Wow Raye Wooden Chair
Assembly Instructions
Dimensions
Width - 41.5cm
Depth - 50cm
Height - 85cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please keep for future reference
322/5837
345/6307
Issue 1 - 08/10/14
