Installing Options
For Information About...
INA Option
Tri-Port Interface Option
Parallel 1284-C Adapter Option
Hard Disk with Adapter Option
Infrared Adapter Option
Printer Memory Option
Flash Memory Option
Optional Drawers
Standard Dual 500-sheet Drawer for the
Optra S 2455
Duplex Option
Optional Envelope Feeder
Optional Output Expander
254
Adding Options to the Printer
.
When you install or remove the printer, the
W :
ARNING
standard dual 500-sheet drawer for the
Optra S 2455, and options, view each piece as
a separate part. Always install or remove a
part by itself. For example, do not pick up the
printer with the duplex option attached and
try to move both at once.
Attaches to the Printer
System Board
System Board
System Board
System Board
Infrared port on the Tri-Port
Interface Option
System Board
System Board
Below
Below
Below
Inside Lower Front Door
Above
See
Page...
309
310
311
312
321
299
304
255
7 or 256
273
261
281
