H3C SecPath NSQ1FAB04B0 Quick Start Manual page 2

Manual version: 6PW106-20210319
Item
Ambient humidity
Compatible device models and
slots
IMPORTANT:
An M9006 gateway and a T9006 IPS each require a minimum of three switching fabric modules, and
slots 6 and 7 must be installed with switching fabric modules.
3 LEDs
The module provides LEDs to show its operating status.
Table 2 LED description
RUN LED
Flashing (0.5 Hz)
Off
Flashing (0.5 Hz)
Off
On
4 Installing and removing the module
CAUTION:
• Wear a well-grounded ESD-preventive wrist strap before you install or remove the module.
• When you install or remove the module, avoid touching the components on it.
Installing the module
4.1
1. Face the rear panel of the device.
2. Remove the filler panel from the target slot.
This example uses slot 7.
3. Place the module vertically with the component side facing left. Open the ejector levers and
gently push the module into the slot along the guide rails, as shown by callout 1 in
4. Close the ejector levers. Make sure the module is in close contact with the backplane, as shown
by callout 2 in
5. Use a Phillips screwdriver to fasten the captive screws on the module, as shown by callout 3
in Figure
Specification
Operating: 10% RH to 95% RH, noncondensing
Storage: 5% RH to 95% RH, noncondensing
•
•
ALM LED
Off
On
On
Off
Off
Figure 3.
3.
M9006 gateway (slots 6 to 9)
T9006 IPS (slots 6 to 9)
Description
The switching fabric module is operating properly.
The switching fabric module is faulty.
The temperature of the switching fabric module has exceeded the
upper or lower limit.
The switching fabric module has not started.
The switching fabric module is starting up.
ii
BOM: 3123A0R3
Figure 3.
