LED Lightbar - Single Color
Featured Highlights & Terminology:
Cruise Mode: Allows the user to program selected lights to "glow" when this feature is activated.
Directional Arrow Built-in: The directional controller is built-in with arrow patterns for each of the 3 modes (left arrow, right arrow, and center out
arrow). The 12 wire control harness is required to activate this feature.
Scene Light Mode: Allows the user to program selected lights to turn steady on when this feature is activated to provide additional scene lighting.
The 12 wire control harness is required to activate this feature.
Stop / Tail / Turn Mode: If lightbar is built with stop/tail/turn modules, separate control wires are included to control stop, tail, left turn and right
turn.
Low Power Mode: Operates lighting at reduced intensity.
Power Cable:
1. Route lightbar power cables as close to vehicles power source (battery) as possible.
2. Connect the BLACK wire to the factory chassis ground right next to the battery.
3. Install a maximum of 10Amp Fuse (customer supplied) to the end of the RED wire of the Lightbar Power Cable.
a. Remove the fuse before connecting any wires to the battery.
b. DO NOT USE CIRCUIT BREAKER OR FUSIBLE LINK.
4. Connect the other end of the Fuse to the POSITIVE (+) terminal of the battery.
a. Do NOT use any more than 2ft of wire between the battery terminal and the fuse and ensure the wire is protected and secured from being
cut into; this is non-fused wire.
Standby Mode (reduced standby current)
If there are no active inputs the lightbar will go into a "standby" mode. The standby mode is a very low power mode that is used to extend the life
of your battery. The lightbar will awaken from the standby mode when any input is activated.
ALL CUSTOMER SUPPLIED POWER WIRES CONNECTING TO THE POSITIVE (+) OR NEGATIVE (-) BATTERY
TERMINAL OR LOCAL CHASIS GROUND (-) MUST BE SIZED TO SUPPLY AT LEAST 125% OF THE MAXIMUM
CURRENT AND PROPERLY FUSED AT THE POWER SOURCE WITH APPROPIATELY RATED FUSE.
IMPORTANT
WHEN PASSING CABLES THROUGH FIREWALL OR OTHER
SHEETMETAL, INSERT GROMMET TO PROTECT THE CABLE!
WARNING
!
Route wires only in locations that are not subjected to
potential wear. Make sure to avoid routing wires in the
deployment area of your air bag. Refer to your vehicle's
owner's manual for airbag deployment zone.
7.
ELECTRICAL INSTALLATION
WARNING
!
