Enclosure Dimensions - Altronix AL100UL Quick Start Manual

1.25"
(31.75mm)
2"
(50.8mm)
2"
(50.8mm)
8.125"
(206.375mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
web site: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A
IIAL100UL Rev. 050101
- 4 -

Enclosure Dimensions

8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm)
0.6"
(15.24mm)
1.125"
(28.575mm)
1"
(25.4mm)
0.6"
(15.24mm)
1"
(25.4mm)
(H x W x D approximate)
7.25"
(184.15mm)
3.625"
(184.15mm)
6.05"
(153.67mm)
6.05"
(153.67mm)
5.25"
(133.35mm) (25.4mm)
C24P
:
1.25"
(31.75mm)
3.5"
(88.9mm)
0.6"
(15.24mm)
1.125"
(28.575mm)
1"
(25.4mm)
0.6"
(15.24mm)
3.5"
(88.9mm)
1"
(25.4mm)
1"
1.25"
(31.75mm)
MEMBER
AL100UL
