Retro Pedestal - Sideboard
Assembly Instructions -
Dimensions
Width - 119.5cm
Depth - 39.5cm
Height - 70cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
343/7395
MADE IN
BRITAIN
Issue 1 - 27/11/14
Advertisement
Related Manuals for Argos Retro Pedestal 343/7395
Summary of Contents for Argos Retro Pedestal 343/7395
- Page 1 Retro Pedestal - Sideboard Assembly Instructions - 343/7395 Please keep for future reference Dimensions Width - 119.5cm Depth - 39.5cm MADE IN Height - 70cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 27/11/14...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 34kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed on pages 1 and 2 Left Side Right Side Divider Short Divider (DF1098) (DF1099) (DF1100)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 7 Prepare the right side Tap 2 wooden dowels into the right side Note: Wooden dowels must not stick out from the edge by more than 10mm 10mm or they may damage other panels. Finished Place a runner on the front edge right side...
- Page 8 Assembly Instructions Step 8 Prepare the cross divider Tap 4 wooden dowels into the cross divider Insert 4 large locking nuts into the cross Finished divider front edge Screw 2 metal dowels into the cross divider Step 9 Fit the cross divider to the right side Push the cross divider onto the right side...
- Page 9 Assembly Instructions Step 10 Prepare the divider Tap 2 wooden dowels into the divider Place a runner on the Finished divider as shown. front edge Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and...
- Page 10 Assembly Instructions Step 11 Fit the divider Push the divider onto the cross divider Use a screwdriver to tighten the 2 large locking nuts fitted to the cross divider Finished front edge Step 12 Finished Prepare the short front edge divider Insert 2 large locking nuts...
- Page 11 Assembly Instructions Step 14 Fit the base Attach the base the right side , the divider and the short divider using 6 screws and tighten them using the allen key Finished front edge Step 15 Prepare the left side Tap 2 wooden dowels Finished into the left side front edge...
- Page 12 Assembly Instructions Step 17 Prepare the top Screw 6 metal dowels into the top Finished front edge Step 18 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 6 large locking nuts fitted the left side , the right side...
- Page 13 Assembly Instructions Step 19 Fit the feet Fit the 4 feet to the base using screws and tighten them using the allen key Note: You may find it easier to turn the foot as the screw is held with the allen key. Step 20 Fit the rail Attach the rail...
- Page 14 Assembly Instructions Step 21 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 15 Assembly Instructions Step 23 Fit the shelves For each of the 2 shelves insert 4 shelf studs as shown. Lower the large shelf and small shelf down onto the shelf studs Step 24 Prepare the 2 doors Push fit 2 hinges into the small door the large door...
- Page 16 Assembly Instructions Step 25 Fit the doors Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinge. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 17 Assembly Instructions Step 23 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the top (or base) of the unit is level, front-to-back and side- to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any...
- Page 18 If in doubt, consult an expert. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 20 ALR3117...
