Soundoff Signal nROADS Instruction Manual page 3

LED Lightbar - Single Color
TOP VIEW WITH COVERS ON
9 8 7
G
9 8 7
F
E
D
BOTTOM VIEW
C
B
A
9 8 7
9 8 7
TOP VIEW WITH COVERS OFF
RC
FC
3.
REAR
6 5 4
6 5 4
FRONT
REAR
6 5 4
FRONT
Wire Exit Holes
6 5 4
IN1 IN2
IN1 IN2
INBOARD LED MODULES
Roof Attachments:
Operating Temperature:
LENGTH
36"
3 2 1
G
3 2 1
42"
G
F
48"
F
E
54"
E
D
60"
D
C
C
Input Voltage Range:
B
Light Bar Component
B
A
Standby Current
3 2 1
Reverse Polarity
A
3 2 1
Load Dump
Wiring
REAR
IN3 IN3
IN3 IN3
FRONT
TECHNICAL SPECIFICATIONS
Aluminum Base, polycarbonate
Material: outer lenses, ASA/PC top cover.
1/4" bolt Stainless A2
-40º to +65º C
# OF INBOARDS
4
5
6
7
8
POWER SPECIFICATIONS
10 -16 Vdc
Current Draw
<0.10 mA
Protected
Protected
Power Cable 15ft, 16 AWG Wires, (+) Red, (-) Black
Control Cable 15ft, 22 AWG, 8 or 12 Conductor
STT Cable 15ft, 22AWG, 4 Conductor
IN2 IN1
IN2 IN1
CORNER MODULE
nROADS Lightbar_Single Color 0820
DIMENSIONS
12"D x 2.5" H
Inboard
Power Consumption
(Watts)
14 mW
RC
FC
