Ohio - Bookcase
Assembly Instructions -
Dimensions
Width - 72cm
Depth - 33cm
Height - 183cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
343/2235
MADE IN
BRITAIN
Issue 1 - 16/10/14
Advertisement
Related Manuals for Argos Ohio Bookcase
Summary of Contents for Argos Ohio Bookcase
- Page 1 Ohio - Bookcase Assembly Instructions - 343/2235 Please keep for future reference Dimensions Width - 72cm Depth - 33cm MADE IN Height - 183cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 16/10/14...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 30kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (D1792A) (718 x 328mm) Shelf (D1795A) (556 x 284mm) Plinth (D1797A) (556 x 95mm) Drawer Front...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Prepare the left side Insert 4 large locking nuts into the left side Note: The arrow on the locking nuts must point towards the holes in the edge of the panel. Turn the left side over Turn the left side over Place a runner onto the left side...
- Page 8 Assembly Instructions Step 9 Prepare the right side Insert 4 large locking nuts into the right side Note: The arrow on the locking nuts must point Turn the right towards the holes in the side over edge of the panel. Turn the right side over Place a runner onto the right side...
- Page 9 Assembly Instructions Step 10 Left side fascia - Prepare the 2 fascias holes nearest this side. Screw 4 metal dowels into each of the 2 fascias Tap a wooden dowel into each of the 2 fascias Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
- Page 10 Assembly Instructions Step 12 Join the right side to the right side fascia Push the right side down onto the right side The runner is fascia panel at this end. Dowel Use a screwdriver to this end tighten the 4 large locking nuts fitted to the right side...
- Page 11 Assembly Instructions Step 14 Fit the shelves Push the 4 shelves onto the right side Use a screwdriver to tighten the 2 large Finished locking nuts fitted to front edge each shelf Finished front edge Finished front edge Finished front edge Step 15 Prepare the plinths Plain chipboard...
- Page 12 Assembly Instructions Step 17 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 10 large locking nuts fitted to the 4 shelves and the 2 plinths Step 18 Fit the top Attach the top to the unit using 4 screws...
- Page 13 Assembly Instructions Step 19 Fit the back Square up the unit by making sure that The measurement from top corner X to bottom corner X must be measurement x to x equal to the measurement from top corner Y to bottom corner Y equals y to y.
- Page 14 Assembly Instructions Step 20 Fit the 4 plastic nails Tap 2 plastic nails into the bottom edge of each of the sides Stand the unit up for the next step. Warning: The unit is heavy. Lift with care.
- Page 15 Assembly Instructions Step 21 Fit the drawer Slide both of the runners forward and locate the drawer sides between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners Working from the inside of the drawer, insert 2 screws through the...
- Page 16 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3082...
