Puerto Rico - Console Table
Assembly Instructions
- Please keep for future reference
345/9627
Dimensions
Width - 107cm
Depth - 40cm
Height - 73.5cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: 03456 400 800
Issue 1 - 10/10/14
Advertisement
Table of Contents
Related Manuals for Argos Puerto Rico - Console Table
Summary of Contents for Argos Puerto Rico - Console Table
- Page 1 Puerto Rico - Console Table Assembly Instructions - Please keep for future reference 345/9627 Dimensions Width - 107cm Depth - 40cm Height - 73.5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below 6 Drawer front (76.4 x 11.2cm) 7 Drawer back 1 Top panel (74 x 11.2cm) (107 x 40cm) 8 Side panel x 2 2 Front and back frame x 2 (90 x 25cm) (25 x 23cm) 3 Leg x 4...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Insert dowels into the indicated parts. Step 2 Attention: Fixing front panel. With help, fit front frame to legs Make sure panel is positioned as shown. Attach front frame to the legs using screws Repeat step 2 for the back frame and legs.
- Page 6 Assembly Instructions Step 4 Attention: Insertig drawer runners. Insert drawer runnes to back frame Attention: Make sure drawer runners are positioned correctly as shown in the diagram. Step 5 Fixing front frame. Two people are required for an easier assembly. With help, p lace front frame properly ensuring...
- Page 7 Assembly Instructions Step 6 Fixing top panel. Two people are required for an easier assembly. Caution: Carefully lay the top panel on a soft and clean surface to avoid damaging the product. Attach cabinet to the top panel using screws Important: With help, after fixing top panel, carefully...
- Page 8 Assembly Instructions Step 8 Fixing back panel. Important: Cabinet MUST ‘square’ when back panel is attached. Attach back panel using nails Step 9 Insert drawer into unit. With the back of the drawer past the front frame, use a hammer to tap dowels in flush to drawer sides.
