Installing Options

Installing a Printer Memory Option

300
Memory and Option Cards
Install one memory option in memory connector 1. If you are
installing two memory options, install the second one in memory
connector 2.
Before you install a memory option, follow the steps under
"Accessing the Printer System Board" on page 293.
W : Electronic components are easily damaged by
ARNING
static electricity. Touch something metal
before you touch the memory option.
1
Unpack the memory option. Avoid touching the
connection points along its edge. Save the packaging.
Memory Connector 1
Memory Connector 2
