INSTRUCTION MANUAL
Automatic Spray Guns
Important
This manual contains IMPORTANT WARNINGS and INSTRUCTIONS.
Equipment in this manual is exclusively for painting purposes.
Do not use for other purposes.
The operator shall be fully conversant with the requirements stated in this instruction manual including important warnings, cautions and
operation and correct handling.
Read and understand the instruction manual, before use and retain for reference.
Be sure to observe warnings and cautions in this instruction manual.
If not, it can cause paint ejection and serious bodily injury by drawing organic solvent.
Be sure to observe following

Important specifications

Max. Pressure
Noise level
Max. Temperature

Main specifications

Type of
Model
WRA-M200-1201
WRA-M200-1202
WRA-M200-1203
Pressure
WRA-M200-1204
WRA-M200N-1205
WRA-M200N-1206
※ 1
Air pressure means air pressure at gun inlet when air valve is opened and air flows.
WRA-M200
marked items which are especially important.
Indicates a potentially hazardous situation which, if not avoided, may result in serious injury or loss of life.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or property
damage.
Indicates notes which we ask you to observe. The safety precautions in this instruction manual are the minimum
necessary conditions. Follow national and local regulations regarding fire prevention, electricity and safety as well
as your own company regulations.
０．７ ＭＰａ / ７．０ bar / １０１．５ ＰＳＩ
(WRA-M200-1201)
９１ ｄ Ｂ （Ａ）
Spray condition ： Recommended
Atmosphere
： ５℃〜４０℃
Nozzle
Air cap
orifice
Ass'y
feed
Mark
φ mm (in)
01
02
03
1.2
(0.047)
04
05
06
Measuring point ： 1m backwards from gun, 1.6 m height
Air ・ Fluid
： ５℃〜４３℃
Recommended condition
※ 1Air pressure
MPa (bar /PSI)
Fluid output
ml/min
Atomizing air Fan air
0.2 0.18
(2.0/29.0)
(1.8/26.1)
0.23 0.21
(2.3/33.4) (2.1/30.5)
0.11 0.12
(1.1/16.0) (1.2/17.4)
0.35 0.23
(3.5/50.8) (2.3/33.4)
0.3 0.35
(3.0/43.5) (3.5/50.8)
0.16 0.16
(1.6/23.2) (1.6/23.2)
※ 2
Paint viscosity is 12(s/NK-2)
−１ −
和文取説は、裏面にあります。
Air Spray
consumption distance
l/min (cfm) mm(in)
300
200
(10.6)
200
(7.9)
360
200
(12.7)
200 100
80
(7.1) (3.9)
440
200
(15.5)
565 200
250
(20.0) (7.9)
430
200
(15.2)
※ 3
Paint viscosity is 20(s/NK-2).
Pattern width Mass
mm(in) g (lbs)
200 ※ 2
(7.9)
180 ※ 3
(7.1) 350
(0.8)
100 ※ 2
(3.9)
200 ※ 2
(7.9)
290 ※ 2
(11.4) 600
(1.3)
300 ※ 3
(11.8)
