2 Door Robe
Assembly Instructions -
Dimensions
Width - 70.5cm
Depth - 51.5cm
Height - 183cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
249/3251
249/3660
244/2518
356/1003
343/3935
339/1194
MADE IN
BRITAIN
Issue 5 - 09/09/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 2 Door Robe
Summary of Contents for Argos 2 Door Robe
- Page 1 2 Door Robe Assembly Instructions - 249/3251 Please keep for future reference 249/3660 244/2518 356/1003 343/3935 339/1194 Dimensions Width - 70.5cm Depth - 51.5cm MADE IN Height - 183cm BRITAIN Important - Please read these instructions fully before starting assembly...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 48kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 Components - Panels Please check you have all the panels listed below 3 Top (D0532A) (702 x 516mm) 4 Horizontal (D0531A) (670 x 490mm) Left Side Right Side 5 Plinth (D0527B) (D0528B) (D0529A) (1808 x 491mm) (1808 x 491mm) (670 x 80mm) 6 Door Hanging Rail (D0530A)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Wooden dowel Metal dowel x 14 Large locking (F22) (F901)
- Page 5 Assembly Instructions Step 1 Prepare the left side Screw 5 metal dowels into the holes shown on the left side Finished front edge Note: Tighten metal dowels up fully against the panel. Push a rail holder into the hole shown. Make sure that it is fitted straight, in line with the panel edges and then...
- Page 6 Assembly Instructions Step 2 Prepare the right side Screw 5 metal dowels into the holes shown on the right side Note: Tighten metal dowels up fully against the panel. Push a rail holder into the hole shown. Make sure that it is fitted straight, in line with the panel edges and then Finished...
- Page 7 Assembly Instructions Step 3 Prepare the horizontal and base Insert 4 large locking nuts into both the horizontal and the base as shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 2 wooden dowels into both the horizontal and the base shown.
- Page 8 Assembly Instructions Step 5 Prepare the plinth Insert 2 large locking nuts into the plinth as shown. Tap 2 wooden dowels into the plinth shown. Step 6 Fit the plinth Push the plinth onto the right side shown. Use a screwdriver to tighten the large locking fitted to the plinth Note: Turn the large...
- Page 9 Assembly Instructions Step 8 Prepare the top Screw 4 metal dowels into the holes shown on the top Rounded front edge Step 9 Fit the top Push the top onto the side panels Use a screwdriver to tighten the 4 large locking nuts fitted to the side panels...
- Page 10 Assembly Instructions Step 10 The measurement from top corner X to bottom corner X must be Fit the back and plas- equal to the measurement from top corner Y to bottom corner Y tic nails Square up the unit by making sure that measurement x to x equals y to y.
- Page 11 Assembly Instructions Step 11 Fit the hanging rail Push the hanging rail into the rail holders fitted to the side panels. Step 12 Prepare the 2 doors Push fit 3 hinges into each door Secure each hinge with 2 screws Note: Before securing with the screws, make sure that the hinges are...
- Page 12 Assembly Instructions Step 13 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 13 Assembly Instructions Step 14 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 14 Lift with care. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 16 ALR3006...
