (19.7")

  • Page 162: Gv-Mount300-2 / 310-2

    Appendix F. GV-Mount300-2 / 310-2 GV-Mount300-2 / 310-2 Packing List   Mounting Bracket Convex Mounting Plate x 2 (for GV-Mount300-2)  Concave Mounting Plate x 2 (for GV-Mount310-2)   Carriage Bolt x 6 1/4” Plain Washer x 6 ...
  • Page 163 To install GV-EBD Series, GV-ABL / TBL Series, GV-ADR2702 / 4702, GV-TDR Series, or GV-AVD / TVD Series directly on GV-Mount300-2 / 310-2, follow the instructions below. Assemble the GV-Mount300-2 / 310-2, by attaching the two mounting plates onto the mounting bracket with the supplied carriage bolts, 1/4”...
  • Page 164 Appendix To install GV-Mount211P / 211-2 / 212-2 / 212P / 213 / 502 / 503 on GV-Mount300-2 / 310-2 Assemble the GV-Mount300-2 / 310-2, by attaching the two mounting plates onto the mounting bracket with the supplied carriage bolts, 1/4” plain washers, and 1/4” flange nuts.

  • Page 165: Screw Position Chart

    G. Screw Position Chart Screws:M4*25 Screws:M4*25 GV-Mount502 GV-Mount503 Screws:M4*25 Screws:M4*25 Screws:M4*25 GV-TBL2703/4703 GV-Mount211P GV-Mount212-2 GV-Mount212P GV-Mount213 GV-ABL2701/4701/2703/4703 GV-Mount211-2 Screws:M4*25 Screws:M3*15 GV-AVD2700/4710/8710 Screws:M3*15 Screws:M3*15 Screws:M3*15 GV-ABL2702/4712/8712 GV-ADR2702/4702 GV-TVD4710/8710 GV-EBD2702 GV-EBD4700/8700 GV-EBD4711/8711 GV-TBL4710/8710 GV-TDR2700/2702/4700/4702 If you cannot find the desired camera model, please visit our website for more information.

This manual is also suitable for:

Gv-abl seriesGv-ebd seriesGv-adr seriesGv-tdr seriesGv-avd seriesGv-tvd series ... Show all

Table of Contents
