WRA 101-S9/S9N AUTOMATIC SPRAY GUN
Before use, adjustment or maintenance, it is important to read this instruction manual very care
GB
fully. This manual must be stored in a safe place for any future reference that may be necessary.
This ANEST IWATA spray guns kit complies to ATEX regulations 94/9/EC,
Protection level: II 2 G X Suitable for using Zones 1 and 2.
X marking: Any static electricity discharge from the spray gun is to be diverted to the ground via the conductive air hose as stipulated.
IMPORTANT
This automatic spray gun should be operated only by an adequately trained operator for safe use and maintenance of the equip-
ment. Any misuse or handling other than those indicated in this Instruction Manual is not covered by guarantee.
ANEST IWATA disclaims all responsibility for any accident or damage caused by failure observing the operational and safety pro-
cedures as from this manual. In the interest of user friendliness, this manual contains information in a brief and concise form.
For any additional information you may require regarding the automatic spray gun operations, or if any missing parts or any dam-
age during transportation is found, or details of training courses, please contact your nearest ANEST IWATA Company (see last
cover page).
Be sure to observe warnings and cautions in this instruction manual.
If not, it can cause paint ejection and serious bodily injury by drawing organic solvent.
Be sure to observe following marked items which are especially important.
WARNING Indicates a potentially hazardous situation which, if not avoided, may result in serious injury or loss of life.
CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or pro-
perty damage.
IMPORTANT Indicates notes which we ask you to observe. The safety precautions in this instruction manual are the mini-
mum necessary conditions. Follow national and local regulations regarding fire prevention, electricity and
safety as well as your own company regulations.
IMPORTANT SPECIFICATIONS
Max. Operating air pressure:
Noise Level (LAeqT):
Air connection:
Fluid connection:
* Measuring point: 1m backwards from gun, 1,6 m height

TECHNICAL SPECIFICATIONS

Model Nozzle Air Cap Air pressure at gun inlet
orifice Set bar (PSI)
mm(in) Mark Atomizing air
WRA-101S9/S9N Pressure feed
WRA-101-S9-04P 0.4 (0.016)
WRA-101-S9-06P 0.6 (0.024)
WRA-101-S9-10P 1.0 (0.039)
E2 1.1 (16)
WRA-101-S9N-04P 0.4 (0.016)
WRA-101-S9N-06P 0.6 (0.024)
WRA-101-S9N-10P 1.0 (0.039)
Manufactured by:
ANEST IWATA Corporation 3176,Shinyoshida-cho, Kohoku-ku, Yokohama, 223-8501 Japan
Instruction Manual
6.8 bar (98 PSI) Max. Temperature:
78.7 dB (A)* Atmosphere 5 ~ 40 °C
3-Rc 1/4" Air and fluid 5 ~ 43 °C
2-Rc 1/4"
Fluid Air Pattern
output comsumption width
Fan air g/m Nl/min mm(in)
35 (1.4)
70 (2.8)
100 (3.9) 310 (0.68)
1.5 (21) 20 140 (4.9)
35 (1.4)
70 (2.8)
100 (3.9) 310 (0.68)
Weight
g (lbs)
290 (0.64)
310 (0.68)
290 (0.64)
310 (0.68)
