Oakhampton - Pair of Dining Chairs
Assembly Instructions
Dimensions
Width - 44cm
Depth - 51cm
Height - 95cm
Important
- Please read these instructions fully before starting assembly.
If you need help or have damaged or missing parts, call the Customer Helpline:
Homebase = 0345 0778888
IW-17-1527E-O6-K4R7-S2VFK-R1
- Please keep for future reference
391/8333
341609
Issue 1 - 22/03/15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Argos Oakhampton 391/8333
Summary of Contents for Argos Oakhampton 391/8333
- Page 1 Oakhampton - Pair of Dining Chairs Assembly Instructions 391/8333 - Please keep for future reference 341609 Dimensions Width - 44cm Depth - 51cm Height - 95cm Important - Please read these instructions fully before starting assembly. If you need help or have damaged or missing parts, call the Customer Helpline: Homebase = 0345 0778888 IW-17-1527E-O6-K4R7-S2VFK-R1 Issue 1 - 22/03/15...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly. • Check you have all the • During assembly do not • We do not stand or put weight on the recommend the use components and tools listed on the following pages.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: Homebase = 0345 0778888 Please check you have all the parts listed below. 3 Right apron x 2 2 Left apron x 2 (6.2 x 35.9cm) (6.2 x 35.9cm) 4 Front leg frame x 2 5 Seat pad x 2...
- Page 4 Assembly Instructions Step 1 Fitting dowels. Screw 2 steel dowels into back leg frame 1 by screwing fittings into the inset fittings that are located on back leg frame 1 as shown. Note: Ensure the direction of the holes on fittings are facing correctly as per diagram.
- Page 5 Assembly Instructions Step 2 Attaching aprons Attach left & right aprons onto back leg frame as shown. Note: Ensure steel dowels and wooden dowels are aligned correctly with the mating holes to avoid damage. Ensure end of aprons are flush with back leg frame Secure aprons to back leg frame...
- Page 6 Assembly Instructions Step 3 Attaching front leg frame. Attach front leg frame onto left & right aprons as shown. Note: Ensure steel dowels and wooden dowels are aligned correctly with the mating holes to avoid damage. Secure front leg frame to left &...
- Page 7 Assembly Instructions Step 4 Placing seat pad. Lift chair frame up and place seat pad below the chair with locator block positioned as shown. Lower chair frame onto seat pad Note: Ensure locator block is inside front leg frame as shown. Step 5 Fixing seat pad.
- Page 8 Assembly Instructions Step 6 Repeat the complete process for second chair. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Homebase = 0345 0778888...
