Argos Denver 339/9622 Assembly Instructions Manual

2 drawer 3 door mirror robe

Hide thumbs

page of 24

/ 24
Bookmarks

Quick Links

Download this manual

Denver - 2 Drawer 3 Door Mirror Robe

Assembly Instructions -

Dimensions

Width - 113.5cm

Depth - 50cm

Height - 181cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800

Please keep for future reference

339/9622

362/3927

346/7712

MADE IN

BRITAIN

Issue 3 - 31/03/15

Need help?

Do you have a question about the Denver 339/9622 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Denver 339/9622

Page 1 Denver - 2 Drawer 3 Door Mirror Robe Assembly Instructions - 339/9622 Please keep for future reference 362/3927 346/7712 Dimensions Width - 113.5cm Depth - 50cm MADE IN Height - 181cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 3 - 31/03/15...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately ??kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Top/Base (DF1877A) (1105 x 495mm) Wide Shelf (D1574A) (718 x 494mm) Divider (DF1878A) 8 Left Side...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the 2 drawer fronts Screw 2 metal dowels into each of the drawer fronts Note: Tighten the metal dowels up fully against the panels.
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
Page 7 Assembly Instructions Step 7 Important: Keep the Hinges and Hinge Plates in their bags until they are used. Prepare the right side They must not get mixed up. Screw 6 metal dowels into the right side Push a rail holder into the right side .
Page 8 Assembly Instructions Step 9 Fit the top and base to the right side Push the top and base onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the top and the base Finished Finished front edge front edge...
Page 9 Assembly Instructions Step 11 Prepare the small shelf Tap 2 wooden dowels into the small shelf Insert 4 large locking Finished nuts into the small front edge shelf Step 12 Fit the small shelf to the right side and fit the 2 brackets to the large vertical rail Push the small shelf...
Page 10 Assembly Instructions Step 13 Prepare the divider Place 2 runners the divider . Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into Finished...
Page 11 Assembly Instructions Step 14 Turn the divider over and prepare the other surface Finished Screw 2 metal dowels front edge into the divider Push a rail holder into the divider . Make sure that it is fitted straight, in line with the panel edges and then secure with screw Step 15...
Page 12 Assembly Instructions Step 16 Prepare the wide shelf Tap 2 wooden dowels into the wide shelf Insert 4 large locking Finished nuts into the wide front edge shelf Step 17 Fit the wide shelf Push the wide shelf onto the divider Use a screwdriver to tighten the 2 large locking nuts...
Page 13 Assembly Instructions Step 18 Fit the small vertical rail Attach the small vertical rail to the top wide shelf using 4 screws Finished front edge Step 19 Prepare the 2 rails Plain chipboard surface Tap 2 wooden dowels into each of the rails Insert 2 large locking nuts into each of the...
Page 14 Assembly Instructions Step 20 Fit the rails Push the rails onto the divider Use a screwdriver to tighten the 2 large locking nuts fitted to the rails...
Page 15 Assembly Instructions Step 21 Prepare the left side Place 2 runners the left side . Slide back the top of runner and use the 2nd hole from the front to fit the Finished 1st screw front edge Slide the runner back the other way and fit the 2nd screw into...
Page 16 Assembly Instructions Step 22 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 8 large locking nuts fitted to the top , base wide shelf and the 2 rails Step 23 Fit the 4 plastic nails Tap 2 plastic nails into the bottom edge of each of the sides...
Page 17 Assembly Instructions Step 24 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back panels Square up the unit by making sure that measurement x:x equals y:y.
Page 18 Assembly Instructions Step 25 Fix the brackets to the divider Secure the 2 brackets on the back of the large vertical rail to the divider using screws Step 26 Fit the hanging rails Push the hanging rails into the rail holders...
Page 19 Assembly Instructions Step 27 Fit the drawers Starting with the bottom drawer, slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners Working from the inside of the drawer, insert 2 screws...
Page 20 Assembly Instructions Step 29 Fit the 3 doors Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
Page 21 Assembly Instructions Step 30 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 22 Assembly Instructions Step 31 Screw Fit the overbalance protector Washer Wall fixing Strap (not supplied) To prevent possible Strap Washer overbalancing we recommend that this unit Screw is secured to a suitable (not supplied) wall by use of the overbalance protector kit fitted to the unit or, an alternative fixing method of your choice.
Page 23 KEEP THESE INSTRUCTIONS FOR FUTURE USE If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
Page 24 ALR3097...

This manual is also suitable for:

Denver 346/7712 Denver 362/3927
