RT2: THERMAL SENSOR CONNECTOR
USB1: 2nd USB Port
GAME/MIDI PORT
MIC port: Microphone Jack
Line In port: Audio In Jack
Line Out / Speaker Out port: Audio Out Jack
a: Connect to RT2.
b: Connect this thermal sensor to
particular device which
generates lots of heat such as
Hard Driver, VGA chip, etc,.
When connected, user could
observe the temperature
change from the BIOS
program.
