1 Drawer Bedside
Assembly Instructions -
Dimensions
Width - 38cm
Depth - 40cm
Height - 44.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
274/6661
258/1187
228/9300
358/9896
331/5929
346/8302
MADE IN
BRITAIN
Issue 4 - 09/09/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 274/6661
Summary of Contents for Argos 274/6661
- Page 1 1 Drawer Bedside Assembly Instructions - 274/6661 Please keep for future reference 258/1187 228/9300 358/9896 331/5929 346/8302 Dimensions Width - 38cm Depth - 40cm MADE IN Height - 44.5cm BRITAIN Important - Please read these instructions fully before starting assembly...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 10kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side (D2350A) (D2351A) (D2349A) (422 x 372mm) (422 x 372mm) (380 x 396mm) 6 Plinth...
-
Page 4: Tools Required
If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Step 1 Prepare the drawer front Screw 2 metal dowels into the holes shown on the back of the drawer front Note: Tighten metal dowels up fully against...
- Page 6 Assembly Instructions Step 4 325mm Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Prepare the left side Place a runner the left side shown. Slide back the Finished front edge top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and Finished front edge fit the 2nd screw...
- Page 8 Assembly Instructions Step 9 Prepare the right side Place a runner the right side shown. Slide back the top of runner and use the Finished front edge 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into...
- Page 9 Assembly Instructions Step 10 Plain Prepare the plinth and chipboard base surface Insert 2 large locking nuts into the holes in the plinth Tap 2 wooden dowels into the ends of the Plain plinth chipboard surface Insert 4 large locking nuts into the base Finished...
- Page 10 Assembly Instructions Step 12 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 3 large locking nuts fitted to the plinth and base Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
- Page 11 Assembly Instructions Step 15 Fit the back The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y.
- Page 12 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3001...
